Inclination limited to +/-90° max.

DE

EN

FR

PL

Camera setup

RU

Accessing the setup menu

Setup menu can be accessed and controlled by OSD control joy stick on the side of

camera.

Five commands are available with the joy stick.

Picture of OSD may differ by the models.

SYMBOL descriptions for joystick operation

▲,▼,◄,► denotes the directions of Joystick lever operation.

● denotes the short press down straightly

♦ denotes the long press down straightly for about 2 seconds

In the menu, use ▲,▼ to move menu, ◄,► to change the settings and

press ● to select or enter.

19

OSD Main menu

MENU V3.07

Press ● to enter the

1. ZOOM/FOCUS ↵

setup menu for about

2. EXPOSURE. ↵

2 second

3. SCENE ENHANCE NORMAL

4. 3D-NR MID

5. DAY/NIGHT EXT↵

6. PICT ADJUST ↵

7. SPECIAL ↵

8. SYSTEM ↵

9. EXIT SAVE&EXIT ↵

Factory

MAIN

Descriptions

Default

ZOOM/FOCUS - Sets FOCUS MODE, D-ZOOM, LENS REFRESH and

LENS INIT.

EXPOSURE - Sets EXPOSURE MODE, BRIGHTNESS, SENS-UP,

AGC, and MOTION DEBLUR.

SCENE

NORMAL NORMAL – Optimized for the normal indoor and

ENHANCE

outdoor in the good lighting condition.

WDR – Improves the visibility for the high bright area

and the dark area by the double captures of image

with LONG and SHORT exposures. With WDR ON,

the frame rate becomes half by the double captures.

WDR level can be selected from LOW, MID and

HIGH. Care should be taken to select this mode

because video may lose its quality in some environ-

ments by the over compensation.
