Aiptek PocketCinema V60: 



User’s Manual

Getting Started

Charging the product

EN

The projector is builted in a 3000 mAh

Li-Polymer battery for mobile use. Please

charge the projector for 8 hours prior to its

first use. Connect one end of the supplied AC

adapter to DC IN jack and the other end to a

power outlet to start charging. Exchange the

plug (EU, US and etc.) of AC adapter that

accommodates the type of power outlet in

your country if it’s different.

Charging Status Charging Time

Power Off, charging by AC power adapter around 5 hours

Power Off, charging by USB connection around 8 hours

Power On and connect AC power adapter no charging

Power On and connected with USB cable no charging

Charging LED Indicator

During charging, the LED on Power Button turns Orange. It turns to Green when the

battery is fully charged.

Turn On / Off the Projector

Push the Power Switch downward for 1 second to turn ON the projector.

To turn off the projector, push the Power Switch downward for 2 seconds.

Adjusting the Focus

Adjust the focus by turning the Focus Wheel

upward or downward to get a sharp and clear

picture.

Select the Language

Use the navigation keys

 

to select ‘Setting’ and press (OK) to enter the

submenu. Select ‘Language’ and press (OK) to enter the language list. Select your

preferred language and confirm with (OK). Press (Exist) to return to Main Menu.

 Page 6

User’s Manual

Preparing the content

Projecting from Internal Memory

The projector has 2GB internal memory for file storage. Please download media files

EN

from your PC to the internal memory for projection:

1. Turn on the PC and the projector.

2. Connect the micro-USB port of the

projector to the PC via USB cable.

Once the connection is established,

the screen and ventilation fan will

automatically turns off to save the

power. Now the projector is in mass

storage mode.

3. You can copy the pictures, videos, music, Windows Office (PowerPoint, Word,

and Excel), and PDF files from your PC to the internal memory or delete the files

on the internal memory.

Note

: The remote controller is not applicable when the projector is connected to

PC or notebook.

Projecting from External Memory

External Micro SD/SDHC card slot

A single built-in memory card reader is available for

reading the following flash memory cards: Micro SD and

SDHC card up to 32GB. Gentally insert the card by

following the direction shown below until it reached the

bottom of the slot. To remove the memory card, gently

push the top edge of the card and pull it out.

USB Device

The projector can project the content

from USB device such as USB memory

stick. Connect one end of the USB

adaptor to the micro-USB port of the

unit and the other end to USB device

as shown.

Note

:

External memory source will be the default memory displayed on the



playlist. When both Micro SD/SDHC card and USB memory stick are

in use, USB memory stick will be the default memory displayed on

the playlist.

Selecting the memory source

Use the navigation keys







to select ‘

Setting’

and press (OK) to enter the

submenu. Select ‘Memory’ and press (OK) to enter the memory options. Select

your preferred memory source and confirm with (OK). Press (Exist) to return

to Main Menu.

 Page 7
