Инструкция к Blomberg KNM 1551 i A+
Refrigerator
Kühlschrank
Réfrigérateur
Køleskab
Koelkast
KNM 1551 i A+
KNM 1551 iF A+
Bedienungsanleitung
Operating instructions
Jääkaappi
Kjøleskap
Kylskåp
Chladnička
KNM 1551 i A+
KNM 1551 iF A+
Bedienungsanleitung
Operating instructions
Chladnička
Холодильник
Frigorífico
Šaldytuvas
Ψυγείο
KNM 1551 i A+
KNM 1551 iF A+
Bedienungsanleitung
Operating instructions
Hladnjak
KNM 1551 i A+
KNM 1551 iF A+
Bedienungsanleitung
Operating instructions
Please read this manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and
checked under the most meticulous quality control procedures, will provide you
an effective service.
For this, we recommend you to carefully read the entire manual of your product
before using it and keep it at hand for future references.
This manual
• Will help you use your appliance in a fast and safe way.
• Read the manual before installing and operating your product.
• Follow the instructions, especially those for safety.
• Keep the manual in an easily accessible place as you may need it later.
• Besides, read also the other documents provided with your product.
Please note that this manual may be valid for other models as well.
Symbols and their descriptions
This instruction manual contains the following symbols:
C Important information or useful usage tips.
A Warning against dangerous conditions for life and property.
B Warning against electric voltage.
This product is supplied with the selective sorting symbol for waste electrical
and electronic equipment (WEEE).
This means that this product must be handled pursuant to European Directive
2002/96/EC in order to be recycled or dismantled to minimise its impact on
the environment. For further information, please contact your local or regional
authorities.
Electronic products not included in the selective sorting process are potentially
dangerous for the environment and human health due to the presence of
hazardous substances.
Recycling
CONTENTS
1 Your refrigerator 3
4 Preparation 13
2 Important Safety Warnings 4
5 Using your refrigerator 14
Intended use .....................................4
Thermostat setting button................14
For products with a water dispenser; .6
Defrost ............................................14
Child safety ........................................6
Zero temperature compartment .......15
HCA Warning ....................................6
Things to be done for energy saving ..7
6 Maintenance and
cleaning 16
Protection of plastic surfaces ..........16
3 Installation 8
Points to be considered when re-
7 Recommended solutions
transporting your refrigerator .............8
for the problems 17
Before operating your refrigerator ......8
Electric connection ............................8
Disposing of the packaging ...............9
Disposing of your old refrigerator .......9
Placing and Installation ......................9
Replacing the interior light bulb .......10
Reversing the doors ........................11
Reversing the doors ........................12
2
EN
3
EN
1
1 Your refrigerator
10
1
2
11
3
12
13
3
12
16
14
3
15
5
4
12
6
7
8
17
8
8
9
1. Interior light
9. Air grille
2. Temperature setting knob
10. Dairy compartment
3. Adjustable shelves
11. Egg tray
4. Defrost water collection
12. Adjustable door shelves
channel - Drain tube
13. Bottle shelf
5. Crisper cover
14. Bottle holder
6. 0 °C Compartment
15. Bottle shelter wire
7. Ice bank
16. Fridge compartment
8. Freezer compartment
17. Freezer compartment
Figures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.
2 Important Safety Warnings
Please review the following
• For products with a freezer
information. Failure to observe this
compartment; Do not put bottled and
information may cause injuries or
canned liquid beverages in the freezer
material damage. Otherwise, all
compartment. Otherwise, these may
warranty and reliability commitments
burst.
will become invalid.
• Do not touch frozen food by hand;
The usage life of the unit you
they may stick to your hand.
purchased is 10 years. This is the
• Unplug your refrigerator before
period for keeping the spare parts
cleaning or defrosting.
required for the unit to operate as
• Vapor and vaporized cleaning
described.
materials should never be used in
cleaning and defrosting processes of
your refrigerator. In such cases, the
Intended use
vapor may get in contact with the
This product is intended to be used
electrical parts and cause short circuit
– indoors and in closed areas such as
or electric shock.
homes;
• Never use the parts on your
– in closed working environments such
refrigerator such as the door as a
as stores and offices;
means of support or step.
– in closed accommodation areas such
• Do not use electrical devices inside
as farm houses, hotels, pensions.
the refrigerator.
• This product should not be used
• Do not damage the parts, where
outdoors.
the refrigerant is circulating, with
drilling or cutting tools. The refrigerant
General safety
that might blow out when the gas
• When you want to dispose/scrap
channels of the evaporator, pipe
the product, we recommend you
extensions or surface coatings are
to consult the authorized service in
punctured causes skin irritations and
order to learn the required information
eye injuries.
and authorized bodies.
• Do not cover or block the ventilation
• Consult your authorized service for
holes on your refrigerator with any
all your questions and problems
material.
related to the refrigerator. Do not
• Electrical devices must be repaired
intervene or let someone intervene to
by only authorised persons. Repairs
the refrigerator without notifying the
performed by incompetent persons
authorised services.
create a risk for the user.
• For products with a freezer
• In case of any failure or during
compartment; Do not eat cone ice
a maintenance or repair work,
cream and ice cubes immediately
disconnect your refrigerator’s mains
after you take them out of the freezer
supply by either turning off the
compartment! (This may cause
relevant fuse or unplugging your
frostbite in your mouth.)
appliance.
4
EN
• Do not pull by the cable when pulling
electricity-saving systems; they may
off the plug.
damage the refrigerator.
• Place the beverage with higher proofs
• If there is a blue light on the
tightly closed and vertically.
refrigerator, do not look at the blue
• Never store spray cans containing
light with optical tools.
flammable and explosive substances
• For manually controlled refrigerators,
in the refrigerator.
wait for at least 5 minutes to start the
• Do not use mechanical devices
refrigerator after power failure.
or other means to accelerate the
• This operation manual should be
defrosting process, other than those
handed in to the new owner of the
recommended by the manufacturer.
product when it is given to others.
• This product is not intended to be
• Avoid causing damage on power
used by persons with physical,
cable when transporting the
sensory or mental disorders or
refrigerator. Bending cable may cause
unlearned or inexperienced people
fire. Never place heavy objects on
(including children) unless they are
power cable. Do not touch the plug
attended by a person who will be
with wet hands when plugging the
responsible for their safety or who will
product.
instruct them accordingly for use of
the product
• Do not operate a damaged
refrigerator. Consult with the service
agent if you have any concerns.
• Electrical safety of your refrigerator
shall be guaranteed only if the earth
system in your house complies with
standards.
• Do not plug the refrigerator if the wall
• Exposing the product to rain, snow,
outlet is loose.
sun and wind is dangerous with
• Water should not be sprayed directly
respect to electrical safety.
on inner or outer parts of the product
• Contact authorized service when
for safety purposes.
there is a power cable damage to
• Do not spray substances containing
avoid danger.
inflammable gases such as propane
• Never plug the refrigerator into
gas near the refrigerator to avoid fire
the wall outlet during installation.
and explosion risk.
Otherwise, risk of death or serious
• Never place containers filled with
injury may arise.
water on top of the refrigerator,
• This refrigerator is intended for only
otherwise this may cause electric
storing food items. It must not be
shock or fire.
used for any other purpose.
• Do not overload your refrigerator
• Label of technical specifications is
with excessive amounts of food. If
located on the left wall inside the
overloaded, the food items may fall
refrigerator.
down and hurt you and damage
• Never connect your refrigerator to
5
EN
refrigerator when you open the door.
Never place objects on top of the
Child safety
refrigerator; otherwise, these objects
• If the door has a lock, the key should
may fall down when you open or
be kept away from reach of children.
close the refrigerator's door.
• Children must be supervised to
• As they require a precise
prevent them from tampering with the
temperature, vaccines, heat-sensitive
product.
medicine and scientific materials
and etc. should not be kept in the
HCA Warning
refrigerator.
If your product's cooling system
• If not to be used for a long time,
contains R600a:
refrigerator should be unplugged. A
This gas is flammable. Therefore, pay
possible problem in power cable may
attention to not damaging the cooling
cause fire.
system and piping during usage and
• The plug's tip should be regularly
transportation. In the event of damage,
cleaned; otherwise, it may cause fire.
keep your product away from potential
• The plug’s tip should be cleaned
fire sources that can cause the
regularly with a dry cloth; otherwise, it
product catch a fire and ventilate the
may cause fire.
room in which the unit is placed.
• Refrigerator may move if adjustable
Ignore this warning if your
legs are not properly secured on the
product's cooling system contains
floor. Properly securing adjustable
R134a.
legs on the floor can prevent the
Type of gas used in the product is
refrigerator to move.
stated in the type plate which is on the
• When carrying the refrigerator, do not
left wall inside the refrigerator.
hold it from door handle. Otherwise, it
Never throw the product in fire for
may be snapped.
disposal.
• When you have to place your product
next to another refrigerator or freezer,
the distance between devices should
be at least 8cm. Otherwise, adjacent
side walls may be humidified.
For products with a water
dispenser;
Pressure of water mains should be
minimum 1 bar. Pressure of water
mains should be maximum 8 bars.
• Use only potable water.
6
EN
Things to be done for energy
saving
• Do not leave the doors of your
refrigerator open for a long time.
• Do not put hot food or drinks in your
refrigerator.
• Do not overload your refrigerator so
that the air circulation inside of it is not
prevented.
• Do not install your refrigerator
under direct sunlight or near heat
emitting appliances such as ovens,
dishwashers or radiators.
• Pay attention to keep your food in
closed containers.
• For products with a freezer
compartment; You can store
maximum amount of food items in
the freezer when you remove the
shelf or drawer of the freezer. Energy
consumption value stated for your
refrigerator has been determined
by removing freezer shelf or drawer
and under maximum load. There
is no harm to use a shelf or drawer
according to the shapes and size of
food to be frozen.
• Thawing frozen food in fridge
compartment will both provide energy
saving and preserve the food quality.
7
EN
3 Installation
BPlease remember that the
manufacturer shall not be held liable if
3.Clean the interior of the refrigerator as
the information given in the instruction
recommended in the “Maintenance
manual is not observed.
and cleaning” section.
Points to be considered
4.Plug the refrigerator into the wall outlet.
when re-transporting your
When the fridge door is open, the
refrigerator
fridge compartment interior light will
1.Your refrigerator must be emptied and
come on.
cleaned prior to any transportation.
5.You will hear a noise as the
2.Shelves, accessories, crisper and etc.
compressor starts up. The liquid and
in your refrigerator must be fastened
gases sealed within the refrigeration
securely by adhesive tape against any
system may also give rise to noise,
jolt before repackaging.
even if the compressor is not running
3.Packaging must be tied with thick
and this is quite normal.
tapes and strong ropes and the
6.Front edges of the refrigerator may feel
rules of transportation printed on the
warm. This is normal. These areas
package must be followed.
are designed to be warm to avoid
Please do not forget…
condensation
Every recycled material is an
Electric connection
indispensable source for the nature
Connect your product to a grounded
and for our national resources.
socket which is being protected by a
If you wish to contribute to recycling
fuse with the appropriate capacity.
the packaging materials, you can
Important:
get further information from the
• The connection must be in compliance
environmental bodies or local
with national regulations.
authorities.
• The power cable plug must be easily
Before operating your
accessible after installation.
refrigerator
• The specified voltage must be equal to
Before starting to use your refrigerator
your mains voltage.
check the following:
• Extension cables and multiway plugs
1.Is the interior of the refrigerator dry and
must not be used for connection.
can the air circulate freely in the rear
BA damaged power cable must be
of it?
replaced by a qualified electrician.
2.Please install the 2 plastic wedges
BProduct must not be operated before
as illustrated in the figure. Plastic
it is repaired! There is danger of
wedges will provide the required
electric shock!
distance between your refrigerator
and the wall in order to allow the air
circulation. (The illustrated figure is
only an example and does not match
exactly with your product.)
8
EN
Disposing of the packaging
3. There must be appropriate air
The packing materials may be
ventilation around your refrigerator
dangerous for children. Keep the
in order to achieve an efficient
packing materials out of the reach
operation. If the refrigerator is to be
of children or dispose of them by
placed in a recess in the wall, there
classifying them in accordance with the
must be at least 5 cm distance with
waste instructions. Do not dispose of
the ceiling and at least 5 cm with
them along with the normal household
the wall. If the floor is covered with
waste.
a carpet, your product must be
The packing of your refrigerator is
elevated 2.5 cm from the floor.
produced from recyclable materials.
4. Place your refrigerator on an even floor
surface to prevent jolts.
Disposing of your old
5. Do not keep your refrigerator in
refrigerator
ambient temperatures under 10°C.
Dispose of your old refrigerator without
giving any harm to the environment.
•You may consult your authorised dealer
or waste collection center of your
municipality about the disposal of
your refrigerator.
Before disposing of your refrigerator, cut
out the electric plug and, if there are
any locks on the door, make them
inoperable in order to protect children
against any danger.
Placing and Installation
A If the entrance door of the room
where the refrigerator will be
installed is not wide enough for the
refrigerator to pass through, then call
the authorised service to have them
remove the doors of your refrigerator
and pass it sideways through the
door.
1. Install your refrigerator to a place that
allows ease of use.
2. Keep your refrigerator away from heat
sources, humid places and direct
sunlight.
9
EN
CThis appliance is designed to
Replacing the interior light
operate at temperatures specified
bulb
in the table below is equipped with
Should the light fail to work, proceed
Advanced Electronic Temperature
as follows.
Control System [AETCS] which
1- Switch off at the socket outlet and
ensures that at the advised setting [4
pull out the mains plug.
- four on the knob] the frozen food in
You may find it useful to remove
the freezer will not defrost even if the
shelves for easy access.
ambient temperature falls as low as
2- Use a flat tipped screwdriver to
-15 °C. When first installed the product
remove the light diffuser cover.
MUST NOT be placed in low ambient
3- First check that the bulb hasn’t
temperatures because the freezer will
worked loose by ensuring it is screwed
not reduce to it’s standard operating
securely in the holder. Replace the
temperature. Once it has reached its
plug and switch on.
steady operating state it can be re-
If the bulb works, replace the light
located. So you may then install your
cover by inserting the rear lug and
appliance in a garage or an unheated
pushing up to locate the front two
room without having to worry about
lugs.
frozen food in the freezer being spoilt.
4- If the light still fails to work, switch
However at low ambient temperatures
off at the socket outlet and pull out
mentioned above, fridge contents are
the mains plug. Replace the bulb with
likely to freeze, so check and consume
a new 15 watt (max) screw cap (SES)
food in the fridge accordingly. When
bulb.
the ambient temperature returns to
5- Carefully dispose of the burnt-out
normal, you may change the knob
light bulb immediately.
setting to suit your needs.
Replacement light bulb can easily be
CIf the ambient temperature is
obtained from a good local electrical or
below 0°C, the food in the fridge
DIY store.
compartment will freeze.So, we
recommend you don’t use the fridge
compartment in such low ambient
conditions. You can continue using the
freezer compartment as usual.
10
EN
Reversing the doors
Proceed in numerical order
1
2
3
4
10
5
6
11
7
12
8
9
13
17
16
15
18
14
22
21
20
23
19
11
EN
Reversing the doors
Proceed in numerical order
1
3
2
4
4
10
14
6
5
5
11
15
7
7
12
16
8
9
8
13
17
28
18
21
21
20
29
22
30
22
19
23
26
26
25
31
27
24
27
12
EN
4 Preparation
C Your refrigerator should be installed at
least 30 cm away from heat sources
such as hobs, ovens, central heater
and stoves and at least 5 cm away
from electrical ovens and should not
be located under direct sunlight.
C The ambient temperature of
the room where you install your
refrigerator should at least be 10°C.
Operating your refrigerator under
cooler conditions than this is not
recommended with regard to its
efficiency.
C Please make sure that the interior
of your refrigerator is cleaned
thoroughly.
C If two refrigerators are to be installed
side by side, there should be at least
2 cm distance between them.
C When you operate your refrigerator
for the first time, please observe the
following instructions during the initial
six hours.
- The door should not be opened
frequently.
- It must be operated empty without
any food in it.
- Do not unplug your refrigerator. If
a power failure occurs out of your
control, please see the warnings in
the “Recommended solutions for
the problems” section.
C Original packaging and foam
materials should be kept for future
transportations or moving.
13
EN
5 Using your refrigerator
Defrost
Fridge compartment
Fridge compartment performs full-
automatic defrosting. Water drops and
a frosting up to 7-8 mm can occur
on the inner rear wall of the fridge
compartment while your refrigerator
cools down. Such formation is normal
as a result of the cooling system.
The frost formation is defrosted by
performing automatic defrosting
with certain intervals thanks to the
automatic defrosting system of the rear
Thermostat setting button
wall. User is not required to scrape the
The interior temperature of your
frost or remove the water drops.
refrigerator changes for the following
Water resulting from the defrosting
reasons;
passes from the water collection
• Seasonal temperatures,
groove and flows into the evaporator
• Frequent opening of the door and
through the drain pipe and evaporates
leaving the door open for long
here by itself.
periods,
Check regularly to see if the drain pipe
• Food put into the refrigerator
is clogged or not and clear it with the
without cooling down to the room
stick in the hole when necessary.
temperature,
Deep freezer compartment does not
• The location of the refrigerator in the
perform automatıc defrosting in order
room (e.g. exposing to sunlight).
to prevent decaying of the frozen food
• You may adjust the varying interior
temperature due to such reasons
The freezer compartment defrosts
by using the thermostat. Numbers
automatically.
around the thermostat button
indicates the cooling degrees.
• If the ambient temperature is higher
than 32 °C, turn the thermostat
button to maximum position.
• If the ambient temperature is lower
than 25 °C, turn the thermostat
button to minumum position.
14
EN
Zero temperature
compartment
This compartment has been
designed to store frozen food which
would be thawed slowly (meat,
fish, chicken,etc.) as required.Zero
temperature compartment is the
coldest place of your refrigerator in
which dairy products (cheese, butter),
meat, fish or chicken may be kept at
ideal storage conditions.Vegetables
and/or fruits must not be placed in
this compartment.
15
EN
6 Maintenance and cleaning
A Never use gasoline, benzene or
Protection of plastic
similar substances for cleaning
surfaces
purposes.
C Do not put the liquid oils or oil-cooked
B We recommend that you unplug the
meals in your refrigerator in unsealed
appliance before cleaning.
containers as they damage the
plastic surfaces of your refrigerator. In
B Never use any sharp abrasive
case of spilling or smearing oil on the
instrument, soap, household
plastic surfaces, clean and rinse the
cleaner, detergent and wax polish for
relevant part of the surface at once
cleaning.
with warm water.
C Use lukewarm water to clean the
cabinet of your refrigerator and wipe it
dry.
C Use a damp cloth wrung out in
a solution of one teaspoon of
bicarbonate of soda to one pint of
water to clean the interior and wipe it
dry.
B Make sure that no water enters the
lamp housing and other electrical
items.
B If your refrigerator is not going to be
used for a long period of time, unplug
the power cable, remove all food,
clean it and leave the door ajar.
C Check door seals regularly to ensure
they are clean and free from food
particles.
A To remove door racks, remove all the
contents and then simply push the
door rack upwards from the base.
16
EN
