General safety instructions

FINISHING SANDER OPERATING INSTRUCTIONS

ENGeneral safety instructions

2. GENERAL SAFETY INSTRUCTIONS

OPERATING INSTRUCTIONSELECTRICAL CIRCULAR SAW

Carefully read, remember and keep these safety instructions

WARNING! In the use of electric machines and power tools, it is necessary to respect

and follow the following safety instructions for the reasons of protection against electric

shock, personal injury and danger of ﬁre. The term “power tool” in the instructions below

refers both to mains-operated (corded) power tool or battery-operated (cordless) power tool.

Save all warnings and instructions for future reference.

Workplace

Keep the work area clean and well lit. Cluttered or dark areas in the workplace invite

accidents. Store power tools that you don’t currently use.

Do not operate power tools in environments with danger of occurrence of a ﬁre or explosion,

such as in the presence of ﬂammable liquids, gases, or dust. Power tools create sparks

which may ignite the dust or fumes.

Keep unauthorised persons, especially children, away from the work area while operating

a power tool! Distractions can cause you to lose control over the performed activity. In no

event leave your power tool unattended. Keep the equipment away from animals.

Electrical Safety

Power tool plugs must match the mains socket outlet. Never modify the plug in any way.

Do not use any adapter plugs with earthed (grounded) power tools. Undamaged plugs and

matching outlets will reduce risk of electric shock. Damaged or fouled supply cables increase

the risk of electric shock. If the power cord is damaged, it must be replaced by a new power

cord which is available at the authorised service centre or the importer.

Avoid body contact with earthed or grounded surfaces such as pipes, radiators, cooking

ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or

grounded.

Do not expose power tools to rain or wet conditions. Never touch the power tool with wet

hands. Never wash the power tool under running water or immerse it in water.

Never use the supply cable for other than intended purposes. Never use the cord for carrying

or pulling the power tool. Never unplug the plug from the outlet by pulling the cable. Keep

electric cables away from sharp or hot objects to prevent mechanical damage.

The power tool was designed to be powered solely by alternating electric current. Always

check if the electric voltage matches the information speciﬁed in the type label of the power

tool.

Never use power tool with damaged electric cable or plug or which has been dropped or is in

any way damaged.

EN 10

General safety instructions

FDB 2004-E

12EN General safety instructions

FDK 2001-E

If an extension cord is used, always check whether its technical parameters match the

information speciﬁed in the type label of the power tool. When operating a power tool

outdoors, use an extension cord suitable for outdoor use. If extension drums are used, these

must be rolled out to prevent overheating of the cord.

If a power tool is operated in a damp location or outdoors, its operation is only permitted if

connected to an electric circuit protected by a residual current device <30 mA. Use of residual

current device (RCD) reduces the risk of electric shock.

Hold the power tool by insulated gripping surfaces only as the cutting or drilling tool may

contact hidden wiring or its own power cord during operation.

Personal Safety

Be careful, stay alert and watch what you are doing when operating a power tool.

Concentrate on your work. Do not use a power tool while you are tired or under the inﬂuence

of drugs, alcohol or medication. A moment of inattention while operating power tools may

result in serious personal injury. Do not eat, drink and smoke while operating a power tool.

Use personal protective equipment. Always wear eye protection. Use protective equipment

corresponding to the type of work you are doing. Protective equipment such as dust mask,

non-skid safety shoes, hard hat, or hearing protection used in accordance with the working

conditions will reduce the risk of personal injury.

Prevent unintentional starting. Do not carry the power tool while it is energised or with

your ﬁnger on the switch or trigger. Ensure the switch or trigger is in the “off” position before

connecting to power source. Carrying power tools with your ﬁnger on the switch or energising

power tools that have the switch on may result in serious injuries.

Remove any adjusting key or wrench before turning the power tool on. An adjusting wrench or

a key left attached to a rotating part of the power tool may result in personal injury.

Keep proper footing and balance at all times. Do not overreach. Never overestimate your own

capabilities. Never use power tools while you are tired.

Dress properly. Wear work clothes. Do not wear loose clothing or jewellery. Keep your hair,

clothing, gloves and other part of your body away from moving or hot parts of the power tool.

Connect the equipment to dust exhaustion. If the tools are provided for the connection of dust

collection or exhaustion devices, ensure these are properly connected and used. Use of such

devices can reduce dust-related hazards.

Fix the work-piece tightly. Use a cabinet clamp or a cramp to ﬁx the work-piece you are about

to machine.

Never use power tools if you are under the inﬂuence of alcohol, drugs, medication or other

narcotic or addictive substances.

This equipment is not intended for use by persons (including children) with limited physical,

sensual or mental capacities or lack of experience or knowledge unless they are supervised

or instructed about the use of the equipment by a person responsible for their safety. Children

must be supervised to make sure they are not playing with the equipment.

General safety instructions

FINISHING SANDER OPERATING INSTRUCTIONS

ENGeneral safety instructions

OPERATING INSTRUCTIONSELECTRICAL CIRCULAR SAW

Power Tool Use and Maintenance

Always disconnect the power tool from the mains in case of any problem during the work,

before cleaning the power tool or its maintenance, during each transportation and after the

completion of the work! Never operate a power tool if it is damaged in any way.

Immediately stop working if the power tool generates abnormal noise or smell.

Do not overload the power tool. The power tool will operate better and safer if it is used at the

rate for which it was designed. Use correct power tool which is intended for the given activity.

The correct power tool will do the job it was designed for better and safer.

Do not use the power tool if it cannot be safely turned on and off using the control switch.

Use of such power tool is dangerous. Defective switches must be repaired by a certiﬁed

service provider.

Disconnect the tool from the power source before making any adjustments, changing

accessories or maintenance. Such preventive safety measure prevents the risk of starting the

power tool accidentally.

Store idle power tools out of the reach of children and unauthorised persons. Power tools can

be dangerous in the hands of untrained users. Store the power tools in a dry and safe place.

Keep the power tool in good condition. Check the adjustment of moving parts and their

mobility. Check for any damage to the protective guards or other parts which could affect

safe operation of the power tool. If damaged, have the power tool properly repaired before

further use. Many accidents are caused by poorly maintained power tools.

Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting

edges facilitate work, reduce the risk of injury and are easier to control. Use of accessories

other than those speciﬁed in the instructions for use could result in damage to the power tool

and cause injuries.

Use the power tool, accessories and tool bits etc. in accordance with these instructions and

in the manner intended for the particular type of power tool taking into account the working

conditions and the work to be performed. Use of the power tool for purposes other than those

the power tool was intended for could result in hazardous situations.

Use of Cordless Power Tools

Before inserting the battery, make sure the switch is in the “0-OFF” position. Inserting a battery

into a switched-on power tool could result in hazardous situations.

Charge batteries only using the chargers prescribed by the manufacturer. Using a charger

intended for other battery type could result in its damage and occurrence of ﬁre.

Use only batteries intended for particular power tool. Use of different batteries could cause

injury or occurrence of ﬁre.

If the battery is not used, keep it separately from metal objects such as clamps, keys, bolts

and other small metal items which could cause connection of one battery contact with the

other. Short-circuiting the battery could result in injury, burns or occurrence of ﬁre.

EN 12

General safety instructions

FDB 2004-E

14EN General safety instructions

FDK 2001-E

Handle the batteries with care. Rough handling could result in leak of chemical substance

from the battery. Avoid contact with such substance and if, nonetheless, any contact occurs

wash the affected area under running water. If eyes get into contact with the chemical

substance seek immediately medical aid. Chemical substance from the battery can cause

serious injuries.

Service

Do not replace parts of the power tool, do not make any repairs or interfere in any way with

the construction of the power tool. Have your power tool repaired by qualiﬁed repair persons.

Any repair or modiﬁcation of the product without our company’s authorisation is

impermissible (it could cause injury or damage to the user).

Always have your power tool repaired in a certiﬁed service centre. Use only original or

recommended replacement parts. This will ensure that your safety and the safety of your

power tool is maintained.

Symbols

2. SYMBOLS

FINISHING SANDER OPERATING INSTRUCTIONS

Wear a breathing mask.

8EN Symbols

2. SYMBOLS

FDV 2001-E, FDV 2002-E

The product complies with the applicable

standards and regulations.

Read the Instruction Manual

attentively prior to use.

Double-insulated.

Use eyes protectiveequipment

Use earsprotectiove equipment

Subjected to recycling

EN 14

General description

3. GENERAL DESCRIPTION

Sanders are used to sand wood and similar products, painted surfaces, metal, stone, etc. There are sanders of

various different shapes in order to do speciﬁc jobs:

The vibrating sander recommended for sanding ﬂat surfaces such as doors or furnitu-

re. Move the sander slowly and regularly, in the direction of the wood ﬁbres.

DESCRIPTION AND LOCATION OF MACHINE PARTS

FIG. A & B

1. On /off switch

2. Sanding board

7. Dust collector

10. Grip handle

12. Ventilator intake

CONTENTS OF BOX

FIG.C

Finishing sander

5. Sandpaper

7. Dust collector

ASSEMBLING THE MACHINE

FIG. D

2. Sandpaper ﬁtting

FUNCTIONS OF THE MACHINE

FIG. E

1. Start-up of the machine

2. Movement to use

3. Connection to a vacuum cleaner

FDB 2004-E

General description | Technical specifications

REPLACING CONSUMABLES

FIG. G

1. Changing sandpaper (FIG D2)

2. Changing carbons For possible carbon replacement, please contact your dealer.

MAINTENANCE, RECOMMENDATIONS AND ADVICE

1. Keep the machine and ventilation intakes dust-free

2. Warning, sanding plaster can seriously damage the machine

4. TECHNICAL SPECIFICATIONS

FINISHING SANDER

Nominal frequency and power 230/50Hz

No-load speed:: 150W

Nominal power:

1 100rpm

Acoustic pressure level: 66dB(A)

Hand/arm vibration level 6,45 m/s2

Acoustic power level 77dB(A)

Insulation class II

Weight 1.4kg

FINISHING SANDER OPERATING INSTRUCTIONS

EN 16

Disposal

5. DISPOSAL

INSTRUCTIONS AND INFORMATION ON DISPOSAL OF USED

PACKAGING

Put any used package material to the place determined by the municipality for waste disposal.

DISPOSAL OF USED ELECTRIC AND ELECTRONIC EQUIPMEN

This symbol on products or accompanying documents means that used electric or

electronic products must not be put to ordinary municipal waste. Hand over such products

to determined collection points for proper disposal, restoration and recycling. Alternatively,

in some countries of the European Union or other European countries you can return your

products to your local dealer when you buy an equivalent new product. By dutiful disposal of

this product you can preserve precious natural resources and you help prevent any potential

adverse effects on the environment and human health which could be the results of wrong

waste disposal. Ask your local authority or the nearest collection point for additional details.

In case of improper disposal of this waste kind penalties can be imposed in accordance

with national regulations.

FOR COMPANIES IN THE EUROPEAN UNION COUNTRIES

Should you want to dispose of electric and electronic devices, ask your dealer or vendor

for necessary information.

DISPOSAL IN OTHER COUNTRIES OUTSIDE THE EUROPEAN UNION

Should you want to dispose of this product, ask your local authorities or your dealer

for necessary information about disposal method

This product fulﬁls all basic requirements of the EU directives that apply to it.

Text, design and technical specifications can change without prior notice and we reserve the right for

their change.

FDB 2004-E

Declaration of conformity

6. DECLARATION OF CONFORMITY

Product / Name: FINISHING SANDER. / FIELDMANN

Type / Model: FDB 2004-E ........................................................................................................................ 230V/50Hz/150W

The product complies with the following directives:

The Directive of the European Parliament and the Council No. 2006/95/EC dated 12 December 2006 on

the harmonisation of the laws of Member States relating to electrical equipment designed for use within

certain voltage limits.

The Directive of the European Parliament and the Council No. 2004/108/EC dated15 December 2004 on

the harmonisation of the laws of the Member States relating to electromagnetic compatibility and repealing

Directive No. 89/336/EEC.

The Directive of the European Parliament and the Council No. 2006/42/EC dated 17 May 2006 on machinery,

and amending Directive No. 95/16/EC.

The Directive of the European Parliament and the Council No. 2002/95/EC dated 27 January 2003 on the

restriction of the use of certain hazardous substances in electrical and electronic equipment.

The Directive of the European Parliament and the Council No. 2005/88/EC dated 14 December 2005

amending Directive No. 2000/14/EC on the harmonisation of the laws of the Member States relating to the

noise emission in the environment by equipment for use outdoors.

and standards:

EN60745-1:2009+A11:2010

EN60745 -2-4:20 0 9+A11:2011

EN 55014-1:2006+A1:2009

EN 55014-2:1997+A1:2001+A2:2009

EN 61000-3-2:2006+A1: 2009+A2:2009

EN 61000-3-3:2008

CE Certification ...............................................................................................................................................................14

FAST ČR, a.s. is authorised to act on behalf of the manufacturer.

Manufacturer:

FAST ČR, a.s.

Černokostelecká 2111, 100 00 Praha 10, Czech Republic

Tax ID:: CZ26726548

In Prague, 23 September 2014

Name: Zdeněk Pech

Chairman of Board Signature and stamps:

FINISHING SANDER OPERATING INSTRUCTIONS

FDB 2004-E

Contents

Vibrační bruska

NÁVOD K OBSLUZE

Děkujeme vám, že jste si zakoupili tuto vibrační brusku. Než ji začnete používat, přečtěte

si, prosím, pozorně tento návod k obsluze a uschovejte jej pro případ dalšího použití.

OBSAH

1. VŠEOBECNÉ BEZPEČNOSTNÍ PŘEDPISY ................................................................................................. 20

OBECNÉ BEZPEČNOSTNÍ POKYNY ............................................................................................................ 21

2. SYMBOLY .............................................................................................................................................................. 25

3. OBECNÝ POPIS .................................................................................................................................................. 26

4. TECHNICKÉ ÚDAJE ........................................................................................................................................... 27

5. LIKVIDACE ............................................................................................................................................................ 28

6. PROHLÁŠENÍ O SHODĚ .................................................................................................................................. 29

VIBRAČNÍ BRUSKA NÁVOD K OBSLUZE
