Fieldmann FZR 2010-E: 14. STORING THE LAWNMOWER

Storing the lawnmower | Possible problems and troubl shooting

14. STORING THE LAWNMOWER

Before storing, clean the outer surface of the lawnmower using a soft brush and cloth. Do not

use water, solvents and polishing agents. Remove any grass remains, particularly from the

vents.

Tilt the machine on the side and clean the blade mechanism. Grass remains in the blade

mechanism can be removed it using a wooden or plastic tool. Store the lawnmower in a dry

place. Do not place any objects on top of the lawnmower.

Unscrew the nut 9 and fold the upper handle 2.

When folding/unfolding the handle, make sure the power cable is not hitched on any part of

the lawnmower. When folding the handle, never let the folded part of the handle fall down.

15. POSSIBLE PROBLEMS AND TROUBL

SHOOTING

The following table shows examples of defects which could prevent trouble-free operation

of the lawnmower and methods of remedying these defects. If the problem persists, despite

the suggested measures, please contact the Customer Service.

ATTENTION! Before trouble-shooting, switch off the lawnmower and unplug the plug from

the socket.

PROBLEM POSSIBLE CAUSE SOLUTION

Lawnmower will not

The lawnmower has not been

Switch the lawnmower on, Use

start

switched on, defective socket,

another socket Check the cable and

damaged extension cable,

replace it if necessary Replace the

Blown fuse, engine protection

fuse Increase the cutting height and

activated, engine protection

tilt the lawnmower on the side Let

activated

it cool down and then increase the

cutting height Let the lawnmower

cool down for a few minutes and

then increase the cutting height

During this time do not operate the

switch lever 1

as this will prolong the time to

automatically

reset the safety cut-out
