Fieldmann FZR 2010-E: 16. TECHNICAL SPECIFICATIONS

Possible problems and troubl shooting | Technical specifications

Interrupted

Damaged extension cable,

Check the cable and replace it if

lawnmower operation

Damaged internal wiring

necessary. Contact the Customer

Engine protection activated,

Service Let the lawnmower cool

Engine protection activated

down for a few minutes and then

increase the cutting height

During this time do not operate the

switch lever 1

as this will prolong the time to

automatically

reset the safety cut-out

Engine is “Choking” Cutting height adjustment too

Increase the cutting height (see

low

Cutting Height Adjustment)

Dull cutting blade

Replace the cutting blade (see

Clogged lower part of the

Cutting Blade Maintenance) Clean

lawnmower

the lawnmower (see Storing the

The cutting blade is attached

Lawnmower) Remove the blade and

the other way round

attach it correctly (see Cutting Blade

Maintenance)

Cutting blade will not

The blade is jammed

Dislodge the blade Tighten the bolt

rotate

Loose blade holder bolt

Extremely strong

Loose nuts / bolts Damaged

Tighten the nuts / bolts Replace the

vibrations / Excessive

cutting blade

blade

noise during operation

16. TECHNICAL SPECIFICATIONS

Lawnmower .............................................................................................................................................. FZR 2010-E

Rated voltage .............................................................................................................................................230 - 240V

Rated frequency ................................................................................................................................................. 50 Hz

Rated input..........................................................................................................................................................1000 W

Idle operation ..............................................................................................................................................3300 rpm.

Width of cut .................................................................................................................................................... 320 mm

Weight ................................................................................................................................................................... 9.5 kg

Guaranteed sound pressure level ..........................................................................79.2 dB(A) KpA:3.0 dB(A)

Guaranteed sound power level ............................................................................................................... 96 dB(A)

2

2

Vibrations.................................................................................................................................2.50 m/s

K 1.5 m/s

Instructions Manual - language version only.
