7 Troubleshooting

Your printer is extremely reliable, but occasionally problems may occur. This chapter provides information on

some of the common problems you may encounter and how you may solve them. If you encounter problems

that you cannot resolve, contact your dealer or service partner for assistance.

Print Quality Problems and Solutions

Problem

Solution

Printing is too light or too dark.

• Make sure that the ribbon cartridge is properly installed and that

the ribbon feeds smoothly.

• Replace the ribbon if necessary.

• Make sure that the print gap lever is set for the thickness of your

paper.

Smears and stains appear on the

page.

• Make sure that the print gap lever is set for the thickness of your

paper.

• Check for ribbon wear. Replace the ribbon if necessary.

• Check whether the tip of the print head is dirty. Clean the head

with a soft cloth if necessary.

• The print head may need to be replaced.

Printing is erratic or the wrong

characters are printed. Many “?” or

unexpected characters are printed.

• Make sure that the interface cable is securely connected to both

the printer and computer.

• Make sure that the printer driver selected in your software is the

same as the emulation selected on the printer.

• Check the length of the interface cable. (Maximum Parallel &

USB: 2 metres)

• Try another interface cable.

The page is blank.

• Make sure that the ribbon cartridge is properly installed.

• Make sure the gap lever is set correctly.

Printing is vertically misaligned

(jagged).

Use the printer's vertical alignment function to check the vertical

print alignment. If necessary, adjust the print alignment.

The top margin is wrong.

• Check the application top margin setting.

• Adjust the Top Margin setting in Page Setup menu if necessary.

Lines are double spaced instead of

single spaced.

Change the Auto LF setting in the System Setup menu to No.

The printer overprints on the same

line.

Change the Auto CR setting in the System Setup menu to No.

The next print line starts where the

previous line ended instead of at

the left margin.

Change the Auto CR setting in the System Setup menu to Yes.

Tally Dascom 1325

39

Paper Handling Problems and Solutions

Problem

Solution

Paper cannot be loaded or fed.

• Make sure that the paper select lever located on the top right of

the printer is set correctly. Move the lever to the front for single

sheets or to the rear for continuous forms.

• Make sure that the paper covers the paper-out sensor.

Paper jams while loading.

• Turn off the printer and remove the jammed paper. Remove any

obstructions from the paper path.

• Make sure that the Print Gap lever is set for the thickness of your

paper.

• Make sure that the paper is not folded, creased, or torn.

• Make sure that the left and right tractors are set so that the

continuous forms are stretched taut.

Paper jams while printing.

• Turn off the printer and remove the jammed paper. Remove any

obstructions from the paper path.

• Make sure that the Print Gap lever is set for the thickness of your

paper.

• For continuous forms, make sure that the incoming and outgoing

paper stacks are correctly placed. Paper should feed straight.

Paper slips off the forms tractors or

the perforated holes of the paper

tear during printing.

Make sure that the forms tractors are positioned correctly for the

width of your paper and that the perforated holes of the paper fit

directly over the tractor pins.

Operating Problems and Solutions

Problem

Solution

The power does not turn on.

• Check whether the mains voltage is correct.

• Make sure that the power cord is securely connected to both the

printer and the mains power outlet.

• Make sure that the power outlet is functional. If not so, use other

outlet.

• Turn the power off. Wait a minute and then turn the printer on

again. If the printer still has no power, contact your dealer.

The printer is on but it will not print.

• Make sure that the Online indicator is lit.

• If you use the interface cable, make sure it is securely connected

to both the printer and the computer.

• Make sure paper is loaded.

• Run the printer Status Page. If printing executes normally, the

problem is caused by: the interface, the computer, incorrect printer

settings, or incorrect software settings.

• Make sure that the printer driver selected in your software is the

same as the emulation selected on the printer.

Tally Dascom 1325

40

Paper select lever error

If paper is loaded and the paper select lever is moved to the

incorrect position, the printer turns offline, and the buzzer sounds

continuously. Switch the paper select lever back to its correct

position.

Printer Failures

A user cannot generally resolve a problem involving defective printer hardware. Power off and on again the

printer to recover any fatal error. If the problem cannot be resolved, contact your dealer or service partner.

Error Indications on LEDs

Error Description

Operation

Status

Paper

Out LED

Online

LED

Tear Off

LED

Buzzer

Sound

Paper jammed

Suspend

Flash

Off

Flash

Once

Friction feed /Tractor feed

Suspend

Flash

Flash

No change

Continuously

Print head hot

Normal

No

change

Flash No

change

--

Carriage initial position

Stop

Flash

Off

Off

Once

EEPROM Normal

Off

Flash

Flash

Once

Print head cold

Suspend

Flash

Flash

No change

--

ROM error

Stop

Flash

Flash

Flash

Once

Tally Dascom 1325

41

Diagnostic Functions

The printer diagnostic functions are Self-Test page, hex-dump mode and print alignment adjustment.



  Self-Test page: Tells you whether the printer hardware is functioning correctly. If the printer hardware

is functional, any problems you are having are probably caused by incorrect printer settings, incorrect

software settings, the interface, or the computer.



  HEX-DUMP MODE: Allows you to determine whether the computer is sending the correct commands

to the printer, and whether the printer is executing the commands correctly. This function is useful to

programmers or others who understand how to interpret hex dumps.



  PRINTING ALIGNMENT ADJUSTMENT: Allows you to check and, if necessary, correct the printer’s

vertical line print alignment in bi-directional mode.

For details on using these functions, please refer to chapters 4 and 5.

Tally Dascom 1325

42

Firmware Update

Sometimes it is necessary update the firmware to solve a problem. The latest firmware file may be obtained

from your dealer or downloaded from our website

www.dascom.com

. Before upgrading firmware, it is strongly

recommended to print the Main Menu page to keep a record of the old settings.

Note: Firmware update should only be performed by an authorized service person. We disclaim any

responsibility for any damage caused if it is performed by any other person.

To load new firmware, proceed as follows:

1.  Switch off the printer. Connect your PC to the

parallel port

 on the printer.

2.  Press and hold down 4 keys (S1, S2, S3, S4) while powering on the printer.

3.  Alternate flashing of L1 and L4 LEDs indicates printer is ready for firmware update.

4.  Go to the DOS prompt window. Copy the firmware file (with extension .MOT) to your printer as follows:

COPY /B <filename>.mot PRN

5.  When new firmware is being received, L1 and L4 will flash together, followed by L1 and L3 flashing

together.

Note: Do not interrupt the downloading process to prevent possible flash memory corruption.

6.  When downloading is completed, the carriage returns to home position. Printer initializes normally.
