Machine description and package content

FDK 2002-E

4. MACHINE DESCRIPTION AND

PACKAGE CONTENT

Machine Description (see Fig. 1.2)

Switch

Handle

Guiding handle

Bevel adjustment knob

Parallel guide adjustment knob

Parallel guide

Circular-saw blade guide

Circular-saw base

Blade stud

Cutting depth adjustment knob

Safety switch

Carbon brush cover

Allen wrench

1 -

2 -

3 -

4 -

5 -

6 -

7 -

8 -

9 -

10 -

11 -

12 -

13 -

Bevel angle measuring rod

16 -

Package Content

Remove the machine carefully from the packaging and check the completeness of the following

parts:

Circular saw

Parallel guide

1 circular-saw blade

Warranty certificate

Operating instructions

Allen wrench

Wrench

2 replacement engine carbon brushes

If some parts are missing or are damaged, please contact the vendor where you purchased the

machine.
