Labconco VACUUBRAND Diaphragm Pump 7393001: Safety information!

 page 9 of 74

Safety information!

Important information!

+

Keep this manual complete and accessible to per-

sonnel at all times!

+

Read this manual carefully before installing or op-

erating the equipment. Observe the instructions

contained in this manual.

+

Do not modify the equipment without authoriza-

tion.

This manual is an integral part of the equipment de-

scribed therein. It describes the safe and proper use

of the vacuum pump.

Make operating personnel aware of dangers arising

from the pump and the pumped substances.

VACUUBRAND disclaims any liability for inappropri-

ate use of these pumps and for damage from failure

to follow instructions contained in this manual.

This manual is only to be used and distributed in its com-

plete and original form. It is strictly the users’ responsibility

to check carefully the validity of this manual with respect

to his product.

Manual-no.: 999156 / 02/14/2012

The following signal word panels and safety

symbols are used throughout this manual:

This is the safety alert symbol. It is used to alert you to po-

tential personal injury hazards. Obey all safety messages

that follow this symbol to avoid possible injury and death.

NOTICE

page 10 of 74

➨

 DANGER indicates a hazardous situation which, if not

avoided, will result in death or serious injury.

+

 WARNING indicates a hazardous situation which, if not

avoided, could result in death or serious injury.

•  CAUTION indicates a hazardous situation which, if not

avoided, could result in minor or moderate injury.

  NOTICE is used to address practices not related to per-

sonal injury.

  Caution! Hot surface!

  Disconnect equipment from AC power.

NOTICE

Formatting used in this manual:

Note

: The signal word panels in all sections of this manual always refer

to all paragraphs of the same format (

➨

 /

+

 / • / plain text)  following each

signal word panel.

The document ”Safety information for vacuum equipment” is

part of this manual! Read the ”Safety information for vacuum

equipment” and observe the instructions contained therein!

 page 11 of 74

General information

Remove all packing material from the packing box. Re-

move the product from its packing-box and retain all pack-

aging until the equipment is inspected and tested. Re-

move the protective caps from the inlet and outlet ports

and retain for future use. Inspect the equipment promptly

and carefully.

If the equipment is damaged, notify the supplier and the

carrier in writing within three days. Retain all packing ma-

terial for inspection. State the item number of the product

together with the order number and the supplier’s invoice

number. Failure to check and give notice of damage will

void any and all warranty claims for those deficiencies.

Replace the protective caps, if the equipment is not used

immediately. Store the equipment in dry and non-corrosive

conditions (see also ”Technical data”, pg. 24).

+

 Do not use any damaged equipment.

•  Use the mounted handle when moving the pump.

Intended use

+

 Do not use the pump or any system parts on humans

or animals.

+

 Prevent any part of the human body from coming into

contact with vacuum.

+

 Ensure that the individual components are only con-

nected, combined and operated according to their de-

sign and as indicated in the instructions for use.

+

 Comply with all notes on correct vacuum and electrical

connections; see section ”Use and operation”, pg. 38.

+

 Do not use the pump to generate pressure.

+

The pumps are designed for

ambient temperatures

during operation between +50°F and +104°F (+10°C

NOTICE

page 12 of 74

and +40°C). Periodically check maximum temperatures

if installing the pump in a cabinet or a housing. Make

sure ventilation is adequate to maintain recommended

operating temperature. Install an external automatic

ventilation system if necessary. If pumping hot process

gases, make sure that the maximum permitted gas in-

let temperature is not exceeded. The maximum permit-

ted gas inlet temperature depends on several param-

eters like inlet pressure and ambient temperature (see

”Technical data”, pg. 24).

+

Do not aspirate particles and dust.

+

Do not pump liquids.

•  Ensure  that  the  pump  is  chemically  resistant  to  the

pumped substances prior to operation.

Use the equipment

 only as intended

, that is, for genera-

tion of vacuum in vessels designed for that purpose. Any

other use will automatically invalidate all warranty and li-

ability claims. Remain aware of safety and risks.

Setting up and installing the equipment

➨

 Equipment must be connected only to a

suitable elec-

trical supply

 and a suitable ground point. As such,

the plug must be plugged into an outlet that is properly

grounded. Failure to connect the motor to ground may

result in deadly electrical shock.

  The  supply  cable  may  be  fitted  with  a  molded  Euro

-

pean IEC plug or a plug suitable for your local electrical

supply. The cable contains wires color coded as fol-

lows: green or green and yellow: ground; blue or white:

neutral; brown or black: hot.

+

 Due to the high compression ratio, the pump may gen-

erate overpressure at the outlet. Check pressure com-

patibility with system components (e.g., exhaust pipe-

line or exhaust valve) at the outlet.

NOTICE

 page 13 of 74

+

 Do not permit any

uncontrolled pressurizing

. Make

sure that the exhaust pipeline cannot become blocked.

If there is an exhaust isolation valve, make sure that you

cannot operate the equipment with the valve closed to

avoid a

risk of bursting!

+

 Always provide a free and pressureless exhaust outlet

to avoid damage to pump valves and risk of bursting of

condenser glassware.

+

 Check the overpressure safety relief device at the ex-

haust waste vapor condenser at appropriate intervals.

+

 Keep the electrical power cord away from heated sur-

faces.

•   Provide a firm, level platform for the equipment. Check

that the system which you are going to evacuate is

mechanically stable. Check that all fittings are secure.

Ensure a stable position of the pump without any me-

chanical contact other than the pump feet.

•  Comply with

maximum permissible pressures

 at in-

let and outlet and with

maximum permissible pres-

sure differences

 between inlet and outlet. See section

”Technical data”, pg. 24. Do not operate the pump

with overpressure at the inlet.

•  Avoid overpressure of more than 17.5 psi absolute (1.2

bar absolute) in the event that gas or inert gas is connect-

ed to the pump, to the gas ballast or to a venting valve.

•

Note

: Flexible elements will shrink when evacuated.

•  Connect hoses gas tight at inlet and outlet of the pump.

•   Ensure that no foreign objects can be drawn into the

pump.

•   Check the power source and the pump’s rating plate

to be sure that the power source and the equipment

match in voltage, phase, and frequency.

•   On  pumps  with  a  dual-voltage  motor,  check  that  the

voltage selection switch is set correctly. Do not change

the setting of the voltage selection switch while the

page 14 of 74

pump is connected to AC power. Unplug the pump be-

fore setting the voltage selection switch.

Note

: If the

pump is switched on with wrong voltage selection, the

motor may be damaged!

•  Ensure that the

coolant outlet pipe

 is always free and

that it cannot get blocked. If installing an optional cool-

ant valve, it must always be in the supply line of the

exhaust waste vapor condenser.

Keep a minimum distance of 8 in (20 cm) between the

cooling fan and surrounding items (e.g., housing, walls,

etc.). Check fan regularly for dust/dirt. Clean fan guard

grill if necessary to avoid a reduction of ventilation.

Use only hoses at the inlet and outlet of the pump with

an inner diameter at least as large as the diameter of the

pump’s tubing (to avoid overpressure at the outlet, and

reduction of pumping speed at the inlet).

Allow the equipment to equilibrate to ambient temperature

if you bring it from cold environment into a room prior to

operation. Notice if there is water condensation on cold

surfaces.

Secure coolant hoses at the hose nozzles (e.g., with hose

clamp) to prevent their accidental slipping.

Comply with all

applicable and relevant safety require-

ments

 (regulations and guidelines).

Implement the re-

quired actions and adopt suitable safety measures.

Ambient conditions

➨

 Do not reach for this product if it has fallen into liquid.

There is a risk of deadly electrical shock. Unplug the

system immediately.

+

 Do not use this product in an area where it can fall or

be pulled into water or other liquids.

NOTICE

 page 15 of 74

+

Pay attention to the

permissible maximum ambient

and gas inlet temperatures

 (see ”Technical data”,  pg.

24).

•   Adopt  suitable  measures  in  case  of  differences  from

recommended conditions, e.g., using the equipment

outdoors, installation in altitudes of more than 3300 ft

(1000 m) above mean sea level, conductive pollution or

external condensation on the pump.

•   Do not operate this product near flames.

To the best of our knowledge the equipment is in com-

pliance with the requirements of the applicable EC-direc-

tives and harmonized standards (see ”Declaration of Con-

formity”) with regard to design, type and model. Directive

EN 61010-1 gives in detail the conditions under which the

equipment can be operated safely (see also IP degree of

protection, ”Technical data”,  pg. 24).

Operating conditions

➨

These pumps are not approved for operation in po-

tentially explosive atmospheres.

Do not operate the

pumps in potentially explosive atmospheres.

➨

Pumps

without the

”

”

mark on the rating plate

 are

not approved

 for the

pumping of potentially explo-

sive atmospheres

.

Do not pump potentially explo-

sive atmospheres

 with those pumps.

➨

Pumps

bearing the

”

”

mark on their rating plates

are

approved for the pumping of potentially ex-

plosive atmospheres

  according  to  their  classifica

-

tion

II 3G IIC T3 X

 according to ATEX, but they are

not approved for operation in potentially explosive

atmospheres

 (see section

”

 Important information:

Equipment marking (ATEX)”, pg. 22)

.

➨

 The pumps are

not suitable

 to pump any of the sub-

stances listed below.

Do not pump:

NOTICE

page 16 of 74

-

unstable substances

- substances which react explosively under

impact

(mechanical stress) without air

-  substances which react explosively when being ex-

posed to

elevated temperatures

 without air,

-  substances subject to

auto-ignition

,

-  substances which are

inflammable without air

-

explosive substances

.

➨

The pumps are

not approved

 for operation below

ground.

Do not operate

 the pump

below ground

.

+

The pumps are

not suitable

 for pumping dust.

  Do not pump dust

.

•

Do not pump

 substances which may form

deposits

 in-

side the pump. The pumps are not suitable for pumping

substances which may form deposits inside the pump.

Deposits and condensate in the pump may lead to in-

creased temperatures even to the point of exceeding

the maximum permitted temperatures.

•   Check the inlet and outlet of the pump, if there is a dan

-

ger of forming

deposits

 inside the pump, e.g., in the

pump chambers (the pump chamber is the part between

diaphragm and head cover. See section ”Replacing

diaphragms and valves”, pg. 52). Inspect the pump

chambers regularly and clean if necessary.

•

Consider interactions and chemical reactions of

the pumped media.

Ensure that the materials of the

pump’s wetted parts are compatible with the pumped

substances, see section ”Technical data”, pg. 24.

  When changing the substances pumped, we recom-

mend purging the pump with air or inert gas prior to

changing the pumped media. Purging the pump will

pump out residues and it will reduce the possibility of

reactions of the pumped substances with each other

and with the pump’s materials.

 page 17 of 74

Safety during operation

➨

 Adopt suitable measures to prevent the release of dan-

gerous, toxic, explosive, corrosive, noxious or polluting

fluids, vapors and gases. To prevent any emission of

such substances from the pump outlet, install an ap-

propriate collecting and disposal system and take pro-

tective action for pump and environment.

➨

 You must take suitable precautions to prevent any for-

mation of explosive mixtures in the pump chamber or

at the outlet of the pump. In case, e.g., of a diaphragm

failure, mechanically generated sparks, hot surfaces or

static electricity may ignite these mixtures. Use inert

gas for gas ballast or venting, if necessary.

➨

  Drain appropriately or otherwise remove any potentially

explosive mixtures at the outlet of the pump, or dilute

them with inert gas to non-explosive concentrations.

➨

Never operate this pump if it has a damaged cord or

plug.

+

 If the pump is not working properly, has been dropped

or has fallen into water, contact your pump service pro-

vider.

+

 Prevent any part of the human body from coming into

contact with vacuum.

+

Never aspirate liquids or dust into the pump.

+

Make sure that the exhaust pipeline cannot become

blocked.

+

 Check the overpressure safety relief device at the ex-

haust waste vapor condenser at appropriate intervals.

+

 Comply with applicable regulations when disposing of

chemicals. Take into consideration that chemicals may

be contaminated. Take adequate precautions to pro-

tect people from the effects of dangerous substances

(chemicals,  thermal  decomposition  products  of  fluo

-

page 18 of 74

roelastomers). Use appropriate protective clothing and

safety goggles.

+

 Use  only

original manufacturer’s spare parts and

accessories

. Otherwise the safety and performance of

the equipment, as well as the electromagnetic compat-

ibility of the equipment might be reduced.

  The CE mark or the cTÜVus mark may be voided if not

using original manufacturer’s spare parts.

+

 Interruption of the pump (e.g., due to power failure),

failure of connected components or of parts of the sup-

ply, or change in parameters must not be allowed to

lead to dangerous conditions. In case of a diaphragm

failure or in case of a leak in the manifold, pumped sub-

stances might be released into the environment or into

the pump housing or motor.

  Comply with all notes regarding proper use of the pumps,

as well as operation and maintenance guidance.

+

 The residual

 leak rate of the equipment

 might render

possible an exchange of gas, albeit extremely slight,

between the environment and the vacuum system.

  Adopt suitable measures to prevent contamination of

the pumped substances or the environment.

•  Ensure that no parts of your clothing, hair or fingers  can

be caught or drawn in at the inlet of the pump. Never

insert fingers or drop any other object into the inlet or

outlet.

•  Pumping at high inlet pressure may lead to overpres

-

sure at the gas ballast valve. Pumped gases or con-

densate might be expelled if the valve is open. If an

inert gas supply is connected to the gas ballast, ensure

that its inlet pipeline is not contaminated.

•

Pay attention to the safety symbol ”hot surfaces” on

the equipment. Hot parts may cause burns if touched.

Adopt suitable measures to prevent any danger arising

 page 19 of 74

from hot surfaces or electric sparks. Ensure that hot

surfaces of the pump do not cause burns. Provide a

suitable contact guard if necessary.

•  Ensure that the

coolant outlet pipe

 at the waste vapor

condenser is always free and that it cannot get blocked.

Do not start the pump if the pressure difference between

inlet and outlet exceeds 16 psi (1.1 bar) at maximum.

Prevent the backpressure of gases and the backflow of

condensates at the outlet.

Check the liquid level in the catchpots regularly and drain

condensate  in  time  to  prevent  overfilling.  Install  a  level

sensor (see ”Accessories”, pg. 48) for monitoring, if

necessary.

Provide appropriate protective measures to allow for the

possibility of failure and

malfunction

. The protective mea-

sures must also allow for the requirements of the respec-

tive application.

In case of overload, the motor is shut down by a

self-hold

thermal cutout

 in the winding.

Note

: Only manual reset is possible. Switch off the pump

and disconnect from the power source. Identify and elimi-

nate the cause of failure. Wait approx. five minutes before

restarting the pump.

 •

Note

: In case of

supply voltage below 100V

, the lock

of the cutout might be impaired and the pump may

restart  on  its  own  after  sufficient  cooling  down.  Take

appropriate precautions, if an automatic restart of the

pump may lead to a dangerous situation (e.g., switch

off the pump and disconnect from the power source).

NOTICE

page 20 of 74

Maintenance and repair

In order to comply with laws (occupational, health and

safety regulations, safety at work law and regulations for

environmental protection) vacuum pumps, components

and measuring instruments can only be returned when

certain procedures (see section ”

Notes on return to the

factory

”, pg. 67) are followed.

Take advantage of our service seminars, which put special

focus on the maintenance and repair of vacuum pumps.

For details and for the online ”Instructions for repair” man-

ual see www.vacuubrand.com.

In case of normal wear, the lifetime of the diaphragms

and valves is > 10000 operating hours. Bearings have a

typical durability of 40000 h. Motor capacitors have a typi-

cal durability in the range of 10000 to 40000 h depending

strongly on operation conditions including ambient tem-

perature, humidity or load.

➨

Ensure that the pump cannot be operated acciden-

tally. Never operate the pump if covers or other

parts of the pump are disassembled.

➨

Switch off the pump. Disconnect the electrical pow-

er cord and wait two minutes

 before starting mainte-

nance to allow the capacitors to discharge.

➨

Note

: The pump may be contaminated with process

chemicals, which have been pumped during operation.

Ensure that the pump is completely decontaminated

before maintenance commences.

+

Take adequate precautions to protect people from the

effects of dangerous substances if contamination has

occurred. Use appropriate protective clothing, safety

goggles and protective gloves.

NOTICE

 page 21 of 74

+

Wear parts have to be replaced regularly.

+

Never operate a defective or damaged pump.

+

 Check every motor capacitor regularly by measuring

its capacity and estimating its time in operation. Re-

place old capacitors early enough to prevent a failure in

operation. If an old motor capacitor fails, the capacitor

may get hot. It may even melt or emit a flame, which

could be

dangerous for persons and equipment in

the vicinity

. The capacitors have to be replaced by an

electrician.

+

 Vent the pump before starting maintenance. Isolate the

pump and other components from the vacuum system.

Allow sufficient cooling of the pump. Separate the pump

from the coolant circuit and drain condensate, if appli-

cable.

Ensure that

maintenance

 is done only by suitably trained

and supervised technicians. Ensure that the maintenance

technician is familiar with the safety procedures, which re-

late to the products processed by the pumping system.

Only dismantle the pump as far as necessary.

NOTICE

page 22 of 74

      Important information: Equipment marking (ATEX)

VACUUBRAND equipment bearing mark (see rating plate)

 II 3G IIC T3 X

Internal Atm. only

Tech. File Ref.: VAC-EX01

and

VACUUBRAND equipment bearing mark (see rating plate)

 X see manual

For equipment labelled with „

 X see manual“ the following classifica

-

tion according to Directive 94/9/EC (ATEX) is valid:   II 3G IIC T3 X,

Internal Atm. only, Tech. File Ref.: VAC-EX01.

The classification II 3G IIC T3 X according to ATEX is only valid for the in

-

ner part (wetted part, pumped gas or vapor) of the equipment. The equip-

ment is not suitable for use in external, potentially explosive atmospheres

(environment).

The overall category of the equipment depends on the connected compo-

nents. If the connected components do not comply with the classification

of the VACUUBRAND equipment, the specified category of the VACU

-

UBRAND equipment is no longer valid.

Vacuum pumps and vacuum gauges in category 3 are intended for con-

nection at equipment in which during normal operation explosive atmo-

spheres caused by gases, vapors or mists normally don’t occur or, if they

do occur, are likely to do so only infrequently and for a short period only.

Equipment in this category ensures the requisite level of protection dur-

ing normal operation.

The use of gas ballast or the operation of venting valves is only permit-

ted if thereby explosive atmospheres normally don’t occur in the interior

of the equipment or, if they do occur, are likely to do so only infrequently

and for a short period.

 page 23 of 74

The pumps are marked with ”X” (according to EN 13463-1), i. e. restric-

tions of the operation conditions:

•  The equipment is designated for a low degree of mechanical stress

and has to be installed in a way so that it cannot be damaged from

outside.

  Pumping units have to be installed protected against shocks from the

outside and against glass splinters in the event of breaking (implo-

sion).

•  The equipment is designated for an ambient and gas inlet tempera

-

ture during operation of +10 to +40°C. Never exceed these ambient

and gas inlet temperatures. If pumping / measuring gases which are

not potentially explosive, extended gas inlet temperatures are valid,

see instructions for use, section “Gas inlet temperatures” or “Technical

data”.

After any intervention at the equipment (e.g., repair / maintenance) the ul-

timate vacuum of the pump has to be checked. Only if the pump achieves

its specified ultimate vacuum, the pump’s leak rate is low enough to en

-

sure that no explosive atmospheres will occur in the interior of the equip-

ment.

After any intervention at the vacuum sensor the leak rate of the equip-

ment has to be checked.

Attention: This manual is not available in all

languages of the EU. The user must not op-

erate the device if he does not understand

this manual. In this case a technically cor-

rect translation of the complete manual has

to be available. The manual must be com-

pletely read and understood before opera-

tion of the device and all required measures

must be applied.
