Fieldmann FDK 2002-E: 8. CLEANING AND MAINTENANCE

Adjustment and operation | Cleaning and maintenance tips

23

EN

ELECTRICAL CIRCULAR SAW OPERATING INSTRUCTIONS

Replacement of carbon brushes

ATTENTION! In case of carbon brush seasoning, immediately switch off the saw and

contact the nearest service centre of FAST ČR, a.s. or your nearest vendor.

Use only correct types of carbon brushes.

After attaching new carbon brushes, let the saw run on idle for approx. 5 minutes.

8. CLEANING AND MAINTENANCE

Keep the engine vent holes clean and dust-free.

If the circular-saw blade is damaged, replace it immediately by a new blade of the same type.

ATTENTION! Before cleaning and maintenance, always unplug the supply cable of the tool

from the socket.

The tool requires no special maintenance, just wipe the cover of the tool with a wet cloth on a

regular basis.

Clean the vent holes on a regular basis.

Never clean any part of the tool using a hard, sharp or rough object.

9. CLEANING AND MAINTENANCE TIPS

Store the tool, accessories and instructions for use in the original packaging to ensure you

always have all necessary parts and information.

If the tool is not used for a long time, do not store it in places with high temperatures.

If practicable, store the tool in a place with constant temperature and humidity.

Avoid contact of the tool with humidity and water. Follow the instructions specified in this

operating manual

EN 24

Declaration of conformity

10. DECLARATION OF CONFORMITY

Product/Name: ELECTRICAL CIRCULAR SAW / FIELDMANN

Type/Model: FDK 2002 - E ............................................................................... 230V/50Hz/1300W/4700rpm/185mm

The product complies with the following directives:

The Directive of the European Parliament and the Council No. 2006/95/EC dated 12 December 2006 on the

harmonisation of the laws of Member States relating to electrical equipment designed for use within certain

voltage limits.

The Directive of the European Parliament and the Council No. 2004/108/EC dated 15 December 2004 on

the harmonisation of the laws of the Member States relating to electromagnetic compatibility and repealing

Directive No. 89/336/EEC.

The Directive of the European Parliament and the Council No. 2006/42/EC dated 17 May 2006 on machinery,

and amending Directive No. 95/16/EC.

The Directive of the European Parliament and the Council No. 2002/95/EC dated 27 January 2003 on the

restriction of the use of certain hazardous substances in electricaland electronic equipment.

The Directive of the European Parliament and the Council No. 2005/88/EC dated 14 December 2005

amending Directive No. 2000/14/EC on the harmonisation of the laws of the Member States relating to the

noise emission in the environment by equipment for use outdoors.

and standards:

EN 60745-1:2009

EN 60745-2-5:2007+A11:2009

EN 60825-1:2007

EN 55014-1:2006

EN 55014-2:1997+A1:2001+A2:2008

EN 61000-3-2:2006

EN 61000-3-3:2008

CE Certification: .............................................................................................................................................................................14

FAST ČR, a.s. is authorised to act on behalf of the manufacturer.

Manufacturer:

FAST ČR, a.s.

Černokostelecká 2111, 100 00 Praha 10, Czech Republic

Tax ID:: CZ26726548

In Prague, 23 Sept 2014

Name: Zdeněk Pech

Chairman of Board Signature and stamps:

FDK 2002-E

Technical data

25

EN

11. TECHNICAL DATA

ELECTRICAL CIRCULAR SAW:

Power supply 230V/50Hz

Power input 1300W

Speed

4700rpm

Protection class II

Blade Diameter: 185mm

Cutting capacity 65mm at 90 degree, 45mm at 45 degree

Power supply cable length 1.8m

Declared noise level 105dB(A)

Instructions Manual - language version only.
