EXECUTING MACROS

ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

To execute a macro, press and release

[MACRO]; its key illumination lights for

5 seconds. While it remains lit, press an

HTR 8 key to which a macro has previ-

ously been stored.

The corresponding macro will run; as

each step executes, its “parent” DEVICE

SELECTOR key ashes briey; when

execution is nished, the [MACRO] key

illumination goes out. Pressing any other

HTR 8 key while a macro is executing

will abort the macro. Remember that

you must hold the HTR 8 so that its

infrared emitter can activate the target

components.

Note

When a macro executes, a 1 second

delay is automatically inserted

between its commands. If you need

more than a 1 second delay between

particular commands—for example,

to permit a component to power up

completely—you can record “empty”

steps into the macro by changing

DEVICE SELECTOR “pages” without

entering actual command functions.

KEy ILLUMINATION TIMEOUT

The HTR 8’s key-illumination can be set

to remain lit for 0-9 seconds. The default

value is 2 seconds. To set the illumination

timeout, simultaneously press-and-hold

for 3 seconds both the HTR 8’s [DISP] and

the [0-9] key, with the digit correspond-

ing to the desired timeout duration; the

Learn LED will ash twice to conrm

the new setting. When set to zero, the

illumination will not turn on at all.

Notes

· Key illumination is activated when

one presses any HTR 8 key.

· If HTR 8 senses movement, key illu-

mination is activated without having

to press a key. If HTR 8 is shaken, key

illumination is also activated.

· Key illumination is the biggest drain

on the HTR 8’s batteries. A short key

illumination timeout will extend

battery life appreciably; turning it o

altogether (set it to 0 seconds) will

lengthen it still further.

8
