Eizo FlexScan S2031W: Selecting Display Mode

Selecting Display Mode

FineContrast allows you to select the best display mode easily according to monitor’s application.

For details of FineContrast, refer to the User’s Manual on the CD-ROM.

FineContrast Mode

Custom Available for making desired setting.

sRGB Suitable for color matching with sRGB compatible peripherals.

Text

Suitable for displaying texts for word processing or spreadsheets.

Picture Suitable for displaying images such as photos or picture images.

Movie Suitable for playing back animated images.

Press .

1

The FineContrast mode appears.

Press again while the FineContrast

2

mode is displayed.

Each time you press the button, the mode is switched to the

other mode. (Refer to the FineContrast Mode table.)

Press at the desired mode.

3

The selected mode is set.

Adjusting Brightness

Press or

.

1

The brightness adjustment screen appears.

Brightness adjustment screen

Adjust the brightness with or

.

2

Press to increase screen brightness or press to

decrease.

Press at the desired brightness.

3

The specified brightness is saved.

NOTE

• Screen will be adjusted automatically to the appropriate brightness that accepted environment as the

sensor on the lower side of the monitor detects the surrounding brightness with the BrightRegulator

function.

For details, refer to the User’s Manual on the CD-ROM.

Performing Advanced Settings/Adjustments

Advanced adjustments for the screen or color

and various settings are available using the

Adjustment menu.

For details of each adjustment function, refer

to the User’s Manual on the CD-ROM.

The basic settings and adjustments are completed. For advanced settings/adjustments,

refer to the User’s Manual on the CD-ROM.

FineContrast mode name

Displays the

current mode.
