EN

TruVision DVR 41 Quick Start

Guide

Figure 1: Back panel connections

1. Connect up to 16 analog cameras.

10. Connect to an optional USB device such as a

2. Connect up to 16 audio inputs to RCA

mouse, CD/DVD burner or HDD. The DVR

connectors.

supports both a USB DVD and a USB HD on the

3. Connect up to two CCTV monitors: Spot and

front and rear USB ports.

main monitors

11. Connect to a network.

4. Connect to speakers for audio output.

12. Terminate the line to the dome cameras using

5. Connect RCA connector to a microphone.

this RS-485 switch. Default is Off.

6. Connect to a RS-232 device.

13. Connect to a PTZ control.

7. Connect to a VGA monitor.

14. Connect to a keyboard (KTD-405 shown)

8. Connect to an optional eSATA device such as

15. Connect up to 16 alarm input cables to relay

SATA HDD, CD/DVD-RM.

outputs.

9. Connect to a HDTV. The HDMI connection

16. Connect up to four alarm relay outputs.

supports both digital audio and video.

17. Connect to ground.

18. Connect to a power supply.

19. Loop through for up to 16 analog cameras.

TVR 41 Quick Start Guide 1 : EN

Figure 2: Front panel controls

1. USB port.

9. Press to manually acknowledge an alarm.

2. Press to eject CD/DVD disc.

10. Alarm indicator bar blinks when there is an alarm.

3. Press to enter archive mode.

11. Move the joystick to select options in menus and

4. Insert CD or DVD disc.

to control playback and PTZ mode.

5. Press to select the viewing mode (multiview or

12. Press to control PTZ zoom and to select presets

full screen) and monitor as well as start/stop

and shadow tours.

sequencing.

13. Press to control playback, replay current

6. IR receiver.

playback file, and to return to live view mode.

7. Press to switch between different cameras in

14. Press to enter the main menu and advanced

live view, PTZ control or playback modes.

search modes.

8. Status LEDs.

Figure 3: Quick access toolbar

1. Freeze: Freeze live image of the selected

5. Quick snapshot: Capture a snapshot of a video

camera.

image.

2. Manual record: Start/stop manual recording.

6. PTZ control: Enter PTZ control mode.

3. Instant playback: Play back the recorded video

7. Digital zoom: Enter digital zoom.

from the last five minutes.

8. Image settings: Modify the image lighting levels.

4. Audio: Enable/disable audio output.

9. Text show: Display inserted text on screen.

10. Close: Close the toolbar.

EN : 2 TVR 41 Quick Start Guide

Package contents

3. Set up the unit with the required

settings using the setup Wizard.

The TruVision DVR 41 (model TVR 41) is

shipped with the following items:

First-time use

• IR (infrared) remote control

The TVR 41 has an express installation

• Two AAA batteries for the remote

wizard that lets you easily configure

control

basic DVR settings when first used. It

• AC power cords (US, Europe, UK)

configures all cameras simultaneously.

• USB mouse

The configuration can then be

• DVR

customized as required.

• Video loop through cable

By default, the setup wizard will start

• CD with software and manuals

once the DVR has loaded. The wizard

• TruVision DVR 41 Quick Start Guide

walks you through some of the more

important settings of your DVR. Select

• TruVision DVR 41 User Manual

(on CD)

the preferred language for the system

and then enter the administrator

Installation environment

password. The default admin password

is 1234. It is strongly recommended that

Refer to the user manual for detailed

this password is changed.

information, but observe these important

requirements:

The wizard will then guide you through

the menus to set the time and date,

• Place the unit in a secure location.

network configuration, HDD

• Ensure that the unit is in a well-

management, and recording

ventilated area.

configuration.

• Do not expose the unit to rain or

moisture.

When all the required changes have

been entered, click Finish to exit the

Quick install

wizard. The TVR 41 is now ready to use.

Recording starts automatically.

Recommended steps for setting up the

DVR:

Operating the TVR 41

1. Connect all the devices required to

the back panel of the TVR 41. See

There are several ways to control the

Figure 1 on page 1.

unit:

Basic connections:

• Front panel

Connect the cameras to the BNC

• IR remote control

camera inputs and monitor A to the

BNC, VGA or HDMI output. Connect

• Mouse

the mouse to the USB port in the front

• Web browser

panel.

Front panel

Optional connections:

All the other connections shown are

The buttons on the front panel control

optional and depend upon installation

most functions. See Figure 2 on page 2

requirements.

for the locations of the controls.

2. Connect the power cord to the unit

and turn on the power.

TVR 41 Quick Start Guide 3 : EN

IR remote control

To access the unit, open a Web browser

and enter the IP address assigned to the

The IR remote control buttons are similar

DVR as a Web address. In the log on

to those on the front panel. Place the two

screen, enter the default user ID and

AAA batteries in the remote control.

password:

• User ID: admin

To connect the remote control to the

DVR:

• Password: 1234

1. Press Menu on the front panel or

The default values for TVR 41 network

right-click the mouse and select

settings are:

Menu. The main menu screen

appears.

• DHCP: Enabled by default.

2. Select Display mode settings >

• IP address - 192.168.1.82

Monitor.

• Subnet mask - 255.255.255.0

3. Check and remember DVR device

• Gateway address - 192.168.1.1

address value. The default value is

255. The device address is valid for

• Ports:

all IR controls.

When using the browser:

4. On the remote control press the

RTSP port: 554

Device button.

HTTP port: 80

5. Enter the device address value. It

When using TruNav:

must be the same as that on the

TVR 41.

RTSP port: 554

6. Press ENTER on the remote or front

Server/Client software port : 8000

panel.

USB mouse

Figure 4: Web browser interface

The USB mouse provided with the

TVR 41 operates all the functions of the

DVR, unlike the front panel, which has

limited functionality. The mouse lets you

navigate and make changes to settings

in the user interface.

Connect the mouse to the DVR by

plugging the mouse USB connector into

Live view mode

the USB port on the front panel. The

mouse is immediately operational and

Live mode is the normal operating mode

the pointer should appear.

of the unit where you watch live pictures

from the cameras.

Web browser control

Regularly used functions in live view can

The TVR 41 Web browser lets you view,

be quickly accessed by clicking the left-

record, and play back videos as well as

button of the mouse on the camera

manage all aspects of the DVR from any

image. The shortcut pop-up toolbar

PC with Internet access. The browser’s

appears. See Figure 3 on page 2 for a

easy-to-use controls give you quick

description of the functions available.

access to all DVR functions.

EN : 4 TVR 41 Quick Start Guide

Configuring the TVR 41

Configures PTZ settings.

The TVR 41 has an icon-driven menu

structure that allows you to configure the

Configures user settings.

unit’s parameters. Each command icon

displays a screen that lets you edit a

group of settings. Most menus are

Configures system settings.

available only to system administrators.

Refer to the TVR 41 user manual for

detailed information on configuring the

Provides reference information

to the various toolbars and

unit.

menus within the interface.

To access the main menu from live

Provides access to logout,

reboot and shutdown options.

view:

 Press the Menu button on the remote

control or front panel

- Or -

Specifications

 Right-click the mouse, and select

Power supply 100 to 240 VAC,

Menu from the pop-up menu.

6.3 A, 50 to 60 Hz

The main menu screen appears. Move

Power consumption

the mouse over a command icon in the

(without HDD or

menu toolbar and click to select it.

DVD-R/W):

TVR 4104

≤ 35 W

TVR 4108

≤ 40 W

TVR 4116

≤ 45 W

Operating

-10 to +55 ºC

temperature

(14 to 131 °F)

Relative humidity 10 to 90%

Description of the command icons in

the menu toolbar:

Dimensions

445 × 470 × 90 mm

(W x H x D)

(17.5 × 18.5 × 3.5 in.)

Configures display settings.

Weight ≤ 8 kg (≤ 17.6 lb.)

(without HDD or DVD-

R/W)

Configures camera settings.

Contact information

Configures recording settings.

For contact information, see

www.interlogix.com, or

www.utcfssecurityproducts.eu

Configures standard network

settings.

Configures alarm settings.

TVR 41 Quick Start Guide 5 : EN
