Lexar Multi-Card 24-in-1 USB Reader: Connecting the Reader

Connecting the Reader

The Lexar Multi-Card 24-in-1 Reader has a plug-and-play design, with no driver

installation needed.

To connect the reader, simply follow these steps:

- Remove cable and reader from the box

- Locate the mini USB port on the back of the reader and

insert the USB cable into the reader as illustrated above

- Locate the USB port on your desktop or laptop and

connect the USB cable into the port

To open the reader, locate the release button on each

side of the reader and push simultaneously. The reader

will pop open.

Note: Windows XP Network users

If your laptop or desktop is linked to a work or home network with multiple drives, your

system may not detect all 5 reader slots. If that’s the case, follow the instructions below:

- On your desktop screen, right click on MY COMPUTER and select MANAGE

- Select DISK MANAGEMENT from the menu located on the left hand side of your screen

- Locate and select your REMOVABLE DRIVE (reader slot), then right click

- Select CHANGE DRIVE LETTER AND PATH and select CHANGE

- On the right side, you will see a drop-down menu with a letter. Click on the drop-down

arrow, select a new letter for your REMOVABLE DRIVE (reader slot), and click OK

Repeat the above process for each undetected reader slot.
