Setup Manual

Important: Please read PRECAUTIONS, this Setup Manual and the User’s Manual

stored on the CD-ROM carefully to familiarize yourself with safe and

effective usage. Please retain this manual for future reference.

English

2

®

FlexScan

HD2442W

HD2442W can be connected to the following devices.

PC

Speakers

(with built-in amplier)

DVI connector

D-Sub mini 15-pin

Allows you to enjoy sound from a

connector

connected PC or AV equipment, etc.

• Connection methods ..............page 10

Enables you to use as a monitor by connecting to

a Windows PC or a Macintosh.

NOTE

• Applicable resolution ............page 3

• Enables you to adjust the speaker

• Connection methods ..............page 8

volume connected to the monitor

using the volume adjustment function

Attention

of the monitor. .......................page 13

• The USB setting is required to change

• Enables you to enjoy sound by

depending on a PC used. ......page 12

connecting a headphone to the

headphone jack. .....................page 10

AV equipment

USB devices

DVD player

Keyboard

Mouse

HDMI connector

• Connection methods ...............

page 9

(Also available to connect a printer or a

Game

scanner, etc.)

HDMI connector

Attention

• Use a PC/OS applicable to USB devices.

Enables you to display projected images by

[Applicable OS]

connecting a DVD, Video, game, etc.

- Windows 2000/XP/Vista

• Applicable signal format .............

page 3

- Mac OS 8.5.1 or later

• Connection methods ................... page 10

English

3

Compatible Resolutions/Signal Format

The monitor supports the following resolutions and signal format.

PC Input

Digital Input Signal Analog Input Signal

Resolution Frequency Mode

Dot Clock (~ 162 MHz) Dot Clock (~ 162 MHz)

640 × 400 70 Hz NEC PC-9821

—

ü

640 × 480 67 Hz Apple Macintosh

—

ü

640 × 480 ~75 Hz VGA, VESA

ü (60Hz) ü

720 × 400 70 Hz VGA TEXT

ü ü

720 × 480 60 Hz

VESA

ü ü

848 × 480 60 Hz

VESA

ü ü

800 × 600 ~75 Hz

VESA

ü (60Hz) ü

832 × 624 75 Hz Apple Macintosh

—

ü

1024 × 768 ~75 Hz

VESA

ü (60Hz) ü

1152 × 864 75 Hz

VESA —

ü

1152 × 870 75 Hz Apple Macintosh

—

ü

*

1

1280 × 768

60 Hz VESA CVT RB —

ü

1280 × 768

*

1

~75 Hz VESA CVT —

ü

1280 × 960 60 Hz

VESA

ü ü

1280 × 960 75 Hz Apple Macintosh

—

ü

1280 × 1024 ~75 Hz

VESA

ü (60Hz) ü

1360 × 768 60 Hz

VESA —

ü

1600 × 1200 60 Hz

VESA

ü ü

1680 × 1050

*

1

60 Hz VESA CVT

ü ü

1680 × 1050

*

1

60 Hz VESA CVT RB

ü ü

1920 × 1200

*

1

*

2

60 Hz VESA CVT RB

ü ü

1280 × 720p

*

3

50, 60 Hz 720p

ü ü

1920 × 1080p

*

3

50, 60 Hz 1080p

ü ü

1

*

When displaying the wide format input signal, a graphics board in conformance with VESA CVT standard is required.

2

*

Recommended resolution (Set this resolution.)

3

*

Resolution for some AV equipments such as Microsoft Xbox 360

HDMI Input

• Video signal

– 525i (480i) / 525p (480p) / 1125i (1080i) / 750p (720p) : 60Hz, 1125p (1080p) : 60Hz / 24Hz

– 625i (576i) / 625p (576p) / 1125i (1080i) / 750p (720p) : 50Hz, 1125p (1080p) : 50Hz / 24Hz

• Audio signal

2ch linear PCM (32kHz / 44.1kHz / 48kHz / 88.2kHz / 96kHz / 176.4kHz / 192kHz)

English

4

[Location of Caution Statement]

Package Contents

Check that all the following items are included in the packaging box. If any items are missing or damaged, contact your local

dealer.

NOTE

• Please keep the packaging box and materials for future movement or transport of the monitor.

□ Monitor

□ EIZO HDMI cable (00M0J262)

□ Remote control

□ AAA batteries (2 pcs)

□ Power cord

□ EIZO USB cable (MD-C93)

□ Digital signal cable (FD-C39)

□ EIZO LCD Utility Disk (CD-ROM)

• User’s Manual

□ Setup Manual (this manual)

□ Remote Control Guide

□ Analog signal cable (MD-C87)

□ PRECAUTIONS

□ Limited warranty

□ Recycling Information

□ Mounting Screws (M4 x 12, 4 pcs)

About Setup Manual and User’s Manual

Setup Manual

Describes basic information ranging from connection of the monitor to

external equipment, such as a PC, etc., to using the monitor.

(this manual)

Remote Control Guide

Describes usage and function of the remote control.

User’s Manual

Describes application information such as screen adjustments, settings,

and specications.

(PDF le on the CD-ROM*)

PRECAUTIONS

Describes how to use the monitor safely.

* Installation of Adobe Reader is required.

• Product specications vary with sales areas. Conrm that the manual is written in the language of the area of purchase.

English

5

Before Using Remote Control

●

How to install batteries

1. On the back of the remote control,

slide the battery cover off in the direction of an arrow.

2. Input AAA batteries, and slide the cover back.

●

Re

ceivable Range of Remote Control

Use the remote control inside of the range as below.

About EIZO LCD Utility Disk (CD-ROM)

●

Disk Contents

• Disk contents and software overview

The following is included in the disk. Refer to the “Readme.txt” or the “Readme” file on the disk for software startup

procedures or file access procedures.

Item Overview For Windows For Macintosh

A “Readme.txt” or “Readme” le

ü ü

Color Proles (ICC Proles) Color proles

ü ü

Screen Adjustment Utility Monitor pattern display software

used when adjusting the image of the

ü

−

analog input signal manually.

ScreenManager Pro for LCD (for

A utility software program to control

Windows)

monitor adjustments from a PC using

its mouse and keyboard.

WindowMovie Checker Software

*

WindowMovie is a function of

ü

−

ScreenManager Pro for LCD.

For more information, refer to the

User’s Manual of ScreenManager Pro

for LCD on the disk.

User’s Manual of this monitor (PDF le)

* WindowMovie Checker Software is not applicable to Windows Vista.

●

To use ScreenManager Pro for LCD

For the installation and use of ScreenManager Pro for LCD, refer to its User’s Manual on the disk.
