 2  Installation instructions

for the professional

This unit may only be erected and electrically

connected by a specialist following the instal-

lation instructions.

First remove the packaging and check accesso-

ries and any enclosures, ensure that no acces-

sories remain in the packaging material.

2.1  Structure of unit

4

  Air outlet grid

5

 Wall

bracket

6

 Closing

bolt

7

  Mains connection cable

8

 Rating

plate

2.2 Provisions  and  specification

The unit should not be

operated

–  in rooms at risk of explosion or fire from

chemicals, dust, gas or vapour,

–  in the immediate vicinity of pipes or

containers which transport or contain

flammable or explosive substances,

–  if the minimum distances from adjacent

object surfaces are not observed.

In workshops or other rooms in which ex-

haust gases, oil or petrol vapours etc. occur

or where solvents and chemicals are used,

persistent odour problems and where appli-

cable contamination can occur.

  The unit may not be used as a freestan-

ding unit.

  Do not stand on the unit.

  No changes may be made to the unit.

  The unit should never be left in operation

accidentally.

  Special care is required if the unit is used

in the presence of children, the infirm or

animals. Risk of injury!

  If part of the unit is damaged, if the unit

has fallen off or is malfunctioning, do not

operate.

  In case the power mains supply is dama-

ged, it must be replaced by the manuf-

acturer, the customer service of the ma-

nufacturer or an authorized and qualified

person. Mandatory for hazard prevention.

1.4  Care and maintenance

If the unit housing shows a slight brown dis-

colouration it should be cleaned as soon as

  The unit may only be fitted to a verti-

cal wall, temperature-resistant up to at

least 80 °C.

  Minimum distances from adjacent object

surfaces must be observed.

  All electrical connection and installation

work must be performed to VDE regula-

tions (0100), the regulations of a compe-

tent utility company and the correspond-

ing national and regional regulations.

  The unit must not be mounted directly

below a wall socket.

  If the unit is permanently connected to

an AC network (junction box) an isolation

distance of at least 3mm is required on all

poles for isolation from the network. For

this, circuit breakers, LS switches, fuses

etc. can be used.

Installation with permanent connection

cables is not permitted.

  The rating plate must be observed. The

rated voltage must correspond to the

nominal voltage.

  On installation of the heater in rooms with

a bath and/or shower, the protection area

to VDE 0100 part 701 as specified on the

unit rating plate must be observed.

  The unit must be mounted such that the

switch and control units are out of reach of

a person in the bath or shower.

  The mains connection cable may only be

replaced with original Stiebel Eltron spare

parts by experts.

2.3 Installation

2.3.1  Installation of wall bracket

B

The wall bracket should be used as a template

for fixing the appliance to the wall. It also

helps to keep the necessary ground clearance.

To attach the unit proceed as follows:

I

 Place the wall bracket (

5

) holding the

centre point horizontally on the ground and

mark the holes

a

 and

d

 on the assembly

wall;

II

 Raise the wall bracket so that the

holes

b

 in the wall bracket coincide with

the marks just made on the assembly wall;

 Mark

holes

c

 and

d

 on the wall bracket on

the assembly wall;

  At all four markings drill holes and attach

the wall bracket to the wall using suitable

fixing materials (wall plugs and screws)

dependig on the type of wall. The vertical

slots allow adjustment for an offset in the

fixing holes.

2.3.2 Unit

installation C

The convector is mounted by attaching the

slots on the rear simultaneously to the four

tabs of the wall bracket pressing down to

lock. The closing bolt (

6

) of the wall bracket is

then turned clockwise to the stop, locking the

fixing. To remove the convector, unscrew the

locking bolt and lift the unit slightly, pulling it

forwards and out of the bracket.

Check that . . .

. . .

the ON/OFF switch is turned on.

. . .

in your fuse box, the corresponding fuse is intact or whether the breaker has tripped.

Eliminate cause!

If the heater still does not warm up, call customer service!

Check whether it is covered, so it could have overheated (e.g. covered air outlet or inlet opening).

Eliminate cause!

If it does not warm up again after a few minutes‘ cooling down period, call customer service!

Read the type (Typ) and number (Nr.) from the rating plate (

8

) on

the unit and tell customer service!

•

the unit does not get hot?

•

the unit switches itself

off?

•
