5. Printer Setting Changes
In order to meet individual print requirements, the printer configurations may be changed as follows: Hold
down the Tear Off key while powering on the printer, release the Tear Off key when the print head starts to
move. The printer will enter Main Menu setup state. Follow the instructions printed on how to make setting
changes. When a new setting is saved, it is retained after the printer has been powered off.
The Main Menu is grouped into 5 sub-menus: System Setup, Page Setup, Print Setup, Interface Setup and
Advanced Setup. A detailed description of the sub-menus is given below. The settings in bold and italic refer to
the default settings.
System Setup
System
Setup
Valid Settings
Function
Emulation
ESC/P2,
IBM 2390
Plus
Selects the printer emulation. This should be the same as the host
printer driver.
Auto CR
(IBM)
Yes,
No
Yes: LF = LF+CR; No: LF = LF
(Applies to IBM emulation only)
Auto LF
Yes,
No
Yes: CR = CR+LF; No: CR = CR
Print Dir
Bi-Dir,
Uni-Dir,
Auto
Auto: Text & graphics in bi-direction; double height in uni-direction.
Uni-Dir: Prints everything in uni-direction. Bi-dir: Prints everything in
bi-direction. Note: Top position print direction may be affected by Top
Print Dir setting.
Top Print
Dir
Bi-Dir,
Uni-Dir
Bi-dir: Prints top position according to Print Dir setting. Uni-dir: Prints
top position in uni-direction regardless of Print Dir setting.
Impact
Normal,
Heavy
Heavy: Higher impact force for multipart printing
IBM AGM
Yes,
No
Selects the IBM graphic mode. Applies to IBM emulation only
Print Setup
Print Setup
Valid Settings
Function
Font
Draft, Roman, Sans Serif, Courier, Prestige, Script,
OCR-B, OCR-A, ORATOR, GOTHIC, SOUVENIR
Pitch
10cpi,
12cpi, 15cpi, 17cpi, 20cpi, PS
Controls the characters per
inch setting.
Zero
0
,Ø
Selects slashed or no-slash
zero.
HS-Draft
On
, Off
On: Prints High Speed Draft
when Draft font is selected.
Tally Dascom 1325
21
Graphic
Speed
Normal,
Fast, Ultra
When printing 180x180 DPI
graphics: Normal – prints in
180x180 DPI, Fast – prints in
90x180 DPI, Ultra – prints in
60x180 DPI.
IBM Set 1/2
Set 1,
Set 2
Selects the IBM character
set. 1: Normal; 2: Extended
Int'l Char Set
USA,
France, Germany, UK, Denmark, Sweden, Italy,
Spain, Japan, Norway, Denmark II, Spain II, Latin AM,
Korea, Legal
14+1 international character
set selections
Code Page
1. CP
437
2. CP
737
3. CP
850
4. CP
851
5. CP
852
6. CP
857
7. CP
858
8. CP
860
9. CP
861
10. CP 863
11. CP 864
12. CP 864 Extended
13. CP 865
14. CP 866 Cyrillic
15. CP 866 Bulgaria
16. CP 1250
17. CP 1251
18. CP 1252
19. CP 1253
20. CP 1254
21. 8859-1
22. 8859-1 (SAP)
23. 8859-2
24. 8859-5
25. 8859-7
26. 8859-9
27. 8859-15
28. BRASCII
29. Abicomp
30. Roman8
31. Coax/Twinax
32. New-437
National code page
selections
Tally Dascom 1325
22
33. New-Dig 850
34. Old-Code 860
35. Flarro 863
36. 865 Hebrew
37. CP 1257
38. 866 Ukraine
39. 866 Kazakhstan
40. Kamenicky
41. Mazovia
42. CP 775
43. CRO-ASCII
44. Arabic Farsi
45. Arabic Urdo
46. Greek DEC
47. Greek ELOT 928
Character
Table
Graphic Table,
Italic Table
Character table type
selection
Page Setup
Page Setup
Valid Settings
Function
Line Per Inch
1, 2, 3, 4, 5,
6
, 7, 8
Sets the line spacing
Fanfold Form Length
3",3.5",11/3", 4", 5", 5.5"
6",7",8", 8.5",
11"
, 70/6", 12",
14", 17"
Sets the page length for tractor mode
Fanfold Top Margin
0/60" …
10/60"
…99/60"
Sets the top margin for tractor mode. Due to
mechanical tolerance, 0/60” is not guaranteed.
Fanfold Bottom
Margin
0/60"…
10/60"
...30/60"
Sets the bottom margin for tractor mode. Due to
mechanical tolerance, 0/60” is not guaranteed.
Single Form Length
3", 3.5", 11/3", 4", 5", 5.5", 6",
7", 8", 8.5",
11"
, 70/6", 12", 14",
17"
Sets the page length for friction mode
Single Top Margin
0/60" …
10/60"
…99/60"
Sets the top margin for friction mode. Due to
mechanical tolerance, 0/60” is not guaranteed.
Single Bottom Margin 0/60"…
10/60"
...30/60"
Sets the bottom margin for friction mode. Due to
mechanical tolerance, 0/60” is not guaranteed.
Perforation Skip
Yes,
No
Skips printing on perforation area
Auto Tear
Manual,
0.5s, 1s, 2s, 3s, 4s, 5s
Specifies the waiting time before feeding the
page to tear-off position automatically. Manual:
Auto tear mode is off. (Applies to tractor mode
only)
Exit Direction
Front,
Rear
Selects eject direction for friction loaded papers.
Slip
Off,
On
Selects the Slip profile mode.
Tally Dascom 1325
23
Interface Setup
Interface
Setup
Valid Settings
Function
Interface
Auto,
Parallel, USB
For multi-host connection. Auto: First come first served;
Parallel/USB: Serves the designated host only.
I-PRIME
Yes,
No
Yes: Host I-Prime signal resets the printer.
Auto IF
Delay
10s,
30s
Determines the waiting time before receiving data from another
interface.
RAM Usage
User Font,
Buffer
User Font: Part of RAM is used for user download characters;
Buffer: Disables user character download function; uses RAM for
expanded buffer size up to 92KB.
Advanced Setup
Advanced Setup
Valid Settings
Function
Auto Load
Manual,
0.5s,
1s, 1.5s, 2s
Specifies the waiting time before loading a cut
sheet automatically. Manual: Auto load mode is
off. (Applies to friction mode only)
Paper Jam
Prevention
Yes,
No
Flattens paper edges by carriage movement
before printing starts.
Paper End Detect
Yes,
No
Yes: Detects paper out and halts printing;
otherwise, ignores paper out and continues
printing.
Form Length Ctrl
Software,
Ignore
Ignore: Ignores form length commands.
Pitch Ctrl
Software,
Ignore
Ignore: Ignores CPI commands.
Font Ctrl
Software,
Ignore
Ignore: Ignores font select commands.
Quality Ctrl
Software,
Ignore
Ignore: Ignores print quality commands.
Buzzer
Yes,
No
Yes: Sounds buzzer on all hardware errors.
Tally Dascom 1325
24
German (Deutsch)
System Setup
Valid Settings
Emulation
ESC/P2
, IBM 2390 Plus
Auto CR (IBM)
Ja,
Nein
Auto LF
Ja,
Nein
Druck Dir
Bi-Dir
, Uni-Dir, Auto
Top Druck Dir
Bi-Dir
, Uni-Dir
Anschlag
Normal
, Stark
IBM AGM
Ja,
Nein
Druck Setup
Valid Settings
Font (Andere)
OCR-B,OCR-A,ORATOR,GOTHIC,
SOUVENIR
Zeichenteilung
10cpi
, 12cpi, 15cpi, 17cpi, 20cpi, PS
Null
0
,Ø
HS-Draft
An
, Aus
Graphikgeschw.
Normal
, Schnell, Ultra
IBM Set ½
Set 1
,
Set 2
Land
USA
, France, Germany, UK, Denmark, Sweden, Italy, Spain,
Japan, Norway, Denmark II, Spain II, Latin AM, Korea, Legal
Zeichensatz
CP 437
, CP 857…
Zeichentabelle
Graphik
, Italic
Seiten Setup
Valid Settings
Zeilen Pro Zoll
1, 2, 3, 4, 5,
6
, 7, 8
Endlos Formularlänge
3",3.5",11/3", 4", 5", 5.5" 6",7",8", 8.5",
11"
, 70/6", 12", 14", 17"
Endlos Oberer Rand
0/60" …
10/60"
…99/60"
Endlos Unterer Rand
0/60"…
10/60"
...30/60"
Einzel Formularlänge
3", 3.5", 11/3", 4", 5", 5.5", 6", 7", 8", 8.5",
11"
, 70/6", 12", 14",
17"
Einzel Oberer Rand
0/60" …
10/60"
…99/60"
Einzel Unterer Rand
0/60"…
10/60"
...30/60"
Rollenpapier
Ja,
Nein
Perforationssprung
Ja,
Nein
Abreissen
Manuell
, 0.5s, 1s, 2s, 3s, 4s, 5s
Auswurfrichtung
Vorne
, Hinten
Beleg
Aus
, An
Schnittstellen Setup
Valid Settings
Schnittstelle
Auto
, Parallel, USB
I-PRIME
Ja
, Nein
Tally Dascom 1325
25
Auto IF Delay
10s
, 30s
RAM Nutzung
Ladbarer Font
, Puffer
Erweitertes Setup
Valid Settings
Auto Laden
Manuell,
0.5s
, 1s, 1.5s, 2s
Papierstau Vorbeugung
Ja
, Nein
Papierende Detekt
Ja
, Nein
Formularlänge Strg
Software
, Ignoriere
Zeichenteilung Strg
Software
, Ignoriere
Font Strg
Software
, Ignoriere
Qualität Strg
Software
, Ignoriere
Summer
Ja
, Nein
Russian (
Россия
)
Системные
установки
Valid Settings
Эмуляция
ESC/P2
, IBM 2390 Plus
Авто
CR (IBM)
Да
,
Нет
Авто
LF
Да
,
Нет
Направление
печати
Двунаправленная
,
Однонаправленная
,
Авто
Направление
печати
загл
.
букв
Двунаправленная
,
Однонаправленная
Удар
Нормальный
,
Сильный
IBM AGM
Да
,
Нет
Настройка
печати
Valid Settings
Дополнительный
шрифт
OCR-B,OCR-A,ORATOR,GOTHIC,
SOUVENIR
знаков
/
дюйм
10cpi
, 12cpi, 15cpi, 17cpi, 20cpi, PS
Перечеркнутый
ноль
0
,Ø
Высокая
скорость
Вкл
,
Выкл
Скорость
графики
Нормальная
,
Быстрая
,
Очень
быстрая
Символы
IBM 1/2
Уст
. 1,
Уст
. 2
Набор
знаков
USA
, France, Germany, UK, Denmark, Sweden, Italy, Spain,
Japan, Norway, Denmark II, Spain II, Latin AM, Korea, Legal
Кодовая
таблица
CP 437
, CP 857…
Таблица
знаков
Графика
,
Курсив
Параметры
страницы
Valid Settings
Строк
на
дюйм
1, 2, 3, 4, 5,
6
, 7, 8
Длина
формы
для
непрерывной
бумаги
3",3.5",11/3", 4", 5", 5.5" 6",7",8", 8.5",
11"
, 70/6", 12", 14", 17"
Отступ
сверху
для
непрерывной
0/60" …
10/60"
…99/60"
Tally Dascom 1325
26
бумаги
Отступ
снизу
для
непрерывной
бумаги
0/60"…
10/60"
...30/60"
Длина
формы
для
отдельных
листов
3", 3.5", 11/3", 4", 5", 5.5", 6", 7", 8", 8.5",
11"
, 70/6", 12", 14",
17"
Отступ
сверху
для
отдельных
листов
0/60" …
10/60"
…99/60"
Отступ
снизу
для
отдельных
листов
0/60"…
10/60"
...30/60"
Рулонная
бумага
Да
,
Нет
Пропуск
перфорации
Да
,
Нет
Авто
прогон
Ручной
, 0.5s, 1s, 2s, 3s, 4s, 5s
Выход
бумаги
Перед
,
Зад
Спящий
режим
Выкл
,
Вкл
Установки
интерфейса
Valid Settings
Интерфейс
Авто
,
Паралел
, USB
Паралел
.
порт
Да
,
Нет
Время
ожидания
10s
, 30s
Назначение
RAM
Пользов
.
шрифт
,
Буфер
Дополнительные
установки
Valid Settings
Автозагрузка
Ручная
,
0.5s
, 1s, 1.5s, 2s
Датчик
движ
.
бумаги
Да
,
Нет
Датчик
конца
бумаги
Да
,
Нет
Контоль
длины
формы
Програмный
,
Игнор
.
Контроль
знаков
/
дюйм
Програмный
,
Игнор
.
Контроль
шрифта
Програмный
,
Игнор
.
Контроль
качества
Програмный
,
Игнор
.
Звук
Да
,
Нет
Italian (Italiano)
Menu Sistema
Valid Settings
Emulazione
ESC/P2
, IBM 2390 Plus
Auto CR (IBM)
Si,
No
Auto LF
Si,
No
Direz. Stampa
Bi-Dir
, Uni-Dir, Auto
Top Print Dir
Bi-Dir
, Uni-Dir
Impatto
Normale
, Pesante
IBM AGM
Si,
No
Tally Dascom 1325
27
Menù Stampa
Valid Settings
Fonte (Altre)
OCR-B,OCR-A,ORATOR,GOTHIC,
SOUVENIR
Spaziatura
10cpi
, 12cpi, 15cpi, 17cpi, 20cpi, PS
Zero
0
,Ø
HS-Bozza
Si
, No
Veloc. Grafica
Normale
, Veloce, Ultra
IBM Set 1/2
Set 1,
Set 2
Set Carat. Int.
USA
, France, Germany, UK, Denmark, Sweden, Italy, Spain,
Japan, Norway, Denmark II, Spain II, Latin AM, Korea, Legal
Code Page
CP 437
, CP 857…
Tab.Carattere
Tab. Grafica
, Italico
Menù Pagina
Valid Settings
Interlinea
1, 2, 3, 4, 5,
6
, 7, 8
Lungh. Mod. Continuo
3",3.5",11/3", 4", 5", 5.5" 6",7",8", 8.5",
11"
, 70/6", 12", 14", 17"
Margine Sup. Continuo
0/60" …
10/60"
…99/60"
Margine Inf. Continuo
0/60"…
10/60"
...30/60"
Lunghezza Foglio
3", 3.5", 11/3", 4", 5", 5.5", 6", 7", 8", 8.5",
11"
, 70/6", 12", 14",
17"
Margine Sup. Foglio
0/60" …
10/60"
…99/60"
Margine Infer. Foglio
0/60"…
10/60"
...30/60"
Rullo Carta
Si,
No
Salto Perforazione
Si,
No
Autostrappo
Manuale
, 0.5s, 1s, 2s, 3s, 4s, 5s
Uscita Carta
Frontale
, Posteriore
Scontrino
Si
, No
Menù Interfacc.
Valid Settings
Interfaccia
Auto
, Parallela, USB
I-PRIME
Si
, No
Ritardo Auto IF
10s
, 30s
Uso RAM
Fonti utente
, Memoria
Menù Avanzato
Valid Settings
Autocaricamento
Manuale,
0.5s
, 1s, 1.5s, 2s
Previene Inceppamento
Si
, No
Rileva Fine Carta
Si
, No
Control. Lungh. Carta
Software
, Ignora
Control. Spaziatura
Software
, Ignora
Controllo Fonti
Software
, Ignora
Controllo Qualità
Software
, Ignora
Tally Dascom 1325
28
Cicalino
Si
, No
French (Français)
Setup système
Valid Settings
Emulation
ESC/P2
, IBM 2390 Plus
RC-Auto (IBM)
Oui,
Non
SL-Auto
Oui,
Non
Dir Impr.
Bidir
, Unidir, Auto
Sup. Dir Impr.
Bidir
, Unidir
Frappe
Normal
, Forte
IBM AGM
Oui,
Non
Setup impression
Valid Settings
Polices (Autres)
OCR-B,OCR-A,ORATOR,GOTHIC,
SOUVENIR
Densités caract.
10cpi
, 12cpi, 15cpi, 17cpi, 20cpi, PS
Zéro
0
,Ø
HS-Draft
Oui
, Non
Vitesse graphiq.
Normal
, Rapide, Ultra
IBM Set 1/2
Set 1,
Set 2
Pays
USA
, France, Germany, UK, Denmark, Sweden, Italy, Spain,
Japan, Norway, Denmark II, Spain II, Latin AM, Korea, Legal
Jeu de caractèr.
CP 437
, CP 857…
Tabl.de caract.
Graphque
, Italique
Setup page
Valid Settings
Lignes par pouce
1, 2, 3, 4, 5,
6
, 7, 8
Papier continu Longueur formulaire
3",3.5",11/3", 4", 5", 5.5" 6",7",8", 8.5",
11"
, 70/6", 12", 14", 17"
Papier continu Bord supérieure
0/60" …
10/60"
…99/60"
Papier continu Bord inférieure
0/60"…
10/60"
...30/60"
Feuille à feuille Longueur formulaire
3", 3.5", 11/3", 4", 5", 5.5", 6", 7", 8", 8.5",
11"
, 70/6", 12", 14",
17"
Feuille à feuille Bord supérieur
0/60" …
10/60"
…99/60"
Feuille à feuille Bord inférieur
0/60"…
10/60"
...30/60"
Papier du rouleau
Oui,
Non
Sauter la perforation
Oui,
Non
Coupe Auto
Manuel
, 0.5s, 1s, 2s, 3s, 4s, 5s
Direction de sortie
Avant
, Arrière
Slip
Arrêt
, Marche
Setup interface
Valid Settings
Interface
Auto
, Parallel, USB
I-PRIME
Oui
, Non
Tally Dascom 1325
29
Auto IF Delay
10s
, 30s
Utilisation RAM
User Font
, Buffer
Setup élargi
Valid Settings
Chargem. Autom.
Manuel,
0.5s
, 1s, 1.5s, 2s
Prévention bourrage
Qui
, Non
Détec.fin de pap
Qui
, Non
Long.formul.Strg
Software
, Ignorer
Densi.caract.Strg
Software
, Ignorer
Police Strg
Software
, Ignorer
Qualité Strg
Software
, Ignorer
Vibrateur
Qui
, Non
Spanish (Español)
System Setup
Valid Settings
Emulación
ESC/P2
, IBM 2390 Plus
Auto CR(IBM)
Si,
No
Auto LF
Si,
No
ModoImpresión
Bi-Dir
, Uni-Dir, Auto
ModoImp.Borde
Bi-Dir
, Uni-Dir
Impacto
Normal
, Fuerte
IBM AGM
Si,
No
Print Setup
Valid Settings
Fuente (Otros)
OCR-B,OCR-A,ORATOR,GOTHIC,
SOUVENIR
Tamaño Letra
10cpp
, 12cpp, 15cpp, 17cpp, 20cpp, PS
Cero
0
,Ø
Alta Velocidad
Activado
, Desactivado
Imp. Grafica
Normal
, Rápido, Ultra
IBM Juego 1/2
Juego 1,
Juego 2
Carácter Local
USA
, Francia, Alemania, UK, Dinamarca, Suecia, Italia, España,
Japón, Noruega, Dinamarca II, España II, AmericaLatina, Corea,
Legal
Tabla Carácter
CP 437
, CP 857…
Tipo Tabla
Tabla Gráfica
, Italica
Page Setup
Valid Settings
Lineas Por Pulgada
1, 2, 3, 4, 5,
6
, 7, 8
Tamaño Papel Continuo
3",3.5",11/3", 4", 5", 5.5" 6",7",8", 8.5",
11"
, 70/6", 12", 14", 17"
Margen Sup. Pap Cont.
0/60" …
10/60"
…99/60"
Tally Dascom 1325
30
Margen Inf. Pap.Cont.
0/60"…
10/60"
...30/60"
Tamaño Hojas Sueltas
3", 3.5", 11/3", 4", 5", 5.5", 6", 7", 8", 8.5",
11"
, 70/6", 12", 14",
17"
Margen Sup. Folios
0/60" …
10/60"
…99/60"
Margen Inf. Folios
0/60"…
10/60"
...30/60"
Rollo de Papel
Si,
No
Salto perforación
Si,
No
Mover a PosiciónCorte
Manual
, 0.5s, 1s, 2s, 3s, 4s, 5s
Expulsión de papel
Delante
, Atrás
Ajustes
Apagado
, Encendido
Interface Setup
Valid Settings
Interface
Auto
, Paralelo, USB
I-Prime
Si
, No
Auto retraso
10s
, 30s
Uso de RAM
Font Usuario
, Buffer
Advanced Setup
Valid Settings
Auto Carga
Manual,
0.5s
, 1s, 1.5s, 2s
Prevención Atascos
Si
, No
Detección Fin Papel
Si
, No
Control Tamaño Papel
Software
, Ignorar
Control Tamaño Letra
Software
, Ignorar
Control Fuente
Software
, Ignorar
Control Calidad
Software
, Ignorar
Alarma
Si
, No
Turkish (Türkce)
Sistem Ayar
ı
Valid
Settings
Benzetim/Emulation
ESC/P2
, IBM 2390 Plus
Otom. Sat
ı
rba
ş
ı
(IBM)
Evet,
Hay
ı
r
Otom. Sat
ı
r besleme
Evet,
Hay
ı
r
Yazd
ı
rma yönü
İ
ki-Yöne
, Tek-Yöne, Otom.
Üstte yazd
ı
rma yönü
İ
ki-Yöne
, Tek-Yöne
Vuru
ş
Normal
, Güçlü
IBM AGM
Evet,
Hay
ı
r
Yazd
ı
rma Ayarlar
ı
Valid
Settings
Yaz
ı
Tipi (Di
ğ
er)
OCR-B,OCR-A,ORATOR,GOTHIC,
SOUVENIR
Karakter S
ı
kl
ı
ğ
ı
10cpi,
12cpi, 15cpi, 17cpi, 20cpi, PS
Tally Dascom 1325
31
S
ı
f
ı
r
0
,Ø
Yük.H
ı
z-Taslak
On
, Off
Grafik H
ı
z
ı
Normal
, H
ı
zl
ı
, Ultra
IBM Karakter Seti 1/2
Set 1,
Set 2
Uluslararas
ı
Kar. Seti
USA,
France, Germany, UK, Denmark, Sweden, Italy, Spain,
Japan, Norway, Denmark II, Spain II, Latin AM, Korea, Legal
Kod Sayfas
ı
CP 437
, CP 857…
Karakter Tablosu
Grafik Tablosu
,
İ
talik
Sayfa Düzeni Ayar
ı
Valid
Settings
İ
nç ba
ş
ı
na sat
ı
r
1, 2, 3, 4, 5,
6
, 7, 8
Sürekli-ka
ğ
ı
t Form Uzunlu
ğ
u
3",3.5",11/3", 4", 5", 5.5" 6",7",8", 8.5",
11"
, 70/6", 12", 14", 17"
Sürekli-ka
ğ
ı
t Üst kenar bo
ş
lu
ğ
u
0/60" …
10/60"
…99/60"
Sürekli-ka
ğ
ı
t Alt kenar bo
ş
lu
ğ
u
0/60"…
10/60"
...30/60"
Tek-ka
ğ
ı
t Form uzunlu
ğ
u
3", 3.5", 11/3", 4", 5", 5.5", 6", 7", 8", 8.5",
11"
, 70/6", 12", 14",
17"
Tek-ka
ğ
ı
t Üst kenar bo
ş
lu
ğ
u
0/60" …
10/60"
…99/60"
Tek-ka
ğ
ı
t Alt kenar bo
ş
lu
ğ
u
0/60"…
10/60"
...30/60"
Rulo ka
ğ
ı
t
Evet,
Hay
ı
r
Delik atlama
Evet,
Hay
ı
r
Otom. Koparma
Elle/Manuel
, 0.5s, 1s, 2s, 3s, 4s, 5s
Ç
ı
kartma Yönü
Önden
, Arkadan
Makbuz/Fi
ş
Kapal
ı
, Aç
ı
k
Arabirim Ayarlar
ı
Valid
Settings
Arabirim
Otom.
, Paralel, USB
I-Prime
Evet
, Hay
ı
r
Otom. Arabirim gecikmesi
10s
, 30s
RAM Kullan
ı
m
ı
Kullan
ı
c
ı
Yaz
ı
Tipi
, Arabellek
Geli
ş
tirilmi
ş
Ayarlar
Valid Settings
Otom. Yükleme
Elle/Manuel
,
0.5s
, 1s, 1.5s, 2s
Ka
ğ
ı
t S
ı
k
ı
ş
mas
ı
n
ı
Önleme
Evet
, Hay
ı
r
Ka
ğ
ı
t Sonunu Alg
ı
lama
Evet
, Hay
ı
r
Form Uzunl. Kont.
Yaz
ı
l
ı
m
, Yoksay
Karak.S
ı
kl. Kont.
Yaz
ı
l
ı
m
, Yoksay
Yaz
ı
Tipi Kont.
Yaz
ı
l
ı
m
, Yoksay
Kalite Kont.
Yaz
ı
l
ı
m
, Yoksay
Alarm Zili
Evet
, Hay
ı
r
Tally Dascom 1325
32
Vertical Alignment
The vertical alignment function is used to resolve any vertical line misalignments in bi-directional printing.
Adjust Vertical Alignment Procedure:
1. Enter the Service Menu by holding down the
【
Tear/Off
】
and
【
LF/FF
】
keys while powering up.
2. Load
paper.
3. The printer will print as follows:
Service Menu
【
LF/FF
】
= OK
【
Tear/Off
】
= Back
【
Load/Eject
】
= Next
【
Online
】
= Exit
Current Setting
：
Vertical Alignment
4. Press
【
LF/FF
】
key to select the current setting. The printer will print as follows:
Vertical Alignment
【
LF/FF
】
= OK
【
Tear/Off
】
= Back
【
Load/Eject
】
= Next
【
Online
】
= Exit
Please select Paper Type
：
Single Ply
For single ply paper, press
【
LF/FF
】
key
to select. For multipart paper, press
【
Load/Eject
】
key to go
to
“Multipart”
，
then press
【
LF/FF
】
key
to select.
5. If single ply is selected for paper type, the following will print:
Single Ply
Current Print Mode: LQ
Press
【
Load/Eject
】
key to scroll to other print modes if required.
6. If LQ is selected, the following will print:
LQ
【
LF/FF
】
= lower ½ to left
【
Load/Eject
】
= lower ½ to right
【
Online
】
= Exit
LQ -2:
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pressing
【
LF/FF
】
or
【
Load/Eject
】
key will allow you to adjust the alignment of the vertical lines
Tally Dascom 1325
33
printed above.
7. Once the setting which gives the best alignment is found, press
【
Online
】
key to exit current level.
Printer will print “Save settings? Yes”. Press
【
LF/FF
】
key to save setting. Press
【
Online
】
key a
few times until the printer exits the Service Menu.
Change Pin Function
When printer has been used for a long time or the print volume is high, the frequently used print head pins may
fail. The Change Pin function enables the user to continue using the printer for a while without compromise in
print quality until a suitable print head replacement is available. This function will reduce the print speed if
activated.
Change Pin Procedure:
1. Enter the Service Menu by holding down the
【
Tear/Off
】
and
【
LF/FF
】
keys while powering up.
2. Load
paper.
3. The printer will print as below:
Service Menu
【
LF/FF
】
=OK
【
Tear/Off
】
= Back
【
Load/Eject
】
= Next
【
Online
】
= Exit
Current Menu
：
Vertical Alignment
Press
【
Load/Eject
】
key to scroll to
“Change Pin”
，
then press
【
LF/FF
】
key to select. The status
of each pin will be printed as follows:
Change Pin
1 ---------- Is this pin OK? Yes / No
2 ---------- Is this pin OK? Yes / No
3 ---------- Is this pin OK? Yes / No
:
24 ---------- Is this pin OK? Yes / No
Press
【
Load/Eject
】
key to choose whether the pin is
Yes
or
No
，
then press
【
LF/FF
】
key to confirm
selection.
4. When all the 24 pins are evaluated, press
【
Online
】
.
The printer will print
“Save settings? Yes”
.
Press
【
LF/FF
】
key to confirm selection. Press
【
Online
】
key a few times until the printer exits the
Service Menu.
Tally Dascom 1325
34
Adjust Physical Margins
Adjust Page Margins allows for adjustments of physical left, top margins and tear-off position. Warning: Once
these settings are changed, resetting the printer to factory defaults will not initialize these settings back to the
original settings; so it is not advisable to perform this adjustment unless it is absolutely necessary.
Adjust Top Margin Procedure:
1. Enter the Adjust Page Margins function by holding down the
【
Load/Eject
】
and
【
Online
】
keys while
powering up until the printer beeps twice.
2. Load
paper.
3. The printer will print as below:
Adjust Page Margins:
【
LF/FF
】
=OK
【
Tear/Off
】
= Back
【
Load/Eject
】
= Next
【
Online
】
= Exit
Current Setting: Adjust Fanfold Top Margin
Press
【
LF/FF
】
key to confirm selection if the paper used is fanfold type. The printer will print as follows:
Procedure
：
Install fanfold paper to tractors
【
LF/FF
】
= Add
【
Load/Eject
】
= Reduce
【
Online
】
= Exit
Each step is 0.5 mm
Function of keys:
【
Tear Off
】
key: Decrease 0.5mm
【
Load/Eject
】
key: Increase 0.5mm
4. Press
【
LF/FF
】
key, printer will print
“Save settings
？
Yes”.
Press
【
Load/Eject
】
key to choose
Yes or No
，
then press
【
LF/FF
】
key to confirm selection and exit “Adjust Page Margins” mode by
pressing
【
Online
】
. The print head moves to the left side and the printer beeps twice, then the print
head moves to the middle position.
Adjust Left Margin Procedure:
1. Enter the Adjust Page Margins function by holding down the
【
Load/Eject
】
and
【
Online
】
keys while
powering up until the printer beeps twice.
2. Load
paper.
3. The printer will print as below:
Adjust Page Margins:
【
LF/FF
】
=OK
【
Tear/Off
】
= Back
【
Load/Eject
】
= Next
【
Online
】
= Exit
Current Setting: Adjust Fanfold Top Margin
4. Press
【
Load/Eject
】
key until the current setting is “Adjust Fanfold Left Margin”. Press
【
LF/FF
】
key to
confirm selection if the paper used is fanfold type. The printer will print as follows:
Adjust Fanfold Left Margin 0
Function of keys:
【
Tear Off
】
key: Decrease 0.5mm
Tally Dascom 1325
35
【
Load/Eject
】
key: Increase 0.5mm
5. Press
【
LF/FF
】
key, printer will print
“Save settings
？
Yes”.
Press
【
Load/Eject
】
key to choose
Yes or No
，
then press
【
LF/FF
】
key to confirm selection and exit “Adjust Page Margins” mode by
pressing
【
Online
】
. The print head moves to the left side and the printer beeps twice, then the print
head moves to the middle position.
Adjust Tear-Off Position Procedure:
1. Enter the Adjust Page Margins function by holding down the
【
Load/Eject
】
and
【
Online
】
keys while
powering up until the printer beeps twice.
2. Load fanfold paper
3. The printer will print as below:
Adjust Page Margins:
【
LF/FF
】
=OK
【
Tear/Off
】
= Back
【
Load/Eject
】
= Next
【
Online
】
= Exit
Current Setting: Adjust Fanfold Top Margin
4. Press
【
Load/Eject
】
key until the current setting is “Adjust Tear-Off Position”. Press
【
LF/FF
】
key to
confirm selection. The printer will print as follows:
Procedure
：
Install fanfold paper to tractors
【
LF/FF
】
= Add
【
Load/Eject
】
= Reduce
【
Online
】
= Exit
Each step is 0.5 mm
Function of keys:
【
Tear Off
】
key: Decrease 0.5mm
【
Load/Eject
】
key: Increase 0.5mm
5. Press
【
LF/FF
】
key, printer will print
“Save settings
？
Yes”.
Press
【
Load/Eject
】
key to choose
Yes or No
，
then press
【
LF/FF
】
key to confirm selection and exit “Adjust Page Margins” mode by
pressing
【
Online
】
. The print head moves to the left side and the printer beeps twice, then the print
head moves to the middle position.
