ﺏﻮﻏﺮﳌﺍ ﻞﻐﺸﻟﺍ ﺔﻌﻄﻗ ﯽﻟﺇ ﺎﻬﻠﻴﻐﺸﺗ ﺪﻌﺑ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻪﺟﻭ

–

ﻦﻣ ﺎﻫﺭﺪﻗ ﺔﻳﻭﺍﺰﺑﻭ ﻒﻴﻔﺧ ﻂﻐﻀﺑ ﻞﻐﺸﻟﺍ ﺔﻌﻄﻗ ﰲ ﺎﻬﺴﻄﻏﺍﻭ ﺎﻬﺘﳉﺎﻌﻣ

.ﺔﺟﺭﺩ

45°

–

30°

15

ﺎﻫﺭﺪﻗ ﺔﻳﻭﺍﺰﺑ ﺔﻔﻴﻔﺧ ﺔﻳﺮﺋﺍﺩ ﺕﺎﻛﺮﺣ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﺔﻄﺳﺍﻮﺑ ﺬﻔﻧ

–

.ﺎﺒﻳﺮﻘﺗ ﺔﺟﺭﺩ

ﰲﺎﻛ ﺪﻳﱪﺗ ﻦﻣﺃ .

19

ﺔﻴﺒﻠﻘﻟﺍ ﺐﻘﺜﻟﺍ ﺔﻤﻘﻟ ﺀﺎﲪﺇ ﺓﺩﺎﻳﺯ ﻡﺪﻋ ﯽﻠﻋ ﺹﺮﺣﺍ

–

 ﺓﺪﳌ ﺐﻘﺜﻟﺍ :ﻼﺜﻣ ،ﻢﻣ

12

ﻦﻋ ﻞﻘﻳ ﺮﻄﻘﺑ ﺔﻴﺒﻠﻘﻟﺍ ﺐﻘﺜﻟﺍ ﻢﻘﻟ ﻡﺍﺪﺨﺘﺳﺍ ﺪﻨﻋ

.ﺎﺛ

5

 ﺓﺪﳌ ﺪﻳﱪﺘﻟﺍ ﻢﺛ ﺎﺛ

10

ﺓﺪﻌﻟﺍ ﺐﺤﺴﺗ ﻻ .ﻞﻐﺸﻟﺍ ﺔﻌﻄﻗ ﺐﻴﻘﺜﺗ ﺭﻮﻓ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﺊﻔﻃﺍ

–

.ﺔﻛﺮﳊﺍ ﻦﻋ ﺖﻔﻗﻮﺗ ﺪﻗ ﺯﺮﻔﻟﺍ ﺔﻤﻘﻟ ﻥﻮﻜﺗ ﻥﺃ ﺪﻌﺑ ﻻﺇ ﺝﺭﺎﺨﻠﻟ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ

 ﯽﻟﺇ

19

ﺔﻴﺒﻠﻘﻟﺍ ﺐﻘﺜﻟﺍ ﺔﻤﻘﻠﺑ ﺔﻴﺒﻧﺎﳉﺍ ﺓﻮﺠﻔﻟﺍ ﱪﻋ ﺕﺎﻳﺎﻔﻨﻟﺍ ﺔﻌﻄﻗ ﻊﻓﺩﺍ

–

.ﻼﺜﻣ ﻲﻏﺍﺮﺑ ﻚﻔﻣ ﺔﻄﺳﺍﻮﺑ ﺝﺭﺎﳋﺍ

ﺔﻣﺪﳋﺍﻭ ﺔﻧﺎﻴﺼﻟﺍ

ﻒﻴﻈﻨﺘﻟﺍﻭ ﺔﻧﺎﻴﺼﻟﺍ

ﯽﻠﻋ ﻞﻤﻋ ﻱﺃ ﺀﺍﺮﺟﺇ ﻞﺒﻗ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺔﻜﺒﺸﻟﺍ ﺲﺒﻘﻣ ﻦﻣ ﺲﺑﺎﻘﻟﺍ ﺐﺤﺳﺍ

◀

.ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ

ﻞﻜﺸﺑ ﻞﻤﻌﻠﻟ ﺔﻳﻮﻬﺘﻟﺍ ﻕﻮﻘﺷﻭ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﺔﻓﺎﻈﻧ ﯽﻠﻋ ﹰﲈﺋﺍﺩ ﻆﻓﺎﺣ

◀

.ﻦﻣﺁﻭ ﺪﻴﺟ

ﺔﻳﺎﻨﻌﺑ ﺖﻌﻨﺻ ﺪﻗ ﺎﳖﺃ ﻦﻣ ﻢﻏﺮﻟﺎﺑ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺎﺑ ﻞﻠﺧ ﻱﺃ ﺙﻭﺪﺣ ﺪﻨﻋ

ﺔﻟﺎﻛﻭ ﺔﻣﺪﺧ ﺰﻛﺮﻣ ﰲ ﺎﻬﺣﻼﺻﺇ ﺐﺟﻮﺗ ﺓﺪﻳﺪﻋ ﺕﺍﺭﺎﺒﺘﺧﺍ ﺕﺯﺎﺘﺟﺍﻭ ﺔﻘﺋﺎﻓ

.ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺵﻮﺑ ﺩﺪﻋ

ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﺯﺍﺮﻃ ﺔﺤﺋﻻ ﺐﺴﺣ ﴩﻌﻟﺍ ﺐﺗﺍﺮﳌﺎﺑ ﻒﻨﺼﻟﺍ ﻢﻗﺭ ﺮﻛﺫ ﯽﺟﺮﻳ

.ﺭﺎﻴﻐﻟﺍ ﻊﻄﻗ ﺕﺎﻴﺒﻠﻃ ﻝﺎﺳﺭﺇ ﺪﻨﻋﻭ ﺓﺭﺎﺸﺘﺳﻻﺍ ﺪﻨﻋ ﻱﺭﻭﴐ ﻞﻜﺸﺑ

ﻦﺋﺎﺑﺰﻟﺍ ﺓﺭﻮﺸﻣﻭ ﺔﻣﺪﺧ

ﺔﻧﺎﻴﺻﻭ ﺢﻴﻠﺼﺗ ﺩﺪﺼﺑ ﺔﺣﻭﺮﻄﳌﺍ ﺔﻠﺌﺳﻷﺍ ﯽﻠﻋ ﻦﺋﺎﺑﺰﻟﺍ ﺔﻣﺪﺧ ﺰﻛﺮﻣ ﺐﻴﳚ

ﻦﻋ ﺕﺎﻣﻮﻠﻌﳌﺍﻭ ﺓﺩﺪﻤﳌﺍ ﻡﻮﺳﺮﻟﺍ ﺪﺠﺘﺳ .ﺭﺎﻴﻐﻟﺍ ﻊﻄﻗ ﺺﳜ ﲈﺑ ﹰﺎﻀﻳﺃﻭ ﺞﹶﺘﻨﳌﺍ

:ﻊﻗﻮﻤﺑ ﺭﺎﻴﻐﻟﺍ ﻊﻄﻗ

www.bosch-pt.com

ﺔﺣﻭﺮﻄﳌﺍ ﺔﻠﺌﺳﻷﺍ ﯽﻠﻋ ﺔﺑﺎﺟﻹﺎﺑ ﺵﻮﺑ ﻦﺋﺎﺑﺯ ﻱﺭﺎﺸﺘﺳﺍ ﻖﻳﺮﻓ ﻙﺪﻋﺎﺴﻴﺳ

.ﺎﻬﻌﺑﺍﻮﺗﻭ ﺕﺎﺠﹶﺘﻨﳌﺍ ﻂﺒﺿﻭ ،ﻡﺍﺪﺨﺘﺳﺍ ،ﺀﺍﴍ ﺩﺪﺼﺑ

ﲔﻣﺄﺗﻭ ﺢﻴﻠﺼﺘﻟﺍﻭ ﻥﲈﻀﻟﺍ ﺭﻮﻣﺄﺑ ﻖﹼﻠﻌﺘﻳ ﲈﺑ ﺺﺘﺨﳌﺍ ﺮﺟﺎﺘﻟﺍ ﯽﻟﺇ ﻪﺟﻮﺘﻟﺍ ﯽﺟﺮﻳ

.ﺭﺎﻴﻐﻟﺍ ﻊﻄﻗ

ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻦﻣ ﺺﻠﺨﺘﻟﺍ

ﺔﺌﻴﺒﻠﻟ ﺔﻔﺼﻨﻣ ﺔﻘﻳﺮﻄﺑ ﻑﻼﻐﻟﺍﻭ ﻊﺑﺍﻮﺘﻟﺍﻭ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺩﺪﻌﻟﺍ ﻦﻣ ﺺﻠﺨﺘﻟﺍ ﻲﻐﺒﻨﻳ

.ﻊﻴﻨﺼﺘﻟﺍ ﺓﺩﺎﻋﻹ ﺔﻠﺑﺎﻘﻟﺍ ﺕﺎﻳﺎﻔﻨﻟﺍ ﻖﻳﺮﻃ ﻦﻋ

!ﺔﻴﻟﺰﻨﳌﺍ ﺕﺎﻳﺎﻔﻨﻟﺍ ﰲ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺩﺪﻌﻟﺍ ﻡﺮﺗ ﻻ

:ﻂﻘﻓ ﰊﻭﺭﻭﻷﺍ ﺩﺎﲢﻻﺍ ﻝﻭﺪﻟ

2002/96/EG

ﰊﻭﺭﻭﻷﺍ ﻪﻴﺟﻮﺘﻟﺍ ﺐﺴﺤﻓ

ﺔﻤﻳﺪﻘﻟﺍ ﺔﻴﻧﻭﱰﻜﻟﻻﺍﻭ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺰﻬﺟﻷﺍ ﺩﺪﺼﺑ

ﻞﺼﻓﻭ ﻊﲨ ﻲﻐﺒﻨﻳ ،ﲇﺤﳌﺍ ﻥﻮﻧﺎﻘﻟﺍ ﻦﻤﺿ ﻪﻘﻴﺒﻄﺗﻭ

ﻝﲈﻌﺘﺳﻼﻟ ﺔﳊﺎﺻ ﺪﻌﺗ ﱂ ﻲﺘﻟﺍ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺩﺪﻌﻟﺍ

ﺔﻘﻳﺮﻄﺑ ﺎﳍﲈﻌﺘﺳﺍ ﺓﺩﺎﻋﺈﺑ ﻡﻮﻘﻳ ﺰﻛﺮﳌ ﺎﻬﻨﻣ ﺺﻠﺨﺘﻟﺍﻭ

.ﺔﺌﻴﺒﻟﺎﺑ ﺔﻔﺼﻨﻣ

.ﺕﻼﻳﺪﻌﺘﻟﺍ ﻝﺎﺧﺩﺇ ﻖﺤﺑ ﻆﻔﺘﺤﻧ

    242 |

ﻲﺑﺮﻋ

2 610 016 614

|

 (2.3.11)

Bosch Power Tools

ﻞﻴﻐﺸﺘﻟﺍ

(

G

ﺓﺭﻮﺼﻟﺍ ﻊﺟﺍﺮﺗ) ﺯﺮﻔﻟﺍ ﻖﻤﻋ ﻂﺒﺿ

.ﺓﺄﻔﻄﻣ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻥﻮﻜﺗ ﺎﻣﺪﻨﻋ ﻂﻘﻓ ﺯﺮﻔﻟﺍ ﻖﻤﻋ ﻂﺒﺿ ﺯﻮﳚ

◀

:ﲇﻳ ﲈﻛ ﺯﺮﻔﻟﺍ ﻖﻤﻋ ﻂﺒﺿ ﻢﺘﻳ

ﻞﻐﺸﻟﺍ ﺔﻌﻄﻗ ﯽﻠﻋ ﺯﺮﻔﻟﺍ ﺔﻤﻘﻟ ﺎﲠ ﺖﺒﻛﺭ ﻲﺘﻟﺍ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﺐﻛﺭ

–

.ﺎﻬﺘﳉﺎﻌﻣ ﺏﻮﻏﺮﳌﺍ

 ﺔﺤﻴﻔﺻ ﺢﺒﺼﺗ ﺚﻴﺤﺑ

5

ﺯﺮﻔﻟﺍ ﻖﻤﻋ ﻂﺒﺿ ﺡﺎﺘﻔﻤﺑ ﺭﺍﻭﺪﻟﺍ ﺭﺰﻟﺍ ﻞﺣ

–

.ﺔﻛﺮﳊﺍ ﺔﻘﻴﻠﻃ

7

ﺓﺪﻋﺎﻘﻟﺍ

 ﻭﺃ ﯽﻠﻋﻸﻟ

7

ﺓﺪﻋﺎﻘﻟﺍ ﺔﺤﻴﻔﺻ ﻊﻓﺩ ﻝﻼﺧ ﻦﻣ ﺏﻮﻏﺮﳌﺍ ﺯﺮﻔﻟﺍ ﻖﻤﻋ ﻂﺒﺿﺍ

–

.ﻞﻔﺳﻷﺍ

.ﻞﻗﻷﺍ ﯽﻠﻋ ﻢﻣ

5

ﺭﺍﺪﻘﻤﺑ ﻞﻐﺸﻟﺍ ﺔﻌﻄﻗ ﻦﻋ ﻞﻐﺸﻟﺍ ﺓﺪﻋ ﺯﱪﺗ ﻥﺃ ﻲﻐﺒﻨﻳ

–

.

5

ﺯﺮﻔﻟﺍ ﻖﻤﻋ ﻂﺒﺿ ﺡﺎﺘﻔﻤﺑ ﺭﺍﻭﺪﻟﺍ ﺭﺰﻟﺍ ﺮﻳﻭﺪﺗ ﻢﻜﺣﺃ

–

ﻪﺤﺤﺻﻭ ﺔﻴﻠﻤﻌﻟﺍ ﺔﺑﺮﺠﺘﻟﺍ ﻝﻼﺧ ﻦﻣ ﻪﻄﺒﺿ ﹼﻢﺗﻱﺬﻟﺍ ﺯﺮﻔﻟﺍ ﻖﻤﻋ ﺺﺤﻔﺗ

–

.ﻚﻟﺫ ﺮﻣﻷﺍ ﺐﻠﻄﺗ ﻥﺇ

ﻞﻴﻐﺸﺘﻟﺍ ﺀﺪﺑ

ﻊﻣ ﺭﺎﻴﺘﻟﺍ ﻊﺒﻨﻣ ﺪﻬﺟ ﻖﺑﺎﻄﺘﻳ ﻥﺃ ﺐﳚ !ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺔﻜﺒﺸﻟﺍ ﺪﻬﺟ ﯽﻟﺇ ﻪﺒﺘﻧﺍ

◀

ﺩﺪﻌﻟﺍ ﻞﻴﻐﺸﺗ ﻢﺘﻳ ﻥﺃ ﻦﻜﻤﻳ .ﺯﺎﻬﳉﺍ ﺯﺍﺮﻃ ﺔﺤﺋﻻ ﯽﻠﻋ ﺓﺭﻮﻛﺬﳌﺍ ﺕﺎﻣﻮﻠﻌﳌﺍ

.ﺎﻀﻳﺃ ﻂﻟﻮﻓ

220

 ـﺑ ﻂﻟﻮﻓ

230

ـﺑ ﺓﺩﺪﺤﳌﺍ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ

ﺎﻘﺒﺴﻣ ﻥﺍﺭﻭﺪﻟﺍ ﺩﺪﻋ ﻂﺒﺿ

 ﺩﺪﻋ ﻂﺒﻀﺗ ﻥﺃ

10

ﹰﺎﻘﺒﺴﻣ ﻥﺍﺭﻭﺪﻟﺍ ﺩﺪﻋ ﻂﺒﺿ ﺔﻠﺠﻋ ﺔﻄﺳﺍﻮﺑ ﻚﻨﻜﻤﻳ

.ﻞﻴﻐﺸﺘﻟﺍ ﺀﺎﻨﺛﺃ ﯽﺘﺣ ﻖﺒﺴﻣ ﻞﻜﺸﺑ ﺏﻮﻠﻄﳌﺍ ﻥﺍﺭﻭﺪﻟﺍ

ﺾﻔﺨﻨﻣ ﻥﺍﺭﻭﺩ ﺩﺪﻋ

20

–

15

ﻂﺳﻮﺘﻣ ﻥﺍﺭﻭﺩ ﺩﺪﻋ

25

–

20

ﻊﻔﺗﺮﻣ ﻥﺍﺭﻭﺩ ﺩﺪﻋ

30

–

25

ﯽﻠﻋ ﺯﺎﻬﳉﺍ ﻞﻴﻐﺸﺗ ﻲﻐﺒﻨﻳ ﲑﻐﺻ ﻥﺍﺭﻭﺩ ﺩﺪﻌﺑ ﺔﻠﻳﻮﻃ ﺓﱰﻔﻟ ﻝﲈﻋﻷﺍ ﺬﻴﻔﻨﺗ ﺪﻌﺑ

.ﻩﺪﻳﱪﺗ ﻞﺟﺃ ﻦﻣ ﯽﺼﻗﻷﺍ ﻥﺍﺭﻭﺪﻟﺍ ﺩﺪﻌﺑ ﹰﺎﺒﻳﺮﻘﺗ ﻖﺋﺎﻗﺩ ﺙﻼﺛ ﺓﺪﳌ ﴈﺎﻔﻟﺍ

ﺀﺎﻔﻃﻹﺍﻭ ﻞﻴﻐﺸﺘﻟﺍ

 ﺔﻜﺒﺸﻟﺍ ﺲﺑﺎﻗ ﻞﺻﻭ ﻞﺒﻗ

9

ﺀﺎﻔﻃﻹﺍﻭ ﻞﻴﻐﺸﺘﻟﺍ ﺡﺎﺘﻔﻣ ﺀﺎﻔﻃﺇ ﻦﻣ ﺪﻛﺄﺗ

◀

ﺐﺒﺴﺘﻟ ﺩﻮﺼﻘﻣ ﲑﻏ ﻞﻜﺸﺑ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﺭﺍﺪﺗ ﺪﻘﻓ ﻻﺇﻭ

.ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ

.ﺕﺎﺑﺎﺻﻹﺍ

.

“

ﺯﺮﻔﻟﺍ ﻖﻤﻋ ﻂﺒﺿ

”

ﺓﺮﻘﻔﻟﺍ ﻊﺟﺍﺭ ،ﺀﺎﻔﻃﻹﺍﻭ ﻞﻴﻐﺸﺘﻟﺍ ﻞﺒﻗ ﺯﺮﻔﻟﺍ ﻖﻤﻋ ﻂﺒﺿﺍ

 ﯽﻟﺇ

9

 ﺀﺎﻔﻃﻹﺍﻭ ﻞﻴﻐﺸﺘﻟﺍ ﺡﺎﺘﻔﻣ ﻊﻓﺪﻳ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ

ﻞﻴﻐﺸﺗ

ﻞﺟﺃ ﻦﻣ

.ﻡﺎﻣﻷﺍ

 ﻞﻴﻐﺸﺘﻟﺍ ﺡﺎﺘﻔﻣ ﺔﻣﺪﻘﻣ ﺲﺒﻜﺗ

9

 ﺀﺎﻔﻃﻹﺍﻭ ﻞﻴﻐﺸﺘﻟﺍ ﺡﺎﺘﻔﻣ

ﺖﻴﺒﺜﺗ

ﻞﺟﺃ ﻦﻣ

.ﻖﺷﺎﻌﺘﻳ ﻥﺃ ﯽﻟﺇ ﻞﻔﺳﻸﻟ

9

ﺀﺎﻔﻃﻹﺍﻭ

 ﻞﻤﻌﻟﺍ ﻝﺎﳎ ﺓﺀﺎﺿﺈﺑ ﺢﻤﺴﻳﻭ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻞﻴﻐﺸﺗ ﺪﻨﻋ

8

ﺡﺎﺒﺼﳌﺍ ﺀﴤﻳ

.ﺔﻤﺋﻼﻣ ﲑﻐﻟﺍ ﺓﺀﺎﺿﻹﺍ ﻑﻭﺮﻇ ﰲ

 ﻥﺎﻛ ﻥﺇ ﺎﻣﺃ

9

 ﺀﺎﻔﻃﻹﺍﻭ ﻞﻴﻐﺸﺘﻟﺍ ﺡﺎﺘﻔﻣ ﻙﱰﻳ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ

ﺀﺎﻔﻃﺇ

ﻞﺟﺃ ﻦﻣ

 ﺔﻈﺤﻠﻟ ﻞﻔﺳﻸﻟ ﻒﻠﳋﺍ ﻦﻣ

9

ﺀﺎﻔﻃﻹﺍﻭ ﻞﻴﻐﺸﺘﻟﺍ ﺡﺎﺘﻔﻣ ﺲﺒﻜﻴﻓ ،ﻪﺘﻴﺒﺜﺗ ﻢﺗ ﺪﻗ

.ﻚﻟﺫ ﺪﻌﺑ ﻙﱰﻳ ﻢﺛ

ﺖﻴﺒﺜﺘﻟﺍ ﺔﻴﻧﻭﱰﻜﻟﺍ

ﻥﻭﺩ ﻞﻴﻐﺸﺘﻟﺍ ﺪﻨﻋ ﻥﺍﺭﻭﺪﻟﺍ ﺩﺪﻋ ﺕﺎﺒﺛ ﻪﺒﺷ ﯽﻠﻋ ﲏﻭﱰﻜﻟﻻﺍ ﺖﺒﺜﳌﺍ ﻆﻓﺎﳛ

.ﺔﻤﻈﺘﻨﻣ ﻞﻤﻋ ﺓﺭﺪﻗ ﻚﻟﺬﺑ ﻦﻣﺆﻳﻭ ﻞﲪ ﻊﻣ ﻞﻴﻐﺸﺘﻟﺍﻭ ﻞﲪ

ﺔﺋﺩﺎﻫ ﺓﺭﺍﺩﺈﺑ ﺀﺪﺒﻟﺍ

ﺓﺪﻣ ﻦﻣ ﺪﻳﺰﻳﻭ ﻞﻴﻐﺸﺘﻟﺍ ﺪﻨﻋ ﻥﺍﺭﻭﺪﻟﺍ ﻡﺰﻋ ﺪﳛ ﺎﻴﻧﻭﱰﻜﻟﺍ ﺔﺋﺩﺎﻫ ﺓﺭﺍﺩﺈﺑ ﺀﺪﺒﻟﺍ ﻥﺇ

.ﻙﺮﺤﳌﺍ ﺔﻴﺣﻼﺻ

ﻞﻐﺷ ﺕﺎﻈﺣﻼﻣ

(

I – H

ﺭﻮﺼﻟﺍ ﻊﺟﺍﺮﺗ) ﻊﻄﻘﳌﺍ ﺯﺮﻓ

.ﺕﺎﺒﻘﻌﻟﺍ ﻦﻣ ﺔﻴﺿﺭﻷﺍ ﺀﻼﺧ ﯽﻠﻋ ﺹﺮﺣﺍ

.ﻡﺎﻜﺣﺈﺑ ﻞﻐﺸﻟﺍ ﺔﻌﻄﻗ ﺪﺷ

–

12

ﻱﻭﺪﻴﻟﺍ ﺾﺒﻘﳌﺍ ﻞﺒﻗ ﻦﻣ ﻞﻤﻌﻟﺍ ﺀﺎﻨﺛﺃ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻚﺴﻣﺍ

–

.ﻡﺎﻜﺣﺈﺑ

ﺏﻮﻏﺮﳌﺍ ﻞﻐﺸﻟﺍ ﺔﻌﻄﻗ ﯽﻟﺇ ﺎﻬﻠﻴﻐﺸﺗ ﺪﻌﺑ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻪﺟﻭ

–

ﻦﻣ ﺎﻫﺭﺪﻗ ﺔﻳﻭﺍﺰﺑﻭ ﻒﻴﻔﺧ ﻂﻐﻀﺑ ﻞﻐﺸﻟﺍ ﺔﻌﻄﻗ ﰲ ﺎﻬﺴﻄﻏﺍﻭ ﺎﻬﺘﳉﺎﻌﻣ

.ﺔﻳﺮﺋﺍﺩ ﺔﻛﺮﺤﺑ ﺔﺟﺭﺩ

45°

–

30°

ﺭﺎﺴﻣ ﯽﻠﻋ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﺔﻄﺳﺍﻮﺑ ﺔﻔﻴﻔﺧ ﺾﻴﻔﲣﻭ ﻊﻓﺭ ﺕﺎﻛﺮﺣ ﺬﻔﻧ

–

.ﻊﻄﻘﳌﺍ ﻂﺧ

.ﻡﺎﻣﻷﺍ ﻮﺤﻧ ﻢﻈﺘﻨﻣ ﻊﻓﺪﺑ ﺯﺮﻔﻟﺍ ﺔﻴﻠﻤﻋ ﺬﻔﻧ

–

ﺔﻤﻘﻟ ﻒﻗﻮﺘﺗ ﻥﺃ ﻞﺒﻗ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻦﻛﺮﺗ ﻻ .ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﺊﻔﻃﺍ

–

.ﺔﻛﺮﳊﺍ ﻦﻋ ﺯﺮﻔﻟﺍ

(

L – J

ﺭﻮﺼﻟﺍ ﻊﺟﺍﺭ) ﺔﻴﺒﻠﻘﻟﺍ ﺐﻘﺜﻟﺍ ﺔﻤﻘﻟ ﺔﻄﺳﺍﻮﺑ ﺯﺮﻔﻟﺍ

 ﰲ ﻭﺃ ﻁﻼﺒﻟﺍ ﰲ ﺓﻮﺠﻓ ﺯﺮﻓ ﻞﺟﺃ ﻦﻣ

19

ﺔﻴﺒﻠﻘﻟﺍ ﺐﻘﺜﻟﺍ ﺔﻤﻘﻟ ﺐﻴﻛﺮﺗ ﻢﺘﻳ

.ﺭﺍﺪﳉﺍ

.ﻡﺎﻜﺣﺈﺑ ﻞﻐﺸﻟﺍ ﺔﻌﻄﻗ ﺪﺷ

–

12

ﻱﻭﺪﻴﻟﺍ ﺾﺒﻘﳌﺍ ﻞﺒﻗ ﻦﻣ ﻞﻤﻌﻟﺍ ﺀﺎﻨﺛﺃ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻚﺴﻣﺍ

–

.ﻡﺎﻜﺣﺈﺑ

ﻲﺑﺮﻋ

 |

243

Bosch Power Tools

2 610 016 614

|

 (2.3.11)

(

B

ﺓﺭﻮﺼﻟﺍ ﻊﺟﺍﺮﺗ) ﻂﺒﻀﻠﻟ ﺔﻠﺑﺎﻘﻟﺍ ﺓﺪﻋﺎﻘﻟﺍ ﺔﺤﻴﻔﺻ ﺐﻴﻛﺮﺗ

.ﺰﻳﺮﻔﺘﻟﺎﺑ ﻡﺎﻴﻘﻟﺍ ﻞﺟﺃ ﻦﻣ

7

ﺓﺪﻋﺎﻘﻟﺍ ﺔﺤﻴﻔﺻ ﺐﻴﻛﺮﺗ ﻢﺘﻳ ﻥﺃ ﺐﳚ

.

6

ﺪﺸﻟﺍ ﻉﺍﺭﺫ ﺢﺘﻓﺍ

–

ﺓﺪﻋﺎﻘﻟﺍ ﺔﺤﻴﻔﺼﺑ ﯽﻠﻋ ﺓﺩﻮﺟﻮﳌﺍ ﻚﻠﺗ ﻊﻣ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺎﺑ ﺔﻣﻼﻌﻟﺍ ﻖﺑﺎﻃ

–

.ﺓﺭﻮﺼﻟﺎﺑ ﲔﺒﻣ ﻮﻫ ﲈﻛ

7

.

6

 ﺪﺸﻟﺍ ﻉﺍﺭﺫ ﻖﻠﻏﺍﻭ ﻡﺩﺎﺼﺘﻟﺍ ﺪﺣ ﯽﻟﺇ

7

ﺓﺪﻋﺎﻘﻟﺍ ﺔﺤﻴﻔﺻ ﻊﻓﺩﺍ

–

(

C

ﺓﺭﻮﺼﻟﺍ ﻊﺟﺍﺮﺗ) ﻲﻗﻮﻄﻟﺍ ﻑﺮﻈﻟﺍ ﻝﺍﺪﺒﺘﺳﺍ

 ﺔﻤﻘﻟ ﺐﺴﺣ ﺯﺮﻔﻟﺍ ﺔﻤﻘﻟ ﺐﻴﻛﺮﺗ ﻞﺒﻗ

13

ﻲﻗﻮﻄﻟﺍ ﻑﺮﻈﻟﺍ ﻝﺍﺪﺒﺘﺳﺍ ﻲﻐﺒﻨﻳ

ﻊﺒﺗﺎﻓ ،ﺢﻴﺤﺼﻟﺍ ﻲﻗﻮﻄﻟﺍ ﻑﺮﻈﻟﺍ ﺐﻴﻛﺮﺗ ﻢﺗﻭ ﻖﺒﺳ ﻥﺇ.ﺔﻣﺪﺨﺘﺴﳌﺍ ﺯﺮﻔﻟﺍ

.

“

ﺯﺮﻔﻟﺍ ﻖﻤﻋ ﻂﺒﺿ

”

ﺓﺮﻘﻔﻟﺍ ﰲ ﺓﺭﻮﻛﺬﳌﺍ ﻞﻤﻌﻟﺍ ﺕﺍﻮﻄﺧ

 ﺐﳚ .ﻂﻴﺴﺑ ﻞﺨﻠﺨﺘﺑ ﻖﻧﺰﻟﺍ ﺔﻟﻮﻣﺎﺻ ﰲ

13

ﻲﻗﻮﻄﻟﺍ ﻑﺮﻈﻟﺍ ﺐﻛﺮﻳ ﻥﺃ ﺐﳚ

 ﺔﻟﻮﻣﺎﺼﺑ ﻒﻠﺗ ﻙﺎﻨﻫ ﻥﺎﻛ ﻥﺇ .ﺔﻟﻮﻬﺴﺑ ﺎﻬﺒﻴﻛﱰﺑ

3

ﻖﻧﺰﻟﺍ ﺔﻟﻮﻣﺎﺻ ﺢﻤﺴﺗ ﻥﺃ

.ﹰﺍﺭﻮﻓ ﲈﳍﺍﺪﺒﺘﺳﺍ ﺐﺟﻮﺗ ،ﻲﻗﻮﻄﻟﺍ ﻑﺮﻈﻟﺎﺑ ﻭﺃ ﻖﻧﺰﻟﺍ

 ﻞﺘﻓﺍ .ﹰﺎﺳﻮﺒﻜﻣ ﻪﺋﺎﻘﺑﺍ ﯽﻠﻋ ﻆﻓﺎﺣﻭ

15

ﻥﺍﺭﻭﺪﻟﺍ ﺭﻮﳏ ﺖﻴﺒﺜﺗ ﺡﺎﺘﻔﻣ ﺲﺒﻛﺍ

–

.ﻖﺷﺎﻌﺘﻳ ﻥﺃ ﯽﻟﺇ ﺪﻴﻟﺍ ﺔﻄﺳﺍﻮﺑ ﺓﺭﻭﴬﻟﺍ ﺪﻨﻋ ﻙﺮﺤﳌﺍ ﻥﺍﺭﻭﺩ ﺭﻮﳏ

.

1

 ﻚﻔﻟﺍ ﺡﻮﺘﻔﳌﺍ ﻂﺑﺮﻟﺍ ﺡﺎﺘﻔﻣ ﺔﻄﺳﺍﻮﺑ

3

ﺔﻴﻧﺍﻮﻄﺳﻻﺍ ﺔﻟﻮﻣﺎﺼﻟﺍ ﻚﻓ

–

.ﻥﺍﺭﻭﺪﻟﺍ ﺭﻮﳏ ﺖﻴﺒﺜﺗ ﺡﺎﺘﻔﻣ ﻖﻠﻃﺍ

–

ﺔﻄﺳﺍﻮﺑ ﺐﻴﻛﱰﻟﺍ ﻞﺒﻗ ﺓﺭﻭﴬﻟﺍ ﺪﻨﻋ ﺎﻬﺒﻴﻛﺮﺗ ﺏﻮﻏﺮﳌﺍ ﻊﻄﻘﻟﺍ ﻊﻴﲨ ﻒﻈﻧ

–

.ﻁﻮﻐﻀﳌﺍ ﺀﺍﻮﳍﺎﺑ ﺎﻬﺨﻔﻧ ﻝﻼﺧ ﻦﻣ ﻭﺃ ﺔﻳﺮﻃ ﺓﺎﺷﺮﻓ

.

14

ﺓﺪﻌﻟﺍ ﻦﺿﺎﺣ ﰲ ﺔﻴﻧﺍﻮﻄﺳﻻﺍ ﺔﻟﻮﻣﺎﺼﻟﺍ ﻢﹼﻘﻟ

–

.ﺔﻔﺨﺑ ﻖﻧﺰﻟﺍ ﺔﻟﻮﻣﺎﺻ ﺪﺷ

–

ﺐﻴﻛﺮﺗ ﹼﻢﺘﻳ ﱂ ﻡﺍﺩ ﺎﻣ ،ﹰﺍﺪﺑﺃ ﻖﻧﺰﻟﺍ ﺔﻟﻮﻣﺎﺼﺑ ﻲﻗﻮﻄﻟﺍ ﻑﺮﻈﻟﺍ ﺪﺷ ﻢﻜﲢ ﻻ

◀

.ﻲﻗﻮﻄﻟﺍ ﻑﺮﻈﻟﺍ ﻑﻼﺗﺇ ﯽﻟﺇ ﻚﻟﺫ ﻱﺩﺆﻳ ﺪﻗ

.ﺯﺮﻔﻟﺍ ﺔﻤﻘﻟ

(

D

ﺓﺭﻮﺼﻟﺍ ﻊﺟﺍﺮﺗ) ﺯﺮﻔﻟﺍ ﻢﻘﻟ ﺐﻴﻛﺮﺗ

ﻦﺨﺴﺗ

.ﺯﺮﻔﻟﺍ ﻢﻘﻟ ﻝﺍﺪﺒﺘﺳﺍﻭ ﺐﻴﻛﺮﺗ ﺪﻨﻋ ﺔﻴﻗﺍﻭ ﺕﺍﺯﺎﻔﻗ ﺀﺍﺪﺗﺭﺎﺑ ﺢﺼﻨﻳ

◀

.ﻞﻤﻌﻟﺍ ﺀﺎﻨﺛﺃ ﺯﺮﻔﻟﺍ ﻢﻘﻟ

ﺮﺟﺎﺘﻟﺍ یﺪﻟ ﻕﺎﻄﻨﻟﺍ ﻊﺳﺍﻮﻟﺍ ﺵﻮﺑ ﺞﻣﺎﻧﺮﺑ ﻦﻣ ﺔﻴﻠﺻﻷﺍ ﺯﺮﻔﻟﺍ ﺩﺪﻋ ﺮﻓﻮﺘﺗ

.ﺺﺘﺨﳌﺍ

.ﻂﻘﻓ ﺔﻔﻴﻈﻨﻟﺍﻭ ﺔﻤﻴﻠﺴﻟﺍ ﺯﺮﻔﻟﺍ ﻢﻘﻟ ﺐﻛﺭ

 ﻞﺘﻓﺍ .ﹰﺎﺳﻮﺒﻜﻣ ﻪﺋﺎﻘﺑﺍ ﯽﻠﻋ ﻆﻓﺎﺣﻭ

15

ﻥﺍﺭﻭﺪﻟﺍ ﺭﻮﳏ ﺖﻴﺒﺜﺗ ﺡﺎﺘﻔﻣ ﺲﺒﻛﺍ

–

.ﻖﺷﺎﻌﺘﻳ ﻥﺃ ﯽﻟﺇ ﺪﻴﻟﺍ ﺔﻄﺳﺍﻮﺑ ﺓﺭﻭﴬﻟﺍ ﺪﻨﻋ ﻙﺮﺤﳌﺍ ﻥﺍﺭﻭﺩ ﺭﻮﳏ

1

 ﻚﻔﻟﺍ ﺡﻮﺘﻔﳌﺍ ﻂﺑﺮﻟﺍ ﺡﺎﺘﻔﻣ ﺔﻄﺳﺍﻮﺑ

3

ﺔﻴﻧﺍﻮﻄﺳﻻﺍ ﺔﻟﻮﻣﺎﺼﻟﺍ ﻞﺣ

–

.

➊

 ﻩﺎﲡﻻﺍ ﯽﻟﺇ ﻩﺮﻳﻭﺪﺗ ﻝﻼﺧ ﻦﻣ (ﻢﻣ

17

ﺡﺎﺘﻔﳌﺍ ﺽﺮﻋ)

 ﺔﻣﻼﻌﻟﺍ ﺪﺣ ﯽﻟﺇ

13

 ﻲﻗﻮﻄﻟﺍ ﻑﺮﻈﻟﺍ ﻞﺧﺍﺩ ﯽﻟﺇ

16

ﺯﺮﻔﻟﺍ ﺔﻤﻘﻟ ﻊﻓﺩﺍ

–

.ﺎﺒﻳﺮﻘﺗ ﺓﺪﻌﻟﺍ ﻕﺎﺳ ﻦﻣ ﻢﻣ

5

ﺔﻳﺅﺭ ﺪﺣ ﯽﻟﺇ ﻭﺃ ﺯﺮﻔﻟﺍ ﺔﻤﻘﻟ ﻕﺎﺳ ﯽﻠﻋ

1

 ﻚﻔﻟﺍ ﺡﻮﺘﻔﳌﺍ ﻂﺑﺮﻟﺍ ﺡﺎﺘﻔﻣ ﺔﻄﺳﺍﻮﺑ

3

ﺔﻴﻧﺍﻮﻄﺳﻻﺍ ﺔﻟﻮﻣﺎﺼﻟﺍ ﺪﺷ

–

.ﻡﺎﻜﺣﺈﺑ

➋

 ﻩﺎﲡﻻﺍ ﯽﻟﺇ ﻩﺮﻳﻭﺪﺗ ﻝﻼﺧ ﻦﻣ (ﻢﻣ

17

ﺡﺎﺘﻔﳌﺍ ﺽﺮﻋ)

.ﻥﺍﺭﻭﺪﻟﺍ ﺭﻮﳏ ﺖﻴﺒﺜﺗ ﺡﺎﺘﻔﻣ ﻖﻠﻃﺍ

–

ﺐﻴﻛﺮﺗ ﹼﻢﺘﻳ ﱂ ﻡﺍﺩ ﺎﻣ ،ﹰﺍﺪﺑﺃ ﻖﻧﺰﻟﺍ ﺔﻟﻮﻣﺎﺼﺑ ﻲﻗﻮﻄﻟﺍ ﻑﺮﻈﻟﺍ ﺪﺷ ﻢﻜﲢ ﻻ

◀

.ﻲﻗﻮﻄﻟﺍ ﻑﺮﻈﻟﺍ ﻑﻼﺗﺇ ﯽﻟﺇ ﻚﻟﺫ ﻱﺩﺆﻳ ﺪﻗ

.ﺯﺮﻔﻟﺍ ﺔﻤﻘﻟ

ﺓﺭﺎﺸﻨﻟﺍ/ﺭﺎﺒﻐﻟﺍ ﻂﻔﺷ

ﺓﱪﻏﺃ) ﻲﻌﻴﺒﻄﻟﺍ ﺮﺠﳊﺍ ﻭﺃ (ﺰﺗﺭﺍﻮﻜﻟﺍ ﺓﱪﻏﺃ) ﻚﻴﻣﺍﴪﻟﺍ ﻁﻼﺑ ﺓﱪﻏﺃ ﻥﺇ

◀

ﺓﱪﻏﻷﺍ ﻕﺎﺸﻨﺘﺳﺍ ﻭﺃ ﺲﳌ ﻱﺩﺆﻳ ﺪﻗ .ﺔﺤﺼﻟﺎﺑ ﺓﴬﻣ ﻥﻮﻜﺗ ﺪﻗ (ﺕﺍﺰﻠﻔﻟﺍ

یﺪﻟ ﺔﻴﺴﻔﻨﺘﻟﺍ ﻱﺭﺎﺠﳌﺍ ﺽﺍﺮﻣﺃ ﯽﻟﺇ ﻭﺃ/ﻭ ﺔﻴﺴﺴﲢ ﻞﻌﻓ ﺩﻭﺩﺭ ﯽﻟﺇ

.ﻞﻤﻌﻟﺍ ﻥﺎﻜﻣ ﻦﻣ ﺔﺑﺮﻘﻣ ﯽﻠﻋ ﻦﻳﺩﻮﺟﻮﳌﺍ ﺹﺎﺨﺷﻷﺍ یﺪﻟ ﻭﺃ ﻡﺪﺨﺘﺴﳌﺍ

ﺔﺒﺒﺴﻣ ﺎﳖﺃ ﯽﻠﻋ ﻼﺜﻣ ﺰﺗﺭﺍﻮﻜﻟﺍ ﺓﱪﻏﺄﻛ ﺔﺻﺎﳋﺍ ﺓﱪﻏﻷﺍ ﺾﻌﺑ ﺪﻌﹸﺗ

ﻞﺒﻗ ﻦﻣ ﺱﻮﺘﺴﺒﺳﻷﺍ ﯽﻠﻋ ﻱﻮﺘﲢ ﻲﺘﻟﺍ ﺩﺍﻮﳌﺍ ﺔﳉﺎﻌﻤﺑ ﺢﻤﺴﻳ .ﻥﺎﻃﴪﻠﻟ

.ﻂﻘﻓ ﲔﺼﺼﺨﺘﳌﺍ ﻝﲈﻌﻟﺍ

.ﻥﺎﻜﻣﻹﺍ ﺭﺪﻗ ﺓﺩﲈﻠﻟ ﺔﻤﺋﻼﻣ ﺭﺎﺒﻏ ﺔﻄﻓﺎﺷ ﻡﺪﺨﺘﺳﺍ

–

.ﺪﻴﺟ ﻞﻜﺸﺑ ﻞﻐﺸﻟﺍ ﻥﺎﻜﻣ ﺔﻳﻮﲥ ﯽﻠﻋ ﻆﻓﺎﺣ

–

.

P2

 ﺢﺷﺮﳌﺍ ﺔﺌﻔﺑ ﺲﻔﻨﺘﻠﻟ ﺔﻳﺎﻗﻭ ﻉﺎﻨﻗ ﺀﺍﺪﺗﺭﺎﺑ ﺢﺼﻨﻳ

–

.ﺎﻬﺘﳉﺎﻌﻣ ﺏﻮﻏﺮﳌﺍ ﺩﺍﻮﻤﻠﻟ ﺔﺒﺴﻨﻟﺎﺑ ﻢﻛﺪﻠﺑ ﰲ ﺔﻳﺭﺎﺴﻟﺍ ﻡﺎﻜﺣﻷﺍ ﯽﻋﺍﺮﺗ

(

E

ﺓﺭﻮﺼﻟﺍ ﻊﺟﺍﺮﺗ) ﺔﻴﺋﺍﻮﺧ ﺭﺎﺒﻏ ﺔﻄﻓﺎﺷ ﻞﺻﻭ

ﻡﻮﻃﺮﺧ ﻞﺻ .

4

 ﻂﻔﺸﻟﺍ ﺔﻠﺻﻭ ﯽﻠﻋ (ﻊﺑﺍﻮﺗ)

17

ﻂﻔﺸﻟﺍ ﻡﻮﻃﺮﺧ ﺯﺮﻏﺍ

.(ﻊﺑﺍﻮﺗ) ﺔﻴﺋﺍﻮﺧ ﺭﺎﺒﻏ ﺔﻄﻓﺎﺸﺑ

17

ﻂﻔﺸﻟﺍ

ﺓﺩﺪﻌﺘﳌﺍ ﺔﻴﺋﺍﻮﳋﺍ ﺵﻮﺑ ﺔﻄﻓﺎﺷ ﺲﺒﻘﻤﺑ ﺓﴍﺎﺒﻣ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻂﺑﺭ ﻦﻜﻤﻳ

ﺪﻨﻋ ﱄﺁ ﻞﻜﺸﺑ ﺎﻬﻠﻴﻐﺸﺗ ﻢﺘﻳﻭ .ﺪﻌﺑ ﻦﻋ ﻞﻴﻐﺸﺘﻟﺍ ﺓﺰﻴﻬﺠﺘﺑ ﺓﺩﻭﺰﳌﺍ ﻝﲈﻌﺘﺳﻻﺍ

.ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻞﻴﻐﺸﺗ

ﺏﻮﻏﺮﳌﺍ ﻞﻐﺸﻟﺍ ﺓﺩﺎﻣ ﻊﻣ ﻝﲈﻌﺘﺳﻼﻟ ﺔﻴﺋﺍﻮﳋﺍ ﺭﺎﺒﻐﻟﺍ ﺔﻄﻓﺎﺷ ﺢﻠﺼﺗ ﻥﺃ ﺐﳚ

.ﺎﻬﺘﳉﺎﻌﻣ

ﻭﺃ ﺔﺤﺼﻟﺎﺑ ﺓﴬﳌﺍ ﺓﱪﻏﻷﺍ ﻂﻔﺷ ﺪﻨﻋ ﺔﺻﺎﺧ ﺔﻴﺋﺍﻮﺧ ﺭﺎﺒﻏ ﺔﻄﻓﺎﺷ ﻡﺪﺨﺘﺳﺍ

.ﻑﺎﻔﳉﺍ ﺓﺪﻳﺪﺸﻟﺍ ﻭﺃ ﻥﺎﻃﴪﻠﻟ ﺔﺒﺒﺴﳌﺍ

ﻡﻮﻃﺮﳋﺍ ﻞﻣﺎﺣ ﻦﺿﺎﺤﺑ ﻂﻔﺸﻟﺍ ﻡﻮﻃﺮﺧ ﻊﻣ ﻞﻣﺎﳊﺍ ﺐﻴﻛﺮﺗ

(

F

ﺓﺭﻮﺼﻟﺍ ﻊﺟﺍﺮﺗ)

 ﻞﻣﺎﺣ ﻦﺿﺎﺣ ﰲ ﲈﻬﻌﻓﺩ ﻝﻼﺧ ﻦﻣ

17

 ﻂﻔﺸﻟﺍ ﻡﻮﻃﺮﺧﻭ

18

ﻞﻣﺎﳊﺍ ﺖﺒﺛ

.

11

ﻡﻮﻃﺮﳋﺍ

    244 |

ﻲﺑﺮﻋ

2 610 016 614

|

 (2.3.11)

Bosch Power Tools

ﺔﻴﻨﻔﻟﺍ ﺕﺎﻧﺎﻴﺒﻟﺍ

GTR 30 CE

Professional

ﻁﻼﺑ ﺓﺯﺭﺎﻓ

3 601 F0C 0..

ﻒﻨﺼﻟﺍ ﻢﻗﺭ

701

ﻁﺍﻭ

ﺔﻴﻨﻘﳌﺍ ﺔﻴﻤﺳﻻﺍ ﺓﺭﺪﻘﻟﺍ

15 000

  – 30 000

١-

ﺔﻘﻴﻗﺩ

ﲇﲪﻼﻟﺍ ﻥﺍﺭﻭﺪﻟﺍ ﺩﺪﻋ

●

ﹰﺎﻘﺒﺴﻣ ﻥﺍﺭﻭﺪﻟﺍ ﺩﺪﻋ ﻂﺒﺿ

●

ﲏﻭﱰﻜﻟﻻﺍ ﺖﻴﺒﺜﺘﻟﺍ

●

ﺭﺎﺒﻐﻟﺍ ﻂﻔﺸﻟ ﺔﻠﺻﻭ

1,5

ﻎﻛ

ﺐﺴﺣ ﻥﺯﻮﻟﺍ

 EPTA-Procedure

01/2003

II

/

ﺔﻳﺎﻗﻮﻟﺍ ﺔﺌﻓ

 ﺎﻣﺪﻨﻋ ﻢﻴﻘﻟﺍ ﻩﺬﻫ ﺕﻭﺎﻔﺘﺗ ﺪﻗ .ﻂﻟﻮﻓ

230

 ﺭﺍﺪﻘﻤﺑ

[U]

ﻲﻤﺳﺍ ﺪﻬﳉ ﻝﻮﻌﻔﳌﺍ ﺔﻳﺭﺎﺳ ﻢﻴﻘﻟﺍ

.ﺔﻨﻴﻌﻣ ﻥﺍﺪﻠﺒﺑ ﺔﺻﺎﺧ ﺕﺍﺯﺍﺮﻄﺑ ﻭﺃ ﻚﻟﺫ ﻦﻋ ﺪﻬﳉﺍ ﻒﻠﺘﳜ

ﺕﺎﻴﻤﺴﺘﻟﺍ ﻒﻠﺘﲣ ﺪﻗ .ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﻚﺗﺪﻋ ﺯﺍﺮﻃ ﺔﺘﻓﻻ ﯽﻠﻋ ﻒﻨﺼﻟﺍ ﻢﻗﺭ ﺓﺎﻋﺍﺮﻣ ﯽﺟﺮﻳ

.ﺓﺩﺮﻔﳌﺍ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺩﺪﻌﻟﺍ ﺾﻌﺒﻟ ﺔﻳﺭﺎﺠﺘﻟﺍ

ﺕﺍﺯﺍﺰﺘﻫﻻﺍﻭ ﺞﻴﺠﻀﻟﺍ ﻦﻋ ﺕﺎﻣﻮﻠﻌﻣ

.

EN 60745

ﺐﺴﺣ ﺕﻮﺼﻟﺍ ﺕﺎﺳﺎﻴﻗ ﻢﻴﻗ ﺪﻳﺪﲢ ﻢﺗ

ﺕﻮﺼﻟﺍ ﻂﻐﺿ یﻮﺘﺴﻣ :ﺓﺩﺎﻋ (

A

ﻉﻮﻧ) ﺯﺎﻬﳉﺍ ﺞﻴﺠﺿ یﻮﺘﺴﻣ ﺔﻤﻴﻗ ﻎﻠﺒﺗ

.(

A

 ﻉﻮﻧ) ﻞﺒﻴﺴﻳﺩ

93

ﺕﻮﺼﻟﺍ ﺓﺭﺪﻗ یﻮﺘﺴﻣ .(

A

 ﻉﻮﻧ) ﻞﺒﻴﺴﻳﺩ

82

.ﻞﺒﻴﺴﻳﺩ

3 = K

ﺱﺎﻴﻘﻟﺍ ﺏﺍﺮﻄﺿﺍ

!ﻊﻤﺳ ﺔﻴﻗﺍﻭ ﺪﺗﺭﺍ

(ﺕﺎﻫﺎﲡﺍ ﺔﺛﻼﺜﺑ ﺕﺎﻬﺠﺘﳌﺍ ﻉﻮﻤﳎ) ﺔﻴﻟﺎﲨﻻﺍ ﺕﺍﺯﺍﺰﺘﻫﻻﺍ ﻢﻴﻗ ﺱﺎﻴﻗ ﻢﺗ

:

EN 60745

ﺐﺴﺣ

ﺱﺎﻴﻘﻟﺍ ﺕﻭﺎﻔﺗ ،

٢

ﺎﺛ/ﻡ

4,5 = a

h

ﺕﺍﺯﺍﺰﺘﻫﻻﺍ ﺙﺎﻌﺘﺑﺍ ﺔﻤﻴﻗ

.

٢

ﺎﺛ/ﻡ

1,5 = K

ﺏﻮﻠﺳﺍ ﺐﺴﺣ ﻩﺬﻫ ﺕﲈﻴﻠﻌﺘﻟﺍ ﰲ ﺭﻮﻛﺬﳌﺍ ﺕﺍﺯﺍﺰﺘﻫﻻﺍ یﻮﺘﺴﻣ ﺱﺎﻴﻗ ﻢﺗ ﺪﻘﻟ

 ﺩﺪﻌﻟﺍ ﺔﻧﺭﺎﻘﳌ ﻪﻣﺍﺪﺨﺘﺳﺍ ﻦﻜﻤﻳﻭ

EN 60745

ﻦﻤﺿ ﲑﻌﻣ ﺱﺎﻴﻗ

ﺕﺍﺯﺍﺰﺘﻫﻼﻟ ﺽﺮﻌﺘﻟﺍ ﺮﻳﺪﻘﺘﻟ ﻢﺋﻼﻣ ﻪﻧﺃ ﲈﻛ .ﺾﻌﺒﻟﺍ ﺎﻬﻀﻌﺒﺑ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ

.ﻲﺋﺪﺒﻣ ﻞﻜﺸﺑ

ﺓﺪﻌﻠﻟ ﺔﻴﺳﺎﺳﻻﺍ ﺕﺎﻣﺍﺪﺨﺘﺳﻻﺍ ﺭﻮﻛﺬﳌﺍ ﺕﺍﺯﺍﺰﺘﻫﻻﺍ یﻮﺘﺴﻣ ﻞﺜﻤﻳ

ﺩﺪﻌﺑ یﺮﺧﺃ ﺕﺎﻣﺍﺪﺨﺘﺳﻻ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻝﲈﻌﺘﺳﺍ ﻢﺗ ﻥﺇ ﲈﻨﻴﺑ .ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ

ﺪﻳﺰﻳ ﺪﻗﻭ .ﺕﺍﺯﺍﺰﺘﻫﻻﺍ یﻮﺘﺴﻣ ﻒﻠﺘﳜ ﺪﻘﻓ ،ﺔﻴﻓﺎﻛ ﲑﻏ ﺔﻧﺎﻴﺼﺑ ﻭﺃ ﺔﻔﻟﺎﳐ ﻞﻐﺷ

.ﺢﺿﺍﻭ ﻞﻜﺸﺑ ﻞﻐﺸﻟﺍ ﺓﱰﻓ ﻝﺍﻮﻃ ﺕﺍﺯﺍﺰﺘﻫﻼﻟ ﺽﺮﻌﺘﻟﺍ ﻚﻟﺫ

ﺓﺎﻋﺍﺮﻣ ﻢﺘﻳ ﻥﺃ ،ﻖﻴﻗﺩ ﻞﻜﺸﺑ ﺕﺍﺯﺍﺰﺘﻫﻼﻟ ﺽﺮﻌﺘﻟﺍ ﺮﻳﺪﻘﺗ ﻞﺟﺃ ﻦﻣ ﻲﻐﺒﻨﻳ ﲈﻛ

ﻪﻠﻴﻐﺸﺗ ﻥﻭﺩ ﻦﻜﻟﻭ ﺎﲠ ﻞﻤﻌﻳ ﻲﺘﻟﺍ ﻭﺃ ﺯﺎﻬﳉﺍ ﺎﳍﻼﺧ ﺄﻔﻄﻳ ﻲﺘﻟﺍ ﺕﺎﻗﻭﻷﺍ

ﱪﻋ ﺢﺿﺍﻭ ﻞﻜﺸﺑ ﺕﺍﺯﺍﺰﺘﻫﻼﻟ ﺽﺮﻌﺘﻟﺍ ﻚﻟﺫ ﺾﻔﳜ ﺪﻗﻭ .ﻼﻌﻓ ﻞﻤﺤﺑ

.ﻞﻤﻌﻟﺍ ﺓﺪﻣ ﻞﻣﺎﻛ

:ﻼﺜﻣ ،ﺕﺍﺯﺍﺰﺘﻫﻻﺍ ﲑﺛﺄﺗ ﻦﻣ ﻡﺪﺨﺘﺴﳌﺍ ﺔﻳﺎﻗﻮﻟ ﺔﻴﻓﺎﺿﺇ ﻥﺎﻣﺃ ﺕﺍﺀﺍﺮﺟﺇ ﺩﺪﺣ

.ﻞﻤﻌﻟﺍ ﺕﺎﻳﺮﳎ ﻢﻴﻈﻨﺗﻭ ﻦﻳﺪﻴﻟﺍ ﺔﺌﻓﺪﺗ ،ﻞﻐﺸﻟﺍ ﺩﺪﻋﻭ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﺔﻧﺎﻴﺻ

ﻖﻓﺍﻮﺘﻟﺍ ﺢﻳﴫﺗ

ﻖﻓﺍﻮﺘﻳ

“

ﺔﻴﻨﻔﻟﺍ ﺕﺎﻧﺎﻴﺒﻟﺍ

”

ﰲ ﻑﻮﺻﻮﳌﺍ ﺞﺘﻨﳌﺍ ﻥﺄﺑ ،ﺎﻨﺘﻴﻟﻭﺆﺴﻣ ﯽﻠﻋ ﺡﴫﻧ ﺎﻨﻧﺇ

 ﻡﺎﻜﺣﺃ ﺐﺴﺣ

EN 60745

:ﺔﻴﻟﺎﺘﻟﺍ ﺔﻳﺭﺎﻴﻌﳌﺍ ﻖﺋﺎﺛﻮﻟﺍ ﻭﺃ ﲑﻳﺎﻌﳌﺍ ﻊﻣ

.

2006/42/EG

 ،

2004/108/EG

ﺕﺍﺩﺎﺷﺭﺇ

:یﺪﻟ ﺔﻴﻨﻔﻟﺍ ﻕﺍﺭﻭﻷﺍ

Robert Bosch GmbH, PT/ESC,

D-70745 Leinfelden-Echterdingen

Dr. Eckerhard Strötgen

Head of Product

Certification

Dr. Egbert Schneider

Senior Vice President

Engineering

Robert Bosch GmbH, Power Tools Division

D-70745 Leinfelden-Echterdingen

05.08.2010

ﺐﻴﻛﱰﻟﺍ

ﯽﻠﻋ ﻞﻤﻋ ﻱﺃ ﺀﺍﺮﺟﺇ ﻞﺒﻗ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺔﻜﺒﺸﻟﺍ ﺲﺒﻘﻣ ﻦﻣ ﺲﺑﺎﻘﻟﺍ ﺐﺤﺳﺍ

◀

.ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ

(

A

ﺓﺭﻮﺼﻟﺍ ﻊﺟﺍﺮﺗ) ﺾﺒﻘﻟﺍ ﲑﺳ ﻂﺒﺿ

ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺎﺑ ﻞﻤﻌﻟﺍ ﻥﲈﻀﻟ ﻙﺪﻳ ﻢﺠﺣ ﺐﺳﺎﻨﻴﻟ ﺾﺒﻘﻟﺍ ﲑﺳ ﻂﺒﺿﺍ

◀

.ﻦﻣﺁ ﻞﻜﺸﺑ

.

2

ﺾﺒﻘﻟﺍ ﲑﺴﺑ ﻕﺯﻼﻟﺍ ﻞﻔﻘﻟﺍ ﺢﺘﻓﺍ

–

ﺐﻠﻄﺗ ﻥﺇ ﺓﲑﺼﻘﻟﺍ ﺓﻭﺮﻌﻟﺍ ﻖﻠﻏﺍﻭ ﻙﺪﻳ ﺔﻄﺳﺍﻮﺑ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻚﺴﻣﺍ

–

.ﻚﻟﺫ ﺮﻣﻷﺍ

.ﻕﺯﻼﻟﺍ ﻞﻔﻘﻟﺍ ﻖﻠﻏﺍﻭ

2

ﺾﺒﻘﻟﺍ ﲑﺴﺑ ﺔﻠﻳﻮﻄﻟﺍ ﺓﻭﺮﻌﻟﺍ ﺪﺷ

–

ﻲﺑﺮﻋ

 |

245

Bosch Power Tools

2 610 016 614

|

 (2.3.11)

ﺯﻮﻣﺮﻟﺍ

ﻝﲈﻌﺘﺳﺍ ﯽﻠﻋ ﺢﻴﺤﺻ ﻞﻜﺸﺑ ﺯﻮﻣﺮﻟﺍ ﲑﺴﻔﺗ ﻙﺪﻋﺎﺴﻳ .ﺎﻫﺎﻨﻌﻣﻭ ﺯﻮﻣﺮﻟﺍ ﻆﻔﺣ ﯽﺟﺮﻳ .ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﻚﺗﺪﻋ ﻝﲈﻌﺘﺳﺍ ﻞﺟﺃ ﻦﻣ ﺔﻴﳘﺃ ﺕﺍﺫ ﺔﻴﻟﺎﺘﻟﺍ ﺯﻮﻣﺮﻟﺍ ﻥﻮﻜﺗ ﺪﻗ

.ﹰﺎﻧﺎﻣﺃ ﺮﺜﻛﺃﻭ ﻞﻀﻓﺍ ﺔﻘﻳﺮﻄﺑ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﻚﺗﺪﻋ

ﺰﻣﺮﻟﺍ

ﯽﻨﻌﳌﺍ

.ﺔﻴﻗﺍﻭ ﺕﺍﺭﺎﻈﻧ ﺪﺗﺭﺍ

◀

.ﻊﻤﺴﻟﺍ ﺓﺭﺪﻗ ﻥﺍﺪﻘﻓ ﯽﻟﺇ ﺞﻴﺠﻀﻟﺍ ﲑﺛﺄﺗ ﻱﺩﺆﻳ ﺪﻗ

.ﻊﻤﺳ ﺔﻴﻗﺍﻭ ﺪﺗﺭﺍ

◀

.ﺭﺎﺒﻐﻟﺍ ﻦﻣ ﺔﻳﺎﻗﻮﻠﻟ ﻉﺎﻨﻗ ﺪﺗﺭﺍ

◀

ﺀﺍﺩﻷﺍﻭ ﺞﹶﺘﻨﳌﺍ ﻒﺻﻭ

ﺏﺎﻜﺗﺭﺍ ﻥﺇ

.ﺕﲈﻴﻠﻌﺘﻟﺍﻭ ﺔﻳﺮﻳﺬﺤﺘﻟﺍ ﺕﺎﻈﺣﻼﳌﺍ ﻊﻴﲨ ﺃﺮﻗﺍ

ﺕﲈﻴﻠﻌﺘﻟﺍﻭ ﺔﻳﺮﻳﺬﺤﺘﻟﺍ ﺕﺎﻈﺣﻼﳌﺍ ﻖﻴﺒﻄﺗ ﺪﻨﻋ ﺀﺎﻄﺧﻷﺍ

ﻖﺋﺍﺮﳊﺍ ﺏﻮﺸﻧ ﯽﻟﺇ ،ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺕﺎﻣﺪﺼﻟﺍ ﯽﻟﺇ ﻱﺩﺆﻳ ﺪﻗ

.ﺓﲑﻄﺧ ﺡﻭﺮﺠﺑ ﺔﺑﺎﺻﻹﺍ ﻭﺃ/ﻭ

ﻙﺮﺗﻭ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﺭﻮﺻ ﻦﻤﻀﺘﺗ ﻲﺘﻟﺍ ﻲﻨﺜﻠﻟ ﺔﻠﺑﺎﻘﻟﺍ ﺔﺤﻔﺼﻟﺍ ﺢﺘﻓ ﯽﺟﺮﻳ

.ﻝﲈﻌﺘﺳﻻﺍ ﺔﺳﺍﺮﻛ ﺓﺀﺍﺮﻗ ﺀﺎﻨﺛﺃ ﺔﺣﻮﺘﻔﻣ ﺔﺤﻔﺼﻟﺍ ﻩﺬﻫ

ﺺﺼﺨﳌﺍ ﻝﲈﻌﺘﺳﻻﺍ

،ﺖﻴﻧﺍﺮﻐﻟﺍ ،ﻚﻴﻣﺍﲑﺴﻟﺍ) ﻁﻼﺒﻟﺍ ﺯﺮﻓﻭ ﺐﻘﺜﻟ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﺖﺼﺼﺧ ﺪﻘﻟ

.ﺀﺎﳌﺍ ﻡﺍﺪﺨﺘﺳﺍ ﻥﻭﺩ (ﻲﻌﻴﺒﻄﻟﺍ ﺮﺠﳊﺍﻭ ﻲﻋﺎﻨﺼﻟﺍ ﺮﺠﳊﺍ ،ﻡﺎﺧﺮﻟﺍ

ﺓﺭﻮﺼﳌﺍ ﺀﺍﺰﺟﻷﺍ

ﰲ ﺓﺩﻮﺟﻮﳌﺍ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻡﻮﺳﺭ ﯽﻟﺇ ﺓﺭﻮﺼﳌﺍ ﺀﺍﺰﺟﻷﺍ ﻢﻴﻗﺮﺗ ﺪﻨﺘﺴﻳ

.ﺔﻴﻄﻴﻄﺨﺘﻟﺍ ﻡﻮﺳﺮﻟﺍ ﺔﺤﻔﺻ

ﻢﻣ

17

ﺡﺎﺘﻔﳌﺍ ﺽﺮﻋ ﻚﻔﻟﺍ ﺡﻮﺘﻔﻣ ﻂﺑﺭ ﺡﺎﺘﻔﻣ

 1

ﺾﺒﻘﻟﺍ ﲑﺳ

 2

ﺔﻴﻧﺍﻮﻄﺳﺍ ﺔﻟﻮﻣﺎﺻ

 3

ﻂﻔﺷ ﺔﻠﺻﻭ

 4

ﺯﺮﻔﻟﺍ ﻖﻤﻋ ﻂﺒﻀﻟ ﺭﺍﻭﺩ ﺭﺯ

 5

ﺪﺷ ﻉﺍﺭﺫ

 6

ﺐﻠﻘﻠﻟ ﺔﻠﺑﺎﻗ ﺓﺪﻋﺎﻗ ﺔﺤﻴﻔﺻ

 7

ﺡﺎﺒﺼﻣ

 8

ﺀﺎﻔﻃﻹﺍﻭ ﻞﻴﻐﺸﺘﻟﺍ ﺡﺎﺘﻔﻣ

 9

ﹰﺎﻘﺒﺴﻣ ﻥﺍﺭﻭﺪﻟﺍ ﺩﺪﻋ ﻂﺒﺿ ﺔﻠﺠﻋ

 10

ﻡﻮﻃﺮﳋﺍ ﻞﻣﺎﺣ ﻦﺿﺎﺣ

 11

(ﻝﻭﺰﻌﻣ ﺾﺒﻘﻟﺍ ﺢﻄﺳ) ﻱﻭﺪﻳ ﺾﺒﻘﻣ

 12

ﻲﻗﻮﻃ ﻑﺮﻇ

 13

ﺓﺪﻌﻟﺍ ﻦﺿﺎﺣ

 14

ﻥﺍﺭﻭﺪﻟﺍ ﺭﻮﳏ ﺖﻴﺒﺜﺗ ﺭﺯ

 15

*

ﺯﺮﻔﻟﺍ ﺔﻤﻘﻟ

 16

*

ﻂﻔﺸﻟﺍ ﻡﻮﻃﺮﺧ

 17

*

ﻂﻔﺸﻟﺍ ﻡﻮﻃﺮﺧ ﻞﻣﺎﺣ

 18

*

ﺔﻴﺒﻠﻗ ﺐﻘﺛ ﺔﻤﻘﻟ

 19

 ﺔﻠﻣﺎﻜﻟﺍ ﻊﺑﺍﻮﺘﻟﺍ ﯽﻠﻋ ﺮﺜﻌﻳ .ﺔﻓﻮﺻﻮﳌﺍ ﻭﺃ ﺓﺭﻮﺼﳌﺍ ﻊﺑﺍﻮﺘﻟﺍ ﻱﺩﺎﻴﺘﻋﻻﺍ ﺪﻳﺭﻮﺘﻟﺍ ﺭﺎﻃﺇ ﻦﻤﻀﺘﻳ ﻻ

*

.ﻊﺑﺍﻮﺘﻠﻟ ﺎﻨﳎﺎﻧﺮﺑ ﰲ

    246 |

ﻲﺑﺮﻋ

2 610 016 614

|

 (2.3.11)

Bosch Power Tools

ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺩﺪﻌﻟﺍ ﻡﺍﺪﺨﺘﺳﺍﻭ ﺔﻠﻣﺎﻌﻣ ﻦﺴﺣ

 (4

 ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻚﻟﺎﻐﺷﺃ ﺬﻴﻔﻨﺘﻟ ﻡﺪﺨﺘﺳﺍ .ﺯﺎﻬﳉﺍ ﻞﻴﻤﺤﺘﺑ ﻁﺮﻔﺗ ﻻ

(a

ﺔﻄﺳﺍﻮﺑ ﹰﺎﻧﺎﻣﺃ ﺮﺜﻛﺃﻭ ﻞﻀﻓﺃ ﻞﻜﺸﺑ ﻞﻤﻌﺗ ﻚﻧﺇ

.ﻚﻟﺬﻟ ﺔﺼﺼﺨﳌﺍ

.ﺭﻮﻛﺬﳌﺍ ﺀﺍﺩﻷﺍ ﻝﺎﳎ ﰲ ﺔﻤﺋﻼﳌﺍ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ

ﺓﺪﻌﻟﺍ

 .ﻒﻟﺎﺗ ﺎﻬﻠﻴﻐﺸﺗ ﺡﺎﺘﻔﻣ ﻥﺎﻛ ﻥﺇ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻡﺪﺨﺘﺴﺗ ﻻ

(b

ﺐﳚﻭ ﺓﲑﻄﺧ ﺎﻬﺋﺎﻔﻃﺈﺑ ﻭﺃ ﺎﻬﻠﻴﻐﺸﺘﺑ ﺢﻤﺴﺗ ﺪﻌﺗ ﱂ ﻲﺘﻟﺍ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ

.ﺎﻬﺤﻴﻠﺼﺗ ﹼﻢﺘﻳ ﻥﺃ

 ﺯﺎﻬﳉﺍ ﻂﺒﺿ ﻞﺒﻗ ﻢﻛﺮﳌﺍ ﻉﺰﻧﺍ ﻭﺃ/ﻭ ﺲﺒﻘﳌﺍ ﻦﻣ ﺲﺑﺎﻘﻟﺍ ﺐﺤﺳﺍ

(c

ﻊﻨﲤ

.ﹰﺎﺒﻧﺎﺟ ﺯﺎﻬﳉﺍ ﻊﺿﻭ ﻞﺒﻗ ﻭﺃ ﻊﺑﺍﻮﺘﻟﺍ ﻊﻄﻗ ﻝﺍﺪﺒﺘﺳﺍ ﻞﺒﻗﻭ

ﲑﻏ ﻞﻜﺸﺑ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻞﻴﻐﺸﺗ ﻩﺬﻫ ﻁﺎﻴﺘﺣﻻﺍ ﺕﺍﺀﺍﺮﺟﺇ

.ﺩﻮﺼﻘﻣ

 ﻝﺎﻨﻣ ﻦﻋ ﹰﺍﺪﻴﻌﺑ ﺎﻬﻣﺍﺪﺨﺘﺳﺍ ﹼﻢﺘﻳ ﻻ ﻲﺘﻟﺍ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺩﺪﻌﻟﺎﺑ ﻆﻔﺘﺣﺍ

(d

ﻪﻟ ﺓﱪﺧ ﻻ ﻦﳌ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻡﺍﺪﺨﺘﺳﺎﺑ ﺢﻤﺴﺗ ﻻ .ﻝﺎﻔﻃﻷﺍ

ﹼﻢﺗ ﻥﺇ ﺓﲑﻄﺧ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺩﺪﻌﻟﺍ

.ﺕﲈﻴﻠﻌﺘﻟﺍ ﻚﻠﺗ ﺃﺮﻘﻳ ﱂ ﻦﳌ ﻭﺃ ﺎﲠ

.ﺓﱪﺧ ﻥﻭﺩ ﺹﺎﺨﺷﺃ ﻞﺒﻗ ﻦﻣ ﺎﻬﻣﺍﺪﺨﺘﺳﺍ

 ﺀﺍﺰﺟﺃ ﺖﻧﺎﻛ ﺍﺫﺇ ﲈﻋ ﺺﺤﻔﺗ .ﺪﻴﺟ ﻞﻜﺸﺑ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺎﺑ ﻦﺘﻋﺍ

(e

ﻦﻋ ﺔﻴﺼﻌﺘﺴﻣ ﲑﻏ ﺎﳖﺄﺑﻭ ﻢﻴﻠﺳ ﻞﻜﺸﺑ ﻞﻤﻌﺗ ﺔﻛﺮﺤﺘﳌﺍ ﺯﺎﻬﳉﺍ

ﺮﺛﺆﺗ ﺔﺟﺭﺪﻟ ﺔﻔﻟﺎﺗ ﻭﺃ ﺓﺭﻮﺴﻜﻣ ﺀﺍﺰﺟﺃ ﻙﺎﻨﻫ ﺖﻧﺎﻛ ﻥﺇ ﻭﺃ ﺔﻛﺮﳊﺍ

ﺀﺍﺰﺟﻷﺍ ﻩﺬﻫ ﺢﻴﻠﺼﺗ ﻲﻐﺒﻨﻳ .ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﺀﺍﺩﺃ ﻦﺴﺣ ﯽﻠﻋ ﺎﻬﻴﻓ

ﺎﻫﺭﺪﺼﻣ ﺙﺩﺍﻮﳊﺍ ﻦﻣ ﲑﺜﻜﻟﺍ

.ﺯﺎﻬﳉﺍ ﻞﻴﻐﺸﺗ ﺓﺩﺎﻋﺇ ﻞﺒﻗ ﺔﻔﻟﺎﺘﻟﺍ

.ﺀﻱﺩﺭ ﻞﻜﺸﺑ ﺎﻬﺘﻧﺎﻴﺻ ﹼﻢﺗﻲﺘﻟﺍ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺩﺪﻌﻟﺍ

ﺕﺍﺫ ﻊﻄﻘﻟﺍ ﺩﺪﻋ ﻥﺇ

 .ﺓﺩﺎﺣﻭ ﺔﻔﻴﻈﻧ ﻊﻄﻘﻟﺍ ﺩﺪﻋ ﺀﺎﻘﺑﺇ ﯽﻠﻋ ﻆﻓﺎﺣ

(f

ﻞﻗﺃ ﻞﻜﺸﺑ ﺐﻠﻜﺘﺗ ﺔﻳﺎﻨﻌﺑ ﺎﻬﺘﻧﺎﻴﺻ ﹼﻢﺗ ﻲﺘﻟﺍﺓﺩﺎﳊﺍ ﻊﻄﻘﻟﺍ ﻑﺍﻮﺣ

.ﴪﻳﺃ ﻞﻜﺸﺑ ﺎﻬﻬﻴﺟﻮﺗ ﻦﻜﻤﻳﻭ

 ﻩﺬﻫ ﺐﺴﺣ .ﺦﻟﺇﻭ ﻞﻐﺸﻟﺍ ﺩﺪﻋﻭ ﻊﺑﺍﻮﺘﻟﺍﻭ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺩﺪﻌﻟﺍ ﻡﺪﺨﺘﺳﺍ

(g

.ﻩﺬﻴﻔﻨﺗ ﺩﺍﺮﳌﺍ ﻞﻤﻌﻟﺍﻭ ﻞﻐﺸﻟﺍ ﻁﻭﴍ ﻚﻟﺫ ﺀﺎﻨﺛﺃ ﯽﻋﺍﺮﺗ .ﺕﲈﻴﻠﻌﺘﻟﺍ

ﺪﻗ ﺎﻬﻠﺟﻷ ﺔﺼﺼﺨﳌﺍ ﻝﺎﻐﺷﻷﺍ ﲑﻐﻟ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺩﺪﻌﻟﺍ ﻡﺍﺪﺨﺘﺳﺍ

.ﺓﲑﻄﳋﺍ ﺕﻻﺎﳊﺍ ﺙﻭﺪﺣ ﯽﻟﺇ ﻱﺩﺆﻳ

ﺔﻣﺪﳋﺍ

 (5

 ﲔﺼﺼﺨﺘﳌﺍ ﻝﲈﻌﻟﺍ ﻞﺒﻗ ﻦﻣ ﻂﻘﻓ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﻚﺗﺪﻋ ﺢﻴﻠﺼﺘﺑ ﺢﻤﺳﺍ

(a

ﯽﻠﻋ ﺔﻈﻓﺎﺤﳌﺍ ﻚﻟﺫ ﻦﻣﺆﻳ

.ﺔﻴﻠﺻﻷﺍ ﺭﺎﻴﻐﻟﺍ ﻊﻄﻗ ﻝﲈﻌﺘﺳﺎﺑ ﻂﻘﻓﻭ

.ﺯﺎﻬﳉﺍ ﻥﺎﻣﺃ

ﺰﻳﺮﻔﺘﻟﺍ ﺕﺎﻨﻴﻛﺎﳌ ﻥﺎﻣﻷﺍ ﺕﲈﻴﻠﻌﺗ

ﻥﺃ ﺫﺇ ،ﻂﻘﻓ ﺔﻟﻭﺰﻌﳌﺍ ﺾﺒﻘﻟﺍ ﺡﻮﻄﺳ ﻞﺒﻗ ﻦﻣ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺎﺑ ﻚﺴﻣﺍ

◀

.ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺎﺑ ﺹﺎﳋﺍ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺔﻜﺒﺸﻟﺍ ﻞﺒﻛ ﺐﻴﺼﺗ ﺪﻗ ﺯﺮﻔﻟﺍ ﺔﻤﻘﻟ

ﺎﻀﻳﺃ ﺏﺮﻬﻜﺗ ﺪﻗ ﻲﺋﺎﺑﺮﻬﻛ ﺪﻬﺟ ﺎﲠ ﻱﴪﻳ ﻲﺘﻟﺍ ﻁﻮﻄﳋﺍ ﺔﺴﻣﻼﻣ ﻥﺇ

.ﺔﻴﺋﺎﺑﺮﻬﻛ ﺔﻣﺪﺻ ﱃﺇ ﻚﻟﺫ ﻱﺩﺆﻴﻓ ،ﺯﺎﻬﳉﺎﺑ ﺔﻴﻧﺪﻌﳌﺍ ﺀﺍﺰﺟﻷﺍ

ﺔﻘﻳﺮﻄﺑ ﻭﺃ ﻡﺯﻼﳌﺍ ﺔﻄﺳﺍﻮﺑ ﺔﺘﺑﺎﺛ ﺔﻴﺿﺭﺃ ﯽﻠﻋ ﻞﻐﺸﻟﺍ ﺔﻌﻄﻗ ﻦﹼﻣﺃﻭ ﺖﹼﺒﺛ

◀

ﻝﻼﺧ ﻦﻣ ﻭﺃ ﻂﻘﻓ ﻙﺪﻳ ﺔﻄﺳﺍﻮﺑ ﻞﻐﺸﻟﺍ ﺔﻌﻄﻘﺑ ﺖﻜﺴﻣﺃ ﻥﺇ

.یﺮﺧﺃ

ﻥﺍﺪﻘﻓ ﯽﻟﺇ ﻱﺩﺆﻳ ﺪﻗ ﺎﳑ ،ﺔﺘﺑﺎﺛ ﲑﻏ ﯽﻘﺒﺘﺳ ﺎﳖﺈﻓ ،ﻙﺪﺴﺟ ﻮﺤﻧ ﺎﻬﻄﻐﺿ

.ﻢﻜﺤﺘﻟﺍ

ﻥﺍﺭﻭﺪﻟﺍ ﺩﺪﻋ ﻞﻗﻷﺍ ﯽﻠﻋ ﺡﻮﻤﺴﳌﺍ ﻞﻐﺸﻟﺍ ﺓﺪﻋ ﻥﺍﺭﻭﺩ ﺩﺪﻋ ﻖﺑﺎﻄﻳ ﻥﺃ ﺐﳚ

◀

ﺭﻭﺪﺗ ﻲﺘﻟﺍ ﻊﺑﺍﻮﺘﻟﺍ ﻒﻠﺘﺗ ﺪﻗ

.ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﯽﻠﻋ ﺭﻮﻛﺬﳌﺍ ﯽﺼﻗﻷﺍ

.ﺔﺣﻮﻤﺴﳌﺍ ﺔﻋﴪﻟﺍ ﻦﻋ ﺪﻳﺰﺗ ﺔﻋﴪﺑ

ﻑﺮﻈﻟﺍ) ﺓﺪﻌﻟﺍ ﻦﺿﺎﺣ ﻊﻣ ﻊﺑﺍﻮﺘﻟﺍ ﻦﻣ ﺎﻫﲑﻏ ﻭﺃ ﺯﺮﻔﻟﺍ ﻢﻘﻟ ﻢﺋﻼﺘﺗ ﻥﺃ ﺐﳚ

◀

ﻢﺋﻼﺘﺗ ﻻ ﻲﺘﻟﺍ ﻞﻐﺸﻟﺍ ﺩﺪﻋ ﻥﺇ

.ﻖﻴﻗﺩ ﻞﻜﺸﺑ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﻚﺗﺪﻌﺑ (ﻲﻗﻮﻄﻟﺍ

ﻢﻈﺘﻨﻣ ﲑﻏ ﻞﻜﺸﺑ ﺭﻭﺪﺗ ﻖﻴﻗﺩ ﻞﻜﺸﺑ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﺩﺪﻋ ﻦﺿﺎﺣ ﻊﻣ

.ﺓﺪﻌﻟﺎﺑ ﻢﻜﺤﺘﻟﺍ ﻥﺍﺪﻘﻓ ﯽﻟﺇ ﻱﺩﺆﺗ ﺪﻗﻭ ﺓﺪﺸﺑ ﺰﺘﲥﻭ

ﺔﻟﺎﺣ ﰲ ﻥﻮﻜﺗ ﺎﻣﺪﻨﻋ ﻂﻘﻓ ﻞﻐﺸﻟﺍ ﺔﻌﻄﻗ ﻮﺤﻧ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻪﺟﻭ

◀

ﻞﻐﺸﻟﺍ ﺓﺪﻋ ﺖﺒﻠﻜﺗ ﻥﺇ ﺔﻳﺩﺍﺪﺗﺭﻻﺍ ﺕﺎﻣﺪﺼﻟﺍ ﺮﻄﺧ ﻞﻜﺸﺘﻳ ﺪﻗ

.ﻞﻴﻐﺸﺘﻟﺍ

.ﻞﻐﺸﻟﺍ ﺔﻌﻄﻗ ﰲ

ﺮﻄﺧ ﻞﻜﺸﺘﻳ ﺪﻗ

.ﺯﺮﻔﻟﺍ ﺔﻤﻘﻟ ﻦﻣ ﻭﺃ ﺯﺮﻔﻟﺍ ﻝﺎﳎ ﻦﻣ ﻚﻳﺪﻴﺑ ﺏﱰﻘﺗ ﻻ

◀

.ﺡﻭﺮﺠﺑ ﺔﺑﺎﺻﻹﺍ

ﻒﻠﺘﺗ ﺪﻗ

.ﺐﻟﺍﻮﻠﻟﺍﻭ ﲑﻣﺎﺴﳌﺍ ﻭﺃ ﺔﻴﻧﺪﻌﳌﺍ ﻊﻄﻘﻟﺍ ﱪﻋ ﹰﺍﺪﺑﺃ ﺰﻳﺮﻔﺘﻟﺎﺑ ﻡﻮﻘﺗ ﻻ

◀

.ﺓﺪﺋﺍﺯ ﺕﺍﺯﺍﺰﺘﻫﺍ ﯽﻟﺇ ﻱﺩﺆﺘﻓ ،ﺯﺮﻔﻟﺍ ﺔﻤﻘﻟ

ﻭﺃ ﺔﻴﻔﺨﳌﺍ ﺩﺍﺪﻣﻹﺍ ﻁﻮﻄﺧ ﯽﻠﻋ ﺭﻮﺜﻌﻠﻟ ﺔﺒﺳﺎﻨﻣ ﺐﻴﻘﻨﺗ ﺓﺰﻬﺟﺃ ﻡﺪﺨﺘﺳﺍ

◀

ﯽﻟﺇ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﻁﻮﻄﳋﺍ ﺔﺴﻣﻼﻣ ﻱﺩﺆﺗ ﺪﻗ

.ﺔﻴﻠﺤﳌﺍ ﺩﺍﺪﻣﻹﺍ ﺔﻛﴩﺑ ﻦﻌﺘﺳﺍ

ﯽﻟﺇ ﻱﺩﺆﻳ ﺪﻗ ﺯﺎﻐﻟﺍ ﻂﺧ ﻑﻼﺗﺇ .ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺕﺎﻣﺪﺼﻟﺍ ﯽﻟﺇﻭ ﺭﺎﻨﻟﺍ ﻉﻻﺪﻧﺍ

.ﺔﻳﺩﺎﳌﺍ ﺭﺍﴐﻷﺍ ﯽﻟﺇ ﻱﺩﺆﻳ ﺀﺎﳌﺍ ﻂﺧ ﻕﺍﱰﺧﺍ .ﺭﺎﺠﻔﻧﺍ ﺙﻭﺪﺣ

ﺞﺘﻨﺗ ﺔﻔﻟﺎﺘﻟﺍ ﻭﺃ ﺔﳌﺎﺜﻟﺍ ﺯﺮﻔﻟﺍ ﻢﻘﻟ ﻥﺇ

.ﺔﻔﻟﺎﺘﻟﺍ ﻭﺃ ﺔﳌﺎﺜﻟﺍ ﺯﺮﻔﻟﺍ ﻢﻘﻟ ﻡﺪﺨﺘﺴﺗ ﻻ

◀

.ﻥﺯﺍﻮﺘﻟﺍ ﻝﻼﺘﺧﺍ ﯽﻟﺇ ﻱﺩﺆﺗﻭ ﻂﻤﻘﻨﺗ ﺪﻗﻭ ،ﺪﺋﺍﺯ ﻙﺎﻜﺘﺣﺍ

ﻞﻜﺸﺘﺗ

.ﻚﻠﻤﻋ ﻥﺎﻜﻣ ﻦﻣ ﺔﺑﺮﻘﻣ ﯽﻠﻋ ﻕﺍﱰﺣﻼﻟ ﺔﻠﺑﺎﻗ ﺀﺎﻴﺷﺄﺑ ﻚﺴﲤ ﻻ

◀

.ﻖﻳﺮﳊﺍ ﻞﻌﺸﺗ ﺪﻗﻭ ﻁﻼﺒﻟﺍ ﺔﳉﺎﻌﻣ ﺪﻨﻋ ﺔﻨﺧﺎﺳ ﺩﺍﻮﻣ ﺓﺭﺎﺸﻧ

.ﹰﺎﺒﻧﺎﺟ ﺎﻬﻌﻀﺗ ﻥﺃ ﻞﺒﻗ ﺔﻛﺮﳊﺍ ﻦﻋ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻒﻗﻮﺘﺗ ﻥﺃ ﯽﻟﺇ ﺮﻈﺘﻧﺍ

◀

.ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﯽﻠﻋ ﺓﺮﻄﻴﺴﻟﺍ ﻥﺍﺪﻘﻓ ﯽﻟﺇ ﻱﺩﺆﺘﻓ ﻞﻐﺸﻟﺍ ﺓﺪﻋ ﺐﻠﻜﺘﺗ ﺪﻗ

ﻲﺑﺮﻋ

 |

247

Bosch Power Tools

2 610 016 614

|

 (2.3.11)

ﻥﺎﻣﻷﺍ ﺕﲈﻴﻠﻌﺗ

ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺩﺪﻌﻠﻟ ﺔﻣﺎﻋ ﺔﻳﺮﻳﺬﲢ ﺕﺎﻈﺣﻼﻣ

ﺏﺎﻜﺗﺭﺍ ﻥﺇ

.ﺕﲈﻴﻠﻌﺘﻟﺍﻭ ﺔﻳﺮﻳﺬﺤﺘﻟﺍ ﺕﺎﻈﺣﻼﳌﺍ ﻊﻴﲨ ﺃﺮﻗﺍ

ﺪﻗ ﺕﲈﻴﻠﻌﺘﻟﺍﻭ ﺔﻳﺮﻳﺬﺤﺘﻟﺍ ﺕﺎﻈﺣﻼﳌﺍ ﻖﻴﺒﻄﺗ ﺪﻨﻋ ﺀﺎﻄﺧﻷﺍ

ﺡﻭﺮﺠﺑ ﺔﺑﺎﺻﻹﺍ ﻭﺃ/ﻭ ﻖﺋﺍﺮﳊﺍ ﺏﻮﺸﻧ ﯽﻟﺇ ،ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺕﺎﻣﺪﺼﻟﺍ ﯽﻟﺇ ﻱﺩﺆﻳ

.ﺓﲑﻄﺧ

.ﻞﺒﻘﺘﺴﻤﻠﻟ ﺕﲈﻴﻠﻌﺘﻟﺍﻭ ﺔﻳﺮﻳﺬﺤﺘﻟﺍ ﺕﺎﻈﺣﻼﳌﺍ ﻊﻴﻤﺠﺑ ﻆﻔﺘﺣﺍ

،ﺔﻳﺮﻳﺬﺤﺘﻟﺍ ﺕﺎﻈﺣﻼﳌﺍ ﰲ ﻡﺪﺨﺘﺴﳌﺍ

“

ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ

”

ﺢﻠﻄﺼﻤﺑ ﺪﺼﻘﻳ

ﺔﻜﺒﺸﻟﺍ ﻞﺑﺎﻛ ﺔﻄﺳﺍﻮﺑ) ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺔﻜﺒﺸﻟﺎﺑ ﺔﻟﻮﺻﻮﳌﺍ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺩﺪﻌﻟﺍ

ﺔﻜﺒﺸﻟﺍ ﻞﺑﺎﻛ ﻥﻭﺩ) ﻢﻛﺮﻤﺑ ﺓﺩﻭﺰﳌﺍ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺩﺪﻌﻟﺍ ﹰﺎﻀﻳﺃﻭ (ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ

.(ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ

ﻞﻐﺸﻟﺍ ﻥﺎﻜﻤﺑ ﻥﺎﻣﻷﺍ

 (1

ﰲ ﯽﺿﻮﻔﻟﺍ

 .ﻚﻠﻐﺷ ﻥﺎﻜﻣ ﺓﺀﺎﺿﺇ ﻦﺴﺣﻭ ﺔﻓﺎﻈﻧ ﯽﻠﻋ ﻆﻓﺎﺣ

(a

ﺙﻭﺪﺣ ﯽﻟﺇ ﻱﺩﺆﺗ ﺪﻗ ﺓﺀﺎﻀﻣ ﲑﻐﻟﺍ ﻞﻤﻌﻟﺍ ﺕﻻﺎﳎﻭ ﻞﻐﺸﻟﺍ ﻥﺎﻜﻣ

.ﺙﺩﺍﻮﳊﺍ

 ﺭﺎﺠﻔﻧﻻﺍ ﺮﻄﳋ ﺽﺮﻌﻣ ﻂﻴﳏ ﰲ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺎﺑ ﻞﻐﺘﺸﺗ ﻻ

(b

.ﻝﺎﻌﺘﺷﻼﻟ ﺔﻠﺑﺎﻘﻟﺍ ﺓﱪﻏﻷﺍ ﻭﺃ ﺕﺍﺯﺎﻐﻟﺍ ﻭﺃ ﻞﺋﺍﻮﺴﻟﺍ ﻪﻴﻓ ﺮﻓﻮﺘﺗ ﻱﺬﻟﺍﻭ

ﺓﱪﻏﻷﺍ ﻞﻌﺸﻴﻓ ،ﺮﻳﺎﻄﺘﻳ ﺪﻗ ﻱﺬﻟﺍ ﺭﴩﻟﺍ ﻞﻜﺸﺗ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺩﺪﻌﻟﺍ

.ﺓﺮﺨﺑﻷﺍﻭ

 ﺎﻣﺪﻨﻋ ﺪﻌﺑ ﯽﻠﻋ ﺹﺎﺨﺷﻷﺍ ﻦﻣ ﻢﻫﲑﻏﻭ ﻝﺎﻔﻃﻷﺍ ﺀﺎﻘﺑ ﯽﻠﻋ ﻆﻓﺎﺣ

(c

ﺪﻨﻋ ﺯﺎﻬﳉﺍ ﯽﻠﻋ ﺓﺮﻄﻴﺴﻟﺍ ﺪﻘﻔﺗ ﺪﻗ

.ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻞﻤﻌﺘﺴﺗ

.ﻲﻬﻠﺘﻟﺍ

ﻲﺋﺎﺑﺮﻬﻜﻟﺍ ﻥﺎﻣﻷﺍ

 (2

 ﺯﻮﳚ ﻻ .ﺲﺒﻘﳌﺍ ﻊﻣ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻞﺻﻭ ﺲﺑﺎﻗ ﻢﺋﻼﺘﻳ ﻥﺃ ﺐﳚ

(a

ﺔﺌﻳﺎﻬﳌﺍ ﺲﺑﺍﻮﻘﻟﺍ ﻞﻤﻌﺘﺴﺗ ﻻ .ﻝﺍﻮﺣﻷﺍ ﻦﻣ ﻝﺎﺣ ﻱﺄﺑ ﺲﺑﺎﻘﻟﺍ ﲑﻴﻐﺗ

ﻲﺘﻟﺍ ﺲﺑﺍﻮﻘﻟﺍ ﺾﹼﻔﲣ

.ﻲﺋﺎﻗﻭ ﺾﻳﺭﺄﺗ ﺔﺿﺭﺆﳌﺍ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺩﺪﻌﻟﺍ ﻊﻣ

.ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺕﺎﻣﺪﺼﻟﺍ ﺮﻄﺧ ﻦﻣ ﺔﻤﺋﻼﳌﺍ ﺲﺑﺎﻘﳌﺍﻭ ﺎﻫﲑﻴﻐﺗ  ﹼﻢﺘﻳ ﱂ

 ﺔﺌﻓﺪﺘﻟﺍ ﺕﺍﺭﻮﺗﺎﻳﺩﺍﺭﻭ ﺐﻴﺑﺎﻧﻷﺎﻛ ﺔﺿﺭﺆﳌﺍ ﺡﻮﻄﺴﻟﺍ ﺔﺴﻣﻼﻣ ﺐﻨﲡ

(b

ﺕﺎﻣﺪﺼﻟﺍ ﺮﻄﺧ ﺩﺍﺩﺰﻳ

.ﻚﻤﺴﺟ ﺔﻄﺳﺍﻮﺑ ﺕﺍﺩﺍﱪﻟﺍ ﻭﺃ ﺊﻓﺍﺪﳌﺍﻭ

.ﺽﺭﺆﻣ ﻚﻤﺴﺟ ﻥﻮﻜﻳ ﺎﻣﺪﻨﻋ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ

ﺮﻄﺧ ﺩﺍﺩﺰﻳ

 .ﺔﺑﻮﻃﺮﻟﺍ ﻭﺃ ﺭﺎﻄﻣﻷﺍ ﻦﻋ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﺪﻌﺑﺃ

(c

.ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻞﺧﺍﺩ ﯽﻟﺇ ﺀﺎﳌﺍ ﺏﴪﺗ ﻥﺇ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺕﺎﻣﺪﺼﻟﺍ

 ﻭﺃ ﺎﻬﻘﻴﻠﻌﺘﻟ ﻭﺃ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻞﻤﳊ ﻞﺑﺎﻜﻟﺍ ﻝﲈﻌﺘﺳﺍ ﺀﴘﺗ ﻻ

(d

ﺓﺭﺍﺮﳊﺍ ﻦﻋ ﻞﺑﺎﻜﻟﺍ ﺩﺎﻌﺑﺇ ﯽﻠﻋ ﻆﻓﺎﺣ .ﺲﺒﻘﳌﺍ ﻦﻣ ﺲﺑﺎﻘﻟﺍ ﺐﺤﺴﻟ

ﺪﻳﺰﺗ

.ﺔﻛﺮﺤﺘﳌﺍ ﺯﺎﻬﳉﺍ ﺀﺍﺰﺟﺃ ﻦﻋ ﻭﺃ ﺓﺩﺎﳊﺍ ﻑﺍﻮﳊﺍﻭ ﺖﻳﺰﻟﺍﻭ

.ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺕﺎﻣﺪﺼﻟﺍ ﺮﻄﺧ ﻦﻣ ﺔﻜﺑﺎﺸﺘﳌﺍ ﻭﺃ ﺔﻔﻟﺎﺘﻟﺍ ﺕﻼﺑﺎﻜﻟﺍ

 ﻲﺟﺭﺎﳋﺍ ﻝﲈﻌﺘﺳﻼﻟ ﺔﳊﺎﺼﻟﺍ ﺪﻳﺪﻤﺘﻟﺍ ﺕﻼﺑﺎﻛ ﻂﻘﻓ ﻡﺪﺨﺘﺳﺍ

(e

ﻝﲈﻌﺘﺳﺍ ﺾﻔﳜ

.ﺀﻼﳋﺍ ﰲ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺎﺑ ﻞﻐﺘﺸﺗ ﺎﻣﺪﻨﻋ ﹰﺎﻀﻳﺃ

ﺕﺎﻣﺪﺼﻟﺍ ﺮﻄﺧ ﻦﻣ ﻲﺟﺭﺎﳋﺍ ﻝﲈﻌﺘﺳﻼﻟ ﺺﺼﳐ ﺪﻳﺪﲤ ﻞﺑﺎﻛ

.ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ

 ﺀﺍﻮﺟﻷﺍ ﰲ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻞﻴﻐﺸﺗ ﺐﻨﲡ ﻥﺎﻜﻣﻹﺎﺑ ﻦﻜﻳ ﱂ ﻥﺇ

(f

ﻡﺍﺪﺨﺘﺳﺍ ﻥﺇ

.ﻒﻠﺨﺘﳌﺍ ﺭﺎﻴﺘﻟﺍ ﻦﻣ ﺔﻳﺎﻗﻮﻠﻟ ﺡﺎﺘﻔﻣ ﻡﺪﺨﺘﺳﺎﻓ ،ﺔﺒﻃﺮﻟﺍ

.ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺕﺎﻣﺪﺼﻟﺍ ﺮﻄﺧ ﻞﻠﻘﻳ ﻒﻠﺨﺘﳌﺍ ﺭﺎﻴﺘﻟﺍ ﻦﻣ ﺔﻳﺎﻗﻮﻠﻟ ﺡﺎﺘﻔﻣ

ﺹﺎﺨﺷﻷﺍ ﻥﺎﻣﺃ

 (3

 ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﺔﻄﺳﺍﻮﺑ ﻞﻤﻌﻟﺎﺑ ﻢﻗﻭ ﻪﻠﻌﻔﺗ ﺎﻣ ﯽﻟﺇ ﻪﺒﺘﻧﺍﻭ ﹰﺎﻈﻘﻳ ﻦﻛ

(a

ﺎﻣﺪﻨﻋ ﻭﺃ ﺐﻌﺘﻣ ﻥﻮﻜﺗ ﺎﻣﺪﻨﻋ ﺔﻴﺋﺎﺑﺮﻬﻛ ﺓﺪﻋ ﻡﺪﺨﺘﺴﺗ ﻻ .ﻞﻘﻌﺘﺑ

ﻩﺎﺒﺘﻧﻻﺍ ﻡﺪﻋ

.ﺔﻳﻭﺩﻷﺍ ﻭﺃ ﻝﻮﺤﻜﻟﺍ ﻭﺃ ﺕﺍﺭﺪﺨﳌﺍ ﲑﺛﺄﺗ ﺖﲢ ﻥﻮﻜﺗ

ﯽﻟﺇ ﻱﺩﺆﻳ ﺪﻗ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻡﺍﺪﺨﺘﺳﺍ ﺪﻨﻋ ﺓﺪﺣﺍﻭ ﺔﻈﺤﻠﻟ

.ﺓﲑﻄﺧ ﺕﺎﺑﺎﺻﺇ

ﺩﺎﺘﻋ ﺀﺍﺪﺗﺭﺍ ﺪﳛ

 .ﺔﻴﻗﺍﻭ ﺕﺍﺭﺎﻈﻧ ﹰﲈﺋﺍﺩ ﺪﺗﺭﺍﻭ ﺹﺎﳋﺍ ﺔﻳﺎﻗﻮﻟﺍ ﺩﺎﺘﻋ ﺪﺗﺭﺍ

(b

ﺔﻴﻗﺍﻮﻟﺍ ﻥﺎﻣﻷﺍ ﺔﻳﺬﺣﺃﻭ ﺭﺎﺒﻐﻟﺍ ﻦﻣ ﺔﻳﺎﻗﻮﻟﺍ ﻉﺎﻨﻘﻛ ،ﺹﺎﳋﺍ ﺔﻳﺎﻗﻮﻟﺍ

ﺓﺪﻌﻟﺍ ﻝﲈﻌﺘﺳﺍﻭ ﻉﻮﻧ ﺐﺴﺣ ،ﲔﻧﺫﻷﺍ ﺔﻴﻗﺍﻭ ﻭﺃ ﺫﻮﳋﺍﻭ ﻕﻻﺰﻧﻻﺍ ﻦﻣ

.ﺡﻭﺮﺠﺑ ﺔﺑﺎﺻﻹﺍ ﺮﻄﺧ ﻦﻣ ،ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ

 ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻥﻮﻛ ﻦﻣ ﺪﻛﺄﺗ .ﺩﻮﺼﻘﻣ ﲑﻏ ﻞﻜﺸﺑ ﻞﻴﻐﺸﺘﻟﺍ ﺐﻨﲡ

(c

ﻞﺒﻗﻭ ،ﻢﻛﺮﳌﺎﺑ ﻭﺃ/ﻭ ﻲﺋﺎﺑﺮﻬﻜﻟﺍ ﺭﺎﻴﺘﻟﺍ ﺩﺍﺪﻣﺈﺑ ﺎﻬﻠﺻﻭ ﻞﺒﻗ ﺓﺄﻔﻄﻣ

ﻞﲪ ﺀﺎﻨﺛﺃ ﺡﺎﺘﻔﳌﺍ ﯽﻠﻋ ﻚﻌﺒﺻﺇ ﻊﻀﺗ ﺖﻨﻛ ﻥﺇ

.ﺎﻬﻠﲪ ﻭﺃ ﺎﻬﻌﻓﺭ

ﺎﻣﺪﻨﻋ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺔﻜﺒﺸﻟﺎﺑ ﺯﺎﻬﳉﺍ ﺖﻠﺻﻭ ﻥﺇ ﻭﺃ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ

.ﺙﺩﺍﻮﳊﺍ ﺙﻭﺪﺣ ﯽﻟﺇ ﻚﻟﺫ ﻱﺩﺆﻳ ﺪﻘﻓ ،ﻞﻴﻐﺸﺘﻟﺍ ﺪﻴﻗ ﻥﻮﻜﻳ

 .ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻞﻴﻐﺸﺗ ﻞﺒﻗ ﻂﺑﺮﻟﺍ ﺡﺎﺘﻔﻣ ﻭﺃ ﻂﺒﻀﻟﺍ ﺩﺪﻋ ﻉﺰﻧﺍ

(d

ﯽﻟﺇ ﺯﺎﻬﳉﺍ ﻦﻣ ﺭﺍﻭﺩ ﺀﺰﺟ ﰲ ﺪﺟﺍﻮﺘﳌﺍ ﺡﺎﺘﻔﳌﺍ ﻭﺃ ﺓﺪﻌﻟﺍ ﻱﺩﺆﺗ ﺪﻗ

.ﺡﻭﺮﺠﺑ ﺔﺑﺎﺻﻹﺍ

 ﻚﻧﺯﺍﻮﺗ ﯽﻠﻋ ﻆﻓﺎﺣﻭ ﻥﺎﻣﺄﺑ ﻒﻗ .ﺔﻴﻌﻴﺒﻃ ﲑﻐﻟﺍ ﺪﺴﳉﺍ ﻉﺎﺿﻭﺃ ﺐﻨﲡ

(e

ﰲ ﻞﻀﻓﺃ ﻞﻜﺸﺑ ﺯﺎﻬﳉﺍ ﯽﻠﻋ ﺓﺮﻄﻴﺴﻟﺍ ﻦﻣ ﻚﻟﺫ ﻚﻟ ﺢﻤﺴﻴﺳ

.ﹰﲈﺋﺍﺩ

.ﺔﻌﻗﻮﺘﻣ ﲑﻐﻟﺍ ﻒﻗﺍﻮﳌﺍ

 ﻆﻓﺎﺣ .ﯽﻠﳊﺍ ﻭﺃ ﺔﺿﺎﻔﻀﻔﻟﺍ ﺏﺎﻴﺜﻟﺍ ﺪﺗﺮﺗ ﻻ .ﺔﺒﺳﺎﻨﻣ ﺏﺎﻴﺛ ﺪﺗﺭﺍ

(f

ﺯﺎﻬﳉﺍ ﺀﺍﺰﺟﺃ ﻦﻋ ﺪﻌﺑ ﯽﻠﻋ ﺕﺍﺯﺎﻔﻘﻟﺍﻭ ﺏﺎﻴﺜﻟﺍﻭ ﺮﻌﺸﻟﺍ ﺀﺎﻘﺑﺇ ﯽﻠﻋ

ﻞﻳﻮﻄﻟﺍ ﺮﻌﺸﻟﺍﻭ ﯽﻠﳊﺍﻭ ﺔﺿﺎﻔﻀﻔﻟﺍ ﺏﺎﻴﺜﻟﺍ ﻚﺑﺎﺸﺘﺗ ﺪﻗ

.ﺔﻛﺮﺤﺘﳌﺍ

.ﺔﻛﺮﺤﺘﳌﺍ ﺀﺍﺰﺟﻷﺎﺑ

 ﺎﳖﺃ ﻦﻣ ﺪﻛﺄﺘﻓ ،ﺭﺎﺒﻐﻟﺍ ﻊﻴﻤﲡﻭ ﻂﻔﺷ ﺕﺍﺰﻴﻬﲡ ﺐﻴﻛﺮﺗ ﺯﺎﺟ ﻥﺇ

(g

ﻡﺍﺪﺨﺘﺳﺍ ﻞﻠﻘﻳ ﺪﻗ

.ﻢﻴﻠﺳ ﻞﻜﺸﺑ ﺎﻬﻣﺍﺪﺨﺘﺳﺍ ﹼﻢﺘﻳ ﻪﻧﺄﺑﻭ ﺔﻟﻮﺻﻮﻣ

.ﺓﱪﻏﻷﺍ ﻦﻋ ﺔﲡﺎﻨﻟﺍ ﺮﻃﺎﺨﳌﺍ ﻦﻣ ﺓﱪﻏﻷﺍ ﻂﻔﺸﻟ ﺕﺍﺰﻴﻬﲡ

    248 |

ﯽﺳﺭﺎﻓ

2 610 016 614

|

 (2.3.11)

Bosch Power Tools

ﻩﺭﺎﻤﺷ ﹰﺎﻤﺘﺣ ،ﺕﺎﻘﻠﻌﺘﻣ ﻭ ﯽﮐﺪﯾ ﺭﺍﺰﺑﺍ ﺵﺭﺎﻔﺳ ﺎﯾ ﻭ ﻝﺍﻮﺌﺳ ﻪﻧﻮﮔﺮﻫ یﺍﺮﺑ

.ﺪﯿﻫﺩ ﻉﻼﻃﺍ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ یﻭﺭ ﺐﺴﭼﺮﺑ ﻖﺑﺎﻄﻣ ﺍﺭ ﻻﺎﮐ ﯽﻤﻗﺭ ﻩﺩ ﯽﻨﻓ

ﻥﺎﯾﺮﺘﺸﻣ ﺎﺑ ﻩﺭﻭﺎﺸﻣ ﻭ ﺵﻭﺮﻓ ﺯﺍ ﺲﭘ ﺕﺎﻣﺪﺧ

ﺲﯾﻭﺮﺳ ،ﺕﺍﺮﯿﻤﻌﺗ ﻩﺭﺎﺑ ﺭﺩ ﺎﻤﺷ ﺕﻻﺍﻮﺌﺳ ﻪﺑ ﺵﻭﺮﻓ ﺯﺍ ﺲﭘ ﺕﺎﻣﺪﺧ ﺮﺘﻓﺩ

ﻭ ﺮﯾﻭﺎﺼﺗ .ﺩﺍﺩ ﺪﻫﺍﻮﺧ ﺦﺳﺎﭘ ﺕﺎﻘﻠﻌﺘﻣ ﻭ ﯽﮐﺪﯾ ﺕﺎﻌﻄﻗ ﻦﯿﻨﭽﻤﻫ ﻭ

ﻩﺩﺮﺒﻣﺎﻧ ﺖﯾﺎﺳ ﺭﺩ ﺪﯿﻧﺍﻮﺘﯿﻣ ﺍﺭ ﺕﺎﻘﻠﻌﺘﻣ ﻭ ﯽﮐﺪﯾ ﺕﺎﻌﻄﻗ ﻩﺭﺎﺑ ﺭﺩ ﺕﺎﻋﻼﻃﺍ

:ﺪﯿﯾﺎﳕ ﻮﺠﺘﺴﺟ ﻞﯾﺫ

www.bosch-pt.com

ﺕﻻﺍﻮﺌﺳ ﻪﺑ ﻞﯿﻣ ﻝﺎﻤﮐ ﺎﺑ ﺵﻮﺑ ﺖﮐﺮﺷ ﺵﻭﺮﻓ ﺯﺍ ﺲﭘ ﺕﺎﻣﺪﺧ ﺭﻭﺎﺸﻣ ﻢﯿﺗ

ﺦﺳﺎﭘ ﺕﺎﻘﻠﻌﺘﻣ ﻭ ﺕﻻﻮﺼﺤﻣ ﻢﯿﻈﻨﺗ ﻭ ﻩﺩﺎﻔﺘﺳﺍ ﺯﺮﻃ ،ﺪﯾﺮﺧ ﻩﺭﺎﺑ ﺭﺩ ﺎﻤﺷ

.ﺪﻫﺪﯿﻣ

ﻪﺑ ﻂﻘﻓ ﯽﻛﺪﻳ ﺭﺍﺰﺑﺍ ﻪﻴﻬﺗ ﻭ ﻩﺎﮕﺘﺳﺩ ﺮﻴﻤﻌﺗ ،ﯽﺘﻧﺍﺭﺎﮔ ﺯﺍ ﻩﺩﺎﻔﺘﺳﺍ یﺍﺮﺑ

.ﺪﻴﻨﻛ ﻪﻌﺟﺍﺮﻣ ﺺﺼﺨﺘﻣ ﺩﺍﺮﻓﺍ

ﻩﺎﮕﺘﺳﺩ ﻥﺩﺮﮐ ﺝﺭﺎﺧ ﻩﺩﺭ ﺯﺍ

ﻂﯿﺤﻣ ﻆﻔﺣ ﺕﺍﺭﺮﻘﻣ ﻖﺒﻃ ﺪﯾﺎﺑ ،ﻥﺁ یﺪﻨﺑ ﻪﺘﺴﺑ ﻭ ﺕﺎﻘﻠﻌﺘﻣ ،ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ

.ﺪﻧﻮﺷ ﺖﻓﺎﯾﺯﺎﺑ ﻭ ﺝﺭﺎﺧ ﻩﺩﺭ ﺯﺍ ﺖﺴﯾﺯ

!ﺪﯾﺯﺍﺪﻧﺎﯿﻧ ﯽﮕﻧﺎﺧ ﻥﺍﺩ ﻪﻟﺎﺑﺯ ﻞﺧﺍﺩ ﺍﺭ ﯽﻗﺮﺑ یﺎﻫﺭﺍﺰﺑﺍ

:ﺎﭘﻭﺭﺍ ﻪﯾﺩﺎﲢﺍ ﻮﻀﻋ یﺎﻫﺭﻮﺸﻛ یﺍﺮﺑ ﻂﻘﻓ

ﯽﺋﺎﭘﻭﺭﺍ ﻞﻤﻌﻟﺍﺭﻮﺘﺳﺩ ﻭ ﻪﻣﺎﻧ ﻦﯿﺋﺁ ﻖﺒﻃ

 ﻪﻨﻬﻛ یﺎﻬﻫﺎﮕﺘﺳﺩ ﻩﺭﺎﺑ ﺭﺩ

2002/96/EG

،ﯽﻠﻣ ﻖﺣ ﻪﺑ ﻥﺁ ﻞﯾﺪﺒﺗ ﻭ ﯽﻜﯿﻧﻭﺮﺘﻜﻟﺍ ﻭ ﯽﻜﯾﺮﺘﻜﻟﺍ

ﻪﻧﺎﮔﺍﺪﺟ ﺍﺭ ﻩﺩﺎﻔﺘﺳﺍ ﻞﺑﺎﻗﺮﯿﻏ ﯽﻗﺮﺑ یﺎﻫﺭﺍﺰﺑﺍ ﺪﯾﺎﺑ

ﺎﺑ ﺐﺳﺎﻨﻣ ﺖﻓﺎﯾﺯﺎﺑ ﻪﺑ ﺖﺒﺴﻧ ﻭ ﺩﺮﻛ یﺭﻭﺁ ﻊﻤﺟ

.ﺩﺭﻭﺁ ﻞﻤﻌﺑ ﻡﺍﺪﻗﺍ ﺖﺴﯾﺯ ﻂﯿﺤﻣ

.ﺖﺳﺍ ﻅﻮﻔﺤﻣ یﺮﯿﯿﻐﺗ ﻪﻧﻮﮔﺮﻫ ﻖﺣ

ﯽﺳﺭﺎﻓ

|  249

Bosch Power Tools

2 610 016 614

|

 (2.3.11)

ﻥﺩﺮﮐ ﺵﻮﻣﺎﺧ ﻭ ﻦﺷﻭﺭ ﻩﻮﺤﻧ

ﻝﺮﺘﻨﮐ ،ﻕﺮﺑ ﻥﺎﯾﺮﺟ ﻊﺒﻨﻣ ﻪﺑ ﻩﺎﮕﺘﺳﺩ ﻪﺧﺎﺷﻭﺩ ﻝﺎﺼﺗﺍ ﺯﺍ ﺶﯿﭘ

◀

ﻦﮑﳑ ﺕﺭﻮﺼﻨﯾﺍ ﺮﯿﻏ ﺭﺩ

 .ﺪﺷﺎﺑ ﺵﻮﻣﺎﺧ

9

ﻞﺻﻭ ﻭ ﻊﻄﻗ ﺪﯿﻠﮐ ،ﺪﯿﻨﮐ

ﺮﺠﻨﻣ ﺍﺭ ﯽﺤﻧﺍﻮﺳ ﻭ ﻩﺪﺷ ﻦﺷﻭﺭ ﻪﺘﺳﺍﻮﺧﺎﻧ ﺭﻮﻄﺑ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﺖﺳﺍ

.ﺩﺩﺮﮔ

،ﺪﯿﻨﮐ ﻢﯿﻈﻨﺗ ﺍﺭ یﺭﺎﮐ ﺯﺮﻓ ﻖﻤﻋ ﺍﺪﺘﺑﺍ ،ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﻥﺩﺮﮐ ﻦﺷﻭﺭ ﺯﺍ ﺶﯿﭘ

.«یﺭﺎﮐ ﺯﺮﻓ ﻖﻤﻋ ﻢﯿﻈﻨﺗ ﻩﻮﺤﻧ» ﺚﺤﺒﻣ ﻪﺑ ﺩﻮﺷ ﻉﻮﺟﺭ

 ﺭﺎﺸﻓ ﻮﻠﺟ ﻑﺮﻄﺑ ﺍﺭ

9

 ﻞﺻﻭ ﻭ ﻊﻄﻗ ﺪﯿﻠﮐ ،ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ

ﻥﺩﺮﮐ ﻦﺷﻭﺭ

یﺍﺮﺑ

.ﺪﯿﻫﺪﺑ

ﻭ ﻊﻄﻗ ﺪﯿﻠﮐ ﯽﺋﻮﻠﺟ ﺖﻤﺴﻗ ،

9

 ﻞﺻﻭ ﻭ ﻊﻄﻗ ﺪﯿﻠﮐ

ﺖﯿﺒﺜﺗ ﻭ ﻞﻔﻗ

یﺍﺮﺑ

.ﺪﺘﻓﺎﯿﺑ ﺎﺟ ﺎﺗ ﺪﯿﻫﺪﺑ ﺭﺎﺸﻓ ﻦﯿﺋﺎﭘ ﻑﺮﻄﺑ ﺍﺭ

9

ﻞﺻﻭ

 ﻖﯾﺮﻃ ﻦﯾﺍ ﺯﺍ ﻭ ﺩﻮﺷ ﯽﻣ ﻦﺷﻭﺭ

8

ﻍﺍﺮﭼ ،ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﻥﺩﺮﮐ ﻦﺷﻭﺭ ﻡﺎﮕﻨﻫ ﻪﺑ

.ﺩﺯﺎﺳ ﯽﻣ ﻢﻫﺍﺮﻓ یﺭﻮﻧ ﺪﻋﺎﺴﻣﺎﻧ ﻂﯾﺍﺮﺷ ﺭﺩ ﺍﺭ ﺭﺎﮐ ﻩﺩﻭﺪﺤﻣ ﯽﯾﺎﻨﺷﻭﺭ

 ﺭﺩ ﻭ ﺪﯿﻨﮐ ﺎﻫﺭ ﺍﺭ

9

 ﻞﺻﻭ ﻭ ﻊﻄﻗ ﺪﯿﻠﮐ ،ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ

ﻥﺩﺮﮐ ﺵﻮﻣﺎﺧ

یﺍﺮﺑ

 ﻩﺎﺗﻮﮐ ﺍﺭ

9

ﻞﺻﻭ ﻭ ﻊﻄﻗ ﺪﯿﻠﮐ ﯽﺋﺎﻬﺘﻧﺍ ﺖﻤﺴﻗ ،ﻥﺁ ﻥﺩﻮﺑ ﻞﻔﻗ ﺕﺭﻮﺻ

.ﺪﯿﻨﮐ ﺎﻫﺭ ﹰﺍﺩﺪﺠﻣ ﺍﺮﻧﺁ ﺲﭙﺳ ﻭ ﺪﯿﻫﺪﺑ ﺭﺎﺸﻓ ﻦﯿﺋﺎﭘ ﻑﺮﻄﺑ

ﯽﮑﯿﻧﻭﺮﺘﮑﻟﺍ ﻩﺪﻨﻨﮐ ﺖﯿﺒﺜﺗ

ﺭﺩ ﻭ ﺩﺍﺯﺁ ﺖﻟﺎﺣﺭﺩ ﺍﺭ ﺶﺧﺮﭼ ﺖﻋﺮﺳ ,ﯽﮑﯿﻧﻭﺮﺘﮑﻟﺍ ﻩﺪﻨﻨﮐ ﺖﯿﺒﺜﺗ ﻭ ﻝﺮﺘﻨﮐ

ﻢﻈﻨﻣ ﺩﺮﻛ ﺭﺎﻛ ﻞﻤﻋ ﻦﯾﺍ ﻭ ﻪﺘﺷﺍﺩ ﻩﺎﮕﻧ ﺖﺑﺎﺛ ﹰﺎﺒﯾﺮﻘﺗ ﻩﺎﮕﺘﺳﺩ ﺩﺮﺑﺭﺎﮐ ﻝﺎﺣ

.ﺪﻨﮑﻴﻣ ﻦﯿﻤﻀﺗ ﺍﺭ ﻩﺎﮕﺘﺳﺩ

ﯽﮑﯿﻧﻭﺮﺘﮑﻟﺍ ﻡﺍﺭﺁ ﻥﺪﺷ ﻦﺷﻭﺭ

ﺩﻭﺪﺤﻣ ﻥﺩﺮﮐ ﻦﺷﻭﺭ ﻡﺎﮕﻨﻫ ﻪﺑ ﺍﺭ ﺭﻭﺎﺘﺸﮔ ،ﯽﮑﯿﻧﻭﺮﺘﮑﻟﺍ ﻪﺘﺴﻫﺁ ﺕﺭﺎﺘﺳﹺﺍ

.ﺩﻮﺷ ﯽﻣ ﺭﻮﺗﻮﻣ ﺮﻤﻋ ﻝﻮﻃ ﺶﯾﺍﺰﻓﺍ ﺚﻋﺎﺑ ﻦﯾﺍ ﻭ ﺩﺯﺎﺳ ﯽﻣ

ﯽﻠﻤﻋ یﺎﻫ ﯽﺋﺎﻤﻨﻫﺍﺭ

(

I – H

ﺮﯾﻭﺎﺼﺗ ﻪﺑ ﺩﻮﺷ ﻉﻮﺟﺭ) ﯽﻠﺧﺍﺩ ﺶﺨﺑ ﮏﯾ (ﻥﺪﯾﺮﺑ) ﻥﺩﺮﮐ ﺯﺮﻓ

ﺮﻫ ﺯﺍ یﺭﺎﻋ ﺭﺎﮐ ﻪﻌﻄﻗ ﻦﯾﺮﯾﺯ ﺢﻄﺳ ﺎﯾ ﻩﺎﮔﺭﺍﺮﻗ ﻪﮐ ﺪﯿﺷﺎﺑ ﻪﺘﺷﺍﺩ ﻪﺟﻮﺗ

.ﺪﺷﺎﺑ ﯽﻌﻧﺎﻣ ﻪﻧﻮﮔ

.ﺪﯿﻨﮐ ﺭﺎﻬﻣ ﻢﮑﺤﻣ ﺭﻮﻄﺑ ﺍﺭ ﺭﺎﮐ ﻪﻌﻄﻗ

–

ﺭﻮﻄﺑ ﻭ ﯽﺑﻮﺨﺑ ،

12

ﺖﺳﺩ یﺎﺟ ﻞﺤﻣ ﺯﺍ ﺍﺭ ﺭﺎﮐ ﻪﻌﻄﻗ ،ﺭﺎﮐ ﻦﯿﺣ ﺭﺩ

–

.ﺪﯾﺮﯿﮕﺑ ﺖﺳﺩ ﺭﺩ ﻢﮑﺤﻣ

،ﺪﯾﺮﺒﺑ ﺭﺎﮐ ﻪﻌﻄﻗ ﻑﺮﻃ ﻪﺑ ﻪﺘﺴﻫﺁ ﺍﺮﻧﺁ ﻭ ﺪﯿﻨﮐ ﻦﺷﻭﺭ ﺍﺭ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ

–

ﯽﺒﯾﺮﻘﺗ ﻪﯾﻭﺍﺯ ﺖﲢ ﺖﺧﺍﻮﻨﮑﯾ ﻭ ﻝﺩﺎﻌﺘﻣ ﺭﺎﺸﻓ ﺎﺑ ﺍﺭ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﺲﭙﺳ

 ﺭﺩ ﺭﺍﻭ ﻩﺮﯾﺍﺩ ﺖﮐﺮﺣ ﺎﺑ ﻭ (ﺭﺎﮐ ﻪﻌﻄﻗ ﻪﺑ ﺖﺒﺴﻧ) ﻪﺟﺭﺩ

30

–

 45°

.ﺪﯿﻨﮐ ﻭﺮﻓ ﺭﺎﮐ ﻪﻌﻄﻗ

ﻦﯿﯾﺎﭘ ﻭ ﻻﺎﺑ ﻑﺮﻃ ﻪﺑ ﺵﺮﺑ ﻂﺧ ﺩﺍﺪﺘﻣﺍ ﺭﺩ ﻪﺘﺴﻫﺁ ﺭﻮﻄﺑ ﺍﺭ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ

–

.ﺪﯿﻫﺪﺑ ﺖﮐﺮﺣ

.ﺪﯿﻫﺩ ﻡﺎﳒﺍ ﺖﺧﺍﻮﻨﮑﯾ ﺖﮐﺮﺣ ﺎﺑ ﺍﺭ یﺭﺎﮐ ﺯﺮﻓ ﻞﻤﻋ

–

ﺭﺍﺰﺑﺍ ،ﺯﺮﻓ ﻪﭽﻐﯿﺗ ﻞﻣﺎﮐ ﻒﻗﻮﺗ ﺯﺍ ﺶﯿﭘ .ﺪﯿﻨﮐ ﺵﻮﻣﺎﺧ ﺍﺭ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ

–

.ﺪﯾﺭﺍﺬﮕﻧ ﺭﺎﻨﮐ ﺍﺭ ﯽﻗﺮﺑ

(

L – J

ﺮﯾﻭﺎﺼﺗ ﻪﺑ ﺩﻮﺷ ﻉﻮﺟﺭ) ﺮﺑ ﺩﺮﮔ ﻪﺘﻣ ﺎﺑ یﺭﺎﮐ ﺯﺮﻓ

ﮏﯾ ﺭﺩ ﻝﺎﺜﻣ ﺭﻮﻄﺑ ﺎﯾ ﻭ ﯽﺷﺎﮐ ﮏﯾ ﻞﺧﺍﺩ ﺭﺩ ﺥﺍﺭﻮﺳ ﮏﯾ ﻥﺩﺮﮐ ﺯﺮﻓ یﺍﺮﺑ

 .ﺩﻮﺷ ﯽﻣ ﻩﺩﺎﻔﺘﺳﺍ

19

ﺮﺑ ﺩﺮﮔ ﻪﺘﻣ ﺯﺍ ،ﺭﺍﻮﯾﺩ

.ﺪﯿﻨﮐ ﺭﺎﻬﻣ ﻢﮑﺤﻣ ﺭﻮﻄﺑ ﺍﺭ ﺭﺎﮐ ﻪﻌﻄﻗ

–

ﺭﻮﻄﺑ ﻭ ﯽﺑﻮﺨﺑ ،

12

ﺖﺳﺩ یﺎﺟ ﻞﺤﻣ ﺯﺍ ﺍﺭ ﺭﺎﮐ ﻪﻌﻄﻗ ،ﺭﺎﮐ ﻦﯿﺣ ﺭﺩ

–

.ﺪﯾﺮﯿﮕﺑ ﺖﺳﺩ ﺭﺩ ﻢﮑﺤﻣ

،ﺪﯾﺮﺒﺑ ﺭﺎﮐ ﻪﻌﻄﻗ ﻑﺮﻃ ﻪﺑ ﻪﺘﺴﻫﺁ ﺍﺮﻧﺁ ﻭ ﺪﯿﻨﮐ ﻦﺷﻭﺭ ﺍﺭ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ

–

ﯽﺒﯾﺮﻘﺗ ﻪﯾﻭﺍﺯ ﺖﲢ ﺖﺧﺍﻮﻨﮑﯾ ﻭ ﻝﺩﺎﻌﺘﻣ ﺭﺎﺸﻓ ﺎﺑ ﺍﺭ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﺲﭙﺳ

 ﺭﺩ ﺭﺍﻭ ﻩﺮﯾﺍﺩ ﺖﮐﺮﺣ ﺎﺑ ﻭ  (ﺭﺎﮐ ﻪﻌﻄﻗ ﻪﺑ ﺖﺒﺴﻧ) ﻪﺟﺭﺩ

30

–

 45°

.ﺪﯿﻨﮐ ﻭﺮﻓ ﺭﺎﮐ ﻪﻌﻄﻗ

 ﻡﺎﳒﺍ ﻪﺟﺭﺩ

15°

ﻪﯾﻭﺍﺯ ﺖﲢ ﺭﺍﻭ ﻩﺮﯾﺍﺩ ﻪﺘﺴﻫﺁ یﺎﻫ ﺖﮐﺮﺣ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﺎﺑ

–

.ﺪﯿﻫﺩ

 .ﺩﻮﺸﻧ (ﻍﺍﺩ) ﻡﺮﮔ ﺪﺣ ﺯﺍ ﺶﯿﺑ

19

ﺮﺑ ﺩﺮﮔ ﻪﺘﻣ ﻪﮐ ﺪﯿﺷﺎﺑ ﻪﺘﺷﺍﺩ ﻪﺟﻮﺗ

–

 ﯽﻣ ﺭﺎﮐ ﺮﺘﻤﯿﻠﯿﻣ

12 mm

ﺯﺍ ﺮﺘﻤﮐ ﺮﻄﻗ ﺎﺑ ﺮﺑ ﺮﮔ ﻪﺘﻣ ﺎﺑ ﻪﭽﻧﺎﻨﭼ

 ﻡﺎﳒﺍ ﻪﯿﻧﺎﺛ

10

ﻝﺎﺜﻣ ﺭﻮﻄﺑ ،ﻥﺁ ﯽﻓﺎﮐ ﻥﺪﺷ ﮏﻨﺧ ﻪﺑ ﺪﯾﺎﺑ ،ﺪﯿﻨﮐ

.ﺪﯿﻨﮐ ﻪﺟﻮﺗ ،ﻥﺪﺷ ﮏﻨﺧ ﻥﺎﻣﺯ ﻪﯿﻧﺎﺛ

5

،یﺭﺎﮑﺧﺍﺭﻮﺳ ﺕﺎﯿﻠﻤﻋ

.ﺪﯿﻨﮐ ﺵﻮﻣﺎﺧ ﺭﺎﮐ ﻪﻌﻄﻗ ﻥﺪﺷ ﺥﺍﺭﻮﺳ ﺯﺍ ﺲﭘ ﻪﻠﺻﺎﻓﻼﺑ ﺍﺭ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ

–

ﺝﺭﺎﺧ ﺭﺎﮐ ﻪﻌﻄﻗ ﻞﺧﺍﺩ ﺯﺍ ﺯﺮﻓ ﻪﭽﻐﯿﺗ ﻞﻣﺎﮐ ﻒﻗﻮﺗ ﺯﺍ ﺲﭘ ﺍﺭ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ

.ﺪﯿﻨﮐ

 ﻪﻠﯿﺳﻮﺑ ﻝﺎﺜﻣ ﺭﻮﻄﺑ ﺍﺭ

19

ﺮﺑ ﺩﺮﮔ ﻪﺘﻣ ﺭﺩ ﺪﯾﺍﺯ ﻩﺪﺷ ﻩﺪﯾﺮﺑ ﻪﻌﻄﻗ

–

.ﺪﯿﻨﮐ ﺝﺭﺎﺧ ﻥﺁ ﯽﺒﻧﺎﺟ ﯽﮔﺪﯾﺮﺑ ﺭﺩ ﯽﺘﺷﻮﮔ ﭻﯿﭘ ﮏﯾ کﻮﻧ ﻥﺩﺮﮐ ﻞﺧﺍﺩ

ﺲﯾﻭﺮﺳ ﻭ ﺖﺒﻗﺍﺮﻣ

ﻩﺎﮕﺘﺳﺩ ﻥﺩﺮﮐ ﺰﯿﲤ ﻭ ﺮﯿﻤﻌﺗ ،ﺖﺒﻗﺍﺮﻣ

ﻪﺧﺎﺷﻭﺩ ،ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ یﻭﺭ ﺮﺑ یﺭﺎﮐ ﻪﻧﻮﮔﺮﻫ ﻡﺎﳒﺍ ﺯﺍ ﺶﯿﭘ

◀

.ﺪﯿﺸﮑﺑ ﻥﻭﺮﯿﺑ ﻕﺮﺑ ﺰﯾﺮﭘ ﻞﺧﺍﺩ ﺯﺍ ﺍﺮﻧﺁ ﻝﺎﺼﺗﺍ

ﯽﻨﻤﯾﺍ ﺎﺗ ،ﺪﯾﺭﺍﺩ ﻩﺎﮕﻧ ﺰﯿﲤ ﺍﺮﻧﺁ ﻪﯾﻮﻬﺗ یﺎﻫﺭﺎﯿﺷ ﻭ ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ

◀

.ﺩﺩﺮﮔ ﻦﯿﻤﻀﺗ ﺭﺎﮐ ﺭﺩ ﺎﻤﺷ

ﺭﺩ ﻪﮐ یﺭﺎﯿﺴﺑ ﺖﻗﺩ ﺩﻮﺟﻭ ﺎﺑ ،ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ ﻥﺩﺎﺘﻓﺍ ﺭﺎﮐ ﺯﺍ ﺕﺭﻮﺻﺭﺩ

ﻪﺑ ﻥﺁ ﺮﯿﻤﻌﺗ یﺍﺮﺑ ﺪﯾﺎﺑ ،ﺖﺳﺍ ﻪﺘﻓﺮﮔ ﺕﺭﻮﺻ ﻥﺁ ﺶﯾﺎﻣﺯﺁ ﻭ ﺪﯿﻟﻮﺗ ﻞﺣﺍﺮﻣ

ﺵﻮﺑ ﯽﻗﺮﺑ ﺕﻻﺁﺭﺍﺰﺑﺍ ﺵﻭﺮﻓ ﺯﺍ ﺲﭘ ﺕﺎﻣﺪﺧ ﻭ ﺯﺎﺠﻣ یﺎﻫ ﻩﺎﮔﺮﯿﻤﻌﺗ ﺯﺍ ﯽﮑﯾ

.ﺪﯿﻨﮐ ﻪﻌﺟﺍﺮﻣ

    250 |

ﯽﺳﺭﺎﻓ

2 610 016 614

|

 (2.3.11)

Bosch Power Tools

ﻢﮑﺤﻣ (

17 mm

 ﺭﺎﭼﺁ ﻪﻧﺎﻫﺩ)

1

 ﺖﺨﺗ ﺭﺎﭼﺁ ﻪﻠﯿﺳﻮﺑ ﺍﺭ

3

ﻩﺮﻬﻣ

–

.ﺪﯿﻧﺎﺧﺮﭽﺑ

➋

ﺖﻬﺟ ﺭﺩ ﺍﺭ ﺖﺨﺗ ﺭﺎﭼﺁ ﺭﺎﮐ ﻦﯾﺍ یﺍﺮﺑ .ﺪﯿﻨﮐ

.ﺪﯿﻨﮐ ﺎﻫﺭ ﺍﺭ ﻩﺎﮕﺘﺳﺩ ﺭﻮﺤﻣ ﻞﻔﻗ ﻪﻤﮐﺩ

–

ﻩﺪﺸﻧ ژﺎﺘﻧﻮﻣ ﺯﺮﻓ ﻪﻐﯿﺗ ﻪﮐ ﯽﻧﺎﻣﺯ ﺎﺗ ﺍﺭ ﺖﻟﻮﮐ ﻩﺮﻬﻣ ﻭ ﺖﻟﻮﮐ ﺰﮔﺮﻫ

◀

ﺖﻟﻮﮐ ﻥﺪﯾﺩ ﺐﯿﺳﺁ ﻥﺎﮑﻣﺍ ﺕﺭﻮﺻ ﻦﯾﺍ ﺮﯿﻏ ﺭﺩ

.ﺪﯿﻨﮑﻧ ﺖﻔﺳ ،ﺖﺳﺍ

.ﺩﺭﺍﺩ ﺩﻮﺟﻭ

ﻪﺷﺍﺮﺗ ﻭ ﻩﺩﺍﺮﺑ ،ﺩﺮﮔ ﺶﮑﻣ

ﺎﯾ ﻭ (ﯽﻫﻮﮐ ﹼﺭﹸﺩ ﺎﯾ ﺰﺗﺭﺍﻮﮐ ﺭﺎﺒﻏ ﻭ ﺩﺮﮔ) ﮏﯿﻣﺍﺮﺳ یﺎﻫ ﯽﺷﺎﮐ ﺭﺎﺒﻏ ﻭ ﺩﺮﮔ

◀

ﯽﺘﻣﻼﺳ یﺍﺮﺑ ﺪﻨﻧﺍﻮﺗ ﯽﻣ (ﯽﻧﺪﻌﻣ ﺩﺍﻮﻣ ﺭﺎﺒﻏ ﻭ ﺩﺮﮔ) ﯽﻌﯿﺒﻃ یﺎﻬﮕﻨﺳ

ﻦﮑﳑ ﺎﻬﻧﺁ ﻥﺩﺮﮐ ﺲﻔﻨﺗ ﺎﯾ ﻭ ﺎﻫﺭﺎﺒﻏ ﻭ ﺩﺮﮔ ﻦﯾﺍ ﺎﺑ ﺱﺎﲤ .ﺪﻨﺷﺎﺑ ﺮﻀﻣ

ﺎﯾ ﻭ ﺮﺑﺭﺎﮐ ﯽﺴﻔﻨﺗ یﺭﺎﺠﻣ یﺭﺎﻤﯿﺑ ﺐﺒﺳ ﺎﯾ ﻭ یژﺮﻟﺁ ﺯﻭﺮﺑ ﺚﻋﺎﺑ ﺖﺳﺍ

.ﺩﻮﺸﺑ ،ﺪﻨﺷﺎﺑ ﯽﻣ ﯽﮑﯾﺩﺰﻧ ﻥﺁ ﺭﺩ ﻪﮐ یﺩﺍﺮﻓﺍ

ﻥﺍﻮﻨﻌﺑ (ﯽﻫﻮﮐ ﹼﺭﹸﺩ) ﺰﺗﺭﺍﻮﮐ ﺭﺎﺒﻏ ﻭ ﺩﺮﮔ ﻪﻠﻤﺟ ﺯﺍ یﺍ ﻩﮋﯾﻭ یﺎﻫﺭﺎﺒﻏ ﻭ ﺩﺮﮔ

ﺺﺼﺨﺘﻣ ﺩﺍﺮﻓﺍ ﻂﻘﻓ .ﺪﻧﺍ ﻩﺪﺷ ﻪﺘﺧﺎﻨﺷ ﺍﺯ ﻥﺎﻃﺮﺳ ﺭﺎﺒﻏ ﻭ ﺩﺮﮔ

.ﺪﻨﻨﮐ ﺭﺎﮐ ﺖﺴﺑﺯﺁ یﻭﺎﺣ ﺩﺍﻮﻣ ﺎﺑ ﺪﻧﺯﺎﺠﻣ

ﻪﻌﻄﻗ) ﻩﺩﺎﻣ ﺭﻮﺧﺭﺩ ﻭ ﺐﺳﺎﻨﻣ ﺶﮑﻣ ﻩﺎﮕﺘﺳﺩ ﮏﯾ ﺯﺍ ﻥﺎﮑﻣﻻﺍ ﯽﺘﺣ

–

.ﺪﯿﻨﮐ ﻩﺩﺎﻔﺘﺳﺍ (ﺭﺎﮐ

 ﯽﻓﺎﮐ یﺍﻮﻫ ﻪﯾﻮﻬﺗ ﺯﺍ ﺎﻤﺷ ﺭﺎﮐ ﻞﺤﻣ ﻪﮐ ﺪﯿﺷﺎﺑ ﻪﺘﺷﺍﺩ ﻪﺟﻮﺗ

–

.ﺪﺷﺎﺑ ﺭﺍﺩﺭﻮﺧﺮﺑ

P2

 ﺮﺘﻠﯿﻓ ﻪﺟﺭﺩ ﺎﺑ ﯽﻨﻤﯾﺍ ﯽﺴﻔﻨﺗ ﮏﺳﺎﻣ ﺯﺍ ﺩﻮﺸﯿﻣ ﻪﯿﺻﻮﺗ

–

.ﺪﯿﻨﮐ ﻩﺩﺎﻔﺘﺳﺍ

ﺯﺍ ﻩﺩﺎﻔﺘﺳﺍ ﺎﺑ ﻪﻄﺑﺍﺭ ﺭﺩ ﺩﻮﺧ ﺭﻮﺸﮐ ﺭﺩ ﺮﺒﺘﻌﻣ ﺕﺍﺭﺮﻘﻣ ﻭ ﻦﯿﻧﺍﻮﻗ ﻪﺑ

.ﺪﯿﻨﮐ ﻪﺟﻮﺗ یﺭﺎﮐ ﺕﺎﻌﻄﻗ ﻭ ﺩﺍﻮﻣ

(

E

ﺮﯾﻮﺼﺗ ﻪﺑ ﺩﻮﺷ ﻉﻮﺟﺭ) ﺭﺎﺒﻏ ﻭ ﺩﺮﮔ ﺶﮑﻣ ﻩﺎﮕﺘﺳﺩ ﻝﺎﺼﺗﺍ ﻩﻮﺤﻧ

 .ﺪﯿﻨﮐ ﻭﺮﻓ

4

 ﻝﺎﺼﺗﺍ ﻞﺤﻣ ﻪﻟﻮﻟ ﻞﺧﺍﺩ ﺍﺭ (ﺕﺎﻘﻠﻌﺘﻣ)

17

ﺶﮑﻣ ﮓﻨﻠﺷ

 (ﺕﺎﻘﻠﻌﺘﻣ) ﯽﻗﺮﺑ ﻭﺭﺎﺟ - ﺶﮑﻣ ﻩﺎﮕﺘﺳﺩ ﮏﯾ ﻪﺑ ﺍﺭ

17

ﺶﮑﻣ ﮓﻨﻠﺷ

.ﺪﯿﻨﮐ ﻞﺼﺘﻣ

ﻭﺭﺎﺟ /ﺶﮑﻣ ﻩﺎﮕﺘﺳﺩ ﮏﯾ ﺰﯾﺮﭘ ﻪﺑ ﹰﺎﻤﯿﻘﺘﺴﻣ ﻥﺍﻮﺗ ﯽﻣ ﺍﺭ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﻦﯾﺍ

ﻩﺍﺭ ﺯﺍ ﻝﺮﺘﻨﮐ ﺎﺑ ﺕﺭﺎﺘﺳﹺﺍ ﻪﺑ ﺰﻬﺠﻣ ﻪﮐ ﺵﻮﺑ ﺖﺧﺎﺳ ﻩﺭﻮﻈﻨﻣ ﻪﻤﻫ ﯽﻗﺮﺑ

ﻞﺼﺘﻣ ﺶﮑﻣ ﻩﺎﮕﺘﺳﺩ ،ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﻥﺩﺮﮐ ﻦﺷﻭﺭ ﺎﺑ .ﺩﻮﳕ ﻞﺼﺘﻣ ،ﺖﺳﺍ ﺭﻭﺩ

.ﺩﻮﺷ ﯽﻣ ﻦﺷﻭﺭ ﮏﯿﺗﺎﻣﻮﺗﺍ ﺭﻮﻄﺑ ﺰﯿﻧ ﻩﺪﺷ

.ﺪﺷﺎﺑ ﺐﺳﺎﻨﻣ ﺮﻈﻧ ﺩﺭﻮﻣ ﺭﺎﮐ ﻪﻌﻄﻗ یﺍﺮﺑ ﺪﯾﺎﺑ ﻩﺪﻨﮑﻣ ﻩﺎﮕﺘﺳﺩ

ﺪﻨﺘﺴﻫ ﺍﺯ ﻥﺎﻃﺮﺳ ﻭ ﺪﻧﺮﻀﻣ ﯽﺘﻣﻼﺳ یﺍﺮﺑ ﻪﮐ یﺭﺎﺒﻏ ﻭ ﺩﺮﮔ ﺶﮑﻣ یﺍﺮﺑ

ﻩﺪﻨﮑﻣ ﻩﺎﮕﺘﺳﺩ ﮏﯾ ﺯﺍ ﺪﯾﺎﺑ ﮏﺸﺧ یﺎﻫ ﻪﺷﺍﺮﺗ ﺶﮑﻣ یﺍﺮﺑ ﺎﯾ ﻭ

.ﺪﯿﻨﮐ ﻩﺩﺎﻔﺘﺳﺍ ﺹﻮﺼﺨﻣ

ﺐﺼﻧ ﻞﺤﻣ ﻪﺑ ﺶﮑﻣ ﮓﻨﻠﺷ ﻩﺪﻧﺭﺍﺪﻬﮕﻧ ﻪﻌﻄﻗ ﻥﺩﺮﮐ ﻞﺼﺘﻣ

(

F

ﺮﯾﻮﺼﺗ ﻪﺑ ﺩﻮﺷ ﻉﻮﺟﺭ)  ﺶﮑﻣ ﮓﻨﻠﺷ ﻩﺪﻧﺭﺍﺪﻬﮕﻧ

 ﻪﺑ ﺎﻬﻧﺁ ﻝﺎﺼﺗﺍ ﻖﯾﺮﻃ ﺯﺍ ﺍﺭ

17

 ﺶﮑﻣ ﮓﻨﻠﺷ ﻭ

18

ﻩﺪﻧﺭﺍﺪﻬﮕﻧ ﻪﻌﻄﻗ

.ﺪﯿﻨﮐ ﺖﯿﺒﺜﺗ ،ﺶﮑﻣ ﮓﻨﻠﺷ ﻩﺪﻧﺭﺍﺪﻬﮕﻧ یﺍﺮﺑ

11

ﺐﺼﻧ ﻞﺤﻣ

ﻩﺎﮕﺘﺳﺩ ﺎﺑ ﺭﺎﮐ ﺯﺮﻃ

(

G

ﺮﯾﻮﺼﺗ ﻪﺑ ﺩﻮﺷ ﻉﻮﺟﺭ) یﺭﺎﮐ ﺯﺮﻓ ﻖﻤﻋ ﻢﯿﻈﻨﺗ ﻩﻮﺤﻧ

ﺭﺍﺰﺑﺍ ﻥﺩﻮﺑ ﺵﻮﻣﺎﺧ ﺕﺭﻮﺻ ﺭﺩ ﻂﻘﻓ ﺪﯾﺎﺑ یﺭﺎﮐ ﺯﺮﻓ ﻖﻤﻋ ﻢﯿﻈﻨﺗ

◀

.ﺩﺮﯿﮕﺑ ﻡﺎﳒﺍ ﯽﻗﺮﺑ

:ﺪﯿﻨﮐ ﻞﻤﻋ ﺮﯾﺯ ﺡﺮﺷ ﻪﺑ ،یﺭﺎﮐ ﺯﺮﻓ ﻖﻤﻋ ﻢﯿﻈﻨﺗ یﺍﺮﺑ

.ﺪﯿﻫﺩ ﺭﺍﺮﻗ ﺭﺎﮐ ﻪﻌﻄﻗ یﻭﺭ ﺮﺑ ﺍﺭ ﻩﺪﺷ ژﺎﺘﻧﻮﻣ ﺯﺮﻓ ﻪﻐﯿﺗ ﺎﺑ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ

–

7

 ﻪﯾﺎﭘ ﺎﺗ ﺪﯿﻨﮐ ﺩﺍﺯﺁ ﺍﺭ یﺭﺎﮐ ﺯﺮﻓ ﻖﻤﻋ ﻦﯿﯿﻌﺗ یﺍﺮﺑ

5

ﻢﯿﻈﻨﺗ ﭻﯿﭘ

–

.ﺪﺷﺎﺑ ﻪﺘﺷﺍﺩ ﻪﻧﺍﺩﺍﺯﺁ ﺖﮐﺮﺣ ﺖﯿﻠﺑﺎﻗ

 ﻑﺮﻃ ﻪﺑ

7

ﻪﯾﺎﭘ ﻥﺩﺍﺩ ﺖﮐﺮﺣ ﻖﯾﺮﻃ ﺯﺍ ﺍﺭ یﺭﺎﮐ ﺯﺮﻓ یﺍﺮﺑ ﺮﻈﻧ ﺩﺭﻮﻣ ﻖﻤﻋ

–

.ﺪﯿﻨﮐ ﻢﯿﻈﻨﺗ ﻦﯿﯾﺎﭘ ﻑﺮﻃ ﻪﺑ ﺎﯾ ﻭ ﻻﺎﺑ

 ﺯﺍ ﺮﺗﻻﺎﺑ ﺮﺘﻤﯿﻠﯿﻣ

5 mm

ﻞﻗﺍﺪﺣ ﺪﯾﺎﺑ (ﺯﺮﻓ ﻪﭽﻐﯿﺗ) یﺭﺎﮐ ﺯﺮﻓ ﺭﺍﺰﺑﺍ

–

.ﺩﺮﯿﮕﺑ ﺭﺍﺮﻗ ﺭﺎﮐ ﻪﻌﻄﻗ

.ﺪﯿﻨﮐ ﻢﮑﺤﻣ ﺍﺭ یﺭﺎﮐ ﺯﺮﻓ ﻖﻤﻋ ﻦﯿﯿﻌﺗ یﺍﺮﺑ

5

ﻢﯿﻈﻨﺗ ﭻﯿﭘ

–

ﺭﺩ ﻭ ﻝﺮﺘﻨﮐ ﯽﻠﻤﻋ ﻥﺎﺤﺘﻣﺍ ﻪﻠﯿﺳﻮﺑ ﺍﺭ ﺯﺮﻓ ﻖﻤﻋ ﻩﺪﺷ ﻡﺎﳒﺍ ﻢﯿﻈﻨﺗ

–

.ﺪﯿﻨﮐ ﺡﻼﺻﺍ ﺍﺮﻧﺁ ﻡﻭﺰﻟ ﺕﺭﻮﺻ

ﻩﺎﮕﺘﺳﺩ ﺩﺮﺑﺭﺎﮐ ﻩﻮﺤﻧ ﻭ یﺯﺍﺪﻧﺍ ﻩﺍﺭ

ﺎﺑ ﺪﯾﺎﺑ ﻕﺮﺑ ﻥﺎﯾﺮﺟ ﻊﺒﻨﻣ ژﺎﺘﻟﻭ !ﺪﯿﻨﮐ ﻪﺟﻮﺗ ﻪﮑﺒﺷ ﻕﺮﺑ ژﺎﺘﻟﻭ ﻪﺑ

◀

ﻪﺘﺷﺍﺩ ﺖﻘﺑﺎﻄﻣ ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ ﺐﺴﭼﺮﺑ یﻭﺭ ﺮﺑ ﺩﻮﺟﻮﻣ ﺮﯾﺩﺎﻘﻣ

 ﺺﺨﺸﻣ ﺖﻟﻭ

230 V

ژﺎﺘﻟﻭ ﺎﺑ ﻪﮐ ﺍﺭ ﯽﻗﺮﺑ یﺎﻫﺭﺍﺰﺑﺍ .ﺪﺷﺎﺑ

.ﺩﺮﺑ ﺭﺎﮑﺑ ﺰﯿﻧ ﺖﻟﻭ

220 V

ژﺎﺘﻟﻭ ﺖﲢ ﻥﺍﻮﺗ ﯽﻣ ،ﺪﻧﺍ ﻩﺪﺷ

ﻩﺎﮕﺘﺳﺩ (ﺖﻋﺮﺳ) ﺭﻭﺩ ﺏﺎﺨﺘﻧﺍ ﻩﻮﺤﻧ

 ﻢﯿﻈﻨﺗ ﻭ ﺏﺎﺨﺘﻧﺍ یﺍﺮﺑ (ﺮﹺﻤﯾﺩ ﺪﯿﻠﮐ)

10

ﺶﺧﺮﭼ ﻞﺑﺎﻗ ﺪﯿﻠﮐ ﻪﻠﯿﺳﻮﺑ

ﺰﯿﻧ ﻩﺎﮕﺘﺳﺩ ﺩﺮﮐﺭﺎﮐ ﻡﺎﮕﻨﻫ ﺍﺭ ﺯﺎﯿﻧ ﺩﺭﻮﻣ ﺖﻋﺮﺳ ﺪﯿﻧﺍﻮﺘﯿﻣ ،ﺖﻋﺮﺳ

.ﺪﯿﻨﮐ ﺏﺎﺨﺘﻧﺍ

ﻢﮐ ﺖﻋﺮﺳ

20

–

15

ﻂﺳﻮﺘﻣ ﺖﻋﺮﺳ

25

–

20

ﺩﺎﯾﺯ ﺖﻋﺮﺳ

30

–

25

ﻥﺪﺷ ﮏﻨﺧ یﺍﺮﺑ ﺍﺭ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﯽﺘﺴﯾﺎﺑ ،ﻢﮐ ﺖﻋﺮﺳ ﺖﲢ ﺭﺎﮐ ﯽﺗﺪﻣ ﺯﺍ ﺲﭘ

.ﺪﯾﺯﺍﺪﻧﺍ ﺭﺎﮑﺑ ﺩﺍﺯﺁ ﺖﻟﺎﺣ ﺭﺩ ﺖﻋﺮﺳ ﺮﺜﮐﺍﺪﺣ ﺎﺑ ﻪﻘﯿﻗﺩ

3

ﹰﺎﺒﯾﺮﻘﺗ ﺕﺪﻣ ﻪﺑ

ﯽﺳﺭﺎﻓ

|  251

Bosch Power Tools

2 610 016 614

|

 (2.3.11)

:ﻂﺳﻮﺗ ﯽﻨﻓ کﺭﺍﺪﻣ

Robert Bosch GmbH, PT/ESC,

D-70745 Leinfelden-Echterdingen

Dr. Eckerhard Strötgen

Head of Product

Certification

Dr. Egbert Schneider

Senior Vice President

Engineering

Robert Bosch GmbH, Power Tools Division

D-70745 Leinfelden-Echterdingen

05.08.2010

ﺐﺼﻧ

ﻪﺧﺎﺷﻭﺩ ،ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ یﻭﺭ ﺮﺑ یﺭﺎﮐ ﻪﻧﻮﮔﺮﻫ ﻡﺎﳒﺍ ﺯﺍ ﺶﯿﭘ

◀

.ﺪﯿﺸﮑﺑ ﻥﻭﺮﯿﺑ ﻕﺮﺑ ﺰﯾﺮﭘ ﻞﺧﺍﺩ ﺯﺍ ﺍﺮﻧﺁ ﻝﺎﺼﺗﺍ

ﯽﮑﻤﮐ ﻪﺘﺳﺩ ﯽﺑﺎﮐﺭ ﺪﻨﺑ ﻥﺩﺮﮐ ﻢﯿﻈﻨﺗ

(

A

ﺮﯾﻮﺼﺗ ﻪﺑ ﺩﻮﺷ ﻉﻮﺟﺭ)

ﻢﯿﻈﻨﺗ ﺩﻮﺧ ﺖﺳﺩ ﻩﺯﺍﺪﻧﺍ ﺎﺑ ﺐﺳﺎﻨﺘﻣ ﺍﺭ ﻩﺎﮕﺘﺳﺩ ﻪﺘﺳﺩ ﯽﺑﺎﮐﺭ ﺪﻨﺑ

◀

.ﺪﯿﻨﮐ ﺭﺎﮐ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﺎﺑ ﻦﺌﻤﻄﻣ ﺭﻮﻄﺑ ﺪﯿﻧﺍﻮﺘﺑ ﺎﺗ ،ﺪﯿﻨﮐ

.ﺪﯿﻨﮐ ﺯﺎﺑ ﺍﺭ

2

ﯽﺑﺎﮐﺭ ﺪﻨﺑ ﺭﺩ ﺩﻮﺟﻮﻣ (ﻩﺪﻨﺒﺴﭼ ﺭﺍﻮﻧ) ﻭﺮﮑﻟﻭ ﻝﺎﺼﺗﺍ

–

ﯽﺑﺎﮐﺭ ﺪﻨﺑ ﻡﻭﺰﻟ ﺕﺭﻮﺻ ﺭﺩ ﻭ ﺪﯾﺭﺍﺩ ﻩﺎﮕﻧ ﺩﻮﺧ ﺖﺳﺩ ﺎﺑ ﺍﺭ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ

–

.ﺪﯾﺪﻨﺒﺑ ﺍﺭ ﻩﺎﺗﻮﮐ

 ،ﻭﺮﮑﻟﻭ ﻩﺪﻨﻫﺩ ﻝﺎﺼﺗﺍ ﺭﺍﻮﻧ ﱳﺴﺑ ﺎﺑ ﻭ ﺪﯿﺸﮑﺑ ﺍﺭ

2

ﺮﺗ ﻞﯾﻮﻃ ﯽﺑﺎﮐﺭ ﺪﻨﺑ

–

.ﺪﯿﻨﮐ ﺖﯿﺒﺜﺗ ﺍﺭ ﯽﺑﺎﮐﺭ ﺪﻨﺑ

(

B

ﺮﯾﻮﺼﺗ ﻪﺑ ﺩﻮﺷ ﻉﻮﺟﺭ) ﻢﯿﻈﻨﺗ ﻞﺑﺎﻗ ﻪﯾﺎﭘ ﻥﺩﺮﮐ ﺐﺼﻧ

.ﺩﻮﺸﺑ ﺐﺼﻧ

7

ﻪﯾﺎﭘ ﺪﯾﺎﺑ ،یﺭﺎﮐ ﺯﺮﻓ یﺍﺮﺑ

.ﺪﯿﻨﮐ ﺯﺎﺑ ﺍﺭ

6

ﺭﺎﻬﳑﺮﻫﺍ

–

 ﺖﻣﻼﻋ ﻞﺤﻣ ﺎﺑ ،ﺍﺭ

7

ﻪﯾﺎﭘ ﺭﺩ ﺩﻮﺟﻮﻣ ﻩﺪﺷ یﺭﺍﺬﮔ ﺖﻣﻼﻋ ﻞﺤﻣ

–

ﯽﻣ ﻩﺩﺍﺩ ﻥﺎﺸﻧ ﺮﯾﻮﺼﺗ ﺭﺩ ﻪﮐ ﻪﻧﻮﮕﻧﺎﻤﻫ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﺭﺩ ﺩﻮﺟﻮﻣ یﺭﺍﺬﮔ

.ﺪﯿﻨﮐ ﻖﺒﻄﻨﻣ ﻢﻫ ﺮﺑ ﻭ ﻩﺩﺍﺩ ﺭﺍﺮﻗ ﺎﺘﺳﺍﺭ ﮏﯾ ﺭﺩ ،ﺩﻮﺷ

 ﻡﺮﻫﺍ ﺲﭙﺳ ﻭ ﺪﯿﻫﺪﺑ ﺭﺎﺸﻓ (ﻩﺎﮕﺘﺳﺩ ﻪﺑ) ﺖﺴﯾﺍ ﻪﻄﻘﻧ ﺎﺗ ﺍﺭ

7

 ﻪﯾﺎﭘ

–

.ﺪﯾﺪﻨﺒﺑ ﺍﺭ

6

ﺭﺎﻬﻣ

(

C

ﺮﯾﻮﺼﺗ ﻪﺑ ﺩﻮﺷ ﻉﻮﺟﺭ) ﺖﻟﻮﮐ ﺾﯾﻮﻌﺗ ﻩﻮﺤﻧ

،ﺯﺮﻓ ﻪﭽﻐﯿﺗ ﻥﺩﺍﺩ ﺭﺍﺮﻗ ﺯﺍ ﺶﯿﭘ ﺪﯾﺎﺑ ،ﻩﺩﺎﻔﺘﺳﺍ ﺩﺭﻮﻣ یﺭﺎﮐ ﺯﺮﻓ ﺭﺍﺰﺑﺍ ﺐﺴﺣﺮﺑ

.ﺪﯿﻨﮐ ﺾﯾﻮﻌﺗ ﺍﺭ

13

ﺖﻟﻮﮐ

ﯽﻣ ،ﺪﺷﺎﺑ ﻩﺪﺷ ﺐﺼﻧ ﺎﻤﺷ ﺯﺮﻓ ﻪﭽﻐﯿﺗ یﺍﺮﺑ ﺐﺳﺎﻨﻣ ﺖﻟﻮﮐ ﻪﭽﻧﺎﻨﭼ

ﻖﻤﻋ ﻢﯿﻈﻨﺗ ﻩﻮﺤﻧ» ﺚﺤﺒﻣ ﺭﺩ ﺡﻭﺮﺸﻣ یﺭﺎﮐ ﻞﺣﺍﺮﻣ ﺎﺑ ﻖﺑﺎﻄﻣ ﺪﯿﻧﺍﻮﺗ

.ﺪﯿﻨﮐ ﻞﻤﻋ ،«یﺭﺎﮐ ﺯﺮﻓ

 ﻪﺑ ﺪﯾﺎﺑ

3

 ﻩﺮﻬﻣ .ﺩﺮﯿﮕﺑ ﺭﺍﺮﻗ ﺖﻟﻮﮐ ﻩﺮﻬﻣ ﺭﺩ ﺩﺍﺯﺁ ﺭﻮﻄﺑ ﺪﯾﺎﺑ

13

ﺖﻟﻮﮐ

،ﺪﻨﺷﺎﺑ ﻩﺪﯾﺩ ﺐﯿﺳﺁ ﺖﻟﻮﮐ ﺎﯾ ﻭ ﻩﺮﻬﻣ ﻪﭽﻧﺎﻨﭼ .ﺪﺷﺎﺑ ﺐﺼﻧ ﻞﺑﺎﻗ ﯽﻧﺎﺳﺁ

.ﺪﯿﻨﮐ ﺾﯾﻮﻌﺗ ﻪﻠﺻﺎﻓﻼﺑ ﺍﺭ ﺎﻬﻧﺁ

 ﺭﺩ .ﺪﯾﺭﺍﺪﻬﮕﻧ ﻭ ﺪﯿﻫﺪﺑ ﺭﺎﺸﻓ ﺍﺭ

15

ﻩﺎﮕﺘﺳﺩ ﺭﻮﺤﻣ ﻞﻔﻗ ﻪﻤﮐﺩ

–

.ﺩﻮﺷ ﻞﻔﻗ ﺎﺗ ﺪﯿﻧﺎﺧﺮﭽﺑ ﺖﺳﺩ ﻪﻠﯿﺳﻮﺑ ﺍﺭ ﺭﻮﺗﻮﻣ ﺭﻮﺤﻣ ﺯﺎﯿﻧ ﺕﺭﻮﺻ

.ﺪﯿﻨﮐ ﺯﺎﺑ

1

 ﺖﺨﺗ ﺭﺎﭼﺁ ﻪﻠﯿﺳﻮﺑ ﺍﺭ

3

ﻩﺮﻬﻣ

–

.ﺪﯿﻨﮐ ﺎﻫﺭ ﺍﺭ ﻩﺎﮕﺘﺳﺩ ﺭﻮﺤﻣ ﻞﻔﻗ ﻪﻤﮐﺩ

–

،ژﺎﺘﻧﻮﻣ ﺯﺍ ﺶﯿﭘ ﺍﺭ ﺪﻧﻮﺷ ﺐﺼﻧ ﺪﯾﺎﺑ ﻪﮐ ﯽﺗﺎﻌﻄﻗ ﻪﻤﻫ ﻡﻭﺰﻟ ﺕﺭﻮﺻ ﺭﺩ

–

ﯽﺋﺍﺩﺯ ﺭﺎﺒﻏ ،ﺩﺎﺑ ﺭﺎﺸﻓ ﺖﲢ ﺎﯾ ﻭ ﻡﺮﻧ یﻮﻣ ﻢﻠﻗ ﺎﯾ ﻡﺮﻧ ﺱﺮﺑ ﮏﯾ ﻪﻠﯿﺳﻮﺑ

.ﺪﯿﻨﮐ

.ﺪﯿﻫﺪﺑ ﺭﺍﺮﻗ

14

ﺮﯿﮔ ﺭﺍﺰﺑﺍ ﺭﺩ ﺍﺭ ﺖﻟﻮﮐ ﻩﺮﻬﻣ

–

.ﺪﺷﺎﺑ ﻩﺪﺸﻧ ﺖﻔﺳ ﺯﻮﻨﻫ ﻪﮐ یﺭﻮﻄﺑ ﺪﯿﻧﺎﭽﯿﭙﺑ ﯽﻤﮐ ﺍﺭ ﺖﻟﻮﮐ ﻩﺮﻬﻣ

–

ﻩﺪﺸﻧ ژﺎﺘﻧﻮﻣ ﺯﺮﻓ ﻪﻐﯿﺗ ﻪﮐ ﯽﻧﺎﻣﺯ ﺎﺗ ﺍﺭ ﺖﻟﻮﮐ ﻩﺮﻬﻣ ﻭ ﺖﻟﻮﮐ ﺰﮔﺮﻫ

◀

ﺖﻟﻮﮐ ﻥﺪﯾﺩ ﺐﯿﺳﺁ ﻥﺎﮑﻣﺍ ﺕﺭﻮﺻ ﻦﯾﺍ ﺮﯿﻏ ﺭﺩ

.ﺪﯿﻨﮑﻧ ﺖﻔﺳ ،ﺖﺳﺍ

.ﺩﺭﺍﺩ ﺩﻮﺟﻭ

ﺯﺮﻓ ﻪﻐﯿﺗ ﻥﺩﺍﺩ ﺭﺍﺮﻗ ﻭ ﺐﺼﻧ ﻩﻮﺤﻧ

(

D

ﺮﯾﻮﺼﺗ ﻪﺑ ﺩﻮﺷ ﻉﻮﺟﺭ)

ﻦﯿﻨﭽﻤﻫ ﻭ ﺯﺮﻓ ﻪﭽﻐﯿﺗ یﺭﺍﺬﮔﺎﺟ ﻭ ﺐﺼﻧ یﺍﺮﺑ ﺩﻮﺷ ﯽﻣ ﻪﯿﺻﻮﺗ

◀

 یﺎﻫ ﻪﭽﻐﯿﺗ

.ﺪﯿﻨﮐ ﻩﺩﺎﻔﺘﺳﺍ ﯽﻨﻤﯾﺍ ﺶﮑﺘﺳﺩ ﺯﺍ ،ﻥﺁ ﺾﯾﻮﻌﺗ یﺍﺮﺑ

.ﺪﻧﻮﺷ ﯽﻣ ﻍﺍﺩ ﺭﺎﯿﺴﺑ ﺭﺎﮐ ﻦﯿﺣ ﺭﺩ ﺯﺮﻓ

ﺯﺍ ﺪﯿﻧﺍﻮﺗ ﯽﻣ ﺍﺭ ﺵﻮﺑ ﺕﺎﻘﻠﻌﺘﻣ ﻊﻣﺎﺟ ﻪﻣﺎﻧﺮﺑ ﺯﺍ ﻞﺻﺍ ﺯﺮﻓ یﺎﻫ ﻪﻐﯿﺗ

.ﺪﯿﻨﮐ یﺭﺍﺪﯾﺮﺧ ﯽﺼﺼﺨﺗ یﺎﻬﻫﺎﮕﺷﻭﺮﻓ

.ﺪﯿﻨﮐ ﻩﺩﺎﻔﺘﺳﺍ ﺰﯿﲤ ﻭ ﻢﻟﺎﺳ ﺯﺮﻓ یﺎﻫ ﻪﻐﯿﺗ ﺯﺍ ﹰﺍﺮﺼﺤﻨﻣ

 ﺭﺩ .ﺪﯾﺭﺍﺪﻬﮕﻧ ﻭ ﺪﯿﻫﺪﺑ ﺭﺎﺸﻓ ﺍﺭ

15

ﻩﺎﮕﺘﺳﺩ ﺭﻮﺤﻣ ﻞﻔﻗ ﻪﻤﮐﺩ

–

.ﺩﻮﺷ ﻞﻔﻗ ﺎﺗ ﺪﯿﻧﺎﺧﺮﭽﺑ ﺖﺳﺩ ﻪﻠﯿﺳﻮﺑ ﺍﺭ ﺭﻮﺗﻮﻣ ﺭﻮﺤﻣ ﺯﺎﯿﻧ ﺕﺭﻮﺻ

.ﺪﯿﻨﮐ ﺯﺎﺑ (

17 mm

 ﺭﺎﭼﺁ ﻪﻧﺎﻫﺩ)

1

 ﺖﺨﺗ ﺭﺎﭼﺁ ﻪﻠﯿﺳﻮﺑ ﺍﺭ

3

ﻩﺮﻬﻣ

–

.ﺪﯿﻧﺎﺧﺮﭽﺑ

➊

ﺖﻬﺟ ﺭﺩ ﺍﺭ ﺖﺨﺗ ﺭﺎﭼﺁ ﺭﺎﮐ ﻦﯾﺍ یﺍﺮﺑ

 ﺎﯾ ﻭ ﻥﺁ ﺭﻮﺤﻣ ﺭﺩ ﻩﺪﺷ یﺭﺍﺬﮔ ﺖﻣﻼﻋ ﻞﺤﻣ ﺎﺗ ﺎﯾ ﺍﺭ

16

ﺯﺮﻓ ﻪﭽﻐﯿﺗ

–

 ﺖﯾﺅﺭ ﻞﺑﺎﻗ ﺯﺮﻓ ﻪﭽﻐﯿﺗ ﺭﻮﺤﻣ ﺯﺍ ﺮﺘﻤﯿﻠﯿﻣ

5 mm

ﹰﺎﺒﯾﺮﻘﺗ ﻪﮐ یﺭﻮﻄﺑ

.ﺪﯿﻫﺪﺑ ﺭﺍﺮﻗ

13

ﺖﻟﻮﮐ ﻞﺧﺍﺩ ،ﺪﺷﺎﺑ

    252 |

ﯽﺳﺭﺎﻓ

2 610 016 614

|

 (2.3.11)

Bosch Power Tools

ﻍﺍﺮﭼ

 8

ﻞﺻﻭ ﻭ ﻊﻄﻗ ﺪﯿﻠﮐ

 9

(ﺮﹺﻤﯾﺩ ﺪﯿﻠﮐ) ﺖﻋﺮﺳ ﺏﺎﺨﺘﻧﺍ ﻭ ﻢﯿﻈﻨﺗ ﺪﯿﻠﮐ

 10

ﺶﮑﻣ ﮓﻨﻠﺷ ﻩﺪﻧﺭﺍﺪﻬﮕﻧ ﻪﻌﻄﻗ ﺐﺼﻧ ﻞﺤﻣ

 11

(ﺭﺍﺩ ﻖﯾﺎﻋ ﺶﮐﻭﺭ ﺎﺑ) ﻪﺘﺳﺩ

 12

ﺖﻟﻮﮐ

 13

ﺮﯿﮔﺭﺍﺰﺑﺍ

 14

ﻩﺎﮕﺘﺳﺩ ﺭﻮﺤﻣ ﻞﻔﻗ ﻪﻤﻛﺩ

 15

*

ﺯﺮﻓ ﻪﺘﻣ ﺎﯾ ﻪﻐﯿﺗ

 16

*

ﺶﻜﻣ ﮓﻨﻠﺷ

 17

*

ﺶﮑﻣ ﮓﻨﻠﺷ ﻩﺪﻧﺭﺍﺪﻬﮕﻧ ﻪﻌﻄﻗ

 18

*

ﺮﺑ ﺩﺮﮔ ﻪﺘﻣ

 19

 ﻩﺍﺮﻤﻫ ﻝﻮﻤﻌﻣ ﺭﻮﻄﺑ ،ﺖﺳﺍ ﻩﺪﻣﺁ ﱳﻣ ﺭﺩ ﺎﯾ ﻭ ﺮﯾﻮﺼﺗ ﺭﺩ ﻪﮐ ﯽﺗﺎﻘﻠﻌﺘﻣ ﻪﯿﻠﮐ

*

ﻪﻣﺎﻧﺮﺑ ﺖﺳﺮﻬﻓ ﺯﺍ ﺍﺭ ﺕﺎﻘﻠﻌﺘﻣ ﻞﻣﺎﮐ ﺖﺴﯿﻟ ﹰﺎﻔﻄﻟ .ﺩﻮﺷ ﯽﳕ ﻪﺋﺍﺭﺍ ﻩﺎﮕﺘﺳﺩ

.ﺪﯿﺋﺎﳕ ﺱﺎﺒﺘﻗﺍ ﺕﺎﻘﻠﻌﺘﻣ

ﯽﻨﻓ ﺕﺎﺼﺨﺸﻣ

GTR 30 CE

Professional

ﯽﺷﺎﮐ ﺯﺮﻓ ﻩﺎﮕﺘﺳﺩ

3 601 F0C 0..

ﯽﻨﻓ ﻩﺭﺎﻤﺷ

701

W

ﯽﻣﺎﻧ یﺩﻭﺭﻭ ﺕﺭﺪﻗ

15 000

  – 30 000

min

-1

ﺩﺍﺯﺁ ﺖﻟﺎﺣ ﺭﺩ ﺖﻋﺮﺳ

●

ﺖﻋﺮﺳ ﺏﺎﺨﺘﻧﺍ

●

ﻩﺪﻨﻨﮐ ﺖﯿﺒﺜﺗ ﻭ ﻝﺮﺘﻨﮐ

ﯽﮑﯿﻧﻭﺮﺘﮑﻟﺍ

●

ﺶﮑﻣ ﻩﺎﮕﺘﺳﺩ ﻪﺑ ﻝﺎﺼﺗﺍ

(ﯽﻗﺮﺑ ﻭﺭﺎﺟ)

1,5

kg

ﺩﺭﺍﺪﻧﺎﺘﺳﺍ ﻖﺑﺎﻄﻣ ﻥﺯﻭ

EPTA-Procedure

01/2003

II

/

ﯽﻨﻤﯾﺍ ﺱﻼﮐ

 ﻭ ژﺎﺘﻟﻭ ﺮﯿﯿﻐﺗ ﺕﺭﻮﺻ ﺭﺩ ﻭ ﺪﻨﺷﺎﺑ ﯽﻣ ﺖﻟﻭ

230 V [U]

ﯽﻣﺎﻧ ژﺎﺘﻟﻭ یﺍﺮﺑ ﺕﺎﻋﻼﻃﺍ ﻦﯾﺍ

.ﺪﻨﻨﮐ ﺮﯿﯿﻐﺗ ﺪﻨﻧﺍﻮﺗ ﯽﻣ ﺮﮕﯾﺩ یﺎﻫﺭﻮﺸﮐ ﺭﺩ ﺎﯾ

یﺭﺎﲡ یﺎﻬﻣﺎﻧ .ﺪﯿﻨﮐ ﻪﺟﻮﺗ ﺩﻮﺧ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﺐﺴﭼﺮﺑ یﻭﺭ ﯽﻨﻓ ﻩﺭﺎﻤﺷ ﻪﺑ ﹰﺎﻔﻄﻟ

.ﺪﻨﺷﺎﺑ ﺕﻭﺎﻔﺘﻣ ﺖﺳﺍ ﻦﮑﳑ ﯽﻗﺮﺑ یﺎﻫﺭﺍﺰﺑﺍ

ﺵﺎﻌﺗﺭﺍ ﻭ ﺍﺪﺻ ﻪﺑ ﻁﻮﺑﺮﻣ ﺕﺎﻋﻼﻃﺍ

ﺩﺭﺍﺪﻧﺎﺘﺳﺍ ﺎﺑ ﻖﺑﺎﻄﻣ ،ﺍﺪﺻ ﻥﺍﺰﯿﻣ یﺍﺮﺑ ﻩﺪﺷ یﺮﯿﮔ ﻩﺯﺍﺪﻧﺍ ﺮﯾﺩﺎﻘﻣ

.ﺪﻧﻮﺷ ﯽﻣ ﻪﺒﺳﺎﺤﻣ

EN 60745

ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﻉﻮﻧ ﻦﯾﺍ ﺹﻮﺼﺧ ﺭﺩ ﻩﺪﺷ ﯽﺑﺎﯾﺯﺭﺍ ،

A

ﺱﻼﮐ ﯽﺗﻮﺻ ﺢﻄﺳ

ﯽﺗﻮﺻ ﺕﺭﺪﻗ ﺢﻄﺳ ;

82 dB(A)

ﯽﺗﻮﺻ ﺭﺎﺸﻓ ﺢﻄﺳ ﺎﺑ ﺖﺳﺍ ﻝﺩﺎﻌﻣ

.

K = 3 dB

(ﺖﯿﻌﻄﻗ ﻡﺪﻋ) ﺎﻄﺧ ﺐﯾﺮﺿ .

93 dB(A)

!ﺪﯿﻨﮐ ﻩﺩﺎﻔﺘﺳﺍ ﯽﻨﻤﯾﺍ ﯽﺷﻮﮔ ﺯﺍ

ﺩﺭﺍﺪﻧﺎﺘﺳﺍ یﺎﻨﺒﻣ ﺮﺑ (ﺖﻬﺟ ﻪﺳ یﺎﻫﺭﺍﺩﺮﺑ ﻊﻤﺟ) ﺕﺎﺷﺎﻌﺗﺭﺍ ﻞﮐ ﻥﺍﺰﯿﻣ

:ﺩﻮﺷ ﯽﻣ ﻪﺒﺳﺎﺤﻣ

EN 60745

(ﺖﯿﻌﻄﻗ ﻡﺪﻋ) ﺎﻄﺧ ﺐﯾﺮﺿ ،

a

h

=4,5 m/s

2

ﺵﺎﻌﺗﺭﺍ ﺭﺎﺸﺘﻧﺍ ﻥﺍﺰﯿﻣ

.

K = 1,5 m/s

2

ﻖﺒﻃ یﺮﯿﮔ ﻩﺯﺍﺪﻧﺍ ﺵﻭﺭ ﺎﺑ ﻞﻤﻌﻟﺍﺭﻮﺘﺳﺩ ﻦﯾﺍ ﺭﺩ ﻩﺪﺷ ﺪﯿﻗ ﺵﺎﻌﺗﺭﺍ ﺢﻄﺳ

 ﻪﺴﯾﺎﻘﻣ یﺍﺮﺑ ﻥﺍﻮﺘﯿﻣ ﻥﺁ ﺯﺍ ﻭ ﺩﺭﺍﺩ ﺖﻘﺑﺎﻄﻣ

EN 60745

ﺩﺭﺍﺪﻧﺎﺘﺳﺍ

ﯽﺘﻗﻮﻣ ﺩﺭﻭﺁﺮﺑ یﺍﺮﺑ ﻦﯿﻨﭽﻤﻫ ﻭ ﺩﻮﳕ ﻩﺩﺎﻔﺘﺳﺍ ﺮﮕﯾﺪﮑﯾ ﺎﺑ ﯽﻗﺮﺑ یﺎﻫﺭﺍﺰﺑﺍ

.ﺖﺳﺍ ﺐﺳﺎﻨﻣ ﺰﯿﻧ ﺵﺎﻌﺗﺭﺍ ﺯﺍ ﯽﺷﺎﻧ ﺭﺎﺸﻓ ﺢﻄﺳ

ﺮﮔﺍ ﻪﺘﺒﻟﺍ .ﺖﺳﺍ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﯽﻠﺻﺍ ﺩﺮﺑﺭﺎﮐ ﻑﺮﻌﻣ ﻩﺪﺷ ﺪﯿﻗ ﺵﺎﻌﺗﺭﺍ ﺢﻄﺳ

ﻭ ﺖﺒﻗﺍﺮﻣ ﻥﻭﺪﺑ ﺎﯾ ﻭ ﺮﮕﯾﺩ یﺩﺮﺑﺭﺎﮐ یﺎﻫﺭﺍﺰﺑﺍ ﺎﺑ ﺮﮕﯾﺩ ﺩﺭﺍﻮﻣ یﺍﺮﺑ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ

ﺵﺎﻌﺗﺭﺍ ﺢﻄﺳ ﺮﯿﯿﻐﺗ ﻥﺎﮑﻣﺍ ﺕﺭﻮﺼﻧﺁ ﺭﺩ ،ﺩﻮﺷ ﻩﺩﺮﺑ ﺭﺎﮑﺑ ﯽﻓﺎﮐ ﺲﯾﻭﺮﺳ

ﻥﺎﻣﺯ ﺕﺪﻣ ﻝﻮﻃ ﺭﺩ ﺍﺭ ﺵﺎﻌﺗﺭﺍ ﺯﺍ ﯽﺷﺎﻧ ﺭﺎﺸﻓ ﺪﻧﺍﻮﺘﯿﻣ ﺮﻣﺍ ﻦﯾﺍ .ﺩﺭﺍﺩ ﺩﻮﺟﻭ

.ﺪﻫﺪﺑ ﺶﯾﺍﺰﻓﺍ ﺡﻮﺿﻭ ﻪﺑ ﺭﺎﮐ

ﻪﮐ ﻢﻫ ﺍﺭ ﯽﺋﺎﻬﻧﺎﻣﺯ ﺪﯾﺎﺑ ،ﺵﺎﻌﺗﺭﺍ ﺯﺍ ﯽﺷﺎﻧ ﺭﺎﺸﻓ ﻖﯿﻗﺩ ﺩﺭﻭﺁﺮﺑ ﺖﻬﺟ

ﻥﺁ ﺭﺩ ﻦﮑﯿﻟﻭ ﺖﺳﺍ ﻦﺷﻭﺭ ﻩﺎﮕﺘﺳﺩ ﻪﮑﻨﯾﺍ ﺎﯾ ﻭ ﺖﺳﺍ ﺵﻮﻣﺎﺧ ﻩﺎﮕﺘﺳﺩ

ﺢﻄﺳ ﺪﻧﺍﻮﺘﯿﻣ ﻪﻠﺌﺴﻣ ﻦﯾﺍ .ﺖﻓﺮﮔ ﺮﻈﻧ ﺭﺩ ،ﺩﻮﺸﯿﳕ ﻪﺘﻓﺮﮔ ﺭﺎﮑﺑ ﻥﺎﻣﺯ

.ﺪﻨﮐ ﻢﮐ ﺡﻮﺿﻭ ﻪﺑ ﺭﺎﮐ ﻝﻮﻃ ﻞﮐ ﺭﺩ ﺍﺭ ﺵﺎﻌﺗﺭﺍ ﺯﺍ ﯽﺷﺎﻧ ﺭﺎﺸﻓ

ﺍﺭ ﺎﻬﻧﺁ یﺭﺍﺬﮔﺮﯿﺛﺄﺗ ﺯﺍ ﻞﺒﻗ ﻭ ﺎﻫ ﺵﺎﻌﺗﺭﺍ ﺮﺑﺍﺮﺑ ﺭﺩ ﻒﻋﺎﻀﻣ ﯽﻨﻤﯾﺍ ﺕﺎﻣﺍﺪﻗﺍ

ﻥﺍﻮﻨﻌﺑ ،ﺪﯾﺮﯿﮕﺑ ﺮﻈﻧ ﺭﺩ ﺪﻨﮑﯿﻣ ﺭﺎﮐ ﻩﺎﮕﺘﺳﺩ ﺎﺑ ﻪﮐ یﺩﺮﻓ ﺖﻇﺎﻔﺣ یﺍﺮﺑ

ﻭ ﺎﻬﺘﺳﺩ ﱳﺷﺍﺪﻬﮕﻧ ﻡﺮﮔ ،ﻥﺁ ﺕﺎﻘﺤﻠﻣ ﻭ ﺭﺍﺰﺑﺍ ﻭ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﺲﯾﻭﺮﺳ ﻝﺎﺜﻣ

.یﺭﺎﮐ ﻞﺣﺍﺮﻣ ﯽﻫﺩ ﻥﺎﻣﺯﺎﺳ

ﺖﻘﺑﺎﻄﻣ ﻪﯾﺭﺎﻬﻇﺍ

ﻪﮐ ،ﻢﯾﺭﺍﺪﯿﻣ ﺭﺎﻬﻇﺍ یﺭﺎﺼﺤﻧﺍ ﺖﯿﻟﻮﺌﺴﻣ ﻝﻮﺒﻗ ﺎﺑ ﻪﻠﯿﺳﻮﻨﯾﺪﺑ

،ﺎﻫﺭﺍﺪﻧﺎﺘﺳﺍ ﺎﺑ «ﯽﻨﻓ ﺕﺎﺼﺨﺸﻣ ﻭ ﻡﺎﻗﺭﺍ» ﺖﲢ ﻪﺣﻭﺮﺸﻣ ﺕﻻﻮﺼﺤﻣ

ﺎﺑ ﻖﺑﺎﻄﻣ ،

EN 60745

:ﺪﻧﺭﺍﺩ ﺖﻘﺑﺎﻄﻣ ﺮﯾﺯ ﯽﻨﻓ کﺭﺍﺪﻣ ﻭ ﺎﻫ ﻡﺭﻮﻧ

.

2006/42/EG

 ،

2004/108/EG

یﺎﻬﻠﻤﻌﻟﺍﺭﻮﺘﺳﺩ ﺕﺍﺭﺮﻘﻣ

ﯽﺳﺭﺎﻓ

|  253

Bosch Power Tools

2 610 016 614

|

 (2.3.11)

ﻭ ﻥﺎﻤﺘﺧﺎﺳ ﺭﺩ ﺩﻮﺟﻮﻣ ﻥﺎﻬﻨﭘ یﺎﻫ ﻢﯿﺳ ﻭ ﺎﻫ ﻪﻟﻮﻟ ﻥﺩﺮﮐ ﺍﺪﯿﭘ یﺍﺮﺑ

◀

ﺎﻫ ﻪﻟﻮﻟ ﱳﻓﺎﯾ یﺍﺮﺑ ﺹﻮﺼﺨﻣ ﺏﺎﯾﺩﺭ ﻩﺎﮕﺘﺳﺩ ﮏﯾ ﺯﺍ ،ﺭﺎﮐ ﻩﺩﻭﺪﺤﻣ

یﺎﻫﺭﺎﮐ یﺎﻫ ﺖﮐﺮﺷ ﺎﺑ ﺎﯾ ﻭ ﺪﯿﻨﮐ ﻩﺩﺎﻔﺘﺳﺍ ﺕﺎﺴﯿﺳﺄﺗ یﺎﻬﻤﯿﺳ ﻭ

ﺎﺑ ﺱﺎﲤ

.ﺪﯾﺮﯿﮕﺑ ﺱﺎﲤ ﻪﻃﻮﺑﺮﻣ ﺕﺎﻣﺪﺧ ﻭ ﻥﺎﻤﺘﺧﺎﺳ ﺕﺎﺴﯿﺳﺄﺗ

ﯽﮕﺘﻓﺮﮔ ﻕﺮﺑ ﺎﯾ ﻭ یﺯﻮﺴﺸﺗﺁ ﺚﻋﺎﺑ ﺖﺳﺍ ﻦﮑﳑ ﻕﺮﺑ یﺎﻬﻤﯿﺳ ﻭ ﻞﺑﺎﮐ

.ﺩﻮﺷ ﺭﺎﺠﻔﻧﺍ ﺚﻋﺎﺑ ﺪﻧﺍﻮﺘﯿﻣ ﺯﺎﮔ ﻪﻟﻮﻟ ﯽﮔﺪﯾﺩ ﺐﯿﺳﺁ ﻭ ﺩﺍﺮﯾﺍ .ﺩﻮﺷ

.ﺩﻮﺸﯿﻣ ﺕﺭﺎﺴﺧ ﺩﺎﺠﯾﺍ ﺚﻋﺎﺑ ﺏﺁ ﻪﻟﻮﻟ ﻥﺪﺷ ﺥﺍﺭﻮﺳ

ﺪﻨﮐ ﺯﺮﻓ ﻪﻐﯿﺗ

.ﺪﯿﻨﮑﻧ ﻩﺩﺎﻔﺘﺳﺍ ﻩﺪﯾﺩ ﺐﯿﺳﺁ ﺎﯾ ﻭ ﺪﻨﮐ ﺯﺮﻓ ﻪﻐﯿﺗ ﺯﺍ

◀

ﺮﯿﮔ ﺖﺳﺍ ﻦﮑﳑ ،ﺩﻮﺷ ﯽﻣ ﺪﯾﺪﺷ کﺎﮑﻄﺻﺍ ﺚﻋﺎﺑ ﻩﺪﯾﺩ ﺐﯿﺳﺁ ﺎﯾ ﻭ

.ﺩﻮﺸﺑ ﻝﺩﺎﻌﺗ ﻥﺩﺍﺩ ﺖﺳﺩ ﺯﺍ ﻪﺑ ﺮﺠﻨﻣ ﻭ ﺪﻨﮐ

ﺭﺎﮐ ﻞﺤﻣ ﯽﮑﯾﺩﺰﻧ ﺭﺩ ﻝﺎﻌﺘﺷﺍ ﻞﺑﺎﻗ ﺩﺍﻮﻣ یﺭﺍﺪﻬﮕﻧ ﻭ ﻉﺎﻤﺘﺟﺍ ﺯﺍ

◀

ﺯﺍ ﻍﺍﺩ یﺎﻫ ﻪﺷﺍﺮﺗ ،ﺎﻫ ﯽﺷﺎﮐ یﻭﺭ ﺮﺑ ﺭﺎﮐ ﻦﯿﺣ ﺭﺩ

.ﺪﯿﻨﮐ ﺏﺎﻨﺘﺟﺍ ﺩﻮﺧ

.ﺩﺭﺍﺩ ﺩﻮﺟﻭ ﻝﺎﻌﺘﺷﺍ ﺮﻄﺧ ﻪﺠﯿﺘﻧ ﺭﺩ ﻭ ﺪﻧﻮﺷ ﯽﻣ ﺪﯿﻟﻮﺗ ﺩﺍﻮﻣ

ﺭﻮﻄﺑ ﻩﺎﮕﺘﺳﺩ ﺎﺗ ﺪﯿﻨﮐ ﺮﺒﺻ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﱳﺷﺍﺬﮔ ﺭﺎﻨﮐ ﺯﺍ ﻞﺒﻗ

◀

ﺖﺳﺍ ﻦﮑﳑ ﻩﺎﮕﺘﺳﺩ ﺕﺎﻘﺤﻠﻣ ﻭ ﺭﺍﺰﺑﺍ

.ﺪﺘﺴﯾﺎﺑ ﺖﮐﺮﺣ ﻭ ﺭﺎﮐ ﺯﺍ ﻞﻣﺎﮐ

.ﺩﻮﺷ ﺝﺭﺎﺧ ﺎﻤﺷ ﺖﺳﺩ ﺯﺍ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﻝﺮﺘﻨﮐ ﻭ ﻩﺩﺮﮐﺮﯿﮔ ﺭﺎﮐ ﻪﻌﻄﻗ ﻪﺑ

ﺎﻫ ﺖﻣﻼﻋ

ﺮﻃﺎﺨﺑ ﺏﻮﺧ ﺍﺭ ﺎﻬﻧﺁ ﻡﻮﻬﻔﻣ ﻭ ﻢﯾﻼﻋ ﻦﯾﺍ ﹰﺎﻔﻄﻟ .ﺪﻨﺷﺎﺑ ﺖﯿﻤﻫﺍ ﺮﭘ ﺎﻤﺷ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﺯﺍ ﻩﺩﺎﻔﺘﺳﺍ ﻭ ﺭﺎﮐ یﺍﺮﺑ ﺪﻨﻧﺍﻮﺘﯿﻣ ﺎﻬﻧﺁ ﯽﻧﺎﻌﻣ ﻭ ﺮﯾﺯ یﺎﻫ ﺩﺎﳕ ﻭ ﻢﯾﻼﻋ

.ﺪﯿﻫﺪﺑ ﺭﺍﺮﻗ ﻩﺩﺎﻔﺘﺳﺍ ﺩﺭﻮﻣ ﺮﺗ ﻦﺌﻤﻄﻣ ﻭ ﺮﺘﻬﺑ ﺍﺭ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﻪﮐ ﺪﻨﮑﯿﻣ ﮏﻤﮐ ﺎﻤﺷ ﻪﺑ ﻢﯾﻼﻋ ﻦﯾﺍ ﺢﯿﺤﺻ ﺮﯿﺴﻔﺗ .ﺪﯾﺭﺎﭙﺴﺑ

ﺖﻣﻼﻋ

ﯽﻨﻌﻣ

.ﺪﯿﻨﻛ ﻩﺩﺎﻔﺘﺳﺍ ﯽﻨﻤﯾﺍ ﻚﻨﯿﻋ ﺯﺍ

◀

.ﺪﻧﺎﺳﺮﺑ ﺐﯿﺳﺁ ﺎﻤﺷ ﯽﯾﺍﻮﻨﺷ ﻪﺑ ﺖﺳﺍ ﻦﮑﳑ ﺪﻨﻠﺑ یﺍﺪﺻ

.ﺪﯿﻨﮐ ﻩﺩﺎﻔﺘﺳﺍ ﯽﻨﻤﯾﺍ ﯽﺷﻮﮔ ﺯﺍ

◀

.ﺪﯿﻨﮐ ﻩﺩﺎﻔﺘﺳﺍ ﺭﺎﺒﻏ ﻭ ﺩﺮﮔ ﺮﺑﺍﺮﺑ ﺭﺩ ﺲﻔﻨﺗ ﯽﻨﻤﯾﺍ ﮏﺳﺎﻣ ﺯﺍ

◀

ﻥﺁ ﺩﺮﮑﻠﻤﻋ ﻭ ﻩﺎﮕﺘﺳﺩ ﺢﯾﺮﺸﺗ

ﻪﻌﻟﺎﻄﻣ ﺍﺭ ﺎﻫ ﯽﺋﺎﻤﻨﻫﺍﺭ ﻭ ﯽﻨﻤﯾﺍ ﺕﺍﺭﻮﺘﺳﺩ ﻪﯿﻠﮐ

ﺕﺍﺭﻮﺘﺳﺩ ﻦﯾﺍ ﺖﯾﺎﻋﺭ ﻡﺪﻋ ﺯﺍ ﯽﺷﺎﻧ ﺕﺎﻫﺎﺒﺘﺷﺍ

.ﺪﯿﻨﮐ

ﺎﯾ ﻭ ﯽﮕﺘﺧﻮﺳ ،ﯽﮕﺘﻓﺮﮔ ﻕﺮﺑ ﺚﻋﺎﺑ ﺖﺳﺍ ﻦﮑﳑ ﯽﻨﻤﯾﺍ

.ﺩﻮﺷ ﺪﯾﺪﺷ یﺎﻫ ﺖﺣﺍﺮﺟ ﺮﯾﺎﺳ

ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﺮﯾﻮﺼﺗ یﻭﺎﺣ ﻪﮐ ﺍﺭ ﺎﻤﻨﻫﺍﺭ ﻪﭼﺮﺘﻓﺩ ﻦﯾﺍ ﻩﺪﺷ ﺎﺗ ﻪﺤﻔﺻ ﹰﺎﻔﻄﻟ

.ﺪﯾﺭﺍﺪﻬﮕﻧ ﺯﺎﺑ ﺍﺮﻧﺁ ،ﺎﻤﻨﻫﺍﺭ ﻪﭼﺮﺘﻓﺩ ﻦﯾﺍ ﻥﺪﻧﺍﻮﺧ ﻡﺎﮕﻨﻫ ﻭ ﺪﯿﻨﮐ ﺯﺎﺑ ،ﺖﺳﺍ

ﻩﺎﮕﺘﺳﺩ ﺯﺍ ﻩﺩﺎﻔﺘﺳﺍ ﺩﺭﺍﻮﻣ

،ﮏﯿﻣﺍﺮﺳ) ﺎﻫ ﯽﺷﺎﮐ ﺭﺩ یﺭﺎﮐ ﺯﺮﻓ ﻭ یﺭﺎﮑﺧﺍﺭﻮﺳ یﺍﺮﺑ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﻦﯾﺍ

ﺯﺍ ﻩﺩﺎﻔﺘﺳﺍ ﻥﻭﺪﺑ (ﯽﻌﯿﺒﻃ ﮓﻨﺳ ،ﻝﺎﻔﺳ ﯽﺷﺎﮐ ،ﺮﻣﺮﻣ ﮓﻨﺳ ،ﺖﯿﻧﺍﺮﮔ

.ﺖﺳﺍ ﻩﺪﺷ ﻪﺘﻓﺮﮔ ﺮﻈﻧ ﺭﺩ ﺏﺁ

ﻩﺎﮕﺘﺳﺩ ﺀﺍﺰﺟﺍ

ﻪﺑ ﻁﻮﺑﺮﻣ ،ﺩﻮﺸﯿﻣ ﻩﺪﻫﺎﺸﻣ ﺮﯾﻮﺼﺗ ﺭﺩ ﻪﮐ ﻩﺎﮕﺘﺳﺩ ﺀﺍﺰﺟﺍ یﺎﻫ ﻩﺭﺎﻤﺷ

.ﺖﺳﺍ ﻩﺪﻣﺁ ﻪﭼﺮﺘﻓﺩ ﻦﯾﺍ ﺭﺩ ﻥﺁ ﺮﯾﻮﺼﺗ ﻪﮐ ﺪﺷﺎﺑ ﯽﻣ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﺡﺮﺷ

ﺮﺘﻤﯿﻠﯿﻣ

17 mm

ﺭﺎﭼﺁ ﻪﻧﺎﻫﺩ ﻩﺯﺍﺪﻧﺍ ،ﺖﺨﺗ ﺭﺎﭼﺁ

 1

ﯽﺑﺎﮐﺭ ﺪﻨﺑ ﺎﺑ ﯽﮑﻤﮐ ﻪﺘﺳﺩ

 2

ﺖﻟﻮﮐ ﻩﺮﻬﻣ

 3

ﺶﻜﻣ ﻩﺎﮕﺘﺳﺩ ﻪﺑ ﻝﺎﺼﺗﺍ ﻪﻟﻮﻟ

 4

یﺭﺎﮐ ﺯﺮﻓ ﻖﻤﻋ ﻢﯿﻈﻨﺗ ﭻﯿﭘ

 5

(ﻪﯾﺎﭘ ﻥﺩﺮﮐ ﻪﺘﺴﺑ ﻭ ﺯﺎﺑ ﻡﺮﻫﺍ) ﺭﺎﻬﻣ ﻡﺮﻫﺍ

 6

ﻢﯿﻈﻨﺗ ﻭ ﺮﯿﯿﻐﺗ ﻞﺑﺎﻗ ﻪﯾﺎﭘ ﻪﺤﻔﺻ

 7

    254 |

ﯽﺳﺭﺎﻓ

2 610 016 614

|

 (2.3.11)

Bosch Power Tools

 .ﺪﺷﺎﺑ ﻪﺘﺷﺍﺩ ﺭﺍﺮﻗ یﺩﺎﻋ ﺖﻟﺎﺣ ﺭﺩ ﺪﯾﺎﺑ ﺎﻤﺷ ﻥﺪﺑ ﺖﯿﻌﺿﻭ

(e

ﻝﺩﺎﻌﺗ ﻭ ﻩﺩﺮﮐ ﺏﺎﺨﺘﻧﺍ ﺩﻮﺧ یﺍﺮﺑ ﯽﻨﺌﻤﻄﻣ یﺎﺟ ﺭﺎﮐ یﺍﺮﺑ

ﺭﺍﺰﺑﺍ ﺪﯿﻧﺍﻮﺗ ﯽﻣ ﺐﯿﺗﺮﺗ ﻦﯾﺍ ﻪﺑ

.ﺪﯿﻨﮐ ﻆﻔﺣ ﻩﺭﺍﻮﻤﻫ ﺍﺭ ﺩﻮﺧ

ﻝﺮﺘﻨﮐ ﺖﲢ ﺮﺘﻬﺑ ﻩﺮﻈﺘﻨﻣ ﺮﯿﻏ یﺎﻫ ﺖﯿﻌﺿﻭ ﺭﺩ ﺍﺭ ﯽﮑﯾﺮﺘﮑﻟﺍ

.ﺪﯿﺷﺎﺑ ﻪﺘﺷﺍﺩ

 ﻭ ﺩﺎﺸﮔ یﺎﻫ ﺱﺎﺒﻟ ﻥﺪﯿﺷﻮﭘ ﺯﺍ .ﺪﯿﺷﻮﭙﺑ ﺐﺳﺎﻨﻣ ﺱﺎﺒﻟ

(f

ﺎﻫ ﺶﮑﺘﺳﺩ ﻭ ﺱﺎﺒﻟ ،ﺎﻫﻮﻣ .ﺪﯿﻨﮐ یﺭﺍﺩ ﺩﻮﺧ ﺕﻻﺁ ﺖﻨﯾﺯ ﻞﻤﺣ

.ﺪﯾﺭﺍﺪﻬﮕﻧ ﺭﻭﺩ ﻩﺎﮕﺘﺳﺩ ﺶﺧﺮﭼ ﻝﺎﺣﺭﺩ یﺎﻫ ﺶﺨﺑ ﺯﺍ ﺍﺭ

ﺭﺩ ﺖﺳﺍ ﻦﮑﳑ ﺕﻻﺁ ﺖﻨﯾﺯ ﻭ ﺪﻨﻠﺑ یﻮﻣ ،ﺩﺎﺸﮔ یﺎﻫ ﺱﺎﺒﻟ

.ﺪﻨﻨﮐ ﺮﯿﮔ ﻩﺎﮕﺘﺳﺩ ﺶﺧﺮﭼ ﻝﺎﺣﺭﺩ یﺎﻫ ﺖﻤﺴﻗ

 ﻪﻠﯿﺳﻭ ﺎﯾ ﻭ ﺭﺎﺒﻏ ﻭ ﺩﺮﮔ ﺶﮑﻣ ﻞﺋﺎﺳﻭ ﺪﯿﻧﺍﻮﺘﯿﻣ ﻪﮑﯿﺗﺭﻮﺻﺭﺩ

(g

ﺪﯾﺎﺑ ،ﺪﯿﻨﮐ ﺐﺼﻧ ﻩﺎﮕﺘﺳﺩ ﻪﺑ ﺍﺭ ﺭﺎﺒﻏ ﻭ ﺩﺮﮔ ﻩﺪﻨﻨﮐ ﻊﻤﺟ

ﻩﺩﺎﻔﺘﺳﺍ ﺖﺳﺭﺩ ﻭ ﺐﺼﻧ ﻞﺋﺎﺳﻭ ﻦﯾﺍ ﻪﮐ ﺪﯾﻮﺷ ﻦﺌﻤﻄﻣ

ﺖﯿﻧﻮﺼﻣ ﺭﺎﺒﻏ ﻭ ﺩﺮﮔ ﺶﮑﻣ ﻞﺋﺎﺳﻭ ﺯﺍ ﻩﺩﺎﻔﺘﺳﺍ

.ﺪﻧﻮﺷ ﯽﻣ

.ﺪﻨﮑﯿﻣ ﺮﺗ ﺩﺎﯾﺯ ﺭﺎﺒﻏ ﻭ ﺩﺮﮔ ﺮﺑﺍﺮﺑ ﺭﺩ ﺍﺭ ﺎﻤﺷ

ﻥﺁ ﺯﺍ ﺖﺒﻗﺍﺮﻣ ﻭ ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ ﺯﺍ ﺢﯿﺤﺻ ﻩﺩﺎﻔﺘﺳﺍ

 (4

 ﺮﻫ یﺍﺮﺑ .ﺪﯿﻨﮐ یﺭﺍﺩ ﺩﻮﺧ ﻩﺎﮕﺘﺳﺩ یﻭﺭ ﺩﺎﯾﺯ ﺭﺎﺸﻓ ﻥﺩﺮﮐ ﺩﺭﺍﻭ ﺯﺍ

(a

ﺭﺎﮑﺑ

.ﺪﯿﻨﮐ ﻩﺩﺎﻔﺘﺳﺍ ﻥﺁ ﺎﺑ ﺐﺳﺎﻨﻣ ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ ﺯﺍ ،یﺭﺎﮐ

ﺯﺍ ﺪﯿﻧﺍﻮﺘﺑ ﻪﮐ ﺩﻮﺸﯿﻣ ﺚﻋﺎﺑ ﺐﺳﺎﻨﻣ ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ ﱳﻓﺮﮔ

.ﺪﯿﻨﮐ ﻩﺩﺎﻔﺘﺳﺍ ﺮﺘﺸﯿﺑ ﻥﺎﻨﯿﻤﻃﺍ ﺎﺑ ﻭ ﺮﺘﻬﺑ ﻩﺎﮕﺘﺳﺩ ﻥﺍﻮﺗ

 ﻩﺎﮕﺘﺳﺩ ﺯﺍ ،ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﻞﺻﻭ ﻭ ﻊﻄﻗ ﺪﯿﻠﮐ ﺭﺩ ﺩﺍﺮﯾﺍ ﺕﺭﻮﺻ ﺭﺩ

(b

ﻭ ﻊﻄﻗ ﺍﺭ ﺎﻬﻧﺁ ﻥﺍﻮﺗ ﯽﳕ ﻪﮐ ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ

.ﺪﯿﻨﮑﻧ ﻩﺩﺎﻔﺘﺳﺍ

.ﺪﻧﻮﺷ ﺮﯿﻤﻌﺗ ﺪﯾﺎﺑ ﻭ ﻩﺩﻮﺑ کﺎﻧﺮﻄﺧ ،ﺩﺮﮐ ﻞﺻﻭ

 ﺭﺎﻨﮐ ﺎﯾ ﻭ ﺕﺎﻘﻠﻌﺘﻣ ﺾﯾﻮﻌﺗ ،ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ ﻢﯿﻈﻨﺗ ﺯﺍ ﻞﺒﻗ

(c

ﺝﺭﺎﺧ ﺍﺮﻧﺁ یﺮﺗﺎﺑ ﺎﯾ ﻭ ﻩﺪﯿﺸﮐ ﻕﺮﺑ ﺯﺍ ﺍﺭ ﻪﺧﺎﺷﻭﺩ ،ﻥﺁ ﱳﺷﺍﺬﮔ

ﻥﺩﺎﺘﻓﺍ ﻩﺍﺭ ﺯﺍ ﯽﻨﻤﯾﺍ یﺮﯿﮕﺸﯿﭘ ﺕﺎﻣﺍﺪﻗﺍ ﻦﯾﺍ ﺖﯾﺎﻋﺭ

.ﺪﯿﻨﮐ

.ﺪﻨﮐ ﯽﻣ یﺮﯿﮔﻮﻠﺟ ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ ﻪﺘﺳﺍﻮﺧﺎﻧ

 ﺱﺮﺘﺳﺩ ﺯﺍ ،ﻩﺩﺎﻔﺘﺳﺍ ﻡﺪﻋ ﺕﺭﻮﺻﺭﺩ ﺍﺭ ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ

(d

ﺎﯾ ﻭ ﺩﺭﺍﻭ ﺎﻧ ﺩﺍﺮﻓﺍ ﻪﮐ ﺪﯿﻫﺪﻧ ﻩﺯﺎﺟﺍ .ﺪﯾﺭﺍﺪﻬﮕﻧ ﺭﻭﺩ ﻥﺎﮐﺩﻮﮐ

ﻦﯾﺍ ﺎﺑ ،ﺪﻧﺍ ﻩﺪﻧﺍﻮﺨﻧ ﺍﺭ ﺎﻤﻨﻫﺍﺭ ﻪﭼﺮﺘﻓﺩ ﻦﯾﺍ ﻪﮐ ﯽﺻﺎﺨﺷﺍ

ﺩﺍﺮﻓﺍ ﺖﺳﺩ ﺭﺩ ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ ﱳﻓﺮﮔ ﺭﺍﺮﻗ

.ﺪﻨﻨﮐ ﺭﺎﮐ ﻩﺎﮕﺘﺳﺩ

.ﺖﺳﺍ کﺎﻧﺮﻄﺧ ﻪﺑﺮﲡ ﯽﺑ ﻭ ﺩﺭﺍﻭﺎﻧ

 ﻪﮐ ﺪﯿﺷﺎﺑ ﺐﻇﺍﻮﻣ .ﺪﯿﻨﮐ ﺖﺒﻗﺍﺮﻣ ﺏﻮﺧ ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ ﺯﺍ

(e

.ﺪﻨﮑﻧ ﺮﯿﮔ ﻭ ﻩﺩﺮﮐ ﺭﺎﮐ ﺏﻮﺧ ﻩﺎﮕﺘﺳﺩ کﺮﺤﺘﻣ یﺎﻫ ﺖﻤﺴﻗ

ﻪﺘﺴﮑﺷ ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ ﺕﺎﻌﻄﻗ ﻪﮐ ﺪﯿﻨﮐ ﺖﻗﺩ ﻦﯿﻨﭽﻤﻫ

ﺯﺍ ﻞﺒﻗ ﺍﺭ ﻩﺪﯾﺩ ﺐﯿﺳﺁ ﺕﺎﻌﻄﻗ .ﺪﻨﺷﺎﺒﻧ ﻩﺪﯾﺩ ﺐﯿﺳﺁ ﺎﯾ ﻭ

،یﺭﺎﮐ ﺢﻧﺍﻮﺳ ﺯﺍ یﺭﺎﯿﺴﺑ ﺖﻠﻋ

.ﺪﯿﻨﮐ ﺮﯿﻤﻌﺗ ﺭﺎﮐ ﻪﺑ ﻉﻭﺮﺷ

.ﺪﺷﺎﺑ ﯽﻣ ﯽﮑﯾﺮﺘﮑﻟﺍ یﺎﻫﺭﺍﺰﺑﺍ ﺯﺍ ﻞﻣﺎﮐ ﺖﺒﻗﺍﺮﻣ ﻡﺪﻋ

ﺖﺒﻗﺍﺮﻣ ﺏﻮﺧ ﻪﮐ ﯽﺷﺮﺑ ﺭﺍﺰﺑﺍ

 .ﺪﯾﺭﺍﺪﻬﮕﻧ ﺰﯿﲤ ﻭ ﺰﯿﺗ ﺍﺭ ﺵﺮﺑ ﺭﺍﺰﺑﺍ

(f

ﻩﺩﺮﮐ ﺮﯿﮔ ﺭﺎﮐ ﻪﻌﻄﻗﺭﺩ ﺮﺘﻤﮐ ،ﺪﻧﺭﺍﺩﺭﻮﺧﺮﺑ ﺰﯿﺗ یﺎﻫ ﻪﺒﻟ ﺯﺍ ﻭ ﻩﺪﺷ

.ﺪﻨﺷﺎﺑ ﯽﻣ ﺖﯾﺍﺪﻫ ﻞﺑﺎﻗ ﺮﺘﻬﺑ ﻭ

 ﻩﺎﮕﺘﺳﺩ یﻭﺭ ﻪﮐ یﺭﺍﺰﺑﺍ ،ﺕﺎﻘﻠﻌﺘﻣ ،ﯽﮑﯾﺮﺘﮑﻟﺍ یﺎﻫﺭﺍﺰﺑﺍ

(g

ﺎﻤﻨﻫﺍﺭ ﻩﻭﺰﺟ ﻦﯾﺍ ﺕﺍﺭﻮﺘﺳﺩ ﻖﺑﺎﻄﻣ ﺍﺭ ﻩﺮﯿﻏ ﻭ ﺪﻧﻮﺷ ﯽﻣ ﺐﺼﻧ

ﻪﺘﺷﺍﺩ ﺐﺳﺎﻨﺗ ﻩﺎﮕﺘﺳﺩ ﻦﯾﺍ ﻝﺪﻣ ﺎﺑ ﻪﮐ ﺪﯾﺮﯿﮔ ﺭﺎﮐ ﻪﺑ یﺭﻮﻃ

.ﺪﯿﻨﮐ ﻪﺟﻮﺗ ﺭﺎﮐ ﻉﻮﻧ ﻭ یﺭﺎﮐ ﻂﯾﺍﺮﺷ ﻪﺑ ﻦﯿﻨﭽﻤﻫ .ﺪﻨﺷﺎﺑ

ﻪﺘﻓﺮﮔ ﺮﻈﻧﺭﺩ ﻥﺁ یﺍﺮﺑ ﻪﮐ یﺭﺎﮐ ﺩﺭﺍﻮﻣ یﺍﺮﺑ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﺩﺮﺑﺭﺎﮐ

.ﺩﻮﺷ ﺮﺠﻨﻣ ﺍﺭ ﯽﮐﺎﻧﺮﻄﺧ ﻂﯾﺍﺮﺷ ﺪﻧﺍﻮﺘﯿﻣ ،ﺖﺳﺍ ﻩﺪﺸﻧ

ﺲﯾﻭﺮﺳ

 (5

 یﺍ ﻪﻓﺮﺣ ﻦﯿﺼﺼﺨﺘﻣ ﻪﺑ ﻂﻘﻓ ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ ﺮﯿﻤﻌﺗ یﺍﺮﺑ

(a

ﺚﻋﺎﺑ ﻦﯾﺍ

.ﺪﯿﻨﮐ ﻩﺩﺎﻔﺘﺳﺍ ﻞﺻﺍ ﯽﮐﺪﯾ ﻞﺋﺎﺳﻭ ﺯﺍ ﻭ ﻩﺩﺮﮐ ﻉﻮﺟﺭ

.ﺩﺩﺮﮔ ﻦﯿﻤﻀﺗ ﺎﻤﺷ ﻩﺎﮕﺘﺳﺩ ﯽﻨﻤﯾﺍ ﻪﮐ ﺪﺷ ﺪﻫﺍﻮﺧ

یﺭﺎﮐﺯﺮﻓ ﻭ ﺎﻫﺯﺮﻓ یﺍﺮﺑ ﯽﻨﻤﯾﺍ ﺕﺎﮑﻧ

،ﺪﯾﺮﯿﮕﺑ ﺖﺳﺩ ﺭﺩ ﻖﯾﺎﻋ یﺎﻬﺘﻤﺴﻗ ﺯﺍ ﺎﻬﻨﺗ ﺍﺭ ﺍﺭ ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ

◀

ﻞﺑﺎﮐ ﮏﯾ ﺎﺑ ﺱﺎﲤ

.ﺩﺭﺍﺩ ﺩﻮﺟﻭ ﻕﺮﺑ ﻞﺑﺎﮐ ﺎﺑ ﺯﺮﻓ ﺩﺭﻮﺧﺮﺑ ﻥﺎﮑﻣﺍ ﻥﻮﭼ

ﺩﺭﺍﻭ ﻥﺎﯾﺮﺟ ﻩﺎﮕﺘﺳﺩ یﺰﻠﻓ یﺎﻬﺘﻤﺴﻗ ﻪﺑ ﺪﻧﺍﻮﺗ ﯽﻣ ﻕﺮﺑ ﻥﺎﯾﺮﺟ ﻞﻣﺎﺣ

.ﺩﻮﺷ ﯽﮑﯾﺮﺘﮑﻟﺍ کﻮﺷ ﺩﺎﺠﯾﺍ ﺚﻋﺎﺑ ﻭ ﺪﻨﮐ

ﺢﻄﺳ ﮏﯾ یﻭﺭ ﺮﮕﯾﺩ ﺵﻭﺭ ﺎﺑ ﺎﯾ ﻥﺩﺍﺩ ﺮﯿﮔ ﻪﻠﯿﺳﻮﺑ ﺍﺭ ﺭﺎﮐ ﻪﻌﻄﻗ

◀

ﺎﯾ ﺖﺳﺩ ﮏﯾ ﺎﺑ ﺍﺭ ﺭﺎﮐ ﻪﻌﻄﻗ ﻪﭽﻧﺎﻨﭼ

.ﺪﯿﻨﮐ ﻢﮑﺤﻣ ﺖﺑﺎﺛ ﺭﺎﮐ

ﻥﺩﺍﺩ ﺖﺳﺩ ﺯﺍ ﺚﻋﺎﺑ ﻭ ﺪﻧﺎﻣ ﯽﳕ ﺖﺑﺎﺛ ،ﺪﯾﺭﺍﺪﻬﮕﻧ ﺩﻮﺧ ﻥﺪﺑ ﻞﺑﺎﻘﻣ

.ﺩﻮﺷ ﯽﻣ ﺎﻤﺷ ﻝﺮﺘﻨﮐ

ﺮﺜﮐﺍﺪﺣ ﻩﺯﺍﺪﻧﺍ ﻪﺑ ﻞﻗﺍﺪﺣ ﺪﯾﺎﺑ ﻩﺎﮕﺘﺳﺩ ﺭﺍﺰﺑﺍ ﺯﺎﺠﻣ ﺭﻭﺩ ﻭ ﺖﻋﺮﺳ

◀

ﻭ ﺭﺍﺰﺑﺍ ﱳﻓﺭ ﻦﯿﺑ ﺯﺍ ﻥﺎﮑﻣﺍ

.ﺪﺷﺎﺑ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ یﻭﺭ ﻩﺪﺷ ﺪﯿﻗ ﺖﻋﺮﺳ

.ﺩﺭﺍﺩ ﺩﻮﺟﻭ ،ﺪﻧﺭﺍﺩ ﺶﺧﺮﭼ ﺯﺎﺠﻣ ﺪﺣ ﺯﺍ ﺶﯿﺑ ﺖﻋﺮﺳ ﺎﺑ ﻪﮐ ﯽﺗﺎﻘﻠﻌﺘﻣ

(ﺖﻟﻮﮐ) ﺮﯿﮔﺭﺍﺰﺑﺍ ﺭﺩ ﹰﺎﻘﯿﻗﺩ ﺪﯾﺎﺑ ﺕﺎﻘﻠﻌﺘﻣ ﺮﯾﺎﺳ ﺎﯾ ﻭ ﺯﺮﻓ ﻪﻐﯿﺗ

◀

ﯽﺗﺎﻘﻠﻌﺘﻣ ﻭ ﺭﺍﺰﺑﺍ

.ﺪﻨﺷﺎﺑ ﻥﺁ ﺐﺳﺎﻨﺘﻣ ﻭ ﺪﻧﺮﯿﮕﺑ یﺎﺟ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ

ﻢﻈﻨﻣﺎﻧ ﺶﺧﺮﭼ ،ﺪﻨﺷﺎﺒﻧ ﻩﺎﮕﺘﺳﺩ ﺮﯿﮔﺭﺍﺰﺑﺍ ﺎﺑ ﻖﺒﻄﻨﻣ ﹰﻼﻣﺎﮐ ﻪﮐ

ﻥﺩﺍﺩ ﺖﺳﺩ ﺯﺍ ﻪﺑ ﺮﺠﻨﻣ ﺪﻨﻧﺍﻮﺗ ﯽﻣ ﻭ ﻪﺘﺷﺍﺩ یﺪﯾﺪﺷ یﺎﻫ ﻥﺎﺳﻮﻧ ﻭ

.ﺪﻧﻮﺸﺑ ﻝﺮﺘﻨﮐ

.ﺪﯿﻨﮐ ﮏﯾﺩﺰﻧ ﺭﺎﮐ ﻪﻌﻄﻗ ﻪﺑ ﻥﺩﻮﺑ ﻦﺷﻭﺭ ﻝﺎﺣ ﺭﺩ ﺎﻬﻨﺗ ﺍﺭ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ

◀

ﺮﯿﮔ ﺭﺎﮐ ﻪﻌﻄﻗ ﺭﺩ ﻩﺎﮕﺘﺳﺩ یﻭﺭ ﺭﺍﺰﺑﺍ ﺖﺳﺍ ﻦﮑﳑ ﺕﺭﻮﺼﻨﯾﺍ ﺮﯿﻏ ﺭﺩ

.ﺩﻮﺷ ﻩﺎﮕﺘﺳﺩ (ﻥﺩﺯ ﺲﭘ) ﻥﺩﺯ ﻪﺑﺮﺿ ﺚﻋﺎﺑ ﻭ ﻩﺩﺮﮐ

ﻪﭽﻐﯿﺗ ﺯﺍ ﻦﯿﻨﭽﻤﻫ ﻭ یﺭﺎﮐ ﺯﺮﻓ ﻩﺩﻭﺪﺤﻣ ﺯﺍ ﺍﺭ ﺩﻮﺧ یﺎﻬﺘﺳﺩ ﻩﺭﺍﻮﻤﻫ

◀

.ﺩﺭﺍﺩ ﺩﻮﺟﻭ ﯽﮔﺪﯾﺩ ﺐﯿﺳﺁ ﻭ ﺖﺣﺍﺮﺟ ﺮﻄﺧ

.ﺪﯾﺭﺍﺩ ﻩﺎﮕﻧ ﺭﻭﺩ ﺯﺮﻓ

ﺐﯿﺳﺁ ﻥﺎﮑﻣﺍ

 .ﺪﯿﻨﮑﻧ یﺭﺎﮐ ﺯﺮﻓ ،ﭻﯿﭘ ﻭ ﺦﯿﻣ ،یﺰﻠﻓ ﺀﺎﯿﺷﺍ یﻭﺭ ﺰﮔﺮﻫ

◀

ﺩﻮﺟﻭ ﻩﺎﮕﺘﺳﺩ ﺪﯾﺪﺷ ﻥﺎﺳﻮﻧ ﻭ ﺵﺎﻌﺗﺭﺍ ﻪﺠﯿﺘﻧ ﺭﺩ ﻭ ﺯﺮﻓ ﻪﻐﯿﺗ ﻥﺪﯾﺩ

.ﺩﺭﺍﺩ

ﯽﺳﺭﺎﻓ

|  255

Bosch Power Tools

2 610 016 614

|

 (2.3.11)

ﯽﻨﻤﯾﺍ یﺎﻫ ﯽﺋﺎﻤﻨﻫﺍﺭ

ﯽﮑﯾﺮﺘﮑﻟﺍ یﺎﻫﺭﺍﺰﺑﺍ یﺍﺮﺑ ﯽﻣﻮﻤﻋ ﯽﻨﻤﯾﺍ یﺎﻫ ﯽﺋﺎﻤﻨﻫﺍﺭ

.ﺪﯿﻧﺍﻮﺨﺑ ﺍﺭ ﺎﻫ ﯽﺋﺎﻤﻨﻫﺍﺭ ﻭ ﯽﻨﻤﯾﺍ ﺕﺍﺭﻮﺘﺳﺩ ﻪﻤﻫ

ﯽﻨﻤﯾﺍ ﺕﺍﺭﻮﺘﺳﺩ ﻦﯾﺍ ﺖﯾﺎﻋﺭ ﻡﺪﻋ ﺯﺍ ﯽﺷﺎﻧ ﺕﺎﻫﺎﺒﺘﺷﺍ

ﺪﯾﺪﺷ یﺎﻫ ﺖﺣﺍﺮﺟ ﺮﯾﺎﺳ ﺎﯾ ﻭ ﯽﮕﺘﺧﻮﺳ ،ﯽﮕﺘﻓﺮﮔ ﻕﺮﺑ ﺚﻋﺎﺑ ﺖﺳﺍ ﻦﮑﳑ

.ﺩﻮﺷ

یﺭﺍﺪﻬﮕﻧ ﺏﻮﺧ ﻩﺪﻨﯾﺁ یﺍﺮﺑ ﺍﺭ ﺎﻫ ﯽﺋﺎﻤﻨﻫﺍﺭ ﻭ ﯽﻨﻤﯾﺍ یﺎﻫ ﺭﺍﺪﺸﻫ ﻪﻤﻫ

.ﺪﯿﻨﮐ

یﺎﻫﺭﺍﺰﺑﺍ ﺭﻮﻈﻨﻣ ،ﺩﻮﺸﯿﻣ ﺖﺒﺤﺻ «ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ» ﺯﺍ ﺎﻤﻨﻫﺍﺭ ﻦﯾﺍ ﺭﺩ ﺎﺟﺮﻫ

ﻢﯿﺳ ﻥﻭﺪﺑ) ﺭﺍﺩ یﺮﻃﺎﺑ ﯽﮑﯾﺮﺘﮑﻟﺍ یﺎﻫﺭﺍﺰﺑﺍ ﺎﯾ ﻭ (ﻕﺮﺑ ﻢﯿﺳﺎﺑ) ﯽﮑﯾﺮﺘﮑﻟﺍ

.ﺪﺷﺎﺑ ﯽﻣ (ﻕﺮﺑ

ﺭﺎﮐ ﻞﺤﻣ ﯽﻨﻤﯾﺍ

 (1

 .ﺪﯾﺭﺍﺪﻬﮕﻧ ﯽﻓﺎﮐ ﺭﻮﻧ ﻪﺑ ﺰﻬﺠﻣ ﻭ ﺐﺗﺮﻣ ،ﺰﯿﲤ ﺍﺭ ﺩﻮﺧ ﺭﺎﮐ ﻞﺤﻣ

(a

.ﺩﻮﺷ یﺭﺎﮐ ﺢﻧﺍﻮﺳ ﺚﻋﺎﺑ ﺪﻧﺍﻮﺘﯿﻣ ﺭﻮﻧ ﻢﮐ ﻭ ﺐﺗﺮﻣﺎﻧ ﺭﺎﮐ ﻂﯿﺤﻣ

 ﺭﺎﺠﻔﻧﺍ ﺮﻄﺧ ﻥﺁﺭﺩ ﻪﮐ ﯽﺋﺎﻫ ﻂﯿﺤﻣ ﺭﺩ ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ ﺎﺑ

(b

ﻪﻗﺮﺘﺤﻣ یﺎﻫﺭﺎﺒﻏ ﻭ ﺎﻫﺯﺎﮔ ،ﺕﺎﻌﯾﺎﻣ یﻭﺎﺣ ﻭ ﻪﺘﺷﺍﺩ ﺩﻮﺟﻭ

ﺩﺎﺠﯾﺍ ﯽﯾﺎﻫ ﻪﻗﺮﺟ ﯽﮑﯾﺮﺘﮑﻟﺍ یﺎﻫﺭﺍﺰﺑﺍ

.ﺪﯿﻨﮑﻧ ﺭﺎﮐ ،ﺪﺷﺎﺑ

یﺎﻫﺭﺎﺨﺑ ﻭ ﺩﺮﮔ ﱳﻓﺮﮔ ﺶﺗﺁ ﺚﻋﺎﺑ ﺪﻨﻧﺍﻮﺗ ﯽﻣ ﻪﮐ ﺪﻨﻨﮑﯿﻣ

.ﺪﻧﻮﺷ ﺍﻮﻫﺭﺩ ﺩﻮﺟﻮﻣ

 ﺯﺍ ﺍﺭ ﺩﺍﺮﻓﺍ ﺮﯾﺎﺳ ﻭ ﻥﺎﮐﺩﻮﮐ ،ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ ﺎﺑ ﺭﺎﮐ ﻡﺎﮕﻨﻫ

(c

،ﺩﻮﺷ ﺕﺮﭘ ﺎﻤﺷ ﺱﺍﻮﺣ ﻪﮑﯿﺗﺭﻮﺻﺭﺩ

.ﺪﯾﺭﺍﺪﻬﮕﻧ ﺭﻭﺩ ﻩﺎﮕﺘﺳﺩ

.ﺩﻮﺷ ﺝﺭﺎﺧ ﺎﻤﺷ ﺖﺳﺩ ﺯﺍ ﻩﺎﮕﺘﺳﺩ ﻝﺮﺘﻨﮐ ﺖﺳﺍ ﻦﮑﳑ

ﯽﮑﯾﺮﺘﮑﻟﺍ ﯽﻨﻤﯾﺍ

 (2

 ﻪﺘﺷﺍﺩ ﺐﺳﺎﻨﺗ ﻕﺮﺑ ﺰﯾﺮﭘ ﺎﺑ ﺪﯾﺎﺑ ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ ﻪﺧﺎﺷﻭﺩ

(a

ﻝﺪﺒﻣ .ﺪﯿﻫﺪﻧ ﻪﺧﺎﺷﻭﺩ ﺭﺩ یﺮﯿﯿﻐﺗ ﻪﻧﻮﮕﭽﯿﻫ .ﺪﺷﺎﺑ

ﻪﺑ ﻝﺎﺼﺗﺍ یﺍﺭﺍﺩ ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ ﺎﺑ ﻩﺍﺮﻤﻫ ﺪﯾﺎﺒﻧ ﻪﺧﺎﺷﻭﺩ

ﻭ ﻩﺪﺸﻧ ﻩﺩﺍﺩ ﺮﯿﯿﻐﺗ ﻭ ﻞﺻﺍ یﺎﻫ ﻪﺧﺎﺷﻭﺩ

.ﺩﻮﺷ ﻩﺩﺎﻔﺘﺳﺍ ﻦﯿﻣﺯ

ﻢﮐ ﺍﺭ ﯽﮕﺘﻓﺮﮔ ﻕﺮﺑ ﻭ ﯽﮑﯾﺮﺘﮑﻟﺍ کﻮﺷ ﺮﻄﺧ ،ﺐﺳﺎﻨﻣ یﺎﻫﺰﯾﺮﭘ

.ﺪﻨﻨﮐ ﯽﻣ

 ﻦﯿﻣﺯ ﻪﺑ ﻝﺎﺼﺗﺍ ﻢﯿﺳ ﻪﺑ ﻞﺼﺘﻣ ﺕﺎﻌﻄﻗ ﺎﺑ ﯽﻧﺪﺑ ﺱﺎﲤ ﺯﺍ

(b

ﺭﺩ

.ﺪﯿﻨﮐ یﺭﺍﺩ ﺩﻮﺧ ﻝﺎﭽﺨﯾ ﻭ ﯽﻗﺮﺑ ﻕﺎﺟﺍ ،ژﺎﻓﻮﺷ ،ﻪﻟﻮﻟ ﺪﻨﻧﺎﻣ

ﻦﯿﻣﺯ ﻪﺑ ﻝﺎﺼﺗﺍ یﺍﺭﺍﺩ ﺕﺎﻌﻄﻗ ﻭ ﺡﻮﻄﺳ ﺎﺑ ﯽﻧﺪﺑ ﺱﺎﲤ ﺕﺭﻮﺻ

ﺶﯾﺍﺰﻓﺍ ﯽﮕﺘﻓﺮﮔ ﻕﺮﺑ ﺮﻄﺧ ،ﻦﯿﻣﺯ ﺎﺑ ﺎﻤﺷ ﺱﺎﲤ ﻦﯿﻨﭽﻤﻫ ﻭ

.ﺪﺑﺎﯾ ﯽﻣ

ﺭﺍﺰﺑﺍ ﻪﺑ ﺏﺁ ﺫﻮﻔﻧ

 .ﺪﯾﺭﺍﺪﻬﮕﻧ ﺭﻭﺩ ﺖﺑﻮﻃﺭ ﻭ ﻥﺍﺭﺎﺑ ﺯﺍ ﺍﺭ ﻩﺎﮕﺘﺳﺩ

(c

.ﺪﻫﺪﯿﻣ ﺶﯾﺍﺰﻓﺍ ﺍﺭ ﯽﮑﯾﺮﺘﮑﻟﺍ کﻮﺷ ﺮﻄﺧ ،ﯽﮑﯾﺮﺘﮑﻟﺍ

 ،ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ ﻞﻤﺣ ﻥﻮﭼ ﯽﺋﺎﻫﺭﺎﮐ یﺍﺮﺑ ﻩﺎﮕﺘﺳﺩ ﻢﯿﺳ ﺯﺍ

(d

ﻩﺩﺎﻔﺘﺳﺍ ﻕﺮﺑ ﺯﺍ ﻪﺧﺎﺷﻭﺩ ﻥﺩﺮﮐ ﺝﺭﺎﺧ ﺎﯾ ﻭ ﻥﺁ ﻥﺩﺮﮐ ﻥﺍﺰﯾﻭﺁ

یﺎﻫ ﻪﺒﻟ ،ﻦﻏﻭﺭ ،ﺕﺭﺍﺮﺣ ﻞﺑﺎﻘﻣ ﺭﺩ ﺍﺭ ﻩﺎﮕﺘﺳﺩ ﻞﺑﺎﮐ .ﺪﯿﻨﮑﻧ

یﺎﻫ ﻞﺑﺎﮐ

.ﺪﯾﺭﺍﺪﻬﮕﻧ ﺭﻭﺩ ﻩﺎﮕﺘﺳﺩ کﺮﺤﺘﻣ یﺎﻫ ﺶﺨﺑ ﻭ ﺰﯿﺗ

ﺶﯾﺍﺰﻓﺍ ﺍﺭ ﯽﮑﯾﺮﺘﮑﻟﺍ کﻮﺷ ﺮﻄﺧ ﻩﺩﺭﻮﺧ ﻩﺮﮔ ﺎﯾ ﻭ ﻩﺪﯾﺩ ﺐﯿﺳﺁ

.ﺪﻨﻫﺪﯿﻣ

 ،ﺪﯿﻨﮑﯿﻣ ﺭﺎﮐ ﺯﺎﺑ ﻂﯿﺤﻣ ﺭﺩ ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ ﺎﺑ ﻪﮑﯿﺗﺭﻮﺻﺭﺩ

(e

ﺰﯿﻧ ﺯﺎﺑ ﻂﯿﺤﻣ یﺍﺮﺑ ﻪﮐ ﺪﯿﻨﮐ ﻩﺩﺎﻔﺘﺳﺍ ﯽﻄﺑﺍﺭ ﻞﺑﺎﮐ ﺯﺍ ﺎﻬﻨﺗ

ﺮﻄﺧ ،ﺯﺎﺑ ﻂﯿﺤﻣ یﺍﺮﺑ ﺐﺳﺎﻨﻣ ﻂﺑﺍﺭ یﺎﻫ ﻞﺑﺎﮐ

.ﺪﺷﺎﺑ ﺐﺳﺎﻨﻣ

.ﺪﻨﻨﮐ ﯽﻣ ﻢﮐ ﺍﺭ ﯽﮕﺘﻓﺮﮔ ﻕﺮﺑ

 ،ﺏﻮﻃﺮﻣ ﻦﮐﺎﻣﺍ ﻭ ﻂﯿﺤﻣ ﺭﺩ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﺎﺑ ﺭﺎﮐ ﻡﻭﺰﻟ ﺕﺭﻮﺻ ﺭﺩ

(f

ﺪﯿﻠﮐ) ﻦﯿﻣﺯ ﯽﺘﺸﻧ ﻭ ﺎﻄﺧ ﻥﺎﯾﺮﺟ ﯽﺘﻇﺎﻔﺣ ﺪﯿﻠﮐ ﮏﯾ ﺯﺍ ﺪﯾﺎﺑ

ﺯﺍ ﻩﺩﺎﻔﺘﺳﺍ

.ﺪﯿﻨﮐ ﻩﺩﺎﻔﺘﺳﺍ (ﻦﯿﻣﺯ ﺎﺑ ﻝﺎﺼﺗﺍ ﻩﺪﻨﻨﮐ ﻊﻄﻗ

ﯽﮕﺘﻓﺮﮔ ﻕﺮﺑ ﺮﻄﺧ ﻦﯿﻣﺯ ﯽﺘﺸﻧ ﻭ ﺎﻄﺧ ﻥﺎﯾﺮﺟ ﯽﺘﻇﺎﻔﺣ ﺪﯿﻠﮐ

.ﺪﻫﺩ ﯽﻣ ﻞﯿﻠﻘﺗ ﺍﺭ

ﺹﺎﺨﺷﺍ ﯽﻨﻤﯾﺍ ﺖﯾﺎﻋﺭ

 (3

 ﻭ ﺪﯿﻨﮐ ﺖﻗﺩ ﺩﻮﺧ ﺭﺎﮐ ﻪﺑ ،ﺪﯿﻨﮐ ﻊﻤﺟ ﺏﻮﺧ ﺍﺭ ﺩﻮﺧ ﺱﺍﻮﺣ

(a

ﺕﺭﻮﺻﺭﺩ .ﺪﯿﻨﮐ ﺭﺎﮐ ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ ﺎﺑ ﻞﻣﺎﮐ ﺵﻮﻫ ﻭ ﺮﮑﻓ ﺎﺑ

ﻭﺭﺍﺩ ﻭ ﻞﮑﻟﺍ ،ﺭﺪﺨﻣ ﺩﺍﻮﻣ ﻪﮑﯿﺗﺭﻮﺻ ﺭﺩ ﺎﯾ ﻭ ﯽﮕﺘﺴﺧ

ﻪﻈﳊ ﮏﯾ

.ﺪﯿﻨﮑﻧ ﺭﺎﮐ ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ ﺎﺑ ،ﺪﯾﺍ ﻩﺩﺮﮐ ﻩﺩﺎﻔﺘﺳﺍ

یﺎﻫ ﺖﺣﺍﺮﺟ ﺪﻧﺍﻮﺘﯿﻣ ،ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ ﺎﺑ ﺭﺎﮐ ﻡﺎﮕﻨﻫ ﯽﻬﺟﻮﺗ ﯽﺑ

.ﺪﺷﺎﺑ ﻪﺘﺷﺍﺩ ﻩﺍﺮﻤﻫ ﻪﺑ یﺪﯾﺪﺷ

 ﻩﺭﺍﻮﻤﻫ ﯽﻨﻤﯾﺍ ﮏﻨﯿﻋ ﺯﺍ ﻭ ﯽﺼﺨﺷ ﯽﻨﻤﯾﺍ ﺕﺍﺰﯿﻬﲡ ﺯﺍ

(b

ﮏﺳﺎﻣ ﺪﻨﻧﺎﻣ ﯽﻨﻤﯾﺍ ﺕﺍﺰﯿﻬﲡ ﺯﺍ ﻩﺩﺎﻔﺘﺳﺍ

.ﺪﯿﻨﮐ ﻩﺩﺎﻔﺘﺳﺍ

ﯽﺷﻮﮔ ﻭ ﯽﻨﻤﯾﺍ ﻩﻼﮐ ،ﺵﺰﻐﻟ ﺪﺿ ﯽﻨﻤﯾﺍ یﺎﻫ ﺶﻔﮐ ،ﯽﻨﻤﯾﺍ

ﺡﻭﺮﺠﻣ ﺮﻄﺧ ،ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ ﺎﺑ ﺭﺎﮐ ﻉﻮﻧ ﺎﺑ ﺐﺳﺎﻨﺘﻣ ﯽﻨﻤﯾﺍ

.ﺪﻫﺪﻴﻣ ﺶﻫﺎﮐ ﺍﺭ ﻥﺪﺷ

 ﺭﺎﮑﺑ ﻪﺘﺳﺍﻮﺧﺎﻧ ﺭﻮﻄﺑ ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ ﻪﮐ ﺪﯿﺷﺎﺑ ﺐﻇﺍﻮﻣ

(c

،ﻕﺮﺑ ﺰﯾﺮﭘ ﺭﺩ ﻩﺎﮕﺘﺳﺩ ﻪﺧﺎﺷﻭﺩ ﻥﺩﺮﮐ ﺩﺭﺍﻭ ﺯﺍ ﻞﺒﻗ .ﺪﺘﻔﯿﻧ

ﺪﯾﺎﺑ ،ﻩﺎﮕﺘﺳﺩ ﻞﻤﺣ ﺎﯾ ﻭ ﻥﺁ ﱳﺷﺍﺩﺮﺑ ،یﺮﻃﺎﺑ ﻪﺑ ﻥﺁ ﻝﺎﺼﺗﺍ

ﻪﮑﯿﺗﺭﻮﺻﺭﺩ

.ﺪﺷﺎﺑ ﺵﻮﻣﺎﺧ ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ ﻪﮐ ﺪﯿﻨﮐ ﺖﻗﺩ

ﻞﺻﻭ ﻭ ﻊﻄﻗ ﻪﻤﮐﺩ یﻭﺭ ﺎﻤﺷ ﺖﺸﮕﻧﺍ ﻩﺎﮕﺘﺳﺩ ﻞﻤﺣ ﻡﺎﮕﻨﻫ

ﺖﺳﺍ ﻦﮑﳑ ،ﺪﯿﻧﺰﺑ ﻕﺮﺑ ﻪﺑ ﻦﺷﻭﺭ ﺖﻟﺎﺣ ﺭﺩ ﺍﺭ ﻩﺎﮕﺘﺳﺩ ﺎﯾ ﻭ ﺪﺷﺎﺑ

.ﺪﯾﺁ ﺶﯿﭘ یﺭﺎﮐ ﺢﻧﺍﻮﺳ

 یﺎﻫﺭﺍﺰﺑﺍ ﻪﻤﻫ ﺪﯾﺎﺑ ،ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ ﻥﺩﺮﮐ ﻦﺷﻭﺭ ﺯﺍ ﻞﺒﻗ

(d

ﻭ ﺭﺍﺰﺑﺍ

.ﺪﯾﺭﺍﺩﺮﺑ ﻩﺎﮕﺘﺳﺩ یﻭﺭ ﺯﺍ ﺍﺭ ﺎﻫ ﺭﺎﭼﺁ ﻭ ﻩﺪﻨﻨﮐ ﻢﯿﻈﻨﺗ

،ﺪﻧﺭﺍﺩ ﺭﺍﺮﻗ ﻩﺎﮕﺘﺳﺩ ﻩﺪﻨﺧﺮﭼ یﺎﻫ ﺶﺨﺑ یﻭﺭ ﻪﮐ ﯽﺋﺎﻫﺭﺎﭼﺁ

.ﺪﻧﻮﺷ ﺖﺣﺍﺮﺟ ﺩﺎﺠﯾﺍ ﺚﻋﺎﺑ ﺪﻨﻧﺍﻮﺘﯿﻣ
