When work on steel materials with a material thickness

of less than 12 mm, the workpiece must be reinforced

with an additional steel plate in order to guarantee the

magnetic holding power.

Connect the drive motor only to the socket outlet on the

backside of the magnetic drill stand.

The magnetic foot is monitored by means of a power

sensor. If the magnetic foot is defective, the drive motor

will not start.

Remove the application tool from the drill hole only

while the motor is running.

Should the application tool become stuck in the material,

stop the drive motor and remove the application tool by

carefully turning it anticlockwise.

After each drilling run, remove the chippings and, if

required, the drilled out core.

Do not touch the chippings with your bare hand.

Always use a chip hook.

When changing the application tool, pay attention not to

damage its cutting edges.

When core drilling layered material, remove the core

and the chippings after drilling each layer.

With a tool inserted, the drive motor may not

move downward by itself; retighten the hexagon

nut as required. (see page 11)

When moving the magnetic drill stand with the

drive motor mounted, the unit can tip over when

the magnet is switched off. If required, make sure

that the magnetic drill stand is secured with a lashing

strap.

Repair and customer service.

When replacing the power tool’s cable is required, have

this carried out by FEIN or by an authorized FEIN Service

Agent, in order to avoid hazardous situations.

If required, you can change the following parts yourself:

Application tools, chipping protector, capstan handle

with handle levers, holder for drive motor

Warranty and liability.

The warranty for the product is valid in accordance with

the legal regulations in the country where it is marketed.

In addition, FEIN also provides a guarantee in accordance

with the FEIN manufacturer’s warranty declaration.

The delivery scope of your power tool may include only

a part of the accessories described or shown in this

instruction manual.

Declaration of conformity.

FEIN declares itself solely responsible for this product

conforming with the relevant provisions given on the last

page of this Instruction Manual.

Environmental protection, disposal.

Packaging, worn out power tools and accessories should

be sorted for environment-friendly recycling.
