Jabra HALO BT650s: instruction

Jabra HALO

(BT650s)

User manual

www.jabra.com

USER MANUAL - LANGUAGES

ENGLISH - EUROPE (click here for manual) ..........................4

ENGLISH - NORTH AMERICA (Click here for manual) . . . . . . . . . . . . . . . 20

ENGLISH - ASIA PACIFIC (Click here for manual) ....................38

DANSK (Klik her for at se vejledningen) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

FRANÇAIS (Cliquez ici pour le manuel). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

FRANÇAIS - NORTH AMERICA (Cliquez ici pour le manuel) . . . . . . . . . 88

DEUTSCH (Klicken Sie hier für Handbuch) . . . . . . . . . . . . . . . . . . . . . . . .107

РУССКИЙ (Щёлкните здесь, чтобы скачать

руководство) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .125

YКРАЇНА (Клацніть тут для завантаження посібника) ......144

NEDERLANDS (Klik hier voor de handleiding) .....................162

SUOMI (Avaa käyttöohje napsauttamalla tässä) . . . . . . . . . . . . . . . . .180

SVENSKA (Klicka här för bruksanvisning) .........................196

ITALIANO (Fare clic qui per il manuale) . . . . . . . . . . . . . . . . . . . . . . . . . . .212

PORTUGUÊS (Clique aqui para acessar o manual) . . . . . . . . . . . . . . . .230

ESPAÑOL (Haga clic aquí para obtener el manual) ................249

ESPAÑOL - NORTH AMERICA (Haga clic aquí para

acceder al manual) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .266

ČESKY (Zde klikněte pro manuál) .................................285

POLSKI (Kliknij tutaj, żeby przejść do instrukcji) . . . . . . . . . . . . . . . . . . .302

ΕΛΛΗΝΙΚΑ (Κάντε κλικ εδώ για το εγχειρίδιο) . . . . . . . . . . . . . . . . . . . . .320

TÜRKÇE (Kullanım kılavuzu için buraya tıklayın) ..................338

MAGYAR (Kattintson ide a kézikönyvért) . . . . . . . . . . . . . . . . . . . . . . . . .355

ROMÂNĂ (Faceţi clic aici pentru manual) . . . . . . . . . . . . . . . . . . . . . . . .372

390

405

简体中文（单击此处查看手册）

. . . . . . . . . . . . . . . . . . . . . . . . . . . .420

繁體中文（按下此處檢視手冊）

. . . . . . . . . . . . . . . . . . . . . . . . . . . .436

日本語 (取扱説明書をご覧になるには、ここをクリック

して くだ さ い )

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .453

한국어(설명서를 보려면 여기를 클릭하십시오)

............471

BAHASA MELAYU (Kullanım kılavuzu için buraya tıklayın) . . . . . . . .488

ภาษาไทย (คลิกที่นี่เพื่ออ่านคู่มือ) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .505

Contents

THANK YOU....................................................2

ABOUT YOUR JABRA HALO .....................................2

WHAT YOUR HEADSET DOES...................................3

GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

english

CHARGING YOUR JABRA HALO ................................4

TURNING YOUR JABRA HALO ON AND OFF .....................5

PAIRING YOUR JABRA HALO TO A PHONE OR OTHER DEVICE ...5

WEARING STYLE ...............................................6

HOW TO .......................................................6

WHAT THE DISPLAY MEANS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

USING YOUR JABRA HALO WITH TWO MOBILE DEVICES ........9

TROUBLESHOOTING & FAQ ....................................9

NEED MORE HELP?............................................10

TAKING CARE OF YOUR HEADSET .............................10

WARNING! ....................................................11

SAFETY INFORMATION! .......................................11

BUILTIN BATTERY CARE: ......................................12

CHARGER CARE: ..............................................13

WARRANTY ...................................................13

CERTIFICATION ...............................................15

GLOSSARY ....................................................16

JABRA HALO

1

thank you

Thank you for purchasing the Jabra HALO Bluetooth® headset. We

hope you enjoy it! This instruction manual will get you started and

ready to make the most of your headset.

about your Jabra haLo

english

1 Answer/End or Play/Pause button

2 Volume Control or Track Change touch sensor

3 Hinges for folding of headset

4 Battery indicator

5 Bluetooth connectivity indicator

2

JABRA HALO

2

3

3

4

5

1

What your headset does

The Jabra HALO lets you listen to stereo music through your

Bluetooth enabled mobile phone or music player, while ensuring

that you never miss a call.

- Play your music wirelessly

- Answer or end phone calls

english

- Reject incoming calls

- Last number redialing

- MultiUse™ – be connected to two Bluetooth devices at the

same time (for instance your PC and mobile)

- Use 3.5mm music cable for wired music listening from e.g. your

mp3 player or PC

Specications

Music:

- Music time up to 8 hours, standby time up to 13 days

- Track changes (next or previous track) on touch control

(AVRCP)

- A2DP (Advanced Audio Distribution Prole) for streaming

music

Call:

- Talk time up to 8 hours

- Dual Microphone solution for Noise Blackout™

- Digital sound enhancement via DSP technology

- Noise reduction on transmitted and received audio

- Noise dependent volume control*

- Automatic volume adjustment on received audio

- Acoustic shock protection

- Qualied for Bluetooth Specication version 2.0 + EDR

(enhanced data rate), supporting Headset and Hands-free

Proles for phone conversations and Advanced Audio

Distribution Prole (A2DP) for streaming music

- e-SCO for enhanced audio quality

- 128-bit encryption

JABRA HALO

3

* Refer to phone’s user manual

The device:

- Rechargeable battery with Micro-USB charging option from AC

power supply, PC via USB cable or car charger (not included)

- Colored LED-lights for Bluetooth status and battery indicator

- Size Unfolded: H 165mm - 190mm x W 136mm x D 45mm

- Size Folded: H 78mm x W 132mm x D 45mm

english

- Weight: 80 grams

- Operating range up to 10 meters (approximately 33 feet)

Please note that your Jabra HALO can withstand a short rain shower

but is not waterproof and cannot be submerged. If your device gets

wet, it should be wiped clean of any traces of water in order to protect

it from potential damage.

GettInG started

Follow these three steps before using your headset:

1. Charge your headset (approximately 2 hours)

2. Activate Bluetooth on your mobile phone (refer to the

manual for your mobile phone)

3. Pair your headset to your mobile phone

CharGInG your Jabra haLo

Make sure that your Jabra HALO is fully charged before you start

using it for the rst time.While charging, the battery indicator

changes from red to green, when fully charged. Charging time is

approximately 2h. You can use the Jabra HALO during recharge.

Please note: The lifetime of the battery will be signicantly reduced

if your device is left uncharged for a long period. Jabra therefore

recommends that you recharge your device at least once a month.

JABRA HALO

4

turnInG your Jabra haLo on and off

Unfolding the headset will turn it on.

Folding the headset will turn it o.

- To fold: Carefully extend the headset at the hinges (3) and fold.

The headset will now conveniently fold into a compact size.

- To unfold: Carefully unfold the headset and lock the hinges into

english

place.

The headset will automatically turn o after 10 minutes if not

connected to a device.

PaIrInG your Jabra haLo to a Phone or other

devICe

Headsets are connected to phones or other Bluetooth devices

using a procedure called ‘pairing’. By following a few simple steps,

pairing can be done in a matter of seconds.

1. Put the headset in pairing mode

1.a. First time pairing

- Fold and Unfold the headset and the Jabra HALO will

automatically enter pairing mode (indicator light (5) is solid

blue) and start searching for a device.

1.b. Later pairing

- Press and hold the Answer/End button (1) until the indicator

light (5) is solid blue (approximately 4 seconds).

2. Set your Bluetooth phone or device to search for the

Jabra HALO

- Follow your phone’s instruction guide. First make sure that

Bluetooth is activated on your mobile phone. Then set your

phone to search for the headset. This usually involves going

to a ‘setup,’ ‘ connect’ or ‘Bluetooth’ menu on your phone and

selecting the option to search for or ‘add’ a Bluetooth device.*

3. Your phone will nd the Jabra HALO

- The phone will nd the headset under name “Jabra HALO”.

- Your phone then asks if you want to pair with the headset.

- Accept by pressing ‘Yes’ or ‘OK’ on the phone and conrm with

the passkey or PIN = 0000 (4 zeros). Your phone will conrm

when pairing is complete.

JABRA HALO

5

* Refer to phone’s user manual

WearInG styLe

Please note the left/right wearing indicators inside the headband.

Alternatively always wear the Jabra HALO with the Answer/end

button on you right.

Adapt the size of your Jabra HALO by extending the length of the

headband by the speakers.

english

hoW to

The Jabra HALO is easy to operate. The Answer/End button

performs dierent functions depending on how long you press

them:

Instruction Duration of press

Tap Press briey

Double tap Touch briey two times

within 0,5 seconds

Press Approximately: 1 second

Press and hold Approximately: 4 seconds

Play music (Some phones may require you to start a media

player rst)*

- Tap the Answer/End button (1)

Pause music

- Tap the Answer/End button – tap again to resume playing

Stop music

- Press the Answer/End button

Answer a call when playing music

- When listening to music and receiving a call, the music will

pause and you will hear your ringtone

- Tap the Answer/End button and the music will be paused and

the call will be connected

End a call

- Tap the Answer/End button to end an active call - when you

end the call, your music will start again**

JABRA HALO

6

* Refer to phone’s user manual

** Device dependent

- Do not dispose of batteries in a re as they may explode.

- Batteries may also explode if damaged.

Battery warning!

- ”Caution” – The battery used in this device may present a risk of

re or chemical burn if mistreated.

- Do not attempt to open the product or replace the battery. It is

built-in and not changeable.

english

- Use of other batteries may present a risk of re or explosion

and the warranty will be terminated.

- Recharge your battery only with the provided approved

chargers designated for this device.

- Dispose of batteries according to local regulations. Please

recycle when possible. Do not dispose as household waste.

- Always store product out of the reach of children.

CharGer Care:

- Do not attempt to charge your headset with anything other

than the AC adaptor provided. The use of any other types

may damage or destroy the headset and may invalidate any

approval or warranty, and may be dangerous. For availability

of approved enhancements, please check with your dealer.

Important: The headset cannot be used while charging.

Charger warning!

- When you disconnect the power cord or any enhancement, grasp

and pull the plug, not the cord, never use a charger that is damaged.

- Do not attempt to disassemble the charger as it may expose

you to dangerous electric shock. Incorrect reassembly can cause

electric shock or re when the product is subsequently used.

- Avoid charging your headset in extremely high or low temperatures

and do not use the charger outdoors or in damp areas.

Warranty

Limited One (1) -year Warranty

GN Netcom A/S (“GN”) warrants this Product to be free from defects

in materials and workmanship (subject to the terms set forth

below) for a period of one (1) year from the date of purchase

(“Warranty Period”). During the Warranty Period, GN will repair

JABRA HALO

13

or replace (at GN’s discretion) this Product or any defective parts

(“Warranty Service”). If repair or replacement is not commercially

practicable or cannot be timely made, GN may choose to refund

to you the purchase price paid for the aected Product. Repair or

replacement under the terms of this Warranty does not give right

to any extension or a new beginning of the period of Warranty.

Claims under the Warranty

english

To obtain Warranty Service, please contact the GN dealer from

which you purchased this product or visit www.jabra.com for

further information about customer support. You will need to

return this Product to the dealer or ship it to the dealer or to GN (if

so indicated on www.jabra.com) in either its original packaging or

packaging aording an equal degree of protection. You will bear

the cost of shipping the product to GN. If the Product is covered

by the warranty, GN will bear the cost of shipping product back

to you after the completion of service under this warranty. Return

shipping will be charged to you for products not covered by the

warranty or requiring no warranty repair.

The Following information must be presented to obtain Warranty

Service: (a) the product, and (b) proof of purchase, which clearly

indicates the name and address of the seller, the date of purchase

and the product type, which is evidence that this product is

within the Warranty Period. Please further include (c) your return

address. (d) daytime telephone number, and (e) reason for return.

As part of GN Netcom’s eorts to reduce environmental waste

you understand that the product may consist of reconditioned

equipment that contains used components, some of which have

been reworked. The used components all live up to GN’s high

quality standards and comply with the GN product performance

and reliability specications. You understand that replaced parts

or components will become the property of GN.

Limitation of Warranty

This Warranty is only valid for the original purchaser and will

automatically terminate prior to expiration, if this Product is sold

or otherwise transferred to another party. The Warranty provided

by GN in this statement applies only to Products purchased for

use, and not for resale. It does not apply to open box purchases,

which are sold “as is” and without any warranty. Specically

exempt from Warranty are limited-life consumable components

subject to normal wear and tear, such as microphone windscreens,

ear cushions, modular plugs, ear tips, decorative nishes, batteries

JABRA HALO

14

and other accessories. This Warranty is invalid if the factory-applied

serial number, date code label, or product label has been altered

or removed from this Product. This Warranty does not cover

defects or damages that result from: (a) improper storage, misuse

or abuse, accident or neglect, such as physical damage (cracks,

scratches, etc.) to the surface of the Product resulting from misuse;

(b) contact with water, extreme humidity, sand, dirt or the like or

extreme heat; (c) use of the Product or accessories for commercial

english

purposes or subjecting the Product or accessories to abnormal

usage or conditions; or (d) other acts which are not the fault of GN.

This Warranty does not cover damage due to improper operation,

maintenance or installation, or attempted repair by anyone other

than GN or a GN dealer which is authorized to do GN warranty

work. Any unauthorized repairs will void this Warranty. This

Warranty does not cover defects or damages that result from the

use of non-GN branded or certied products, accessories, or other

peripheral equipment.

REPAIRS OR REPLACEMENTS AS PROVIDED UNDER THIS

WARRANTY ARE THE EXCLUSIVE REMEDY OF THE CONSUMER.

GNSHALL NOT BE LIABLE FOR ANY INCIDENTAL OR

CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR

IMPLIED WARRANTY ON THIS PRODUCT. EXCEPT TO THE EXTENT

PROHIBITED BY LAW, THIS WARRANTY IS EXCLUSIVE AND IN

LIEU OF ALL OTHER EXPRESS AND IMPLIED WARRANTIES WHAT

SO EVER, INCLUDING BUT NOT LIMITED TO THE WARRANTY OF

MERCHANTABILITY AND FITNESS FOR A PRACTICAL PURPOSE.

NOTE! This warranty gives you specic legal rights. You may

have other rights which vary from location to location. Some

jurisdictions do not allow the exclusion or limitation of incidental

or consequential damages or implied warranties, so the above

exclusions may not apply to you. This warranty does not aect your

legal (statutory) rights under your applicable national or local laws.

CertIfICatIon

CE

This product is CE marked according to the provisions of the R & TTE

Directive (99/5/EC). Hereby, GN Netcom A/S, declares that this product

is in compliance with the essential requirements and other relevant

provisions of Directive 1999/5/EC. For further information please

consult http://www.jabra.com.

JABRA HALO

15

Bluetooth

The Bluetooth® word mark and logos are owned by the Bluetooth

SIG, Inc. and any use of such marks by GN Netcom A/S is under

license. Other trademarks and trade names are those of their

respective owners.

Dispose of the product according to local standards and regulations.

www.jabra.com/weee.

english

GLossary

1 Bluetooth is a radio technology that connects devices, such

as mobile phones and headsets, without wires or cords over

a short distance (approx. 10 meters/33 feet). Bluetooth is safe

to use. It is secure too, so once a connection has been made

no-one can listen in and there is no interference from other

Bluetooth devices either. Get more information at

www.bluetooth.com.

2 Bluetooth proles are the dierent ways that Bluetooth

devices communicate with other devices. Bluetooth phones

support the headset prole, the hands-free prole or both. In

order to support a certain prole, a phone manufacturer must

implement certain mandatory features within the phone’s software.

3 Pairing creates a unique and encrypted link between two

Bluetooth devices and lets them communicate with each other.

Bluetooth devices will not work if the devices have not been paired.

4 Passkey or PIN is a code that you enter on your Bluetooth

enabled device (e.g. a mobile phone) to pair it with your Jabra

HALO. This makes your device and the Jabra HALO recognize

each other and automatically work together.

5 Standby mode is when the Jabra HALO is passively waiting

for a call. When you ‘end’ a call on your mobile phone, the headset

goes into standby mode.

Dispose of the product according

to local standards and regulations.

www.jabra.com/weee

JABRA HALO

16

Contents

THANK YOU....................................................2

ABOUT YOUR JABRA HALO .....................................2

WHAT YOUR HEADSET DOES...................................3

GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

english

CHARGING YOUR JABRA HALO ................................4

TURNING YOUR JABRA HALO ON AND OFF .....................5

PAIRING YOUR JABRA HALO TO A PHONE OR OTHER DEVICE ...5

WEARING STYLE ...............................................6

HOW TO .......................................................6

WHAT THE DISPLAY MEANS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

USING YOUR JABRA HALO WITH TWO MOBILE DEVICES ........9

TROUBLESHOOTING & FAQ ....................................9

NEED MORE HELP?............................................10

TAKING CARE OF YOUR HEADSET .............................10

WARNING! ....................................................11

SAFETY INFORMATION! .......................................12

BUILTIN BATTERY CARE: ......................................13

CHARGER CARE: ..............................................14

WARRANTY ...................................................14

CERTIFICATION AND SAFETY APPROVALS.....................16

GLOSSARY ....................................................18

JABRA HALO

1

thank you

Thank you for purchasing the Jabra HALO Bluetooth® headset. We

hope you enjoy it! This instruction manual will get you started and

ready to make the most of your headset.

about your Jabra haLo

english

1 Answer/End or Play/Pause button

2 Volume Control or Track Change touch sensor

3 Hinges for folding of headset

4 Battery indicator

5 Bluetooth connectivity indicator

2

JABRA HALO

2

3

3

4

5

1

What your headset does

The Jabra HALO lets you listen to stereo music through your

Bluetooth enabled mobile phone or music player, while ensuring

that you never miss a call.

- Play your music wirelessly

- Answer or end phone calls

english

- Reject incoming calls

- Last number redialing

- MultiUse™ – be connected to two Bluetooth devices at the

same time (for instance your PC and mobile)

- Use 3.5mm music cable for wired music listening from e.g. your

mp3 player or PC

Specications

Music:

- Music time up to 8 hours, standby time up to 13 days

- Track changes (next or previous track) on touch control

(AVRCP)

- A2DP (Advanced Audio Distribution Prole) for streaming

music

Call:

- Talk time up to 8 hours

- Dual Microphone solution for Noise Blackout™

- Digital sound enhancement via DSP technology

- Noise reduction on transmitted and received audio

- Noise dependent volume control*

- Automatic volume adjustment on received audio

- Acoustic shock protection

- Qualied for Bluetooth Specication version 2.0 + EDR

(enhanced data rate), supporting Headset and Hands-free

Proles for phone conversations and Advanced Audio

Distribution Prole (A2DP) for streaming music

- e-SCO for enhanced audio quality

- 128-bit encryption

JABRA HALO

3

* Refer to phone’s user manual

The device:

- Rechargeable battery with Micro-USB charging option from AC

power supply, PC via USB cable or car charger (not included)

- Colored LED-lights for Bluetooth status and battery indicator

- Size Unfolded: H 165mm - 190mm x W 136mm x D 45mm

- Size Folded: H 78mm x W 132mm x D 45mm

english

- Weight: 80 grams

- Operating range up to 10 meters (approximately 33 feet)

Please note that your Jabra HALO can withstand a short rain shower

but is not waterproof and cannot be submerged. If your device gets

wet, it should be wiped clean of any traces of water in order to protect

it from potential damage.

GettInG started

Follow these three steps before using your headset:

1. Charge your headset (approximately 2 hours)

2. Activate Bluetooth on your mobile phone (refer to the

manual for your mobile phone)

3. Pair your headset to your mobile phone

CharGInG your Jabra haLo

Make sure that your Jabra HALO is fully charged before you start

using it for the rst time.While charging, the battery indicator

changes from red to green, when fully charged. Charging time is

approximately 2h. You can use the Jabra HALO during recharge.

Please note: The lifetime of the battery will be signicantly reduced

if your device is left uncharged for a long period. Jabra therefore

recommends that you recharge your device at least once a month.

JABRA HALO

4

turnInG your Jabra haLo on and off

Unfolding the headset will turn it on.

Folding the headset will turn it o.

- To fold: Carefully extend the headset at the hinges (3) and fold.

The headset will now conveniently fold into a compact size.

- To unfold: Carefully unfold the headset and lock the hinges into

english

place.

The headset will automatically turn o after 10 minutes if not

connected to a device.

PaIrInG your Jabra haLo to a Phone or other

devICe

Headsets are connected to phones or other Bluetooth devices

using a procedure called ‘pairing’. By following a few simple steps,

pairing can be done in a matter of seconds.

1. Put the headset in pairing mode

1.a. First time pairing

- Fold and Unfold the headset and the Jabra HALO will

automatically enter pairing mode (indicator light (5) is solid

blue) and start searching for a device.

1.b. Later pairing

- Press and hold the Answer/End button (1) until the indicator

light (5) is solid blue (approximately 4 seconds).

2. Set your Bluetooth phone or device to search for the

Jabra HALO

- Follow your phone’s instruction guide. First make sure that

Bluetooth is activated on your mobile phone. Then set your

phone to search for the headset. This usually involves going

to a ‘setup,’ ‘ connect’ or ‘Bluetooth’ menu on your phone and

selecting the option to search for or ‘add’ a Bluetooth device.*

3. Your phone will nd the Jabra HALO

- The phone will nd the headset under name “Jabra HALO”.

- Your phone then asks if you want to pair with the headset.

- Accept by pressing ‘Yes’ or ‘OK’ on the phone and conrm with

the passkey or PIN = 0000 (4 zeros). Your phone will conrm

when pairing is complete.

JABRA HALO

5

* Refer to phone’s user manual

WearInG styLe

Please note the left/right wearing indicators inside the headband.

Alternatively always wear the Jabra HALO with the Answer/end

button on you right.

Adapt the size of your Jabra HALO by extending the length of the

headband by the speakers.

english

hoW to

The Jabra HALO is easy to operate. The Answer/End button per-

forms dierent functions depending on how long you press them:

Instruction Duration of press

Tap Press briey

Double tap Touch briey two times

within 0,5 seconds

Press Approximately: 1 second

Press and hold Approximately: 4 seconds

Play music (Some phones may require you to start a media

player rst)*

- Tap the Answer/End button (1)

Pause music

- Tap the Answer/End button – tap again to resume playing

Stop music

- Press the Answer/End button

Answer a call when playing music

- When listening to music and receiving a call, the music will

pause and you will hear your ringtone

- Tap the Answer/End button and the music will be paused and

the call will be connected

End a call

- Tap the Answer/End button to end an active call - when you

end the call, your music will start again**

JABRA HALO

6

* Refer to phone’s user manual

** Device dependent
