Eizo FlexScan S2001W: Displaying the Screen

English

5

Displaying the Screen

Press to turn on the monitor.

1

The monitor’s power indicator lights up blue.

Turn on the PC.

2

The screen image appears.

When turning on the monitor and PC for the first time with the analog signal, the Auto Adjustment

function works to adjust the clock, phase, and display position automatically.

Attention

• Turn off the monitor and PC after using them. Unplugging the power cord completely shuts off power

supply to the monitor.

Adjusting Speaker Volume

Speaker volume adjustment screen

Press or .

1

The speaker volume adjustment screen appears.

Adjust the speaker volume with or .

2

Selecting Display Mode

FineContrast allows you to select the best display mode easily according to monitor’s application.

For details of FineContrast, refer to the User’s Manual on the CD-ROM.

FineContrast Mode

Custom Available for making desired setting.

sRGB Suitable for color matching with sRGB compatible peripherals.

Text

Suitable for displaying texts for word processing or spreadsheets.

Picture Suitable for displaying images such as photos or picture images.

Movie Suitable for playing back animated images.

Press .

1

The FineContrast mode appears.

FineContrast mode name

Displays the

Press again while the FineContrast

2

current mode.

mode is displayed.

Each time you press the button, the mode is switched to the

other mode. (Refer to the FineContrast Mode table.)

Press at the desired mode.

3

The selected mode is set.
