Jotul F500: 1.0 Relationship to the authorities

11

Installation manual with technical data

1.0

Relationship to the authorities ...................11

2.0

Technical data  ..............................................11

3.0 Installation

.................................................. 12

4.0 Service

.......................................................... 13

5.0

Optional equipment  .................................. 13

Figures/ Pictures   ..................................................37

General use and maintenance manual

6.0

Safety

precautions

7.0

  Choice of fuel

8.0

Use

9.0

Maintenance

10.0     Operational problems - troubleshooting

ENGLISH

1.0  Relationship to the  authorities

Installation of a fireplace must be according to local codes and

regulations in each country. All local regulations, including

those which refer to national and European standards, must be

observed when installing the product.

Both an installation manual with technical data and a manual

on general use and maintenance are enclosed with the product.

The installation can only be used after it has been inspected by

a qualified inspector.

A name plate of heat-resistant material is affixed to the

product. This contains information about identification and

documentation for the product.

2.0 Technical data

Material:

Cast iron

Finish:

Black paint, enamel

Fuel:

Wood

Log length, max.:

55 cm

Flue outlet:

Top/back

Flue pipe dimension:

Ø150 mm, 177 cm

2

 cross section

Approx. weight:

200 kg

Optional extras:

Connecting pipe for outdoor

ventilation, rear heat shield

Dimensions, distances etc.   See

fig. 1

Technical data according to EN 13240

Nominal heat output:

8,5 kW

Flue gas mass flow:

8,0 g/sec

Recommended chimney draught:

10 Pa

Efficiency: 78%@8,7

kW

CO emission (13% O

2

): 0,10%

Flue gas temperature:

285

o

 C

Operational type:

Intermittent

“Intermittent combustion” here means normal use of a stove.

That is to say, if you want to continue producing heat, you add

more fuel as soon as the previous load of wood has burnt down

to embers.

Wood consumption

Jøtul F

500

has a nominal heat output of

8,5

 kW. Use of

wood, with nominal heat emission: Approx.

2,7 kg/h

.

Another

important factor for proper fuel consumption is that the

logs are the correct size. The size of the logs should be:

Kindling:

Length: 30 - 55cm

Diameter: 2 - 5 cm

Amount per fire: 8 -10 pieces

Firewood (split logs):

Recomended length: 35 cm

Diameter: Approx. 8 - 13 cm

Intervals for adding wood: Approximately every 80 minutes

Size of the fire:  3,5 kg

Amount per load:  2 - 3 pieces

Nominal heat emission is achieved when the airvent is open

approximately 50%

.

les combustibles recommandés.

Respectez les consignes d'utilisation. Utilisez uniquement

Verwenden Sie nur empfohlenen Brennstoffen.

Montage- und Bedienungsanleitung beachten.

Follow user`s instructions. Use only recommended fuels.

standard

Certificate/

The appliance can be used in a shared flue.

Minimum distance to adjacent combustible materials:

Emission of CO in combustion products

Serial no: Y-xxxx, Year: 200x

Manufacturer:

N-1602 Fredrikstad

Norway

Jøtul AS

POB 1441

Sweden

EUR

Intermittent

Nominal heat output

Norway

Country

Operational type

Fuel type

Operation range

Efficiency

Klasse II

Classification

Standard

Flue gas temperature

Room heater fired by solid fuel

Product:

Jøtul

SP Sveriges Provnings- och

221546

Forskningsinstitut AB

SP Swedish National

Testing and Research

Institute

:

Approved by

:

:

:

:

:

:

:

Minimum distance to adjacent combustible materials:

OGC

SP

EN

Serial no.

On all our products there is a label

indicating the serial number and

year. Write this number in the

place indicated in the installation

instructions.

Always quote this serial number when

contacting your retailer or Jøtul.
