Putting the components into operation

Putting the components into

operation

Setting up the charging case

Note:

The charging case as well as the accupacks and the

receivers’ built-in rechargeable batteries will get

hot during charging. Please ensure the following so

that the generated heat can dissipate:

•The air vents of the charging case must not be

covered or blocked.

• The charging case must be kept away from heat

sources and must never be exposed to direct

sunlight.

• During charging, do not put the case cover on the



charging case.

The charging case has four plastic feet to ensure that

it cannot slip on the surface on which it is placed.

CAUTION!

Some furniture surfaces have been

treated with varnish, polish or synthetics

which might cause stains when they

come into contact with other synthetics.

Despite a thorough testing of the syn-

thetics used by us, we cannot rule out the

possibility of staining.

 Place the charging case on a flat, even surface.

 Connect the supplied mains cable to the IEC mains

socket  on the charging case.

 Connect the mains cable to a wall socket.

Note:

The case cover can be used as a stand for the

charging case (see diagram on the left).

25
