Technical specifications

11. TECHNICAL SPECIFICATIONS

Power supply ………………………..……........................................................................................………. 230V~ / 50Hz

Power input ........................................................................................................................................................ 800 W

Speed ......................................................................................................................................................... 0-2800 rpm

Cutting depth in wood ................................................................................................................................. 100 mm

Cutting depth in steel ...................................................................................................................................... 10 mm

Pendulum positions ……................................................................................................................................. 0, I, II, III

Bevel angle ........................................................................................................................................................ 0°- 45°

Sound pressure level …………..………………............................................................… 88.27 dB(A) K = 3 dB(A)

Sound power level ……………………………....................................................……….......… 102 dB(A) K = 3 dB(A)

2

2

Vibration level ……………….......................……………………................….......….. a

= 11.427 m/s

K = 1.5 m/s

hB

2

2

a

= 8.523 m/s

K = 1.5 m/s

hM
