Device Registration
To use the functions provided by iRAS, you must rst
register a device and add the device to a device group.
1
Select System > iRAS Setup > Device in the menu at
the top of the screen.
2
On the Site panel, click on All Devices, then click on
the
E
6
Click Device Group on the Sites panel and click
button at the bottom of the Site List panel on
the right. A Device Scan window will appear on the
screen.
3
After selecting a scan mode, click on Start Scan button
and the scan results will be displayed on the list.
4
Click Add Devices at the bottom of the Device Scan
window.
5
When user authentication window appears, enter the
User ID and Password set up on each device, and then
select OK for remote access.
E
at
the bottom. Add Device Group window will appear.
● Name: Enter a name for the device group.
● Location: Select a location for the subject device
group.
When you select a device from the device List on the
left, it will be added to the Selected Device List on
the right. Click OK to register the device group.
7
Make sure that the device has been added to the
device group correctly. Click Device Group on the
Sites panel and click on next to Device Group. When
you click on a registered device group, a list of devices
added the selected device group will be displayed on
the right.
To modify a device group that has been registered,
select a device group and click
E
DE
EN
FR
PL
RU
on the bottom of
the Sites panel. Modify Device Group window will
appear. You can modify the selected device group
from this window.
Live Video Mode
1
In the Site List, make sure that the device has been
added to the device group.
2
In the panel tabs, click the Live tab. In the Site list,
select a zone you wish to connect to. Then, drag &
drop the selected site on the Live screen using your
mouse. The live video of the selected site will be
displayed on the screen.
25
Recorded Video Playback
2
In the panel tabs, click on the Play tab. In the Site list,
select a site you wish to connect to. Then, drag & drop
the selected site on the playback screen using your
1
In the Site List, make sure that the device has been
mouse.
The recorded video of the selected site will be
added to the device group.
displayed on the screen.
RAS Mobile
This service requires heavy data trac, and using a Wi-Fi connection is recommended. Using wireless internet (3G, LTE)
may result in excessive data charges.
● Accounts: Enter the User ID and Password used to
Android OS device
login to the device. (Default value of User ID: admin,
1
Open the Play Store(Google Play) on your Android
No default value of password)
device.
2
In Play Store (Google Play), enter RAS Mobile in the
iOS device
search eld.
3
Install RAS Mobile program and open it.
1
Open the App Store on your device.
4
The start-up menu appears when pressing the Menu
2
Enter RAS Mobile in the search led of the App Store.
button on your mobile device.
3
Install RAS Mobile program and open it.
5
Register the device by pressing Add Remote Host and
4
Register the device by pressing + button and entering
entering the device (network camera) information.
the device (NVR) information.
● General: Enter a name of the device to be used in
RAS Mobile app.
● General: Enter a name of the device to be used in
RAS Mobile.
● Connection Info: Turn Use FEN ON and enter the
device name used to register the device to the FEN.
● Connection Info
– Use FEN: Select the check box. Deselect the
If FEN feature is not enabled on the device, turn Use
checkbox if FEN is not enabled on the device. If
FEN OFF and enter the device's IP address. For port
the device is using an additional FEN server, press
number, using the default value is recommended.
Settings in the start-up menu and enter the FEN
● Accounts: Enter the User ID and Password used to
server information. (Default site: dvrnames.net,
login to the device. (Default value of User ID: admin,
Default port number: 10088). For more details,
contact your FEN server administrator.
No default value of password).
– Address, Watch: Enter the device name used to
register the device to FEN. If FEN feature is not
enabled on the device, deselect FEN checkbox
and enter the device's IP address. For port number,
using the default value is recommended.
26
Further information
The User‘s Guide, and other software tools are
Information on compatible video management
available on the eneo website at www.eneo-security.
software solutions can be found at www.eneo-
com or on the included CD.
security.com.
