Mounting options

The vertical faste-

The vertical faste-

ning, with bracket

ning, with bracket

on the bottom,

upwards, allows

allows directing

directing the illumi-

the illuminator ho-

nator horizontally

rizontally towards

towards right. (Not

DE

left. (Not recom-

recommended for

EN

mended for IRLED-

IRLED-40xE illumi-

40xE illuminators.)

nators.)

FR

The horizontal

The horizontal

PL

fastening, with

fastening, with

bracket on the

bracket upwards,

RU

bottom, allows

allows directing

directing the illu-

the illuminator ver-

minator vertically

tically upwards.

downwards.

The ceiling moun-

The fastening on

ting, or under a

a parapet, with

housing, allows

bracket on the bot-

directing the

tom, allows direc-

illuminator in all

ting the illuminator

directions.

in all directions.

The wall moun-

ting, with optional

bracket BWHYP1,

allows directing

the illuminator in

all directions.

15

Remove the cover protective film after the unit installation.

Wall mounting

60

B

A

• Install the illuminator in a properly airy zone.

• In case of pole mounting, use a pole mount adapter.

• Place the bracket ⓐ in the desired position against the wall.

• To make this operation easier, it is possible to loosen the knurled hand-

wheel ⓑ or in case the nut opposite to the handwheel, and rotate the

bracket ⓐ as to the illuminator.

• Mark the position of mounting holes.

• Make the mounting holes, taking into consideration the type of material,

which the wall is made of, and the type of fixings to be used.

• Mount the bracket ⓐ to the wall in a firm way.

• If loosened during the bracket installation, please remember to tighten

the knurled handwheel ⓑ and/or the nut opposite to the handwheel.

16

122.5

44

28

6,5

6,5
