Owner’s Instruction Manual
25 Litre Electronic Microwave
MEE 3150 X
EN
2
Read the Instructions carefully and Keep for Future Reference
IMPORTANT SAFETY INSTRUCTIONS. READ CAREFULLY AND KEEP FOR
FUTURE REFERENCE
WARNING:
When the appliance is operated in the combination mode, children should
only use the oven under adult supervision due to the temperatures generated;
WARNING:
If the door or door seals are damaged, the oven must not be operated until
it has been repaired by a competent person;
WARNING:
It is hazardous for anyone other than a competent person to carry out any
service or repair operation that involves the removal of a cover which gives protection
against exposure to microwave energy;
WARNING:
Liquids and other foods must not be heated in sealed containers since they
are liable to explode
WARNING:
Only allow children to use the oven without supervision when adequate
instructions have been given so that the child is able to use the oven in a safe way and
understands the hazards of improper use;
•
Only use utensils that are suitable for use in microwave ovens
•
When heating food in plastic or paper containers, keep an eye on the oven due to
the possibility of ignition;
•
If smoke is observed, switch of or unplug the appliance and keep the door closed in
order to stifle any flames;
•
Microwave heating of beverages can result in delayed eruptive boiling, therefore
care must be taken when handling the container;
•
The contents of feeding bottles and baby food jars shall be stirred or shaken and
the temperature checked before consumption, in order to avoid burns;
•
Eggs in their shell and whole hard-boiled eggs should not be heated in microwave
ovens since they may explode, even after microwave heating has ended;
•
The oven should be cleaned regularly and any food deposits removed;
•
Failure to maintain the oven in a clean condition could lead to deterioration of the
surface that could adversely affect the life of the appliance and possibly result in a
hazardous situation;
•
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
•
The temperature of accessible surfaces may be high when the appliance is
operating.
EN
3
1 Specifications
..............................................4
2 Radio Interference
.......................................5
3 Installation....................................................5
4 Important Safety Instructions ....................7
5 Safety Instructions For General Use .........8
6 Operation Instruction
................................11
7 Care Of Your Microwave Oven ................14
Table of Content
EN
4
Power consumption:
230 V~50 Hz,1400 W
Output:
900 W
Grill Heater:
1200 W
Operating Frequency:
2.450 MHz
Outside Dimensions:
510 mm( W) X 382 mm (D) X 310 mm (H)
Oven Cavity Dimensions:
330 mm (W) X 330 mm (D) X 230 mm (H)
Oven Capacity:
25 litres
Uncrated Weight:
Approx. 14.5 kg
1
Specifications
1. If the oven will not perform at all,
the display does not appear or the
display disappears:
a) Check to ensure that the oven
is plugged in securely. If it is not,
remove the plug from the outlet,
wait 10 seconds and plug it in again
securely.
b) Check the premises for a blown
circuit fuse or a tripped main
circuit breaker. If these seem to be
operating properly, test the outlet
with another appliance.
2. If the microwave power does not
function:
a) Check to see whether the timer is
set.
b) Check to make sure that the door is
securely closed to engage the safety
interlocks. Otherwise, the microwave
energy will not flow into the oven.
Note:
The appliance is for household use
for heating food and beverages using
electromagnetic energy and for indoor use
only.
BEFORE YOU CALL FOR SERVICE
IF NONE OF THE ABOVE RECTIFIES THE SITUATION, THEN CONTACT THE
AUTHORIZED SERVICE AGENT.
EN
5
2
Radio Interference
3
Installation
IMPORTANT
The wires in this mains lead are coloured
in accordance with the following code:
Green-and-yellow :
Earth
Blue :
Neutral
Brown :
Live
As the colours of the wires in the mains
leads of the appliance may not correspond
with the coloured markings identifying the
terminals in your plug, proceed as follows:
The wire which is coloured green-and-
yellow must be connected to the terminal
in the plug which is marked with the letter
E or by the earth symbol coloured
green of green-and-yellow.
The wire which is coloured blue must be
connected to the terminal which is marked
with the letter N or coloured black.
The wire which is coloured brown must be
connected to the terminal which is marked
with the letter L or coloured red.
Microwave oven may cause interference
to your radio, TV, or similar equipment.
When interference occurs, it may be
eliminated or reduced by the following
procedures.
a. Clean the door and sealing surface of
the oven.
b. Place the radio, TV, etc. as far
away from your microwave oven as
possible.
c. Use a properly installed antenna for
your radio, TV, etc. to get a strong
signal reception.
1) Make sure all the packing materials
are removed from the inside of the
door.
2) Inspect the oven after unpacking for
any visual damage such as:
-
Misaligned Door
-
Damaged Door
-
Dents or Holes in Door Window and
Screen
-
Dents in Cavity
-
If any of the above are visible, DO
NOT use the oven.
3) This Microwave Oven weighs 14.5 kg
and must be placed on a horizontal
surface strong enough to support this
weight.
4) The oven must be placed away from
high temperature and steam.
5) DO NOT place anything on top of the
oven.
6) DO NOT remove the turn -table drive
shaft.
7) As with any appliance, close
supervision is necessary when used
by children.
WARNING - THIS APPLIANCE MUST
BE EARTHED.
1) The plug socket should be within
easy reach of the power cord
2) This oven requires 1.5 KVA for its
input. consultation with service
engineer is suggested when installing
the oven.
CAUTION
: This oven is protected
internally by ac 250V,10 Amp Fuse.
EN
6
ATTENTION: The following steps are for
the Microwave Oven models with the Built-
in Trim Kit Frame Only.
1. After taking all the accessories out
of the microwave oven, turn the
microwave oven over on its back and
keep the base of the microwave oven
facing towards you.
2. Remove the adjustable feet (Fig. No.
2) from the plastic bag and screw
them into the holders (Fig. No. 1), one
by one.
3. Once all 4 feet are fitted, turn the
microwave oven back over onto its
feet to check if the adjustable feet
are level. If the microwave oven is
unstable, adjust the feet by screwing
them up or down accordingly.
EN
7
WARNING:
When the appliance is
operated in the combination mode,
children should only use the oven under
adult supervision due to the temperatures
generated; (Only for the model with grill
function)
WARNING:
If the door or door seals are
damaged, the oven must not be operated
until it has been repaired by a competent
person;
WARNING:
It is hazardous for anyone
other than a competent person to carry
out any service or repair operation that
involves the removal of a cover which
gives protection against exposure to
microwave energy;
WARNING:
Liquids and other foods must
not be heated in sealed containers since
they are liable to explode.
WARNING:
Only allow children to use the
oven without supervision when adequate
instructions have been given so that the
child is able to use the oven in a safe way
and understands the hazards of improper
use;
•
The oven must have sufficient air
flow. Keep 10 cm space at back;15
cm at both sides and 30cms from
top of the oven. Don’t remove oven’s
feet, do not block air events of the
oven.
•
Only use utensils that are suitable for
use in microwave ovens.
•
When heating food in plastic or paper
containers, keep an eye on the oven
due to the possibility of ignition;
4
Important Safety Instructions
•
If smoke is observed, switch off or
unplug the appliance and keep the
door closed in order to stifle any
flames;
•
Microwave heating of beverages can
result in delayed eruptive boiling,
therefore care must be taken when
handling the container;
•
The contents of feeding bottles and
baby food jars shall be stirred or
shaken and the temperature checked
before consumption, in order to avoid
burns;
•
Eggs in their shell and whole hard-
boiled eggs should not be heated
in microwave ovens since they may
explode, even after microwave
heating has ended;
•
When cleaning surfaces of door, door
seal, cavity of the oven, use only mild,
nonabrasive soaps, or detergents
applied with a sponge or soft cloth.
•
The oven should be cleaned regularly
and any food deposits removed;
•
Failure to maintain the oven in a clean
condition could lead to deterioration
of the surface that could adversely
affect the life of the appliance and
possibly result in a hazardous
situation;
•
If the supply cord is damaged, it must
be replaced by the manufacturer,
its service agent or similarly qualified
persons in order to avoid a hazard.
EN
8
Listed below are, as with all appliances,
certain rules to follow and safeguards to
assure top performance from this oven:
1. Always have the glass tray, roller
arms, coupling and roller track in
place when operating the oven.
2. Do not use the oven for any reason
other than food preparation, such
as for drying clothes, paper, or any
other nonfood items, or for sterilizing
purposes.
3. Do not operate the oven when
empty. This could damage the oven.
4. Do not use the oven cavity for any
type of storage, such a papers,
cookbooks, etc.
5. Do not cook any food surrounded
by a membrane, such as egg yolks,
potatoes, chicken livers, etc without
first being pierced several times with
a fork.
6. Do not insert any object into the
openings on the outer case.
7. Do not at any time remove parts from
the oven such as the feet, coupling,
screws, etc.
8. Do not cook food directly on the
glass tray. Place food in/on proper
cooking utensil before placing in the
oven.
9. IMPORTANT-COOKWARE NOT TO
USE IN YOUR MICROWAVE OVEN
Do not use metal pans or dishes with
metal handles.
Do not use anything with metal trim.
Do not use paper covered wire twist-
ties on plastic bags.
5
Safety Instructions For General Use
Do not use melamine dishes as they
contain a material which will absorb
microwave energy. This may cause
the dishes to crack or char and will
slow down the cooking speed.
Do not use Centura Tableware. The
glaze is not suitable for microwave
use. Corelle Livingware closed handle
cups should not be used.
Do not cook in a container with a
restricted opening, such as a pop
bottle or salad oil bottle, as they may
explode if heated in a microwave
oven.
Do not use conventional meat or
candy thermometers. There are the
thermometers available specifically for
microwave cooking. These may be
used.
10. Microwave utensils should be
used only in accordance with
manufacturer’s instructions.
11. Do not attempt to deep-fry foods in
this oven.
12. Please remember that a microwave
oven only heats the liquid in a
container rather than the container
itself. Therefore, even though the lid
of a container is not hot to the touch
when removed from the oven, please
remember that the food/liquid inside
will be releasing the same amount of
steam and/or spitting when the lid is
removed as in conventional cooking.
EN
9
13. Always test the temperature of
cooked food yourself especially if
you are heating or cooking food/
liquid for babies. It is advisable never
to consume food/liquid straight from
the oven but allow it to stand for a
few minutes and stir food/ liquid to
distribute heat evenly.
14. Food containing a mixture of fat and
water, e.g. stock, should stand for
30-60 seconds in the oven after it
has been turned off. This is to allow
the mixture to settle and to prevent
bubbling when a spoon is placed
in the food/liquid or a stock cube is
added.
15. When preparing/cooking food/liquid
and remember that there are certain
foods, e.g. Christmas puddings, jam
and mincemeat, which heat up very
quickly. When heating or cooking
foods with a high fat or sugar content
do not use plastic containers.
16. Cooking utensil may become hot
because of heat transferred from the
heated food. This is especially true
if plastic wrap has been covering
the top and handles of the utensil.
Potholders may be needed to handle
the utensil.
17. To reduce the risk of fire in the oven
cavity:
(a) Do not overcook food. Carefully
attend microwave oven if paper,
plastic, or other combustible
materials are placed inside the oven
to facilitate cooking.
(b) Remove wire twist-ties from bags
before placing bag in oven.
(c) If materials inside the oven should
ignite, keep oven door closed, turn
the oven off at the wall switch, or
shut off power at the fuse or circuit
breaker panel.
(1) Door Safety Lock System
(2) Oven
Window
(3) Oven Air Vent
(4) Roller
Ring
(5) Glass
Tray
(6) Control
Panel
(7) Grill
rack
Feature Diagram
EN
10
Computer Control Panel
(1) Display
Window
(3) Defrost
(2) Grill
(5) Memory
(8) Clock/Time
(4) Micro
(10) Start
(6) Combi
(7) Auto Menu
(9) Pause/Cancel
(11) Time Setting
EN
11
6
Operation Instruction
1. Single Button Heating
Only with a single press of a button,
you can start simple cooking, it is very
convenient and quick to heat a glass of
water etc.
Example:
To heat a glass of milk.
a) Put a glass of milk onto the glass
turntable, and close the door.
b) Press the button “Start”, the
microwave oven will work on 100%
power for 1 minutes.
c) You will hear 5 beeps when cooking is
completed.
2. Microwave Heating
This function has two options.
1) Quick microwave heating (100%
power)
Example:
To heat food on 100% power for
5 minutes.
a) Set cooking time to “5:00”.
b) Press
“Start”.
2) Manual-operation microwave heating
Example:
To heat food on 70% power for
10 minutes.
a) Press “Micro” button, select “70%”
power;
b) Set time cooking to “10:00”.
c) Press
“Start”.
There are 5 power levels and the longest
microwave heating time is 60 minutes.
Touching times
Microwave power
Display
1
100%
P100
2
70%
P70
3
50%
P50
4
30%
P30
5
10%
P10
3. Auto weight defrost
Select the food type and weight, it will
automatically help you to adjust the power
level and time.
Example:
Defrost 500 g frozen meat.
a) Press the button “Auto defrost” ,
“DEF” will be displayed.
b) Rotate the knob “Time setting” to set
the weight 500g.
c) Press
“Start”.
The weight of food must be less than
2000g.
4. Auto-Menu
You only need to select the food type
and weight, it will automatically adjust the
power and time.
Example:
Auto cooking 400g fish
a) Press “Auto menu” button until “A-5”
display.
b) Rotate the knob “Time setting” until
“400” display.
c) Press
“Start”.
Menu
Weight (g)
Touching Times
A-1
Rice
A-2
Vegetable
A-3
Meat
A-4
Spaghetti
A-5
Fish
A-6
Bread
1
100
100
200
1
100
100
2
200
200
300
2
200
200
3
300
300
400
300
300
4
400
400
500
400
400
5
500
500
600
500
500
6
600
800
600
600
7
1000
700
8
800
9
900
10
1000
EN
12
5. Memory cooking function:
This function can memorize some useful
cooking programes to avoid reseting time
and power operation.
a) If no memory has been set press
“memory” “1” will be displayed,
input cooking power and time, press
“memory” again, the set program will
be memorized. If you press “Start”
instead of “memory” button, the oven
will start work, and the program also
will be memorized.
b) It there is any memory has been set
already, when you press “memory”
button, “1” will be displayed, the
oven will operate according to the
memorized program after you press
“Start” button.
The progrume will not be kept when the
electrity is off.
6. Grill
This function has two patterns, you may
press “Grill” to select such functions: (the
longest cooking time is 60 minutes).
Pattern 1: 85% grill power, display G-1
Pattern 2: 50% grill power, display G-2
Example:
Cooking food with grill for 20
minutes
a) Press “Grill” until the LED displayed
“G-1”.
b) Set cooking time “20:00”.
c) Press
“Star”.
When grilling, the food isn’t heated by
microwave, heat is radiated from the
metal heater at the top of the oven. When
grill is working, the cooking time has 2
stages, after the 1st half of the cooking,
the program will automatically pause and
sound 2 beeps, indicating you to open
the oven and turn food over, close the
door after turn the food over, press “Start”
button, the cooking will continue for the
2nd half. If you do not want to turn the
food over, the oven will re-start after 1 min
pause.
7. Combination Cooking
This appliance offers you a choice of two
methods of combination cooking.
Option 1: 55% Micro + 45% Grill), display
“C-1”.
Option 2: 30% Micro + 70% Grill), display
“C-2”.
Example:
Cooking food using option 2 for
30 minutes.
a) Press “Combi” button to select “C-2”.
b) Set cooking time for 30 minutes.
c) Press “Start “.
8. Clock
The oven can be used as a clock.
Example:
To input current time 16:30.
a) Press “Clock”, the clock symbol will
flash in display. Rotate the “Time
setting” knob to set “16:00”.
b) Press “Clock” again, rotate the “Time
setting” knob to set “16:30”.
c) Press “Clock” again, the clock setting
is finished, the time start to go on
working.
EN
13
9. Timer
The timer function helps the microwave
oven begin automatic cooking at set time,
and automatically stop operation after
finishing cooking. (You should set the
clock before using timer function).
Example:
The current time of microwave
oven is 16:30, to set cooking at 18:15 on
70% power for 10 minutes.
a) Press “Timer” and set time to18:15
(same procedure as setting clock).
b) Press “Micro” to set 70% power.
c) Input cooking time 10 minutes by
rotating the knob “Time Setting”.
d) Press
“Start”.
If you don’t set power and cooking time
(omit B and C steps), and directly press
“Start” button, the microwave oven will
work only as a clock, there will be 10
beeps at 18:15, but no other function will
run.
10. Child-safety lock
To activate the child safety lock, press
“Auto Menu” and “Combi” button at the
same time for 2 seconds. Press “Auto
Menu” and “Combi” button, at the same
time for 2 seconds again, it will unlock this
function.
11. Pause/Cancel
a) In the course of operation, pressing
“Pause/Cancel” button will stop
operation.
b) If any program was set before
pressing start, pressing this button
will cancel all the set program.
EN
14
1. Turn the oven off and remove the
power plug from the wall socket before
cleaning.
2. Keep the inside of the oven clean.
When food splatters or spilled liquids
adhere to oven walls. wipe with a damp
cloth. The use of harsh detergent or
abrasives is not recommended.
3. The outside oven surface should be
cleaned with a damp cloth. To prevent
damage to the operating parts inside the
oven. water should not be allowed to seep
into the ventilation openings.
4. Do not allow the Control Panel to
become wet. Clean with a soft, damp
cloth, Do not use detergents, abrasives or
spray-on cleaners on the control Panel.
5. If steam accumulates inside or around
the outside of the oven door, wipe with
a soft cloth. This may occur when the
microwave oven is operated under
high humidity conditions and in no way
indicates malfunction of the unit.
6. It is occasionally necessary to remove
the glass tray for cleaning. Wash the tray
in warm sudsy water or in a dishwasher.
7
Care Of Your Microwave Oven
7. The roller ring and oven cavity floor
should be cleaned regularly to avoid
excessive noise. Simply wipe the bottom
surface of the oven with mild detergent,
water or window cleaner and dry. The
roller ring may be washed in mild sudsy
water or dish washer. Cooking vapour
collect during repeated use but in no way
affect the bottom surface or roller ring
wheels.
When removing the roller ring from cavity
floor for cleaning. be sure to replace it in
the proper position.
8. Remove odors from your oven by
combining a cup of water with the
juice and skin of one lemon in a deep
microwaveable bowl. Microwave for 5
minutes. wipe thoroughly and dry with a
soft cloth.
9. When it becomes necessary to replace
the oven light. please consult a dealer to
have it replaced.
