Eizo FlexScan S2411W: Selecting Display Mode

Prior to use Installation TroubleshootingSetting/Adjustment

Selecting Display Mode

FineContrast allows you to select the best display mode easily according to monitor’s application.

For details of FineContrast, refer to the User’s Manual on the CD-ROM.

English

FineContrast Mode

Custom Available for making desired setting.

sRGB Suitable for color matching with sRGB compatible peripherals.

External Switches to this External mode when you start up the UniColor Pro and perform the simulation.

Text Suitable for displaying texts for word processing or spreadsheets.

Picture Suitable for displaying images such as photos or picture images.

Movie Suitable for playing back animated images.

Touch or .

FineContrast menu

1

The FineContrast menu appears.

Displays the

current mode.

Touch or again while the FineContrast

2

menu is displayed.

Each time you touch the switch, the mode is switched to the

other mode. (Refer to the FineContrast Mode table.)

Touch at the desired mode.

3

The selected mode is set.

Adjusting Brightness

Touch or .

1

The brightness adjustment window appears.

Brightness menu

Adjust the brightness with or .

2

Touch to increase screen brightness or touch to

decrease.

Touch at the desired brightness.

3

The specifi ed brightness is saved.

Performing Advanced Settings/Adjustments

Advanced adjustments for the screen or color and various settings are

Adjustment menu

available using the Adjustment menu.

For details of each adjustment function, refer to the User’s Manual on

the CD-ROM.

The basic settings and adjustments are completed. For advanced settings/adjustments,

refer to the User’s Manual on the CD-ROM.

5
