9. EXTENSION CABLE ATTACHMENT

(Fig . D)

Insert the plug of the extension cable into the socket of the switch box.

The extension cable should be of the type H05VV-F 2X 1.5 mm2.

Insert the extension cable into the holder to prevent its damage by the cutting blade.

ATTENTION! Then, it is advisable to check whether the cable is properly lodged in the

holders.

10. STARTING AND STOPPING THE

ENGINE (Fig. E)

ATTENTION! Before you switch the lawnmower on, make sure the cutting blade is not

rotating. Never switch the engine rapidly on and off.

Starting the engine:

Press and hold the safety button. ( 2 ).

Pull the switch lever ( 1 ) towards the handle.

Stopping the engine:

Release the switch lever. ( 1 )

11. MOWING (Fig. F)

We recommend to start mowing from the power supply and to work your way away from the

power supply. Mow the lawn at a right angle from the power supply and place the power

cable only to the side which has already been cut. (F).

ATTENTION! Never allow the engine to labour. When the engine labours you will hear a

change in the engine sound accompanied by drop of the speed of the engine. When this

occurs stop mowing, release the switch lever and increase the cutting height. Failure to do so

could damage the engine.

ATTENTION! The engine is protected by a safety cut-out which is automatically activated

when the blade becomes jammed or if the engine is overloaded. When this occurs, stop the

machine and remove the plug of the supply cable from the socket outlet. The safety cut-out

will only reset when the switch lever 1 is released. Clear any obstructions and wait for a few

minutes for the safety cut-out to reset. During this time do not operate the switch lever 1 as
