Eizo FlexScan S2001W: No-Picture Problem

English

7

No-Picture Problem

If no picture is displayed on the monitor even after the following remedial action is taken, contact your local dealer.

1. Check the Power indicator.

Symptom Status Possible cause and remedy

No picture Power indicator does not light. Check whether the power cord is connected

correctly. If the problem persists, turn off the

monitor, and then turn it on again a few minutes

later.

Press .

Power indicator is lighting blue. Check <Gain>* setting.

Power indicator is lighting

Switch the input signal with .

orange.

Operate the mouse or keyboard.

Check whether the PC is turned on.

* For details of the gain adjustment, please refer to the User’s Manual on the CD-ROM.

2. Check the error message on the screen.

These messages appear when the input signal is incorrect even if the monitor is functioning.

Symptom Status Possible cause and remedy

No signal is input. The message shown left may appear, because

some PCs do not output the signal soon after

power-on.

Check whether the PC is turned on.

Check whether the signal cable is connected

properly.

At analog signal input

Switch the input signal with .

At digital signal input

The input signal is out of the

Reboot the PC.

specified frequency range.

Select an appropriate display mode using the

(Such signal frequency is

graphics board’s utility software. Refer to the

displayed in red.)

manual of the graphics board for details.
