88
−
Insert the water filter into the tank and place the tank on the
base.
−
Close the top lid.
−
Insert the ending of the hose in the position where the tops marks on
the hose ending and tank cover each other and turn it right or left,
so that the marks change position in reference to each other.
−
Poł
ą
cz:
a
. sucking tubes,
b.
tube with hose,
c.
tube with
chosen nozzle or brush.
−
Insert the hose stub into the valve inside the vacuum
cleaner base.
−
Make sure that the stub fastening is exactly locked in the seating,
ATTENTION!!! In case of difficulties in a/m elements connection lubricate the sealing with i.e.
Vaseline grease, water, etc.
−
Take the connection cord plug and remove it from the vacuum cleaner.
ATTENTION!!! Be careful during pulling the cord out, the yellow mark on the
cord show the end of the cord.
Further trials (pulling) can lead to damage the cord.
−
Insert the plug to the mains supply receptacle and switch the vacuum cleaner on
pressing the on/off button.
ATTENTION!!! The vacuum cleaner is equipped with a float, which shall
automatically block the suction, if the foam filter is very dirty.
It is indicated with increased engine rotation.
In such situation:
−
Switch off the vacuum cleaner pressing the on/off button and unplug it.
−
Turn the ending of the hose up to the position where the tops marks on the
hose ending and tank cover each other and remove the hose from the tank.
−
Open the top lid and remove the front tank.
−
Remove the water filter and take the foam filter out of it.
−
Clean the a/m filters thoroughly (see the “After operation”
section.
−
Release the hook of the filter housing bottom and remove the rubbish.
−
If the rubbish have been collected to the paper bag before, please release the
top cover hooks 1 following the above mentioned activities (Item”
A
”).
−
Pour dirty water out including the dirtiness form the tank and
rinse the tank.
−
Pour clean water, insert the water filter, place the tank on the base and close the
top lid.
−
Insert the plug to the mains supply receptacle, switch the vacuum cleaner on and
continue vacuuming.
ATTENTION!!! The float can also operate during sudden movements, sharp pulling, hitting, or
crossing the doorsteps
.
