ASRock 970 EXTREME4: 1. Introduction

5

ASRock  970 Extreme4  Motherboard

English

1.  Introduction

Thank you for purchasing ASRock

970 Extreme4

 motherboard, a reliable mother-

board produced under ASRock’s consistently stringent quality control. It delivers

excellent performance with robust design conforming to ASRock’s commitment to

quality and endurance.

In this manual, chapter 1 and 2 contain introduction of the motherboard and step-

by-step guide to the hardware installation. Chapter 3 and 4 contain the con

fi

 guration

guide to BIOS setup and information of the Support CD.

Because the motherboard speci

fi

 cations and the BIOS software might

be updated, the content of this manual will be subject to change without

notice. In case any modi

fi

 cations of this manual occur, the updated ver-

sion will be available on ASRock website without further notice. You may

fi

 nd the latest VGA cards and CPU support lists on ASRock website as

well.  ASRock website    http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for speci

fi

 c information about the model you are using.

www.asrock.com/support/index.asp

1.1  Package Contents

ASRock

970 Extreme4

 Motherboard

(ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm)

ASRock

970 Extreme4

 Quick Installation Guide

ASRock

970 Extreme4

Support CD

4 x Serial ATA (SATA) Data Cables (Optional)

1 x 3.5mm Audio Cable (Optional)

1 x I/O Panel Shield

1 x ASRock SLI_Bridge_2S Card

 ASRock Reminds You...

To get better performance in Windows

®

 7 / 7 64-bit / Vista

TM

 / Vista

TM

 64

bit, it is recommended to set the BIOS option in Storage Con

fi

 guration

to  AHCI mode. For the BIOS setup, please refer to the “User Manual” in

our support CD for details.

6

ASRock  970 Extreme4  Motherboard

1.2  Specifications

 Platform

- ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm

- All Solid Capacitor design (100% Japan-made high-quality

  Conductive Polymer Capacitors)

 CPU

- Support for Socket AM3+ processors

- Support for Socket AM3 processors: AMD Phenom

TM

 II X6 /

  X4 / X3 / X2 (except 920 / 940) / Athlon II X4 / X3 / X2 /

  Sempron processors

- Supports 8-Core CPU

- Supports UCC feature (Unlock CPU Core) (see

CAUTION 1

)

- V4 + 1 Power Phase Design

- Supports CPU up to 140W

- Supports AMD’s Cool ‘n’ Quiet

TM

 Technology

- FSB 2600 MHz (5.2 GT/s)

- Supports Untied Overclocking Technology (see

CAUTION 2

)

- Supports Hyper-Transport 3.0 (HT 3.0) Technology

 Chipset

- Northbridge: AMD 970

- Southbridge: AMD SB950

 Memory

- Dual Channel DDR3 Memory Technology (see

CAUTION 3

)

- 4 x DDR3 DIMM slots

- Support DDR3 2000(OC)/1866(OC)/1800(OC)/1600(OC)/

  1333/1066/800 non-ECC, un-buffered memory

  (see

CAUTION 4

)

- Max. capacity of system memory: 32GB (see

CAUTION 5

)

 Expansion Slot

- 3 x PCI Express 2.0 x16 slot  (PCIE2/PCIE4: single at

  x16 (PCIE2) / x8 (PCIE4), or dual at x8 (PCIE2) / x8 (PCIE4);

  PCIE5: x4 mode)

- 2 x PCI Express 2.0 x1 slots

- 2 x PCI slots

 -

Supports

AMD

TM

 Quad CrossFireX

TM

, 3-Way CrossFireX

TM

  and CrossFireX

TM

- Supports NVIDIA

®

 SLI

TM

 Audio

- 7.1 CH HD Audio with Content Protection

  (Realtek ALC892 Audio Codec)

- Premium Blu-ray audio support

 LAN

- PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Realtek RTL8111E

- Supports Wake-On-LAN

- Supports LAN Cable Detection

English

7

ASRock  970 Extreme4  Motherboard

English

- Supports Energy Ef

fi

 cient Ethernet 802.3az

- Supports PXE

 Rear Panel I/O

I/O Panel

- 1 x PS/2 Mouse Port

- 1 x PS/2 Keyboard Port

- 1 x Coaxial SPDIF Out Port

- 1 x Optical SPDIF Out Port

- 4 x Ready-to-Use USB 2.0 Ports

- 2 x Ready-to-Use USB 3.0 Ports

- 1 x eSATA3 Connector

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

   LED)

- 1 x IEEE 1394 Port

- 1 x Clear CMOS Switch with LED

- HD Audio Jack: Side Speaker/Rear Speaker/Central/Bass/

  Line in/Front Speaker/Microphone (see

CAUTION 6

)

 SATA3

- 5 x SATA3 6.0 Gb/s connectors

E\$0'6%

, support

RAID (RAID 0,

 RAID 1, RAID 0+1, JBOD and RAID 5),

NCQ, AHCI and "Hot

 Plug" functions

 USB 3.0

- 2 x Rear USB 3.0 ports by ASMedia ASM1042, support

  USB 1.0/2.0/3.0 up to 5Gb/s

- 1 x Front USB 3.0 header (supports 2 USB 3.0 ports) by

  ASMedia ASM1042, supports USB 1.0/2.0/3.0 up to 5Gb/s

Connector

- 5 x SATA3 6.0Gb/s connectors

- 1 x IR header

- 1 x CIR header

- 1 x COM port header

- 1 x IEEE 1394 header

- 1 x HDMI_SPDIF header

- 1 x Power LED header

- CPU/Chassis/Power FAN connector

- 24 pin ATX power connector

- 8 pin 12V power connector

- Front panel audio connector

- 3 x USB 2.0 headers (support 6 USB 2.0 ports)

- 1 x USB 3.0 header (supports 2 USB 3.0 ports)

- 1 x Dr. Debug (7-Segment Debug LED)

Smart Switch

- 1 x Clear CMOS Switch with LED

- 1 x Power Switch with LED

- 1 x Reset Switch with LED

 BIOS Feature

- 32Mb AMI UEFI Legal BIOS with GUI support

8

ASRock  970 Extreme4  Motherboard

English

 BIOS Feature

- 32Mb AMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- SMBIOS 2.3.1 Support

- CPU, VCCM, NB, SB Voltage Multi-adjustment

 Support CD

- Drivers, Utilities, AntiVirus Software (Trial Version),

  CyberLink MediaEspresso 6.5 Trial

 Unique Feature

- ASRock Extreme Tuning Utility (AXTU) (see

CAUTION 8

)

- ASRock Instant Boot

- ASRock Instant Flash (see

CAUTION 9

)

- ASRock APP Charger (see

CAUTION 10

)

- ASRock XFast USB (see

CAUTION 11

)

- ASRock On/Off Play Technology (see

CAUTION 12

)

- Hybrid Booster:

    - CPU Frequency Stepless Control (see

CAUTION 13

)

    - ASRock U-COP (see

CAUTION 14

)

    - Boot Failure Guard (B.F.G.)

 -

Turbo

UCC

Hardware

- CPU Temperature Sensing

Monitor

- Chassis Temperature Sensing

- CPU/Chassis/Power Fan Tachometer

- CPU Quiet Fan

- CPU/Chassis Fan Multi-Speed Control

- Voltage Monitoring: +12V, +5V, +3.3V, Vcore

 OS

 -

Microsoft

®

Windows

®

7 / 7 64-bit / Vista

TM

/ Vista

TM

 64-bit / XP

   / XP 64-bit compliant

 Certifi cations

- FCC, CE, WHQL

- ErP/EuP Ready (ErP/EuP ready power supply is required)

  (see

CAUTION 15

)

 * For detailed product information, please visit our website: http://www.asrock.com

WARNING

Please realize that there is a certain risk involved with overclocking, including adjusting the

setting in the BIOS, applying Untied Overclocking Technology, or using the third-party over-

clocking tools. Overclocking may affect your system stability, or even cause damage to the

components and devices of your system. It should be done at your own risk and expense.

We are not responsible for possible damage caused by overclocking.

9

ASRock  970 Extreme4  Motherboard

English

CAUTION!

1.  ASRock UCC (Unlock CPU Core) feature simpli  es AMD CPU activa-

tion. As long as a simple switch of the UEFI option “ASRock UCC”, you

can unlock the extra CPU core to enjoy an instant performance boost.

When UCC feature is enabled, the dual-core or triple-core CPU will boost

to the quad-core CPU, and some CPU, including quad-core CPU, can

also increase L3 cache size up to 6MB, which means you can enjoy the

upgrade CPU performance with a better price. Please be noted that UCC

feature is supported with AM3/AM3+ CPU only, and in addition, not every

AM3/AM3+ CPU can support this function because some CPU’s hidden

core may be malfunctioned.

2.  This motherboard supports Untied Overclocking Technology. Please read

“Untied Overclocking Technology” on page 40 for details.

3.  This motherboard supports Dual Channel Memory Technology. Before

you implement Dual Channel Memory Technology, make sure to read the

installation guide of memory modules on page 14 for proper installation.

4.  Whether 2000/1866/1800/1600MHz memory speed is supported de-

pends on the AM3/AM3+ CPU you adopt. If you want to adopt DDR3

2000/1866/1800/1600 memory module on this motherboard, please refer

to the memory support list on our website for the compatible memory

modules.

ASRock website    http://www.asrock.com

5.  Due to the operating system limitation, the actual memory size may be

less than 4GB for the reservation for system usage under Windows

®

 7 /

Vista

TM

 / XP. For Windows

®

 64-bit OS with 64-bit CPU, there is no such

limitation.

6.  For microphone input, this motherboard supports both stereo and mono

modes. For audio output, this motherboard supports 2-channel, 4-chan-

nel, 6-channel, and 8-channel modes. Please check the table on page 3

for proper connection.

7.  ASRock Extreme Tuning Utility (AXTU) is an all-in-one tool to ne-tune

different system functions in a user-friendly interface, which is including

Hardware Monitor, Fan Control, Overclocking, OC DNA and IES. In Hard-

ware Monitor, it shows the major readings of your system. In Fan Control,

it shows the fan speed and temperature for you to adjust. In Overclock-

ing, you are allowed to overclock CPU frequency for optimal system

performance. In OC DNA, you can save your OC settings as a pro  le

and share with your friends. Your friends then can load the OC pro  le to

their own system to get the same OC settings. In IES (Intelligent Energy

Saver), the voltage regulator can reduce the number of output phases to

improve ef  ciency when the CPU cores are idle without sacri  cing com-

puting performance. Please visit our website for the operation procedures

of ASRock Extreme Tuning Utility (AXTU).

ASRock website: http://www.asrock.com

10

ASRock  970 Extreme4  Motherboard

English

9.  ASRock Instant Flash is a BIOS   ash utility embedded in Flash ROM.

This convenient BIOS update tool allows you to update system BIOS

without entering operating systems   rst like MS-DOS or Windows

®

. With

this utility, you can press <F6> key during the POST or press <F2> key to

BIOS setup menu to access ASRock Instant Flash. Just launch this tool

and save the new BIOS   le to your USB   ash drive,   oppy disk or hard

drive, then you can update your BIOS only in a few clicks without prepar-

ing an additional   oppy diskette or other complicated   ash utility. Please

be noted that the USB   ash drive or hard drive must use FAT32/16/12   le

system.

10.  If you desire a faster, less restricted way of charging your Apple devices,

such as iPhone/iPod/iPad Touch, ASRock has prepared a wonderful solu-

tion for you - ASRock APP Charger. Simply installing the APP Charger

driver, it makes your iPhone charged much quickly from your computer

and up to 40% faster than before. ASRock APP Charger allows you to

quickly charge many Apple devices simultaneously and even supports

continuous charging when your PC enters into Standby mode (S1), Sus-

pend to RAM (S3), hibernation mode (S4) or power off (S5). With APP

Charger driver installed, you can easily enjoy the marvelous charging

experience than ever.

ASRock website: http://www.asrock.com/Feature/AppCharger/index.asp

11.  ASRock XFast USB can boost USB storage device performance. The

performance may depend on the property of the device.

12.  ASRock On/Off Play Technology allows users to enjoy the great audio ex-

perience from the portable audio devices, such like MP3 player or mobile

phone to your PC, even when the PC is turned off (or in ACPI S5 mode)!

This motherboard also provides a free 3.5mm audio cable (optional) that

ensures users the most convenient computing environment.

13.  Although this motherboard offers stepless control, it is not recommended

to perform over-clocking. Frequencies other than the recommended CPU

bus frequencies may cause the instability of the system or damage the

CPU.

14.  While CPU overheat is detected, the system will automatically shutdown.

Before you resume the system, please check if the CPU fan on the moth-

erboard functions properly and unplug the power cord, then plug it back

again. To improve heat dissipation, remember to spray thermal grease

between the CPU and the heatsink when you install the PC system.

11

ASRock  970 Extreme4  Motherboard

English

15.  EuP, stands for Energy Using Product, was a provision regulated by Eu-

ropean Union to de  ne the power consumption for the completed system.

According to EuP, the total AC power of the completed system shall be

under 1.00W in off mode condition. To meet EuP standard, an EuP ready

motherboard and an EuP ready power supply are required. According to

Intel’s suggestion, the EuP ready power supply must meet the standard

of 5v standby power ef  ciency is higher than 50% under 100 mA current

consumption. For EuP ready power supply selection, we recommend you

checking with the power supply manufacturer for more details.
