De Dietrich DVI300: Installing your dishwasher

Installing your dishwasher

Foam strip and soundproofing

Installation of the adjustable

seal. To provide better noise

plinth on built-in appliances

insulation on built-in appliances,

(depending on the model)

install the soundproofing seals and

the foam strip supplied with your

machine

(depending on the model).

AVAILABLE FROM

THE AFTER-SALES

DEPARTMENT UNDER

REFERENCE: 32X0050

Safety instructions

For your safety’s sake, never leave your dishwasher’s door fully

open after use.

If the machine is operating incorrectly, disconnect it from the

electricity supply (remove the plug) or switch off the circuit involved

and close the water supply tap. Contact our After-Sales department.

If your dishwasher is being installed on a carpeted floor, make

sure to adjust the feet to leave a ventilation space under the

machine

Building in under a hob

If your worktop is fitted with a built-in hob over your

dishwasher, you must provide thermal insulation on top of the

machine. You can obtain this insulation kit from your dealer. Take care

to leave a space between the gas pipe and the top of your machine.
