Manual for USRobotics 24-Port 10/100
24-Port 10/100 Ethernet Switch
Installation Guide
Guide d'installation
Installationsanleitung
Guida per l’installazione
Installatiegids
Guía de instalación
Manual de Instalação
Installationshandbok
Руководство по установке
R24.0463.00
Installation Guide ................................................................................... 1
Guide d'installation ................................................................................9
Installationsanleitung............................................................................. 17
Guida per l’installazione.........................................................................25
Installatiegids......................................................................................... 33
Guía de instalación................................................................................. 41
Manual de Instalação ............................................................................. 49
Installationshandbok.............................................................................. 57
Руководство по установке .....................................................................65
Installation
Package Contents:
- 24-Port 10/100 Ethernet Switch - Quick Installation Guide - Power cord
LEDS Action Function
PWR Lighted Receiving power
Off Not receiving power
10/100 1-24
Lighted 100 Mbps LAN link is achieved
(Each LED corresponds
Off 10 Mbps LAN link is achieved
with a LAN port on the
front.)
LINK/ACT 1-24
Lighted Link is achieved
(Each LED corresponds
with a LAN port on the
Blinking Sending and receiving data at the corresponding LAN port
front.)
2468 10
12 14 16 18
20 22
24
24 Port 10/100Mbps Switch
U.S. Robotics
24 Port 10/100Mbps Switch
1357
9111315
17 19 21 23
Front Function
LAN Ports 1 through 24 The LAN ports are used to connect Ethernet devices to the LAN.
1
Before You Begin
Note: For more information, you can also refer to the Support section of the U.S. Robotics
Web site at http://www.usr.com/support
Note: Your model number is 7924A. It is important that you have your serial number
written down before you install the 24-Port 10/100 Ethernet Switch. You can find your serial
number on the bottom label of the 24-Port 10/100 Ethernet Switch and on the side of the
package. If you ever need to call our Technical Support department, you will need this number to
receive assistance.
Step 1. Connect the power supply
ON
OFF
100-240VAC
100-240VAC
Step 2. Connect your 24-Port 10/100 Ethernet Switch to your Ethernet-ready
device
2468 10
12 14 16 18
20 22 24
24 Port 10/100Mbps Switch
U.S. Robotics
24 Port 10/100Mbps Switch
1357
9111315
17 19 21 23
Ethernet cable
2
Congratulations! The installation of your U.S.Robotics 24-Port 10/100 Ethernet Switch is
complete. As connections are established with the 24-Port 10/100 Ethernet Switch, the
corresponding LED lights will turn on. Repeat this step as needed for up to twenty three
additional devices.
2468 10
12 14 16 18
U.S. Robotics
24 Port 10/100Mbps Switch
1357
9111315
This is one of many possible configurations.
Note: For networking information, refer to your operating system’s documentation.
Register your product online at http://www.usr.com/productreg
3
17
1
9
21
2
3
20 22 24
24 Port 10/100Mbps Switch
