Fieldmann FZR 4610-B: 10. TECHNICAL DATA

Technical data | Declaration of conformity

10. TECHNICAL DATA

Engine type: .........................................................................................................................................................SG475

Nominal output: .................................................................................................................................................2,5 kW

Engine speed: ................................................................................................................................................3000rpm

3

Stroke volume: .................................................................................................................................................139 cm

Starting: ...........................................................................................................................................................By pulling

Fuel tank capacity: ........................................................................................................................................ 1.6 liters

Oil tank capacity: ........................................................................................................................................... 0.5 liters

Adjustable mowing height : ...................................................................................25-75mm with 8 positions

Height setup: .............................................................................................................................Central height setup

Mowing width: ................................................................................................................................................460 mm

Wheel spacing: .....................................................................................................................178 mm (front wheel)

..............................................................................................................................254 mm (rear wheel)

Wheel width: ......................................................................................................................................................50 mm

Collection basket capacity: .................................................................................................................................60 l

Bogie: .........................................................................................................................................................................steel

Declared noise level: .....................................................................................................................................96dB(A)

Netto/brutto weight: ..............................................................................................................................32 kg/34 kg

11. DECLARATION OF CONFORMITY

EC Declaration of Conformity

FAST ČR, a.s., Černokostelecká 1621, 251 01 Říčany u Prahy, tel.: 323204111, declares

obligatorily that Fieldmann FZR 4610-B gasoline mower (year of manufacture is marked on the

type plate and is followed by the machine serial number) conforms to regulations of the COUNCIL

DIRECTIVES:

EC no. 2006/42/EC, 2004/108/EC, (number of the approval certificate: AM5016511760001)

EC no.2004/26/EC (emission of gaseous and particulate pollutants)

Approval number: e11*97/68SA*2010/26*2533*00

and it was tested in conformity with standards below:

EN ISO 5395-1:2013, EN ISO 5395-2:2013; EN ISO 14982:2009

FAST ČR, a.s. company is entitled to act on behalf of the manufacturer.

CE label: 2014

In Říčany, on 12/11/2014

ing Zdeněk Pech

Name Stamp Signature

Chairman of the Board
