6. Connect a 75 ohm coaxial video cable to

the video cable, and connect a 12 VDC

or 24 VAC power supply to the power

cable.

7. Adjust the camera position and angle as

required.

8. If necessary, use a flat blade screwdriver

to adjust the zoom first, and then adjust

the focus (Figure 3 on page 9).

Specifications

Power supply 24 VAC/12 VDC

Current TVC-BIR6-MR(-P):

180 mA (IR OFF)

590 mA (IR ON)

TVC-BIR6-HR(-P):

180 mA (IR OFF)

630 mA (IR ON)

EN 14

Power

TVC-BIR6-MR(-P):

consumption

7.08 W max.

TVC-BIR6-HR(-P):

7.56 W max.

Weight (net) TVC-BIR6-MR(-P):

2.04 lb. (950 g)

TVC-BIR6-HR(-P):

2.53 lb. (1150 g)

Dimensions

TVC-BIR6-MR(-P):

(D × H × L)

2.99 x 7.09 x 7.47 in.

(76 x 180 x 190 mm)

TVC-BIR6-HR(-P):

3.5 x 7.56 x 8.09 in.

(88 x 192 x 206 mm)

15 EN
