Инструкция к Blomberg KSM 9520 X A+
Bedienungsanleitung
Operating instructions
Refrigerator
Réfrigérateur
Kühlschrank
Koelkast
Chłodziarka
KSM 9520 A+
KSM 9520 XA+
Bedienungsanleitung
Operating instructions
Køleskab
Kylskåp
Kjøleskap
Jääkaappi
Frigorifero
Холодильник
KSM 9520 A+
KSM 9520 XA+
Bedienungsanleitung
Operating instructions
Bedienungsanleitung
Operating instructions
Hladnjak
KSM 9520 A+
KSM 9520 XA+
Bedienungsanleitung
Operating instructions
Please read this manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and
checked under the most meticulous quality control procedures, will provide you
an effective service.
For this, we recommend you to carefully read the entire manual of your product
before using it and keep it at hand for future references.
This manual
• Will help you use your appliance in a fast and safe way.
• Read the manual before installing and operating your product.
• Follow the instructions, especially those for safety.
• Keep the manual in an easily accessible place as you may need it later.
• Besides, read also the other documents provided with your product.
Please note that this manual may be valid for other models as well.
Symbols and their descriptions
This instruction manual contains the following symbols:
C Important information or useful usage tips.
A Warning against dangerous conditions for life and property.
B Warning against electric voltage.
This product is supplied with the selective sorting symbol for waste electrical
and electronic equipment (WEEE).
This means that this product must be handled pursuant to European Directive
2002/96/EC in order to be recycled or dismantled to minimise its impact on
the environment. For further information, please contact your local or regional
authorities.
Electronic products not included in the selective sorting process are potentially
dangerous for the environment and human health due to the presence of
hazardous substances.
Recycling
CONTENTS
1 Your refrigerator 3
4 Using your refrigerator 12
Thermostat setting button................12
2 Important Safety Warnings 4
Defrost ............................................12
Intended use .....................................4
For products with a water dispenser; .6
5 Maintenance and
cleaning 14
Child safety ........................................6
Protection of plastic surfaces ..........14
HCA Warning ....................................6
Things to be done for energy saving ..7
6 Recommended solutions
for the problems 15
3 Installation 8
Preparation ........................................8
Points to be considered when re-
transporting your refrigerator .............8
Before operating your refrigerator ......8
Electric connection ............................9
Disposing of the packaging ...............9
Disposing of your old refrigerator .......9
Adjusting the legs ............................10
Replacing the interior light bulb .......10
Reversing the doors ........................11
2
EN
1 Your refrigerator
12
1
2
13
3
14
4
16
3
13
3
5
6
7
15
8
9
17
10
10
11
1. Interior light
10. Freezer compartment
2. Thermostat knob
11. Adjustable front feet
3. Movable shelves
12. Dairy compartment
4. Wine rack
13. Adjustable door shelves
5. Defrost water collection channel -
14. Egg tray
Drain tube
15. Wine rack
6. Crisper cover
16. Fridge compartment
7. Salad crisper
17. Freezer compartment
8. Ice bank
9. Icematic and ice storage container
Figures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.
3
EN
2 Important Safety Warnings
• For products with a freezer
Please review the following
compartment; Do not put bottled and
information. Failure to observe this
canned liquid beverages in the freezer
information may cause injuries or
compartment. Otherwise, these may
material damage. Otherwise, all
burst.
warranty and reliability commitments
• Do not touch frozen food by hand;
will become invalid.
they may stick to your hand.
The usage life of the unit you
• Unplug your refrigerator before
purchased is 10 years. This is the
cleaning or defrosting.
period for keeping the spare parts
• Vapor and vaporized cleaning
required for the unit to operate as
materials should never be used in
described.
cleaning and defrosting processes of
your refrigerator. In such cases, the
Intended use
vapor may get in contact with the
This product is intended to be used
electrical parts and cause short circuit
– indoors and in closed areas such as
or electric shock.
homes;
• Never use the parts on your
– in closed working environments such
refrigerator such as the door as a
as stores and offices;
means of support or step.
– in closed accommodation areas such
• Do not use electrical devices inside
as farm houses, hotels, pensions.
the refrigerator.
• This product should not be used
• Do not damage the parts, where
outdoors.
the refrigerant is circulating, with
drilling or cutting tools. The refrigerant
General safety
that might blow out when the gas
• When you want to dispose/scrap
channels of the evaporator, pipe
the product, we recommend you
extensions or surface coatings are
to consult the authorized service in
punctured causes skin irritations and
order to learn the required information
eye injuries.
and authorized bodies.
• Do not cover or block the ventilation
• Consult your authorized service for
holes on your refrigerator with any
all your questions and problems
material.
related to the refrigerator. Do not
• Electrical devices must be repaired
intervene or let someone intervene to
by only authorised persons. Repairs
the refrigerator without notifying the
performed by incompetent persons
authorised services.
create a risk for the user.
• For products with a freezer
• In case of any failure or during
compartment; Do not eat cone ice
a maintenance or repair work,
cream and ice cubes immediately
disconnect your refrigerator’s mains
after you take them out of the freezer
supply by either turning off the
compartment! (This may cause
relevant fuse or unplugging your
frostbite in your mouth.)
appliance.
4
EN
• Do not pull by the cable when pulling
• Never connect your refrigerator to
off the plug.
electricity-saving systems; they may
• Place the beverage with higher proofs
damage the refrigerator.
tightly closed and vertically.
• If there is a blue light on the
• Never store spray cans containing
refrigerator, do not look at the blue
flammable and explosive substances
light with optical tools.
in the refrigerator.
• For manually controlled refrigerators,
• Do not use mechanical devices
wait for at least 5 minutes to start the
or other means to accelerate the
refrigerator after power failure.
defrosting process, other than those
• This operation manual should be
recommended by the manufacturer.
handed in to the new owner of the
• This product is not intended to be
product when it is given to others.
used by persons with physical,
• Avoid causing damage on power
sensory or mental disorders or
cable when transporting the
unlearned or inexperienced people
refrigerator. Bending cable may cause
(including children) unless they are
fire. Never place heavy objects on
attended by a person who will be
power cable. Do not touch the plug
responsible for their safety or who will
with wet hands when plugging the
instruct them accordingly for use of
product.
the product
• Do not operate a damaged
refrigerator. Consult with the service
agent if you have any concerns.
• Electrical safety of your refrigerator
shall be guaranteed only if the earth
system in your house complies with
standards.
• Do not plug the refrigerator if the wall
• Exposing the product to rain, snow,
outlet is loose.
sun and wind is dangerous with
• Water should not be sprayed directly
respect to electrical safety.
on inner or outer parts of the product
• Contact authorized service when
for safety purposes.
there is a power cable damage to
• Do not spray substances containing
avoid danger.
inflammable gases such as propane
• Never plug the refrigerator into
gas near the refrigerator to avoid fire
the wall outlet during installation.
and explosion risk.
Otherwise, risk of death or serious
• Never place containers filled with
injury may arise.
water on top of the refrigerator,
• This refrigerator is intended for only
otherwise this may cause electric
storing food items. It must not be
shock or fire.
used for any other purpose.
• Do not overload your refrigerator
• Label of technical specifications is
with excessive amounts of food. If
located on the left wall inside the
overloaded, the food items may fall
refrigerator.
down and hurt you and damage
5
EN
refrigerator when you open the door.
Child safety
Never place objects on top of the
• If the door has a lock, the key should
refrigerator; otherwise, these objects
be kept away from reach of children.
may fall down when you open or
• Children must be supervised to
close the refrigerator's door.
prevent them from tampering with the
• As they require a precise
product.
temperature, vaccines, heat-sensitive
medicine and scientific materials
HCA Warning
and etc. should not be kept in the
If your product's cooling system
refrigerator.
contains R600a:
• If not to be used for a long time,
This gas is flammable. Therefore, pay
refrigerator should be unplugged. A
attention to not damaging the cooling
possible problem in power cable may
system and piping during usage and
cause fire.
transportation. In the event of damage,
• The plug's tip should be regularly
keep your product away from potential
cleaned; otherwise, it may cause fire.
fire sources that can cause the
• The plug’s tip should be cleaned
product catch a fire and ventilate the
regularly with a dry cloth; otherwise, it
room in which the unit is placed.
may cause fire.
Ignore this warning if your
• Refrigerator may move if adjustable
product's cooling system contains
legs are not properly secured on the
R134a.
floor. Properly securing adjustable
Type of gas used in the product is
legs on the floor can prevent the
stated in the type plate which is on the
refrigerator to move.
left wall inside the refrigerator.
• When carrying the refrigerator, do not
Never throw the product in fire for
hold it from door handle. Otherwise, it
disposal.
may be snapped.
• When you have to place your product
next to another refrigerator or freezer,
the distance between devices should
be at least 8cm. Otherwise, adjacent
side walls may be humidified.
For products with a water
dispenser;
Pressure of water mains should be
minimum 1 bar. Pressure of water
mains should be maximum 8 bars.
• Use only potable water.
6
EN
Things to be done for energy
saving
• Do not leave the doors of your
refrigerator open for a long time.
• Do not put hot food or drinks in your
refrigerator.
• Do not overload your refrigerator so
that the air circulation inside of it is not
prevented.
• Do not install your refrigerator
under direct sunlight or near heat
emitting appliances such as ovens,
dishwashers or radiators.
• Pay attention to keep your food in
closed containers.
• For products with a freezer
compartment; You can store
maximum amount of food items in
the freezer when you remove the
shelf or drawer of the freezer. Energy
consumption value stated for your
refrigerator has been determined
by removing freezer shelf or drawer
and under maximum load. There
is no harm to use a shelf or drawer
according to the shapes and size of
food to be frozen.
• Thawing frozen food in fridge
compartment will both provide energy
saving and preserve the food quality.
7
EN
3 Installation
Please remember that the
manufacturer shall not be held liable if
Points to be considered
the information given in the instruction
when re-transporting your
manual is not observed.
refrigerator
1. Your refrigerator must be
Preparation
emptied and cleaned prior to any
C Your refrigerator should be installed at
transportation.
least 30 cm away from heat sources
2. Shelves, accessories, crisper and etc.
such as hobs, ovens, central heater
in your refrigerator must be fastened
and stoves and at least 5 cm away
securely by adhesive tape against any
from electrical ovens and should not
jolt before repackaging.
be located under direct sunlight.
3. Packaging must be tied with thick
C The ambient temperature of
tapes and strong ropes and the
the room where you install your
rules of transportation printed on the
refrigerator should at least be 10°C.
package must be followed.
Operating your refrigerator under
Please remember…
cooler conditions than this is not
Every recycled material is an
recommended with regard to its
indispensable source for the nature
efficiency.
and for our national resources.
C Please make sure that the interior
If you wish to contribute to recycling
of your refrigerator is cleaned
the packaging materials, you can
thoroughly.
get further information from the
C If two refrigerators are to be installed
environmental bodies or local
side by side, there should be at least
authorities.
2 cm distance between them.
Before operating your
C When you operate your refrigerator
refrigerator
for the first time, please observe the
Before starting to use your refrigerator
following instructions during the initial
check the following:
six hours.
1. Is the interior of the refrigerator dry
- The door should not be opened
and can the air circulate freely in the
frequently.
rear of it?
- It must be operated empty without
2. Insert the 2 plastic wedges onto
any food in it.
the rear ventilation as illustrated in
- Do not unplug your refrigerator. If
the following figure. Plastic wedges
a power failure occurs out of your
will provide the required distance
control, please see the warnings in
between your refrigerator and the wall
the “Recommended solutions for the
in order to allow the air circulation.
problems” section.
3. Clean the interior of the refrigerator as
C Original packaging and foam
recommended in the “Maintenance
materials should be kept for future
and cleaning” section.
transportations or moving.
8
EN
4. Plug the refrigerator into the wall
Disposing of the packaging
outlet. When the fridge door is open
The packing materials may be
the fridge compartment interior light
dangerous for children. Keep the
will come on.
packing materials out of the reach
5. You will hear a noise as the
of children or dispose them of by
compressor starts up. The liquid and
classifying them in accordance
gases sealed within the refrigeration
with the waste instructions. Do not
system may also give rise to noise,
dispose them of along with the normal
even if the compressor is not running
household waste.
and this is quite normal.
The packing of your refrigerator is
6. Front edges of the refrigerator may
produced from recyclable materials.
feel warm. This is normal. These
Disposing of your old
areas are designed to be warm to
refrigerator
avoid condensation.
Dispose of your old machine without
Electric connection
giving any harm to the environment.
Connect your product to a grounded
You may consult your authorized dealer
socket which is being protected by a
or waste collection center of your
fuse with the appropriate capacity.
municipality about the disposal of
Important:
your refrigerator.
The connection must be in compliance
Before disposing of your refrigerator,
with national regulations.
cut out the electric plug and, if there
The power cable plug must be easily
are any locks on the door, make them
accessible after installation.
inoperable in order to protect children
Voltage and permitted fuse protection
against any danger.
are indicated in the “Specifications”
section.
The climate class rate of your appliance is given
The specified voltage must be equal to
your mains voltage.
Extension cables and multiway plugs
must not be used for connection.
A damaged power cable must be
replaced by a qualified electrician.
Product must not be operated before it
is repaired! There is danger of electric
shock!
9
EN
on the rating label located inside the appliance.
It specifies the appropriate operating ambient
temperatures as explained below.
Climatic class Ambient temperatures
SN .......................+10 °C to 32 °C
N .........................+16 °C to 32 °C
ST........................+18 °C to 38 °C
T..........................+18 °C to 43 °C
SN-ST .................+10 °C to 38 °C
SN-T....................+10 °C to 43 °C
Adjusting the legs
Replacing the interior light
If your refrigerator is unbalanced;
bulb
You can balance your refrigerator by
Should the light fail to work, proceed
turning the front legs of it as illustrated
as follows.
in the figure. The corner where the
1- Switch off at the socket outlet and
leg exists is lowered when you turn
pull out the mains plug.
in the direction of black arrow and
You may find it useful to remove
raised when you turn in the opposite
shelves for easy access.
direction. Taking help from someone to
2- Use a flat tipped screwdriver to
slightly lift the refrigerator will facilitate
remove the light diffuser cover.
this process.
3- First check that the bulb hasn’t
worked loose by ensuring it is screwed
securely in the holder. Replace the
plug and switch on.
If the bulb works, replace the light
cover by inserting the rear lug and
pushing up to locate the front two
lugs.
4- If the light still fails to work, switch
off at the socket outlet and pull out
the mains plug. Replace the bulb with
a new 15 watt (max) screw cap (SES)
bulb.
5- Carefully dispose of the burnt-out
light bulb immediately.
Replacement light bulb can easily be
obtained from a good local electrical or
DIY store.
10
EN
Reversing the doors
Proceed in numerical order
4
5
4
2
7
1
10
6
11
12
45 °
3
9
8
17
16
15
180°
17
20
22
21
19
22
18
14
13
11
EN
4 Using your refrigerator
Defrost
A) Fridge compartment
Fridge compartment performs full-
automatic defrosting. Water drops and
a frosting up to 7-8 mm can occur
on the inner rear wall of the fridge
compartment while your refrigerator
cools down. Such formation is normal
as a result of the cooling system.
The frost formation is defrosted by
performing automatic defrosting
with certain intervals thanks to the
automatic defrosting system of the rear
Thermostat setting button
wall. User is not required to scrape the
The interior temperature of your
frost or remove the water drops.
refrigerator changes for the following
Water resulting from the defrosting
reasons;
passes from the water collection
• Seasonal temperatures,
groove and flows into the evaporator
• Frequent opening of the door and
through the drain pipe and evaporates
leaving the door open for long
here by itself.
periods,
Check regularly to see if the drain pipe
• Food put into the refrigerator
is clogged or not and clear it with the
without cooling down to the room
stick in the hole when necessary.
temperature,
• The location of the refrigerator in the
Deep freezer compartment does not
room (e.g. exposing to sunlight).
perform automatic defrosting in order
• You may adjust the varying interior
to prevent decaying of the frozen food.
temperature due to such reasons
by using the thermostat. Numbers
around the thermostat button
indicates the cooling degrees.
• If the ambient temperature is higher
than 32°C, turn the thermostat button
to maximum position.
• If the ambient temperature is lower
than 25°C, turn the thermostat button
to minimum position.
12
EN
B) Freezer compartment
Defrosting is very straightforward and
without mess, thanks to a special
defrost collection basin.
Defrost twice a year or when a
frost layer of around 7 (1/4”) mm
has formed. To start the defrosting
procedure, switch off the appliance
at the socket outlet and pull out the
mains plug.
All food should be wrapped in several
layers of newspaper and stored in a
cool place (e.g. fridge or larder).
Containers of warm water may be
placed carefully in the freezer to speed
up the defrosting.
Do not use pointed or sharp-edged
objects, such as knives or forks to
remove the frost.
Never use hair dryers, electrical
heaters or other such electrical
appliances for defrosting.
Sponge out the defrost water
collected in the bottom of the freezer
compartment. After defrosting, dry the
interior thoroughly.
Insert the plug into the wall socket and
switch on the electricity supply.
13
EN
5 Maintenance and cleaning
A Never use gasoline, benzene or
Protection of plastic
similar substances for cleaning
surfaces
purposes.
C Do not put the liquid oils or oil-cooked
B We recommend that you unplug the
meals in your refrigerator in unsealed
appliance before cleaning.
containers as they damage the
C Never use any sharp abrasive
plastic surfaces of your refrigerator. In
instrument, soap, household
case of spilling or smearing oil on the
cleaner, detergent and wax polish for
plastic surfaces, clean and rinse the
cleaning.
relevant part of the surface at once
C Use lukewarm water to clean the
with warm water.
cabinet of your refrigerator and wipe it
dry.
C Use a damp cloth wrung out in
a solution of one teaspoon of
bicarbonate of soda to one pint of
water to clean the interior and wipe it
dry.
B Make sure that no water enters the
lamp housing and other electrical
items.
B If your refrigerator is not going to be
used for a long period of time, unplug
the power cable, remove all food,
clean it and leave the door ajar.
C Check door seals regularly to ensure
they are clean and free from food
particles.
C To remove door racks, remove all the
contents and then simply push the
door rack upwards from the base.
14
EN
6 Recommended solutions for the problems
Please review this list before calling the service. It might save you time and
money. This list includes frequent complaints that are not arising from defective
workmanship or material usage. Some of the features described here may not
exist in your product.
The refrigerator does not operate
• Is the refrigerator properly plugged in? Insert the plug to the wall socket.
• Is the fuse of the socket which your refrigerator is connected to or the main fuse
blown out? Check the fuse.
Condensation on the side wall of the fridge compartment. (MULTI ZONE, COOL
CONTROL ve FLEXI ZONE)
• Very cold ambient conditions. Frequent opening and closing of the door. Highly
humid ambient conditions. Storage of food containing liquid in open containers.
Leaving the door ajar.
• Switching the thermostat to a colder degree.
• Decreasing the time the door left open or using it less frequently.
• Covering the food stored in open containers with a suitable material.
• Wipe the condensation using a dry cloth and check if it persists.
Compressor is not running
• Protective thermic of the compressor will blow out during sudden power failures or
plug-out plug-ins as the refrigerant pressure in the cooling system of the refrigerator
has not been balanced yet.
• Your refrigerator will start running approximately after 6 minutes. Please call the
service if your refrigerator does not startup at the end of this period.
• The fridge is in defrost cycle. This is normal for a full-automatically defrosting
refrigerator. Defrosting cycle occurs periodically.
• Your refrigerator is not plugged into the socket. Make sure that he plug is inserted
tightly to the wall socket.
• Are the temperature adjustments correctly made? There is a power failure. Call
your electricity supplier.
15
EN
The fridge is running frequently or for a long time.
• Your new refrigerator may be wider than the previous one. This is quite normal.
Large refrigerators operate for a longer period of time.
• The ambient room temperature may be high.This is quite normal.
• The refrigerator might have been plugged in recently or might have been loaded
with food. Cooling down of the refrigerator completely may last for a couple of
hours longer.
• Large amounts of hot food might have been put in the refrigerator recently. Hot
food causes longer running of the refrigerator until they reach the safe storage
temperature.
• Doors might have been opened frequently or left ajar for a long time. The warm
air that has entered into the refrigerator causes the refrigerator to run for longer
periods. Open the doors less frequently.
• Freezer or fridge compartment door might have been left ajar. Check if the doors
are tightly closed.
• The refrigerator is adjusted to a very low temperature. Adjust the refrigerator
temperature to a warmer degree and wait until the temperature is achieved.
• Door seal of the fridge or freezer may be soiled, worn out, broken or not properly
seated. Clean or replace the seal. Damaged/broken seal causes the refrigerator to
run for a longer period of time in order to maintain the current temperature.
Freezer temperature is very low while the fridge temperature is sufficient.
• The freezer temperature is adjusted to a very low temperature. Adjust the freezer
temperature to a warmer degree and check.
Fridge temperature is very low while the freezer temperature is sufficient.
• The fridge temperature is adjusted to a very low temperature. Adjust the fridge
temperature to a warmer degree and check.
Food kept in the fridge compartment drawers are freezing.
• The fridge temperature is adjusted to a very low temperature. Adjust the fridge
temperature to a warmer degree and check.
16
EN
Temperature in the fridge or freezer is very high.
• The fridge temperature is adjusted to a very high degree. Fridge adjustment has an
effect on the temperature of the freezer. Change the temperature of the fridge or
freezer until the fridge or freezer temperature reaches to a sufficient level.
• The door might be left ajar. Close the door completely.
• Large amounts of hot food might have been put in the refrigerator recently. Wait
until the fridge or freezer reaches the desired temperature.
• Refrigerator might have been plugged in recently. Cooling down of the refrigerator
completely takes time because of the size.
Noise similar to the sound of seconds heard from an analog clock is coming from
the refrigerator.
• This noise is coming from the solenoid valve of the refrigerator. Solenoid valve
functions for the purpose of ensuring coolant passage through the compartment
which can be adjusted to cooling or freezing temperatures, and performing cooling
functions. This is normal and is not fault cause.
The operation noise increases when the refrigerator is running.
• The operating performance characteristics o f the refrigerator may change
according to the changes in the ambient temperature. It is normal and not a fault.
Vibrations or noise.
• The floor is not even or it is weak. The refrigerator rocks when moved slowly. Make
sure that the floor is level, strong and capable to carry the refrigerator.
• The noise may be caused by the items put onto the refrigerator. Such items should
be removed from the top of the refrigerator.
There are noises like liquid spilling or spraying.
• Liquid and gas flows happen in accordance with the operating principles of your
refrigerator. It is normal and not a fault.
There is a noise like wind blowing.
• Air activators (fans) are used in order to allow the refrigerator to cool efficiently. It is
normal and not a fault.
Condensation on the inner walls of refrigerator.
• Hot and humid weather increases icing and condensation. It is normal and not a
fault.
• The doors are ajar. Make sure that the doors are closed completely.
• Doors might have been opened very frequently or they might have been left open
for along time. Open the door less frequently.
Humidity occurs on the outside of the refrigerator or between the doors.
• The weather may be humid. This is quite normal in humid weather. When the
humidity is less, condensation will disappear.
17
EN
