3M SPEEDGLAS SL: 1ï

1ï

Note!

Flashing light sources (e.g. safety strobe lights) can trigger the welding fil-

ter making it flash when no welding is occurring. This interference can occur

from long distances and/or from reflected light. Welding areas must be shiel-

ded from such interference.

Caution!

Should the Speedglas SL welding shield fail to switch to the dark state upon

ignition of an arc, stop welding immediately and inspect the welding filter as

described in these instructions. Continued use of the welding filter that fails

to switch to the dark state may cause temporary vision loss. If the problem

cannot be identified and corrected, do not use the welding filter, contact your

supervisor, distributor or 3M for assistance.

MAINTENANCE

Replacement of outer protection plate.

Remove the used outer protection plate and place the new outer protection

plate on the welding shield as indicated in

ffiigguurreess CC::11–– CC::22..

Note!

Make sure that the protection plate is correctly snapped in on all four

columns.

SSeeee ffiigguurree CC::33..

Replacement of inner protection plate.

The used inner protection plate is removed as illustrated in

ffiigguurree DD::11..

The

new inner protection plate should be inserted after the protective film is

removed as illustrated in

ffiigguurree DD::22..

Locate one of the sides by fitting the

corners according to

ffiigguurree DD::33

. Bend the middle part and fit the other two

corners. Make sure that the inner protection plate is mounted correctly as

illustrated in

ffiigguurree DD::33..

Replacement of welding filter.

The welding filter can be removed and replaced according to

ffiigguurree CC::11

aanndd EE::11..

Replacement of headband.

The headband can be replaced according to

ffiigguurree FF::11––FF::22..

Replacement of battery.

The welding filter must be removed to acess the battery compartment. Take

out the battery holder (use a small screwdriver if necessary).

9
