Fieldmann FZP 2001-E: 3. MACHINE DESCRIPTION AND CONTENT OF DELIVERY

Machine description and content of delivery

3. MACHINE DESCRIPTION AND

CONTENT OF DELIVERY

Machine description (see Fig. 1)

1 -

Chain

10 -

Fast tightening handgrip

2 -

Guide

11 -

Cord with plug

3 -

Grab stop

12 -

Rear handle

4 -

Protective guard

13 -

Switch safeguard

5 -

Oil refill hole for chain lubrication

14 -

Front handle

6 -

Protection of right hand

15 -

Protective guard of guide

7 -

Oil control tank for chain lubrication

16 -

Serial number

8 -

Chain drive cover

17 -

Switch

9 -

Sprocket wheel

When cabling gets damaged, pull the

plug out of mains.

Maximum acceptable length of guide.

Noise level and its impact on the

environment complies with the

European standard. Electrical saw

105

noise level is specified in chapter

„Technical Data“ and is shown on the

machine label.
