Jotul I400 Panorama: 7.0 Choice of fuel

23

ENGLISH

7.0 Choice of fuel

Always use the specified fuel. (Fuel type is described in

«2.0

Technical data»

 in the installation manual for each product).

This will give you optimal results. Use of other fuels may damage

to the product.

7.1 Jøtul’s definition of quality firewood

By good quality firewood we mean logs of, for example,

birch, beech and oak.

Good quality wood should be dried so that the water content is

approx. 20%.

To achieve this the wood should be chopped at the latest in late

winter or early spring. It should be cut and stacked so that air

circulates around it. The stacks must be protected so as to avoid

absorbing excessive rainwater. The logs should be taken indoors

in autumn for use during the winter season.

The amount of energy obtainable from 1 kg of wood varies very

little. On the other hand the specific weight of the different kinds

of wood varies considerably. As an example, a certain volume of

fir will provide less kWh than the same volume of oak, which has

a higher specific weight.

The amount of energy produced by 1 kg quality wood is about

3,8 kWh. 1 kg of completely dry wood (0% moisture) produces

approximately 5 kWh, while wood with a moisture level of 60%

produces only around 1,5 kWh/kg.

Consequences of using damp wood may include:

•  Appearance of soot/tar on the glass, in the fireplace and in

the chimney.

•  Fireplace will give less heat.

•

Risk of chimney fire as a consequence of accumulation of soot

in the fireplace, flue pipe and chimney.

•  The wood is difficult to light and the fire can die.

Be especially careful never to lay a fire using any of the following

materials:

•  Household waste, plastic bags, etc.

•  Painted or impregnated wood (highly toxic).

•  Chipboard or laminated boards.

• Driftwood

(seawater).

This may harm the product and pollute the atmosphere.

N.B. Never use combustible liquids such as petrol, kerosene,

alcohol or similar to start the fire. This may cause harm to both

yourself and the product.

7.2 Jøtul’s definition of quality coal

By good quality coal we mean mineral coal according to

the specifications in EN 13240, table B.2. (Briquetted fuel

for closed appliances.)

For example use: Phurnacite.

7.3 Fuel size and amount

Jøtul’s products are developed to have excellent combustion.

An important factor for good combustion is that the fuel is the

correct size.  The size and amount of fuel should be as described in

«2.0 Technical data» in the installation manual for each product.

7.4 Intermittent/continuous

c

ombustion

Intermittent combustion

Most of Jøtul’s products are designed for intermittent

combustion. (See installation manual

«2.0 Technical data«

for each product).

Intermittent combustion in this context means normal use

of the fireplace, i.e. fuel is added as soon as the fuel has

burnt down to a suitable amount of embers.

Continuous combustion

Some products are suitable for continuous combustion. (See

installation manual

«2.0 Technical data«

 for each product).

Continuous combustion in this context means that a

fireplace can burn overnight without having to relight

the fire.
