Gigaset 5020 Quick Guide

z

No memory content

{ Telephone locked

zzzz

When trying to connect: telephone locked

0

–

9

Phone number

With tone dialling:

n

– * key pressed

-

– # key pressed

With additional services from public network providers:

| New call in calls list

† (Flashing) A new message has arrived

ë Call waiting

™ Call forwarding immediately

˜ Call forwarding on no reply

— Call forwarding when busy

š Anonymous call on

Safety precautions

When installing, connecting and operating the telephone,

Keys

always observe the following precautions:

1 Repertory keys

◆ Only use the plugs and leads supplied.

2 Redial key

◆ Only connect the connecting lead to the socket/jack

3 Recall key

provided for that purpose.

4Mute key

◆ Only connect approved accessories.

5Shift key

◆ Arrange the connecting lead where it will not cause

6Quiet key

accidents.

7 Loudspeaker key (handsfree)

◆ Position the telephone on a non-slip surface.

8Loud key

◆ For your safety and protection, the telephone must not

9Set key

be used in bath or shower rooms (wet locations).

10 Up key

The telephone is not splash proof.

11 Down key

◆ Never expose the telephone to sources of heat, direct

sunlight or other electrical devices.

12 OK key (dial number displayed)

◆ Protect your telephone from moisture, dust, corrosive

Display symbols

liquids and vapours.

P In setting mode

◆ Never open up the telephone yourself.

‡ Shift key pressed

◆ Do not touch the plug contact with pointed or metallic

objects.

--- Ready for use

◆ Do not carry the telephone by the leads.

y Microphone off

◆ If you give your Gigaset 5020 to someone else, make

è Baby Call (direct call) number set

sure you also give them the user guide.

o Entry mark when setting (e.g. volume)

u

Recall key pressed

g

gase

eng-

ra-russ-

ro

-

-

-

-

.

m

.

.

2

GB

This crossed-out wheeled bin symbol on the product

means the product is covered by the European Direc-

tive 2002/96/EC.

The correct disposal and separate collection of your old

appliance will help prevent potential negative conse-

quences for the environment and human health. It is a pre-

condition for reuse and recycling of used electrical and elec-

tronic equipment.

For more detailed information about disposal of your old

appliance, please contact your local council refuse centre or

the original supplier of the product.

Preparing the telephone for use

Recommended installation of telephone

◆ Do not expose the telephone to direct sunlight or other

sources of heat.

◆ Operate at temperatures between +5°C and +40°C.

◆ Maintain a distance of at least one metre between the

Setting the internal clock

telephone and radio equipment, e.g. wireless

telephones, wireless pagers or TV sets. Otherwise,

?3 Initiate function.

telephone communication could be impaired.

The current set time is displayed in 24-hour

◆ Do not install the telephone in dusty areas as this can

mode (default setting: 00:00).

shorten the service life of the telephone.

o Enter the correct time in hours <hh> and

◆ To clean, wipe with a moist or antistatic cloth only, never

minutes <mm> (24-hour mode).

with a dry cloth (risk of electrostatic charging and

? Press the Set key.

discharge) or harsh cleaning agent.

◆ Furniture lacquer and polish can be damaged by contact

with parts of the unit (e.g. device feet).

Making calls

Connecting

Dialling a number

Insert the short end of the coiled handset cord in the socket

co Lift handset, dial number.

provided in the handset and the long end in the socket

or ...

marked with an

a on the underside of the device. Plug the

phone cord into the outlet on the wall and the other end

o Bc Dial number (you can delete wrongly entered

into the socket marked with a

Y on the underside of the

digits with

A and then enter the correct

device. Then your telephone is ready to use.

digit) and press the OK key.

After 2 seconds the number is dialled.

Lift the handset if you want to talk via the

handset.

Any digits after the 20th digit are moved from right to left in

the display. The Last number redial key

; can be used to

insert pauses when dialling, starting from the 2nd digit.

Select phone number from the calls list (if available):

see 6.

g

gase

eng-

ra-russ-

ro

-

-

-

-

.

m

.

.

3

GB

Activating/deactivating handsfree talking

Saving numbers

With this telephone you can also make calls (handsfree

Different telephone settings must be completed with the

mode) or settings without lifting the handset. The best

Set key

? so that they are available permanently.

distance from the microhone for speaking is about 50 cm.

In order to cancel without saving, e. g. after an incorrect

◆ Activating during a call via the handset

entry, replace the handset instead of pressing

? at the

L + a With the Loudspeaker key pressed replace the

end. The original setting is then retained.

handset.

Saving with notebook function

◆ Activating before dialling the number

You can also save phone numbers during a conversation

L Before dialling: hold down the Loudspeaker

with the notebook function.

key until you can hear the dialling tone.

Saving repertory numbers

Deactivating handsfree talking

You can save up to 20 phone numbers (or even functions,

c Lift the handset during the call.

see page 7) on both levels of the repertory keys.

Last number redial

? Press the Set key. (For 2nd memory level, also

The last 5 numbers dialled (up to 32 digits) are saved

press

=.)

automatically. You can retrieve these numbers from the last

: Press the repertory key under which you want

number redial list and dial them again:

to save the repertory number.

A number that has already been saved is

Redialling the last number dialled

shown in the display. If the memory for this

c; Lift the handset and press the last number

repertory key is empty,

z

appears in the display

redial key. The last number dialled is redialled

o Enter the number to be saved (up to 32 digits).

immediately.

or ...

Dialling from the last number redial list

Saving from the calls list (if service is available)

; Without lifting the handset: Press the last

A...C Press the Down/Up key until the desired

number redial key.

number appears in the display.

The last number dialled is displayed. (You can

or ...

leave the last number redial list at any time by

Saving from the redial list:

pressing

>.)

; Press the last number redial key.

A...C Using the Down/Up key, scroll through the list

to the desired number.

A...C If necessary, press the Down/Up key until the

desired number appears in the display.

B Press OK or L key.

After 2 seconds the number is dialled.

To terminate the process:

Lift the handset if you want to talk via the

? Press the Set key.

handset.

Saving during a call

You can also save phone numbers in the same way during a

Dialling using the repertory keys

call (notebook function).

c Lift handset. (If necessary, press = for a 2nd

Note:

level repertory key).

After the 20th digit, any following digits are moved from right to left

: Press repertory key.

in the display.

or ...

Delete all repertory numbers

: Press repertory key. (If necessary, press = for

?1251

a 2nd level repertory key).

Initiate function.

Bc Press OK or L key.

? Press the Set key.

After 2 seconds the number is dialled.

Lift the handset if you want to talk via the

handset.

g

gase

eng-

ra-russ-

ro

-

-

-

-

.

m

.

.

4

GB

Adjusting the telephone

Adjusting the loudspeaker

While in handsfree mode, you can set the volume to one of

Adjusting the ringer volume

7 levels and save it (default setting: 1).

H...I Adjust the volume with the Loud/Quiet key.

The volume of the ringer can be set to one of 4 levels and

can also be deactivated completely (default setting: level 4).

Activating/deactivating the mute melody

◆ To adjust when the telephone is idle:

You can activate and deactivate the mute melody for the

?5 Initiate function.

mute (default setting: on).

H...I Adjust the volume with the Loud/Quiet key.

?19 #

? Press the Set key.

Initiate function.

◆ To adjust while the telephone is ringing:

0/1 0: deactivate; 1: activate.

Press

H...I before lifting the handset.

? Press the Set key.

The last value set is saved.

Baby call (direct call) number setting

Setting the ringer frequency

If a phone number is set for the Baby Call function, it is

The frequency (speed) of the ringer can be set to one of

dialled automatically when the telephone is locked

three levels (default setting: level 3).

(s. "Activating/deactivating the telephone lock") after you

lift the handset (or press the Loudspeaker key) and press

?6 Initiate function.

any key (except

?, L,H and I). The telephone

1...3 Press one of the keys 1...3:

does not allow other phone numbers to be dialled, but

1: highest frequency; 3: lowest frequency.

incoming calls can be received.

? Press the Set key.

?82

Setting the ringtone

Initiate function.

o Enter direct call number (max. 32 digits).

Ten different ringtones can be set for the ringer (default

setting: ringtone 9).

? Press the Set key.

◆ To set with the telephone is idle:

When the baby call function is activated, you will see

è

?7 Initiate function.

and

{ in the display.

0...9 Press one of the keys 0 ... 9

Deactivating

? Press the Set key.

?80

◆ To set while the telephone is ringing:

Initiate function.

0...9 Press one of the keys 0 to 9.

? Press the Set key.

Deleting a baby call phone number

Setting the handset volume

?1253

The volume on the handset can be set to one of 3 levels and

Initiate function.

saved (default setting: level 1).

? Press the Set key.

?9 Initiate function.

H...I Adjust the volume with the Loud/Quiet key.

Activating/deactivating the telephone lock

? Press the Set key.

The telephone can be locked completely (with the exception

of a baby call phone number if set) so that it cannot dial any

Mute

phone numbers, including the baby call phone number. You

You can deactivate the telephone's handset and

can continue to receive incoming calls.

microphone. Then the other party can no longer hear you.

?8 Initiate function..

J During a call: Press the Mute key

0/ 1 0: unlock; 1: lock

Activate: Press the key again.

? Press the Set key.

When the telephone is locked, you will see

{ in the

display.

g

gase

eng-

ra-russ-

ro

-

-

-

-

.

m

.

.

5

GB

Activate/deactivate call duration display

Operation on a PABX

The telephone can display the approximate call duration in

the display (up to 99 min. 59 sec., default setting: on). If the

Enter/delete an external line prefixe

call duration display is activated, the time display begins

If you are using your telephone on a PABX, you may have to

8 seconds after the last digit is dialled.

save one or more external line prefixes. A dialling pause is

?18#

set automatically with the external line prefixe. You can save

Initiate function.

up to three external line prefixes.

0/ 1 0: deactivate; 1: activate.

?0 Initiate function.

? Press the Set key.

If no external line prefixe has been set in a

location,

z

appears in the display.

Setting the pause time

If several external line prefixes are saved, these

If necessary, the pause time of the Pause key ; (pause

are displayed next to one another; the current

function from second input position) can be changed to 1,

external line prefixe to be edited flashes.

3 or 6 seconds (default setting: 3 seconds).

If necessary, use the

; key to toggle

?102

between the external line prefixes displayed,

Initiate function.

to edit them as follows:

0...2 0: 1 sec.; 1: 3 sec.; 2: 6 sec..

To delete an external line prefix:

? Press the Set key.

? Press the Set key.

To enter an external line prefixe:

Changing the dialling mode

o Enter a one- to three-digit code.

?# Initiate function.

Enter additional external line prefixes:

1/ 2 1: Tone dialling.

; o Press the Redial key, enter next external line

2: Pulse dialling without flash function.

prefixe.

? Press the Set key.

? Press the Set key.

Changing dialling modes during a call

Recall key (on a PABX)

If your telephone is set to pulse dialling and you want to use

functions that require tone dialling (e.g. remote access to

During an external call, you can make a recall or divert the

an answering machine), you can change the dialling mode

call. To do this, press the Recall key

>. The subsequent

during a call.

procedure depends on your PABX. By default, the Recall key

is preset to a flash time (interruption time) of 90 ms for use

* With an open connection: press the star key.

of new features on public telephone systems. With a

o Enter digits for remote control/data transfer.

connection to a PABX, it may be necessary to change the

The telephone is reset to the original dialling mode by hang-

flash time (e.g. 600 ms). To do this, please refer to the

ing up the handset.

operating instructions for your PABX.

g

gase

eng-

ra-russ-

ro

-

-

-

-

.

m

.

.

6

GB

Setting the flash time for the Recall key

Calls list

?195

The calls list includes up to 50 entries. If the same subscriber

Initiate function.

calls more than once, a new entry is not created. Up to 99

0...4 Enter desired flash code:

repeated calls are displayed in the additional information.

0: 90 ms (default setting); 1: 120 ms;

Sequence of list entries: The most recent call is displayed

2: 270 ms; 3: 375 ms; 4: 600 ms.

in the first position (position number "01"). Older entries are

? Press the Set key.

moved downwards with each new incoming phone number

until they are deleted from the list.

In the calls list

Using functions for additional services of

◆ you can scroll through the phone numbers displayed,

public telephone systems

◆ query additional information:

(a) date and time, if this is transferred from the

If you want to use services that are to be triggered with the

telephone system, otherwise only the time according to

Recall key, make sure beforehand that the correct flash time

the telephone's internal clock,

is set for the key.

(b) frequency of an incoming phone number,

◆ delete entries,

Recall key (in public telephone systems)

◆ save phone numbers from the calls list to a repertory key

In public telephone systems, this key is required to use

(see page 3),

certain additional services.

◆ dial a displayed phone number directly.

The appropriate flashtime for the specific country must be

set before using the Recall key can be used:

Viewing caller histories and dialling phone numbers

◆ Belgium, Netherlands, Switzerland: 120 ms

If there are entries in the calls list that have you have not yet

(access code 1)

seen,

| flashes in the display.

◆ France, Luxemburg, Portugal, Germany, Greece: 270 ms

You can retrieve the calls list, scroll through its entries, view

(access code 2)

additional information about a call and call back directly:

◆ other European countries: 90 ms (access code 0).

A Press the Down key.

Using Calling Line Identification

The phone number of the most recent call

appears in the display. Its position number "01"

Under the following conditions, the phone numbers of

is displayed to the left of the number.

incoming calls are

If the phone number contains more than

(a) shown on the display (up to the first 20 digits) and

17 digits, the first 17 digits will be displayed

(b) automatically saved in a calls list:

first, then the rest after one second. (You can

◆ Both your network provider and the caller's network

leave the calls list at any time by pressing

>.)

provider must offer Calling Line Identification.

To scroll through the calls list:

◆ Both you and the caller must have requested this service

A...C Press the Down/Up key.

(if necessary) from your respective network providers.

If these conditions are met, but a caller has suppressed

To view additional information:

Calling Line Identification before making the call, you will

= Press the Shift key.

see

---P--- on the display instead of the phone number. If it

The date and time of the displayed entry is dis-

has not been possible to identify the number for other (tech-

played with the number of calls (on the right).

nical) reasons, you will see

---0--- or ---E--- on the display.

Back to the calls list (calling line display):

Up to 20 digits can be shown on the display. Longer phone

= Press the Shift key again.

numbers are shown with the end of the number shortened.

Dial the phone number:

B Press OK or L key.

After 2 seconds the number is dialled.

Lift the handset if you want to talk via the

handset.

g

gase

eng-

ra-russ-

ro

-

-

-

-

.

m

.

.

7

GB

Deleting entries in the calls list

Using the repertory keys as "function keys"

Delete all entries at the same time

Different public telephone services/functions – possibly by

A/C Press the Down/Up key.

order/request – can be selected via predetermined key com-

binations which you can obtain from your network provider.

?*?Press the Set key, star key and Set key one after

another.

You can save the necessary key combinations like normal

The calls list is deleted and closed.

phone numbers on repertory keys and similarly "select" and

also deactivate the service again.

Delete individual entries

Note:

A...C Scroll to the desired entry.

If you activate the symbol display and save the function calls

?? Press the Set key twice.

on the 2nd level of the repertory keys, you can link the

The entry is deleted.

activation and deactivation of different services for each

"function key" with the display or hiding of certain symbols

Activating/deactivating display of the area code

on the display.

You can set the telephone so that the area code is not dis-

Therefore, when setting the repertory keys on the 2nd

played for incoming calls. This can be useful, for example, if

level, bear in mind that activating and deactivating the dis-

you cannot see the last digits of a long phone number on

play symbols

™, ˜, —,ë and š is linked to very specific

the display.

keys in the 2nd level – regardless of the phone numbers or

You can deactivate the display for 2 area codes (up to

function calls stored on it!

5digits each).

Deactivating/activating the symbol display for additional

?4 Initiate function.

services

If no number has been set in a storage location

Displaying the symbols can be activated or deactivated as

z

appears in the display.

needed. In the default setting, the display is activated.

If both storage locations are in use, these are

displayed side by side; the current storage

?145

location to be edited flashes. If necessary, use

Initiate function.

the

; key to toggle between the storage

0/1 0: deactivate; 1: activate.

locations displayed to edit them as follows:

? Press the Set key.

Delete a number:

Recommended assignment of symbols to keys

? Press the Set key.

When the symbol display

= is activated and you then

Enter a number:

press one of the following repertory keys, the display sym-

o Enter a one to five digit number.

bol assigned to each is activated or deactivated respectively

Enter another prefix:

(key numbering from top to bottom):

; o Press the last number redial key, enter next

prefix.

=+Assignment Display

? Press the Set key.

icon

: 1

on

™

"You have a message" display

Call forwarding immediately

:

2off

Different network providers offer services for saving

: 3

on

messages (e.g. voice mail services).

˜

Call forwarding on no reply

If one or more newly received messages have been stored

:

4off

with the network provider, it may inform you via your tele-

: 5

on

—

phone. In the display, this notification from the network

Call forwarding when busy

:

6off

provider is displayed with the flashing

† symbol and the

phone number.

: 7

on

ë

Call waiting

You can now dial the corresponding phone number in order

:

8off

to check the stored messages. If there are no more new

: 9 Anonymous call (only the next call)

š

messages for you, the

† symbol disappears.

g

gase

eng-

ra-russ-

ro

-

-

-

-

.

m

.

.

8

GB

Assigning/changing function keys

Saving call forwarding on a function key

?= Initiate function.

?= Initiate function.

: Press the function key (=repertory key) that is

: Press the repertory key that is designated for

to be assigned.

the symbol display "

™

on", see "Deactivating/

If the function key is already assigned, the key

activating the symbol display for additional

assignment appears in the display. If the mem-

services" on page 7.

ory for this function key is empty,

z

appears in

A number already saved is shown in the

the display.

display. If the memory for this repertory key is

empty,

z

appears in the display.

o Enter the key combination/code for the desired

service.

*21*

Enter the select function for "Immediate call

Important!

forwarding".

If a part of the key combination to be saved

includes numbers/characters that must be

(a) Set the phone number for the

changeable (e.g. a phone number for a

call forwarding

forwarded call destination, or a time for the

o Enter the phone number of the forwarded call

appointment reminder), the shift key

=

destination.

must be used in this place.

# Press the hash key to mark the function end.

During a later activation of the service, this key

? Press the Set key.

makes the cursor for entering the changeable

or ...

part flash.

(b) Reserve changeable call forwarding

? Press the Set key.

= Press the Shift key.

Example: Call forwarding

When "Call forwarding immediately" is acti-

vated later, this key makes the cursor for enter-

In the following, you will see an example of repertory keys

ing the phone number of the forwarded call

used as "function keys". If the symbol display is activated, in

destination flash.

the "call forwarding" example when the service is activated,

the symbol provided for it is displayed, or hidden when the

# Press the hash key to mark the function end.

service is deactivated.

? Press the Set key.

The key sequence for activating the function "call forward-

Activating call forwarding with a function key

ing immediately" from your network provider consists of

e.g. three parts:

c = Lift handset, press Shift key.

: Press the repertory key for the symbol display

Select function Forwarded call destination End of

"

™

on".

function

™

appears in the display.

*21*

Phone number of the

#

(a) Phone number for call forwarding set

forwarded call destination

You may hear an announcement that the

You now have the following options:

service is activated.

◆ You can dial the entire key sequence each time on the

a Replace the handset.

keypad.

From now on, incoming calls will be forwarded

◆ You can save the key sequence on Repertory keys as an

to the forwarded call destination. Your tele-

entire function together with the phone number of a

phone will not ring.

set forwarded call destination

or

only the select function and the function end. With

this, you still have the option to set a forwarded call

destination that may change on a case-by-case basis.

g

gase

eng-

ra-russ-

ro

-

-

-

-

.

m

.

.

9

GB

(b) Changeable call forwarding

If your telephone is not working perfectly

o ; Enter the phone number of the forwarded call

No signal tone: The tone volume might be set to 0.

destination, press the last number redial key to

Lift handset, no dialling tone: Is the connecting lead

mark the end of the phone number entered.

correctly plugged into the telephone and the telephone

You may hear an announcement that the

socket?

service is activated.

Dialling tone audible but telephone will not dial:

a Replace the handset.

The connection is OK. Is the dialling mode set correctly

Incoming calls will be forwarded from now on

(see page 5)?

to the forwarded call destination. Your tele-

PABX only: No connection or incorrect connection when

phone will not ring.

dialling from memory (e.g. redial, speed dial):

Program external line prefixe.

Saving "Deactivate call forwarding" on a function key

The other party cannot hear you: Have you pressed the

The call forwarding, as described in the previous example,

Mute key? Press the key again. Is the plug from the handset

can be deactivated again with your network provider e.g.

cord inserted correctly?

with key sequence

#21#.

Recall key does not work: Set appropriate flash time.

You can save this key sequence on a dedicated repertory key

The caller's phone number and the calls list are not

as well. If the symbol display is activated and the service is

displayed:

activated as described, the

™ symbol in the display disap-

Is the adapter connected (see page 2)?

pears after the service is deactivated.

Can Calling Line Identification be used (see page 6)?

?= Initiate function.

: Press the repertory key that is designated for

Insert strips

symbol display "

™ off", see "Deactivating/acti-

Blank insert strips for the repertory keys can be found on the

vating the symbol display for additional serv-

Internet at www.gigaset.com/cordedphones

.

ices" on page 7.

Contacts

#21#

Enter the select function for "Immediate call

If you should encounter any problems when operating the

forwarding".

telephone connected to a communication system with

? Press the Set key.

analogue network access, please contact the network

operator responsible or your dealer.

Deactivating call forwarding with a function key

Authorisation

c= Lift handset, press the Shift key.

This device is intended for connection to analogue networks

:a Press the repertory key for symbol display

outside the EEA (with the exception of Switzerland)

"

™ off". Replace handset.

depending on national type approval.

The

™ symbol disappears. You may hear an announcement

Country-specific requirements have been taken into consid-

that the service is deactivated.

eration.

We, Gigaset Communications GmbH, declare that this

Appendix

device meets the essential requirements and other relevant

regulations laid down in Directive 1999/5/CE.

Care

A copy of the 1999/5/EC Declaration of Conformity is availa-

ble at this Internet address:

To clean, wipe with a moist or antistatic cloth only, never

www.gigaset.com/docs

with a dry cloth (risk of electrostatic charging and

discharge) or harsh cleaning agent.
