3. MACHINE DESCRIPTION AND

DELIVERY CONTENT

Machine description (see Fig.1)

1 -

Brake lever

7 - Mulching blind flange

2 -

Travel lever

3 -

Upper handle

4 -

Bottom handle

5 -

Engine

6 -

Bogie

Delivery content

Take the garden machine carefully out of the package and check whether the following parts are

complete:

Rotational mower

Collection basket

Upper and bottom part of the mower handle

4 wheels

Installation set

Mulching blind flange

Operation manual

Warranty certificate

In the case of some parts missing or damaged, please, contact the dealer where you’ve bought

the machine.

4. MACHINE ASSEMBLY

Collection basket installation (Fig.2)

Insert the metal frame into the collection basket and fix (Fig. 2)

3 in 1 Introduction:

Rear spitting with grass collection (Fig. 3)

Remove the mulching blind flange (Fig. 7) and fasten the grass collection basket on its place

(Fig. 6).

Mulching (Fig. 4)
