Серия

Кратко ръководство

Изглед отдясно

# Икона Обект Описание

5

Четец на карти

Чете Secure Digital (SD), MultiMediaCard

Много-в-1

(MMC), Memory Stick (MS), Memory Stick

PRO (MS PRO) и xD-Picture Card (xD).

Бележка: Натиснете, за да извадите/

деинсталитюрате картата. Едновременно

може да работи само една карта.

6

Жак за вход за

Приема входящ сигнал от външни

микрофон

микрофони.

Жак за слушалки/изход

За връзка с изходни аудио устройства

за високоговорители

(напр. високоговорители, слушалки).

7

USB 2.0 порт За връзка с USB 2.0 устройства

(напр. USB мишки).

8

Слот за заключващ

За връзка с Kensington-съвместим

механизъм Kensington

компютърен заключващ механизъм.

9

Порт за Ethernet (RJ-45) За връзка с мрежа, базирана на Ethernet

10/100.

Изглед отзад и отдолу

10

Отделение за батерии Тук се поставя батерийният модул на

компютъра.

11

Гнездо за 3G SIM карта Приема 3G SIM карта за 3G комуникация

(само за определени модели).

12

Езиче за освобождаване

Освобождава батерията, за да можете да я

на батерията

извадите.

13

Придържащ механизъм

Държи батерията на мястото й.

на батерията

14

Вентилационни слотове

Позволява на компютъра да се охлажда

и охлаждащ вентилатор

дори и при продължителна употреба.

Бележка: Не покривайте и не препречвайте

отвора на вентилатора.

15

Високоговорител Излъчва аудио от Вашия компютър.

6

Серия

Кратко ръководство

Работна среда

Температура:

За работа: 5°C дo 35°C

За съхранение: -20°C дo 65°C

Влажност (без кондензация):

За работа: 20% дo 80%

За съхранение: 20% дo 80%

7

seeria

Lühijuhend

© 2010 Kõik õigused kaitstud

Aspire One seeria lühijuhend

Originaalväljaanne: 04/2010

Aspire One ’i seeria sülearvuti

Mudeli number: _____________________________

Seerianumber: _____________________________

Ostukuupäev: ______________________________

Ostukoht: _________________________________

seeria

Lühijuhend

Federal Communications Commission

Declaration of Conformity

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not

cause harmful interference, and (2) this device must accept any interference received, including interference that may cause

undesired operation.

The following local Manufacturer/Importer is responsible for this declaration:

Product name: Notebook PC

Brand: Acer

Model number: PAV01

Machine type:

Aspire one series; AO533 series

Name of Responsible Party: Acer America Corporation

Address of responsible party: 333 West San Carlos St., San Jose

CA 95110, U. S. A.

Contact person: Acer Representative

Phone No.: 1-254-298-4000

Fax No.: 1-254-298-4147

April 23, 2010

CE Declaration of Conformity

We,

Acer Incorporated

8F, 88, Sec. 1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan

Contact Person: Mr. Easy Lai, e-mail:easy_lai@acer.com.tw

And,

Acer Europe SA

Via Cantonale, Centro Galleria 2 6928 Manno Switzerland

Hereby declare that:

Product: Notebook Computer

Trade Name: Acer

Model Number: PAV01

Machine Type: Aspire one series; AO533 series

Is compliant with the essential requirements and other relevant provisions of the following EC directives, and that all the

necessary steps have been taken and are in force to assure that production units of the same product will continue comply with

the requirements.

R&TTE Directive 1999/5/EC as attested by conformity with the following harmonized standard:

• Article 3.1(a) Health and Safety

-. EN60950-1

-. EN62311

• Article 3.1(b) EMC

-. EN301 489-1

-. EN301 489-3 (Applicable to non-bluetooth wireless keyboard mouse set).

-. EN301 489-7

-. EN301 489-17

-. EN301 489-24

seeria

Lühijuhend

• Article 3.2 Spectrum Usages

-. EN300 440-2 (Applicable to non-bluetooth wireless keyboard mouse set).

-. EN300 328

-. EN301 511

-. EN301 893 (Applicable to 5GHz high performance RLAN).

-. EN301 908-1

-. EN301 908-2

EMC Directive 2004/108/EC as attested by conformity with the following harmonized standards:

-. EN55022, AS/NZS CISPR22, Class B

-. EN55024

-. EN61000-3-2 Class D

-. EN61000-3-3

Low Voltage Directive 2006/95/EC as attested by conformity with the following harmonized standard:

-. EN60950-1

RoHS Directive 2002/95/EC on the Restriction of the Use of certain Hazardous Substances in Electrical and Electronic Equipment

-. The maximum concentration values of the restricted substances by weight in homogenous material are:

Lead

0.1%

Polybrominated Biphenyls (PBB’s)

0.1%

Mercury

0.1%

Polybrominated Diphenyl Ethers (PBDE’s)

0.1%

Hexavalent Chromium

0.1%

Cadmium

0.01%

Directive 2009/125/EC with regard to establishing a framework for the setting of ecodesign requirements for energy-related

product.

Year to begin affixing CE marking 2010.

Apr. 23, 2010

Easy Lai /Manager

Regulation Center, Acer Inc.

Date

Alustuseks

1 2 3

2-2

3-2

3-1

2-1

Veenduge, et aku on korralikult

kohale lukustunud, nagu kujutatud

joonisel 2-2.

4 5 6

Illustratsioonid on ainult üldiseks võrdlusaluseks. Toodete tegelikud tehnilised andmed võivad erineda.

1

seeria

Lühijuhend

Tähtsamad asjad kõigepealt

Täname teid, et valisite oma kaasaskantavaks arvutiks Aceri sülearvuti.

Teie teejuhid

Et aidata teil kasutada Aceri sülearvutit, oleme loonud komplekti juhiseid*:

Kõigepealt aitab Lühijuhend Teil alustada oma arvuti häälestamist.

Kui soovite rohkem teada saada, kuidas arvuti aitab Teil produktiivsem olla, vaadake AcerSystem User Guide. Teatmik sisaldab

täpsemat informatsiooni sellistel teemadel, nagu süsteemiutiilidid, andmete taastamine, laiendusvõimalused ja probleemide

lahendamine. Sellele lisaks sisaldab see garantiiteavet ning sülearvuti kohta kehtivaid üldiseid regulatsioone ja ohutuseeskirju. See on

saadaval PDF-formaadis (Portable Document Format) ning on laaditud teie sülearvutisse.

Märkus. Faili vaatamiseks on vajate programmi Adobe Reader. Kui Adobe Reader pole arvutisse installitud, käivitab AcerSystem

User Guide’i klõpsamine kõigepealt Adobe Readeri installimisprogrammi. Installimise lõpetamiseks järgige ekraanil olevaid

juhiseid. Juhiseid Adobe Readeri kasutamiseks leiate menüüst Spikker ja Tugi.

* TÄHTIS MÄRKUS: Palun pidage silmas, et ülalmainitud juhised, nii trükitud kui elektroonilisel kujul, on ainult

teavitava iseloomuga ning välja arvatud juhtudel, kui AcerSystem User Guide’is sisalduvas spetsiilises garantiiteabes

pole näidatud teisiti, ei kujuta miski neis juhistes toodud teabes endast Aceri esindatust või garantiid teie poolt ostetud

tootele. Acer vabastab end selgesõnaliselt igasugustest kohustustest seoses juhistes esineda võivate vigadega.
