Phottix Strato II Multi: Connecting to the camera hot shoe Setting Channels on the transmitter

Active group settings will be remembered when the

receivers are set to the same channel.

transmitter is turned o and turned back on.

Connecting to the camera hot shoe

Setting Channels on the transmitter

1. Turn o the camera.

1. The Phottix Strato Multi transmitter has 4 transmission

2. Slide the Strato Multi transmitter into the camera’s hot

channels

shoe mount.

2. Move the Channel Selector Switch to 1, 2, 3, or 4 to

3. Turn the Strato Multi locking ring until tight.

select a channel.

4. Turn on the Strato Multi transmitter.

3. Make sure Phottix Strato Multi transmitters and

5. Turn on the camera and set the shooting mode.

receivers are set to the same channel.

Connecting to the camera sync port by

Setting Groups on the receiver

3.5mm Sync cable (included)

1. The Phottix Strato Multi receiver has four group

The Strato Multi Transmitter can also be attached to a

settings.

camera’s PC Sync port if you do not wish to use the hot

2. Move the Group Selection Switch to A, B, C or D to

shoe.

select a group for each receiver.

1. Turn o the camera.

2. Connect a cable to Strato Multi transmitter 3.5mm

Setting Channels on the receiver

port.

1. The Phottix Strato Multi receiver has 4 transmission

3. Connect the opposite end of the cable to the camera’s

channels.

PC Sync Port.

2. Move the Channel Selector Switch to 1, 2, 3, or 4 to

4. Turn on the Strato Multi transmitter.

select a channel.

5. Turn on the camera and set the shooting mode.

3. Make sure Phottix Strato Multi transmitters and

6
