INSTRUCTION MANUAL

Status LED

Compatibility with Phottix Strato 4-in-

1. The Status LED on the Phottix Strato Multi transmitter

1 Wireless Triggers

will turn solid green upon a half-press of the shutter

Phottix Strato Multi System is compatible with the

button (on camera or the Strato Multi transmitter being

Phottix Strato 4-in-1 Wireless receivers.

used as a wireless shutter release) and turn red when

1. Phottix Strato 4-in-1 receivers can be triggered on

sending a signal or taking a photo

channels 1 to 4. They cannot be assigned groups and will

2. The Status LED on the Phottix Strato Multi receiver will

re if the Strato Multi transmitter is set to groups A, B,

ash green while the power is on and idle. The LED will

C or D.

turn red when a signal is received from the transmitter

2. The Phottix Strato 4-in-1 transmitter cannot trigger

and the ash or camera is red.

Phottix Strato Multi receivers.

Groups and Channels

Setting Groups on the transmitter

1. The Phottix Strato Multi System has 4 groups: A, B, C,

1. The Phottix Strato Multi System has 4 groups: A, B, C,

and D. Each group contains 4 channels: 1, 2, 3, 4.

and D.

2. Receivers can be assigned both group and channel

2. Pressing the Group Selection Buttons on the

designations.

transmitter allow you to select with groups will be

3. The transmitter will re groups A, B, C or D, or any

triggered. Selected groups on the transmitter will trigger

combination on the same channel: 1, 2, 3 or 4. Any

receivers assigned that group and channel.

ashes or strobes connected to Strato Multi receivers

3. The Group Selection Button will turn red when pressed

set to the same group(s) and channel as the transceiver

and selected.

will re.

4. The green light (red light) will go o when pressed and

deselected.
