Remove sliding piece (c), actuation

bar (d), compression spring (e) and

spring guide (f) from the magazine

housing. Take off the magazine hous-

ing. Blow out all parts with compressed

air. Remove major debris, e.g., with a

cloth. Especially clean the recess (d1) in

the actuation bar (d), as this could lead

to malfunctions of the magazine. Do

not use water for the cleaning; do not

apply oil or lubricate.

Assembling the disassembled magazine

holder

➤

Slide the dismounted and cleaned mag-

azine housing over the screwdriver bit

and place onto the spindle collar of the

driving tool to the stop.

➤

Press the roll (g) outwards and position

the switching strip (d) into the guide in

the middle between the stop and the

roll (g).

➤

Place the pressure spring (e) into the

sliding piece.

➤

Insert the spring guide (f) into the pres-

sure spring (e) as shown in the figure.

➤

Insert the complete assembled compo-

nents in the magazine housing and hold

tightly.

➤

Press back the switching strip (d) on

the outside as far as the stop until it

notches automatically in the magazine

housing. If necessary, press the release

knob (2) to notch the switching

strip (d).

➤

After the switching strip (d) has

notched in the magazine housing, let go

of the sliding piece (c) again.

Maintenance and repairs.

Risk of injury

Service, testing and repairs may only be car-

ried out by electrical engineers in conformity

with the regulations valid in the respective

country.

Maintenance and repairs.

For repairs, we recommend our FEIN cus-

tomer service centre, the FEIN authorised

service centres and FEIN agencies.

When carrying out your own repairs by

qualified electricians we supply the repair

documentation upon request.

Repairs may only be carried out by quali-

fied electricians in conformity with the

valid regulations.

Please always hand this Instruction Manual

to the those carrying out the repair.

Accessories.

Only use accessories recommended by

FEIN.

Warranty and liability.

The warranty for the product is valid in

accordance with the legal regulations in

the country where it is marketed.

In addition, FEIN also provides a guarantee

in accordance with the FEIN manufac-

turer’s guarantee. For further details on

this, please contact your specialist dealer,

your national FEIN representative, or the

FEIN customer service centre.

!
