Notes on safety

Please also pay attention to the enclosed safety instructions, and carefully

read through this instruction guide before initial operation.

Important points of advice are marked with a caution symbol.

DE

EN

FR

Warnings

PL

The product must only be installed and used by qualified technicians, in

RU

compliance with statutory regulations of the place where the product is

used.

Before starting any installation or maintenance operations, activate all

safety cut-outs on the main supply with a contact breaker gap of at

least 3 mm.

If properly installed, the illuminator is completely maintenance free.

For a correct installation, it is not necessary to open the device.

Do not try to open or repair the product; in case of need, contact after-

sales service.

In case of opening or tampering of the device, warranty conditions will

be lost.

The device gives out infrared radiation through LED; the use of controls,

regulations or proceedings, which are different from those stated in this

manual, can cause dangerous exposures to infrared radiation.

To clean plastic parts, use only water.

13

When the illuminator is working, it gives out an infrared radiation

which is not visible to the human eye. Do not look directly the

radiant side (front side of the device) from a distance less than 2

meters.

2 m

When the illuminator is on, it could be hot. Before touching the

illuminator or making any maintenance, turn off the device and

wait till it is cooled.

Put the illuminator in such a way that the environmental brightness

sensor is not directly exposed to light sources.

Parts supplied

IRLED-40xX

Instruction manual

L-Bracket BWHYP1

Fixing screws for BWHYP1

3 pin power connector
