Gembird STR-W1-VF: instruction

HANDBUCH

HANDLEIDING

MANUEL DESCRIPTIF

РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ

КЕРІВНИЦТВО КОРИСТУВАЧА

WIRELESS 2.4GHZ LENKRAD MIT VIBRATION

DRAADLOOS 2.4GHZ STUURWIEL MET VIBRATIE

ROUE DE DIRECTION SANS FIL 2.4GHZ AVEC VIBRATION

БЕСПРОВОДНОЙ ИГРОВОЙ РУЛЬ ДИАПАЗОНА 2.4Г

ВИБРАЦИОННОЙ ОБРАТНОЙ СВЯЗЬЮ

БЕЗДРОТОВИЙ ІГРОВИЙ КЕРМО ДІАПАЗОНУ 2.4ГГЦ З ВІБРАЦІЙНОГО

STR-W1-VF

2

GEMBIRD EUROPE B.V. http://www.gembird.eu

All brands and logos are registered trademarks of their respective owners

VIBRATION

Features

• 2.4GHz RF technology for wireless comfortable gaming

• Vibration feedback for realistic driving sense

• More than 65 hours of non-stop gaming on 1000 mAH batteries

• 2 spring acceleration and brake pedals

• The released wheel returns by itself to the center position

• 2 axis, direction-pad and 12 independent control buttons

• USB plug-and-play receiver with the force connection pairing button

Specifications

• USB1.1/2.0 compatible RF receiver

• 4 pcs x AA battery wheel power supply

• Working distance: up to 10 m

• Vibration feedback motor

• 180 degrees rotation

• Power consumption: 6 V DC up to 15 mA (less than 1 mA during sleep

mode)

• Power and connection LED indications

• 1 m USB receiver cable

• 1.6 m pedals cable

• 5 desktop holders

• Dimensions (LxHxW): 320 x 260 x 240 mm

• Net weight of the whole set: 1.4 kg

3

GEMBIRD EUROPE B.V. http://www.gembird.eu

All brands and logos are registered trademarks of their respective owners

VIBRATION

Power Switch

(ON/OFF)

4

GEMBIRD EUROPE B.V. http://www.gembird.eu

All brands and logos are registered trademarks of their respective owners

VIBRATION

Compartment for 4 AA

Batteries

5

GEMBIRD EUROPE B.V. http://www.gembird.eu

All brands and logos are registered trademarks of their respective owners

VIBRATION

FC Button

6

GEMBIRD EUROPE B.V. http://www.gembird.eu

All brands and logos are registered trademarks of their respective owners

VIBRATION

Wheel Connection

Connect the pedal to the wheel

Insert the receiver cable into PC USB port

Load 4 batteries correctly into the wheel. Slide the power switch to “ON”

The receiver will automatically start connecting to the wheel.

Operate the wheel when receiver connection LED stays lit

Press FC button to designate a certain wheel if the receiver fails to connect a

wheel automatically for more than one wheel gaming. Reviver connection

LED starts blinking fast. Press button 9 and down of D-PAD to start

connecting to the wheel

Note: Do not power on the wheel if the pedals are not connected to the

wheel. Doing that may cause pedal and wings function failures.

Featured Functions

MODE function

Cycle Setup

Digital (LED OFF) Analog (RED LED ON)

3-level Wheel Sensitivity Adjustment

Press button 9 and button 10 at the same time. Hold for 3 seconds until

PROG LED turns orange.

Press button 9 again. Current sensitivity is displayed

7

GEMBIRD EUROPE B.V. http://www.gembird.eu

All brands and logos are registered trademarks of their respective owners

VIBRATION

Press button 9 a third time to select a sensitivity level. It cycles as below:

Middle (PROG LED is on) → High (PROG LED flashes quickly) → Low

(PROG LED flashes slowly)

Press UP of the D-PAD to confirm and quit

Button Programming

Program source buttons: button 1 to 8

Programmed button: left wing, right wing, gas pedal, brake pedal, button 11,

button 12

Program setup

Press button9 and button 10 at the same time. Hold for 3 seconds until

PROG LED turns orange

Press the programmed button and PROG LED starts blinking.

Press program source button. PROG LED is off. Program is set.

Clear single program

Press button 9 and button 10 at the same time. Hold for 3 seconds until

PROG LED turns orange

Press programmed button and PROG LED start blinking.

Press programmed button again and PROG LED is off. Single programmed

button is cleared.

8

GEMBIRD EUROPE B.V. http://www.gembird.eu

All brands and logos are registered trademarks of their respective owners

VIBRATION

Clear all programs

Press button 9 and button 10 at the same time. Hold for 3 second and

PROG LED turns orange. Release the button.

Press button 10 and hold for 4 seconds. PROG LED is off. All programmed

buttons are cleared. Default is restored.

Note: All the settings will be cleared when the wheel power is cut off

Low Power Mode /Sleep Mode Function (Receiver Connection LED is

blinking)

To save power and prolong battery life, this wheel provides low power mode.

Low power is active in the following situations:

The wheel is powered on without a receiver for 4 minutes

There is no button or axis actions for 3 minutes when connection is done

Press button 10 to wake up from low power mode/ sleep mode. Receiver

connection LED stays lit.

Low Voltage Alarm Function

When batteries are low, PROG LED starts blinking to indicate low voltage.

That means you need to change the batteries or charge the rechargeable

batteries in time. Motor vibration will be automatically shut down

Activate and Deactivate Motor Vibration Function

Motor vibration function is active by default when the wheel is powered on

9

GEMBIRD EUROPE B.V. http://www.gembird.eu

All brands and logos are registered trademarks of their respective owners

VIBRATION

Press button 9 and button 6 at the same time. Hold for 4 seconds. Motor

vibration function is deactivated

Press button 9 and button 6 again. Hold for 4 seconds. Motor vibration

function is activated

Troubleshooting

Problem description Proposed solution

a). Check connection with the PC USB port

b). Go to Control panel → System → Hardware tab

→ Device manager. Check the setting “Game Port

The Steering Wheel

Controller” of your device, it should be

does not work after the

“Confirmation”, and the setting “ID” should be “1”.

installation

Check the converter I/O settings and make sure

they do not conflict with your other peripherals

c). Try to reboot your PC.

The driver cannot be

Check your DirectX version. Version 7.0 or higher

installed or does not work

is required.

after installation

During gaming, some

Check whether the device is properly calibrated

analog axes do not work or

(Note: in the inactive state all the axis cursors

operate erratically

should be positioned in the center).

a). Check your DirectX version. Version 7.0 or

There is no vibration

higher is required.

b). Try to restart the game or reboot your PC
