Native Union Monocle: инструкция

MONOCLE

by

QUICK START GUIDE

GUIDE DE PRISE EN MAIN

KURZANLEITUNG

GUIDA RAPIDA

GUÍA DE INICIO RÁPIDO

GUIA DE INÍCIO RÁPIDO

快速入门指南

クイック スタート ガイド

빠른 시작 안내서

КРАТКОЕ РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ

HIZLI BAŞLANGIÇ KILAVUZU

English

MONOCLE SPECIFICATIONS:

IN THE BOX

1. MONOCLE

SPEAKER Mono speaker

2. Loop

3. Nylon USB / Micro-USB

BATTERY Lithium-ion Polymer

Charging Cable

CHARGE TIME ~70 minutes

4. Quick Start Guide

PLAY TIME

(speaker/speakerphone mode) ~5 hours

TALK TIME

(speaker/speakerphone mode) ~5 hours

POWER SUPPLY DC5V

USB 2.0

MONOCLE

by

OPERATING TEMP 0 to 45c

QUICK START GUIDE

GUIDE DE PRISE EN MAIN

KURZANLEITUNG

GUIDA RAPIDA

GUÍA DE INICIO RÁPIDO

GUIA DE INÍCIO RÁPIDO

快速入门指南

クイックスタートガイド

빠른 시작 안내서

КРАТКОЕ РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ

HIZLI BAŞL ANGIÇ KILAVUZ U

1 2 3 4

Specs are subject to change without prior notice.

English

MONOCLE

8

DIAGRAM 2

DIAGRAM 3

1

Wheel

1. The button

4

2. Micro USB port

9

3. AUX-out

2

3

4. Speaker

LED

5. Microphone

6. Cable management

7. 3.5 mm jack

DIAGRAM 4

8. Wheel

5

9. LED light

6

7

English

CONNECTING

DAISY-CHAIN (DIAGRAMS 3 and 4)

Insert the 3.5mm jack into your device.

Shared private calling/speakerphone:

Link up to 2 MONOCLES together to share your calls either in handset or speakerphone mode.

COMMUNICATING

Insert the 3.5mm jack of the second MONOCLE into the AUX-out of the rst MONOCLE

Calling: Use your device to dial.

and then use your device to dial.

Answering/ending a call: Click the button (1) on your MONOCLE once to answer or end a call.

Speaker: Daisy-chain up to 10 MONOCLES together to create the best shared listening experience

Volume: Use the volume control function on your device.

by inserting the 3.5mm jack of the second MONOCLE into the AUX-out of the rst MONOCLE

– repeat these steps for up to 10 MONOCLES.

SPEAKER / SPEAKERPHONE MODE (DIAGRAM 2)

Turn the speaker/speakerphone mode on: Rotate the wheel until it clicks.

CHARGING

The white LED indicates speaker/speakerphone mode is ‘ON’.

Use the Nylon USB / Micro-USB charging cable (2) to plug your MONOCLE into a USB power source.

Turn the speaker/speaker mode off: Rotate the wheel until it clicks and the LED turns off.

Volume: Rotate the wheel clockwise or anticlockwise to increase or decrease the volume.

(To ensure the best sound, we recommend setting the volume on your device to maximum).

To prevent possible hearing damage, do not listen at high volume levels for long periods.

LISTENING

Listen: Press the button once to play or pause music, alternatively use your device to control manually.

Skip: Double click to skip to the next track.*

Back-track: Triple click to go back a track.*

*not all devices support this function.

For further information on your MONOCLE please refer to the full instruction manual online at www.nativeunion.com.

English

FCC COMPLIANCE STATEMENT

SAFETY INFORMATION

This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions:

Please read these instructions carefully.

(1) this device may not cause harmful interference, and

This product has been designed and manufactured to meet strict quality and safety standards. However, please take note of the following important safety information.

(2) this device must accept any interference received, including inference that may cause undesired operation.

Changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

PRODUCT MAINTENANCE

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

Use of non-original accessories may result in performance deterioration, injury, product damage, electric shock and warranty termination.

These limits are designed to provide reasonable protection against harmful interference in a residential installation.

Attempting to disassemble your MONOCLE may damage it and the warranty will be void. Use only a clean soft cloth to clean your MONOCLE.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

CAUTIONS

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning off and on, the user is encouraged to try

- Permanent hearing loss may occur if earphones or speakers are used at high volume for prolonged periods of time.

to correct the interference by one or more of the following measures:

- Use this unit only as intended.

- Reorient or relocate the receiving antenna.

- To prevent re or shock hazard, do not expose this unit to rain or moisture. Do not use within a meter of any water such as swimming pools, bathtubs, or sinks.

- Increase the separation between the equipment and receiver.

- Do not expose the batteries to excessive heat such as sunshine, re or the like.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- To avoid electrical shock, do not dissemble. Refer servicing to qualied personnel only.

- Consult the dealer or an experienced radio/TV technician for help.

- Never insert objects of any kind, other than authorized items into the product as they may touch dangerous voltage points or short out parts that could result in re

or electrical shock.

- Do not dispose of this product in re. Refer to local country, state and city guidelines for appropriate methods of battery disposal.

- This product contains small parts that may cause choking if swallowed. Not intended for use by children under 3 years of age.

Disposal of old electrical and electronic equipment:

After the implementation of the European Directive (Waste Electrical and Electronic Equipment (WEEE)) in the national legal system, the following applies:

Electrical and electronic devices may not be disposed of with domestic waste. Consumers are obliged by law to return electrical and electronic devices at the

Assembled in China.

end of their services lives to the public collecting points set up for this purpose or point sale. Details to this are dened by the national law of the respective country. This

symbol on the product, the instruction manual or the package indicates that a product is subject to these regulations. By recycling, reusing the materials or other forms of

utilizing old devices, you are making and important contributions to protecting our environment.

© NATIVE UNION and NATIVE UNION Logo are registered trademarks of Design Pool Ltd.

All other trademarks and registered trademarks are the property of their respected owners.

Other products and company names mentioned herein may be trademarks of their respective companies.
