Fieldmann FZP 2001-E: 15. TECHNICAL DATA

Technical data

15. TECHNICAL DATA

Model .......................................................................................................................................................... FZP 2001-E

Motor 2200

Nominal voltage .................................................................................................................................. 230-240 VAC

Nominal output ............................................................................................................................................... 2200 W

Mains frequency ................................................................................................................................................. 50 Hz

Clutch .......................................................................................................................................................................... Yes

Electronic start control .......................................................................................................................................... Yes

Weight

Excluding guide and chain ............................................................................................................................. 4,4 kg

including 16“ guide and chain ...................................................................................................................... 5,1 kg

Chain lubrication

Oil tank capacity ............................................................................................................................................ 0.13 liter

Oil pump ....................................................................................................................................................... automatic

Noise level

Equivalent of noise intensity as per international standards ..................................................... 105 dB(A)

Vibrations

2

Front handle .............................................................................................................................................. 2,788 m/s

2

Rear handle .............................................................................................................................................. 3,536 m/s

Chain / guide

Recommended guide length ........................................................................................................... 16“/405 mm

Actual cutting length ........................................................................................................................... 16“/405 mm

Chain speed, nominal output ................................................................................. 12,5 m/sec., 7 teeth/drive

Number of driving links .................................................................................................................................. 16“/57

( “= Inch=palec)
